Foxconn D70S-P User manual

D70S Series
Motherboard
User’s Manual

Statement:
This manual is the intellectual property of Foxconn, Inc. Although the infor-
 mationinthismanualmaybechangedormodiedatanytime,Foxconn
does not obligate itself to inform the user of these changes.
Trademark:
All trademarks are the property of their respective owners.
Version:
User’s Manual V1.0 for D70S Series motherboard.
Symbol description:
Note:
Refers to important information that can help you to use motherboard better,
and tells you how to avoid problems.
Caution:
Indicating a potential risk of hardware damage or physical injury may exist.
WEEE:
The use of this symbol indicates that this product may not be treated as
household waste. By ensuring this product is disposed of correctly, you
will help prevent potential negative consequences for the environment
and human health, which could otherwise be caused by inappropriate waste
handling of this product. For more detailed information about recycling of
 thisproduct,pleasecontactyourlocalcityofce,yourhouseholdwaste
disposal service or the shop where you purchased this product.
More information:
If you want more information about our products, please visit:
http://www.foxconnchannel.com
© All rights reserved.
All trade names are registered trademarks of respective manufacturers listed.
Allimagesareforreferenceonly,pleaserefertothephysicalmotherboardforspecicfeatures.
CAUTIO
N

Declaration of conformity
HON HAI PRECISION INDUSTRY COMPANY LTD
66 , CHUNG SHAN RD., TU-CHENG INDUSTRIAL DISTRICT,
TAIPEI HSIEN, TAIWAN, R.O.C.
declares that the product
Motherboard D70S Series
is in conformity with
(referencetothespecicationunderwhichconformityisdeclaredin
accordance with 89/336 EEC-EMC Directive)
■EN55022:1998/A2:2003 Limitsandmethodsofmeasurementsofradio  
disturbance characteristics of information technology
equipment
■EN61000-3-2/:2000 Electromagneticcompatibility(EMC)
Part 3: Limits
 Section2:Limitsforharmoniccurrentemissions
(equipment input current <= 16A per phase)
■EN61000-3-3/A1:2001 Electromagneticcompatibility(EMC)
Part 3: Limits
 Section2:Limitsofvoltageuctuationsandickerinlow 
voltage supply systems for equipment with rated current
<= 16A
■EN55024/A2:2003 Informationtechnologyequipment-Immunity  
characteristics limits and methods of measurement
Signature:   Place/Date:TAIPEI/2013
Printed Name : James Liang

Declaration of conformity
Trade Name: FOXCONN
Model Name: D70S Series
Responsible Party: PCE Industry Inc.
 Address: 458E.LambertRd.
  Fullerton,CA92835
 Telephone: 714-738-8868
 Facsimile: 714-738-8838
 EquipmentClassication: FCCClassBSubassembly
Type of Product: Motherboard
Manufacturer: HON HAI PRECISION INDUSTRY
COMPANY LTD
Address: 66 , CHUNG SHAN RD., TU-CHENG
INDUSTRIAL DISTRICT, TAIPEI HSIEN,
TAIWAN, R.O.C.
Supplementary Information:
ThisdevicecomplieswithPart15oftheFCCRules.Operationissubjecttothefollowingtwo
conditions:(1)thisdevicemaynotcauseharmfulinterference,and(2)thisdevicemustaccept
any interference received, including interference that may cause undesired operation.
Tested to comply with FCC standards.
Signature:  Date:2013

