MX2400 Programmer's Manual
4FPC s.r.o. 2021Rev. 2021.4.22
1Introduction
This document describes usage of MX2400 device plugin.
The MX2400 device is represented by a minimum of four virtual devices: Master, IO interface, Matrix and
Multimeter. Optionally there can be also DIO cards device. Each of them controls the specified section of
MX2400.
Plugin files:
FpcMx2400.dll (main library)
FpcMx2400.local.xml (localization)
Lcs.Fastboot.dll (bootloader library)
Lcs.Printing.dll (print library)
PdfSharp.dll (print to PDF capability)
2Configuration
Plugin requires to configure the target MX2400 device(s) in the configuration dialog:
In the list of configured devices, insert new row by entering IP address of target MX2400 to be connected.
After dialog is closed, the new devices will appear in the detected device list, if connection was successful.
When re-open the configuration dialog, you can see the MAC address of target host and status information.
Default IP address
192.168.100.250
Mask
255.255.255.0
Default ports
2400 and 2401 (see
note below)
Ports note:
Two ports are used - 2400 and 2401. First is for the control channel and second for the asynchronous event
channel (i.e. for IO interface). Port numbers cannot be changed.
IP address can be configured using the service terminal.
There is a web-based administration, accessible on port 8080 (enter "http://<your-mx-ip-address>:8080" to
your web-browser). Actually it only shows summary information and list of detected cards. No configuration is
possible to do here.

MX2400 Programmer's Manual
5FPC s.r.o. 2021Rev. 2021.4.22
2.1 Service terminal
MX2400 supports the low-level configuration using the RS-232 service interface. The connection to computer is
done using the RS-232 (DSUB-9) connector on the master card (see the Hardware manual for description).
The service interface emulates standard VT100 ANSI terminal. It is recommended to use the PuTTY
software or any other VT100-compatible ANSI terminal.
2.1.1 Connection
Parameters of communication:
115200 bps, 8 data bits, no parity, no flow control
Required cable wiring:
Computer RS-232
Master card RS-232/SYNC-IO
Pin
Signal
Pin
Signal
2
RxD
3
TxD
3
TxD
2
RxD
5
GND
5
GND
(CAN9 female to CAN9 female, cross-link)
The easiest way how to connect using the PuTTY is via command-line:
putty.exe -serial COM1 -sercfg 115200,8,n,1,N
Replace COM1 argument for COMx that you really used.
You can of course connect using the PuTTY's GUI - do not forget to enter correct baudrate (115200 bps) and
configure the serial communication:

MX2400 Programmer's Manual
6FPC s.r.o. 2021Rev. 2021.4.22
Connecting via PuTTY

MX2400 Programmer's Manual
7FPC s.r.o. 2021Rev. 2021.4.22
When you see the black terminal screen, on the keyboard press Ctrl + S + T (Ctrl + Service + Terminal). You
should see similar to following on the screen:
MatrixBox MX2400 Service Terminal
2015-2-6 14:20:42
F1 System
F2 Network
F3 Misc
If nothing is shown, check the connection between Master card's RS-232 and computer and/or the cable
wiring.
Navigation in the terminal:
F1 to F12: go to sub-menu
Enter: confirm value
Esc: discard value, go back to the previous screen
2.1.2 IP address configuration
Press F2 - enter Network:
MatrixBox MX2400 Service Terminal
2015-2-6 14:46:25
Network
F1 Set IP address and mask
F2 Restore default configuration
MAC address: 00:1E:C0:AF:AF:C3
Link: 100 Mb/s, full-duplex
Connected host: none
IP address: 192.168.1.253
Mask: 255.255.255.0
Press F1 to set IP adress:
...
Enter IP address: 192.168.10.5
Press Enter to confirm:
...
Enter IP address: 192.168.10.5
Enter mask (optional):
Leave the mask empty and press Enter:
...
IP address: 192.168.10.5
Mask: 255.255.255.0
IP address and mask successfully changed.

MX2400 Programmer's Manual
8FPC s.r.o. 2021Rev. 2021.4.22
3Master
Master device is the main device of the MX2400.
3.1 Features
Connection control to MX2400 via ethernet
List of detected MX cards, redetecting cards
Show state of MX cards
Controls of special features of MX cards if available (LCMX card diagnostics for example)
Updating firmware
3.2 Commands
3.2.1 *idn? (Identification)
*idn?
Return identification string.
Parameters
No paramters.
Return value
No return value.
3.2.2 *detect (Card detection)
*detect{:rst=[bool]}
Re-detect cards in the MX2400 system.
Parameters
rst
[bool]
Reset all cards before detection (via dedicated BUS signal).
Optional, default: false
Return value
No return value.
3.2.3 cards? (List of cards)
cards?
Get list of all detected cards.