Installation Precautions
Website: http://www.foxconnchannel.com
Support Website: http://www.foxconnsupport.com
Worldwide online contact Support: http://www.foxconnsupport.com/inquiry.aspx
CPU Support List: http://www.foxconnsupport.com/cpusupportlist.aspx
Memory, VGA Compatibility List: http://www.foxconnsupport.com/complist.aspx
Technical Support
■ Electrostaticdischarge(ESD)isthesuddenandmomentaryelectriccurrent
 thatowsbetweentwoobjectsatdifferentelectricalpotentials.Normallyit
comes out as a spark which will quickly damage your electronic equipment.
Please wear an electrostatic discharge (ESD) wrist strap when handling
components such as a motherboard, CPU or memory.
■ EnsurethattheDCpowersupplyisturnedoffbeforeinstallingorremovingCPU,
memory, expansion cards or other peripherals. It is recommended to unplug the
AC power cord from the power supply outlet. Failure to unplug the power supply
cord may result in serious damage to your system.
CAUTIO
N
Please carefully read the following procedures to install your computer :
■ Itissuggestedtoselecthigh-quality,certiedfansinordertoavoiddamageto
the motherboard and CPU due to high temperature. Never turn on the computer
if the CPU fan is not properly installed.
■ WecannotguaranteethatyoursystemcanoperatenormallywhenyourCPU
is overclocked. Normal operation depends on the overclocking capacity of your
device.
■ Ifthereisany,whenconnectingUSB,audio,1394a,RS232COM,IrDAor
S/PDIF cables to the internal connectors on the motherboard, make sure their
pinouts are matching with the connectors on the motherboard. Incorrect
connections might damage the motherboard.
■ Whenhandlingthemotherboard,avoidtouchinganymetalleadsorconnectors.
■ IfthereisaPCIExpressx16graphicscardinstalledinyoursystem,we
 recommendusinga24-pinATXpowersupplytogetthebestperformance.
■ Beforeturningonthepower,pleasemakesurethepowersupplyACinput
 voltagesettinghasbeenconguredtothelocalstandard.
■ Topreventdamagetothemotherboard,donotallowscrewstocomeincontact
with the motherboard circuit or its components. Also, make sure there are no
leftover screws or metal components placed on the motherboard or within the
computer casing.
■ Ifyouareuncertainaboutanyinstallationstepsorhaveaproblemrelatedtothe
 useoftheproduct,pleaseconsultacertiedcomputertechnician.

Chapter 1 Product Introduction
1-1ProductSpecications............................................................................2
1-2Layout ....................................................................................................4
1-3 Back Panel Connectors..........................................................................5
Chapter 2 Hardware Installation
2-1InstalltheMemory..................................................................................8
2-2InstallotherInternalConnectors ............................................................9
2-3Jumpers ...............................................................................................13
Chapter 3 BIOS Setup
Enter BIOS Setup.......................................................................................16
Main............................................................................................................17
F-center ......................................................................................................19
Smart BIOS.............................................................................................19
Fox Intelligent Stepping ..........................................................................20
CPUConguration ..................................................................................21
Advanced ...................................................................................................22
North Bridge............................................................................................22
ME Subsystem........................................................................................23
OnboardDeviceConguration................................................................24
SATAConguration .................................................................................25
SuperIOConguration ...........................................................................26
Trusted Computing..................................................................................27
Network Stack.........................................................................................27
Boot ............................................................................................................28
CSM parameters....................................................................................29
Power .........................................................................................................30
Health .........................................................................................................32
Security ......................................................................................................33
Save & Exit.................................................................................................34
Chapter 4 CD Instruction
4-1Installdriverandutility..........................................................................36
1. Install Driver ........................................................................................36
2.InstallUtility.........................................................................................37
4-2FOXONE .............................................................................................38
1. Main Page...........................................................................................39
2.CPUPage-CPUControl....................................................................42
3. Frequency Page - Frequency Control (Optional) ................................45
4.LimitSetting ........................................................................................45
5.VoltagePage-VoltageControl(Optional) ..........................................48
6. Fan Page - Fan Control ......................................................................48
TABLE OF CONTENTS

4-3FOXLiveUpdate...................................................................................49
1. Local Update.......................................................................................49
2.OnlineUpdate .....................................................................................51
3.Congure ............................................................................................54
4.About&Help .......................................................................................56
4-4FOXLOGO ..........................................................................................57
4-5FOXDMI ..............................................................................................58
4-6Smartcharger ......................................................................................58

Thank you for buying Foxconn D70S Series mother-
board. Foxconn products are engineered to maximize
computing power, providing only what you need for
break-through performance.
This chapter includes the following information:
■ProductSpecications
■Layout
■BackPanelConnectors
Chapter 1 Product Introduction

PRODUCT INTRODUCTION
2
1-1 Product Specications
CPU SupportIntel®Celeron847(D70S-V/-VD)&1007u(D70S/-D)&1037u
(D70S-P/-PD) Dual-core Processors
Max processor power up to 17W
For the latest CPU information, please visit:
http://www.foxconnsupport.com/cpusupportlist.aspx
Chipset Intel®NM70
Memory 1x240-pinSO-DDR3DIMM
Support up to 8GB of system memory
Support DDR3 1600(1007u&1037u)/1333MHz architecture
Expansion Slots 1 x PCI Express X1 slot
-SupportPCIExpressGen25GT/sdatarate
1 x MINI PCI Express slot (Reserved)
-SupportPCIExpressGen25GT/sdatarate
Storage Intel®NM70 chipset
-3xSATA2.0connectors(3Gb/sdatatransferrate)
- 1 x SATA 3.0 connectors (6Gb/s data transfer rate)
LAN Realtek RTL8111F Gigabit LAN controller
Support 10/100/1000Mbps
Audio RealtekALC662
-HighDenitionAudio
-2/4/5.1-channel
-Support Jack-Sensing function
USB Supportupto8xUSB2.0ports(4rearpanelports,2onboardUSB
headerssupporting4extraports)
SupportUSB2.0protocolupto480Mb/s
Internal
Connectors
1x24-PinATXpowerconnector
1x4-pinATX12Vpowerconnector
1xCPUFANheader(4-pin)
1xSystemFANheader(4-pin)
1 x Front panel header
1 x Front Audio header
1 x SATA 3.0 connectors
3xSATA2.0connectors
2xUSB2.0headers
1 x Speaker header
1 x LPT header
1 x TPM header
1 x INTR header
1 x COM1 header
1 x ME header
1 x Clear CMOS header
Back Panel
Connectors
1xPS/2Keyboardport
1xPS/2Mouseport
4xUSB2.0ports

PRODUCT INTRODUCTION
3
Back Panel
Connectors
1xCOM2port
1 x HDMI port (D70S/D70S-V/D70S-P)
1 x VGA port
1 x DVI-D port (D70S-D/D70S-VD/D70S-PD)
1xRJ45LANport
3 x Audio ports
Hardware Monitor System voltage detection
CPU/System temperature detection
CPU/System fan speed detection
CPU Overheating warning
CPU/System fan speed control
Green Function SupportACPI(AdvancedCongurationandPowerInterface)
SupportS0(normal),S1(poweronsuspend),S3(suspendtoRAM),S4
(suspendtodisk),S5(soft-off)
Support EuP function
Bundled Software FOX ONE
FOX LiveUpdate
FOX LOGO
FOX DMI
Smart Charger
Operating System Support for Microsoft®Windows®8/7
Form Factor Mini-ITX Form Factor, 6.7 inches x 6.7 inches (17cm x 17cm)

PRODUCT INTRODUCTION
4
1-2 Layout
Note : The above motherboard layout is for reference only, please refer to the physical
motherboard for detail.
1.4-pinATX12VPowerConnector
2.System_FanHeader
3. Front Audio Header
4.MINIPCIExpressSlot
5.PCIExpressX1Slot
6. Speaker Header
7. ME Header
8. Clear CMOS Header
9. Front USB Headers
10. Front Panel Header
11. SATA Connectors
12.24-pinATXPowerConnector
13. INTR Header
14.LPT Header
15.DDR3DIMMSlot
16. COM1 Header
17. TPM Header
18. Chipset: Intel®NM70
13 14
1
32
4
10 1512
16
17
18
6
7
5
9
8
11

PRODUCT INTRODUCTION
5
1-3 Back Panel Connectors
1. PS/2 Mouse Port
Usetheupperport(green)toconnectaPS/2mouse.
2. PS/2 Keyboard Port
Usethelowerport(purple)toconnectaPS/2keyboard.
3. COM2 Port
ThisisoutputofRS232COM2port.
4. VGA Port
To connect with external display devices, such as monitor or LCD display.
5. DVI-D Port (D70S-D/D70S-VD/D70S-PD)
TheDVI-DportsupportsDVI-Dspecication.ConnectamonitorthatsupportsDVI-Dconnec
tion to this port.
5. HDMI Port (D70S/D70S-V/D70S-P)
TheHDMI(High-Denition MultimediaInterface)providesan all-digitalaudio/videointerface
to transmit the uncompressed audio/video signals and is HDCP compliant. Connect the HDMI
VGA Port
VGA Port
LAN Port
LAN Port
PS/2KeyboardPort
PS/2KeyboardPort
PS/2MousePort
PS/2MousePort
Line Out
Line Out
Microphone In
Microphone In
Line In
Line In
1
1
8
8
5
5
6
6
2
2
7
7
USB Ports
USB Ports
Audio Ports
Audio Ports
4
4
3
3
Backpanelconnectorsof5.1channel(D70S/D70S-V/D70S-P):
Backpanelconnectorsof5.1channel(D70S-D/D70S-VD/D70S-PD):
COM2Port
COM2Port
DVI-D Port
HDMI Port

PRODUCT INTRODUCTION
6
audio/video device to this port. The HDMI Technology can support a maximum resolution of
1920x1080pbuttheactualresolutionssupporteddependonthemonitorbeingused.
6.USB 2.0 Ports
TheUSBportsupportstheUSB2.0/1.1specication.UsethisportforUSBdevicessuchas
anUSBkeyboard/mouse,USBprinter,USBashdriveandetc.
7. RJ45 LAN Port
The Ethernet LAN port provides Internet connection at up to 10/100/1000Mb/s data rate.
8. Audio Ports
Forthedenitionofeachaudioport,pleaserefertothetablebelow:
Port 2-channel 4-channel 5.1-channel
Blue Line In Rear Speaker Out* Rear Speaker Out*
Green Line Out Front Speaker Out Front Speaker Out
Pink Microphone In Microphone In Center/Subwoofer Out*
Active Link
LED LED
LAN Type Left: Active Right: Link
Status Description Status Description
1000M
Off No Link Off No Link
Green
Blinking
Data
Activity
Off 10Mb/s Connection
Green 100Mb/s Connection
Orange 1000Mb/s Connection

This chapter introduces the hardware installation
process, including memory, slots, pin headers and the
mounting of jumpers. Caution should be exercised dur-
ing the installation of these modules. Please refer to the
motherboard layout prior to any installation and read the
contents in this chapter carefully.
This chapter includes the following information :
■InstalltheMemory
■InstallotherInternalConnectors
■Jumpers
Chapter 2 Hardware Installation

HARDWARE INSTALLATION
8
2-1 Install the Memory
If you take a look at front side of memory module, it has asymmetric pin counts on both sides
separatedbyanotchinthemiddle,soitcanonlytinonedirection.Followthestepsbelowto
correctly install your memory modules into the sockets.
204-Pin
Step2:
The clips at both ends of the socket will
snap into place when the memory moule
is securely inserted and pressed.
Notch
Step 1:
Plug the pin side of the memory module
into the socket slantwise, then press it
downrmly.
Read the following guidelines before you begin to install the memory :
■ Alwaysturnoffthecomputerandunplugthepowercordfromthepoweroutlet
before installing the memory to prevent hardware damage.
■ Memorymoduleshaveafoolproofdesign.Amemorymodulecanbeinstalledin
only one direction. If you are unable to insert the memory, switch the direction.

HARDWARE INSTALLATION
9
2-2 Install other Internal Connectors
Power Connectors
This motherboard uses an ATX power supply. In order not to damage any device, make sure all
the devices have been installed properly before applying the power supply.
24-pin ATX power connector : PWR1
PWR1 is the ATX power supply connector. Make sure that the power supply cable and pins are
properly aligned with the connector on the motherboard. Firmly plug the power supply cable into
the connector and make sure it is secure.
4-pin ATX 12 V Power Connector : PWR2
Connectthe4-pinATX12VpowersupplytoPWR2andprovidespowertotheCPU.
Pin # Denition
1 GND
2GND
3+12V
4 +12V
Werecommendyouusinga24-pinpower
supply.Ifyouareusinga20-pinpower
supply, you need to align the ATX power
connector according to the picture.
Pin # Denition Pin # Denition
1 3.3V 13 3.3V
23.3V 14 -12V
3 GND 15 GND
4 +5V 16 PS_ON(SoftOn/Off)
5GND 17 GND
6+5V 18 GND
7 GND 19 GND
8 Power Good 20 NC
9+5VSB(Standby+5V) 21 +5V
10 +12V 22 +5V
11 +12V 23 +5V
12 3.3V 24 GND
20-PinPower
PinNo.24
PWR1
24 13
12 1
PWR2
1
3
24

HARDWARE INSTALLATION
10
Audio Header : F_AUDIO
The audio header supports HD Audio standard.
It provides the Front Audio output choice.
Fan Header : SYS_FAN
The fan speed can be controlled and monitored
in “Health” section of the BIOS Setup. The fan
can be automatically turned off after the system
entersS3,S4andS5sleepingstates.
USB Headers : F_USB1/2
In addition to the USB ports on the rear panel,
this product also provides 10-pin USB headers
on its motherboard. By connecting through USB
cables with them, user can quickly expand another
USB ports on the front panel.
LPT Hearder : LPT
The header supports parallel port which can
be connected to a printer or a scanner. System
usually assign IRQ7 as it’s default interrupt re-
quest and the parallel port has three operation
mode: [SPP], [EPP], [ECP].
A_MIC2_L
A_MIC2_R
A_LINE2_L
SENSE_SEND
SENSE1_RETURN
PRESENCEJ
EMPTY
SENSE2_RETURN
AUD_GND
12
109
F_AUDIO
A_LINE2_R
SYS_FAN
SENSE
POWER
GND
CONTROL
1
VCC
D-
EMPTY
D+
GND
D+
D-
GND
NC
VCC
12
109
F_USB1/2
Strobe Auto Feed
12
25 26
Error
SLCT IN
INIT
Ground
Ground
Ground
Ground
Ground
Ground
Ground
Ground
Empty
Data it [0]
Data it [1]
Datait[2]
Data it [3]
Datait[4]
Data it [6]
Datait[5]
Data it [7]
ACK
Busy
Paper End
Select
LPT

HARDWARE INSTALLATION
11
Front Panel Header : FP1
This motherboard includes one header for
connecting the front panel switch and LED
Indicators.
Hard Disk LED Connector (HDD-LED)
Connect to the chassis front panel IDE
indicator LED. It indicates the active status
of the hard disks. This 2-pin connector is
directional with +/- sign.
Reset Switch (RESET-SW)
Attach the connector to the Reset switch on
the front panel of the case; the system will
restart when the switch is pressed.
Power LED Connector (PWR-LED)
Connect to the power LED indicator on the
front panel of the chassis. The Power LED
indicates the system’s status. When the
system is in operation (S0 status), the LED
is on. When the system gets into sleep mode
(S1) , the LED is blinking; When the system
is in S3/S4 sleep state or power off mode
(S5),theLEDisoff.This2-pinconnectoris
directional with +/- sign.
Power Switch Connector (PWR-SW)
Connect to the power button on the front
panel of the chassis. Push this switch allows
the system to be turned on and off rather than
using the power supply button.
Serial ATA Connectors : SATA_1/2/3/4
The Serial ATA connector is used to connect with
SATA Hard Disk or CD devices which support
thisfeature.TheSATA_2/3/4allowsupto3GB/s
data transfer rate, the SATA_1 support SATA
3.0 specication, and allows up to 6GB/s data
transfer rate.
TPM Header : TPM
The TPM (Trusted Platform Module) provides the
ability to the PC to run applications more secure
and to make transactions and communication
more trustworthy. To utilize this function, you
should purchase additional device and install it.
HDD-LED
RESET-SW
NC
+
-
PWR-SW
+
-PWR-LED
EMPTY
12
10
9
FP1
LCLK
LFRAMEn
LRESETn
LAD3
VDD
LAD0
3D3V_DUAL
NC_1
GND
LPCPDn
GND
EMPTY
LAD2
5V_SYS
LAD1
GND
NC_4
SERIRQ
CLKRUNin
NC_5
12
19 20
TPM
GND
TX+
TX-
GND
RX-
RX+
GND
1
SATA_2/3/4
GND
TX+
TX-
GND
RX-
RX+
GND
1
SATA_1

HARDWARE INSTALLATION
12
MINI PCIE Slot : MINI PCIE
The MINI PCIE Slot is used to connect MINI
PCIE device.
Speaker Header : SPEAKER
The speaker header is used to connect speaker
of the chassis.
Chassis Intrusion Alarm Header : INTR
The header can be connected to a security switch
on the chassis. The system can detect the chassis
intrusion through the function of this connector. If
eventually the chassis is closed, the system will
send a message out.
COM Header : COM1
This motherboard supports one serial RS232
COM1 port for legacy compatibility. User must
purchaseanotherRS232cablewitha9-pinD-sub
connector at one end to connect with the external
RS232deviceandanotherendwith10-pinfemale
connector to connect with COM1 header in the
motherboard.
NC
PWR
EMPTY
SPEAKER
SPKJ
1
2
3
4
INTR
GND
INTRUDERJ
1
DCD
SOUT
RI
GND
RTS
DSR
DTR
CTS
EMPTY
SIN
12
109
COM1

HARDWARE INSTALLATION
13
2-3 Jumpers
For some features needed, users can change the jumper settings on this motherboard to modify
them. This section explains how to use the various functions of this motherboard by changing the
jumper settings. Users should read the following content carefully prior to modifying any jumper
setting.
Description of Jumpers
1.Foranyjumperonthismotherboard,Pin1canbeidentiedbytheboldsilkscreennexttoit.
However, in this manual, Pin 1 is simply labeled as “1”.
2.Thefollowingtableexplainsdifferenttypesofthejumpersettings."Closed"meansplacinga
jumper cap on the two pins to temporarily short them. The shorting can also be done by touching
two pins by a screwdriver for a few seconds, but using jumper cap is recommended. It can
prevent hazardous ESD (Electrical Static Discharge) problem.
Clear CMOS Jumper: CLR_CMOS
The motherboard uses CMOS RAM to store the basic hardware information (such as BIOS data,
date, time information, hardware password...etc.). Clear CMOS data is the fast way to go back to
factorydefaultwhentheBIOSsettingsweremistakenlymodied.
The steps to clear CMOS data are :
1. Turn off the computer, unplug the power cord from the power outlet.
2.Removejumpercapfrompins2-3,putitontopins1-2toshortthem.ThiswillclearCMOSdata.
3.Returnthesettingtoitsoriginalwithpins2-3closed.
4.Pluginthepowercordtoyourcomputerandturniton.
5.GotoBIOSSetuptocongurenewsystemasdescribedinnextchapter.
Clear
1
2
3
Normal
(Default)
1
2
3
CLR_CMOS
Jumper Diagram Denition Description
Closed SetPin1andPin2closed
Open SetPin1andPin2Open
1-2 SetPin1andPin2closed
2-3 SetPin2andPin3closed
1
1
1
1
1
1
■ Disconnectthepowercablebeforeadjustingthejumpersettings.
■ DonotcleartheCMOSwhilethesystemisturnedon.
CAUTIO
N