MX2400 Programmer's Manual
9FPC s.r.o. 2021Rev. 2021.4.22
Parameters
No parameters.
Return value
<pos0>,<type0>:<pos1>,<type1>:...:<posN>,<typeN>
..where pos is the zero-based position of card in the system and type is the card type-ID:
139: MXC2-LCMX-32
144: MXC2-DEV-4/2/2
167: MXC2-HCMX-16
200: MXC2-DIO-64
Examples
cards?
Returns 0,139:1,139:17,144 for example, which means MXC2-LCMX-32 cards on positions 1 and 2
and MXC2-DEV-4/2/2 card on position 18.
3.2.4 diag? (Diagnostics)
diag?:<location>
Run diagnostics on selected card.
Note: currently supports only LCMX and HCMX cards.
Parameters
location
[string]
Card position in the system:
location in format #{box.}card, where box is box number
(1 or 2, only when two boxes are interconnected together)
and card is card position, starting by 1 (same, like the
marking on the top of the box)
direct address (zero-based)
Return value
Depends on diagnosed card type.
Generally: when diagnostics was successful, return value is PASS
MXC2-LCMX
MXC2-HCMX
when OK, returns PASS
when NG, returns bLbH:t0...tN, where "b" represents BUS A and C (* = OK, S = NG - short) and "t"
represents TP1..N (* = OK, L = SHORT to L, H = SHORT to H, S = SHORT both)
Examples
diag?:0
Perform diagnostics of card with address 0. Returns i.e. PASS - card is OK.
diag?:#6
Perform diagnostics of card at location 6. Returns i.e. (for LCMX card)
**:**L****************************H, which FAIL - in detail: buses are OK, but TP3 is shorted
to L and TP32 is shorted to H.

MX2400 Programmer's Manual
10 FPC s.r.o. 2021Rev. 2021.4.22
diag?:#1.13
Perform diagnostics of card in the box 1, location 13. Returns i.e. PASS - card is OK.
diag?:*
Run diagnostics of all cards.
Note: currently supports only LCMX and HCMX cards.
Parameters
No parameters.
Return value
Number of FAILs:
0: PASS
>=1: FAIL
4IO interface
Internal MX2400 IO interface, featuring 16 inputs and 16 outputs.
4.1 Commands
Commands to control IO interface. Chaining of commands is supported. This allows to pass more
commands to IO interface at once.
Chaining example:
s:0:d:100:r:1:d:10:c:0
Will do:
Set output 0
Delay for 100 ms
Read state of input 1
Delay for 10 ms
Clear output 0
4.1.1 *idn? (Identification)
*idn?
Return identification string.
Parameters

MX2400 Programmer's Manual
11 FPC s.r.o. 2021Rev. 2021.4.22
No paramters.
Return value
No return value.
4.1.2 s (Set outputs)
s:<out0>{:<out1>:...:<outN>}
Set (switch ON) specified output(s).
Parameters
out
[int]
Number of output signal in range of 0 to 15.
Return value
No return value.
Examples
s:0:5:12
Set outputs 0, 5 and 12 to ON.
4.1.3 c (Clear outputs)
c:<out0>{:<out1>:...:<outN>}
Clear (switch OFF) specified output(s).
Parameters
out
[int]
Number of output signal in range of 0 to 15.
Return value
No return value.
Examples
c:0:5:12
Set outputs 0, 5 and 12 to OFF.
c:*
c:all
Clear all output(s).
Parameters
No parameters.
Return value
No return value.

MX2400 Programmer's Manual
12 FPC s.r.o. 2021Rev. 2021.4.22
4.1.4 r (Read inputs)
r:<in0>{:<in1>:...:<inN>}
Read current state of specified input(s).
Parameters
in
[int]
Number of input signal in range of 0 to 15.
Return value
"0" when input is OFF
"1" when inputs is ON
If there is more than 1 input to read, the return value contains all input states (0 or 1), separated by a
colon (":").
Examples
r:7
Read state if input number 7, return value will be for example "1" (ON).
r:2:8:11
Read state if inputs 2, 8 and 11, return value will be for example "1:0:1" (2 = ON, 8 = OFF, 11 = ON).
r:*
r:all
Read current state of all inputs.
Parameters
No parameters.
Return value
16 states ("0" or "1") in ordered by input 15 to 0 (MSB first), separated by a colon (":").
4.1.5 d (Delay)
d:<delay>
Put a delay between sub-commands in the sequence.
Parameters
delay
[int]
Delay in milliseconds
Return value
No return value.
Examples
s:0:d:250:c:0
Set output 0 for 250 ms (make a pulse).

MX2400 Programmer's Manual
13 FPC s.r.o. 2021Rev. 2021.4.22
5Matrix
Matrix and routing interface.
5.1 Features
Test-point control (connecting any TP to LOW or HIGH bus)
Routing control of each MX card
Master routing control (Connection cards)
Sequence measure control
5.2 Routing
Generally, routing is about interconnection of internal card's buses to main back-plane buses (BUS 1 - 4).
MX2400 has two routings:
Card routing - define LCMX card interconnection of internal buses to main bus
Master routing - define Connection card interconnection of inputs/outputs to main bus
This chapter describes a little bit the internal electrical solution and simplified schematics of routing for
understanding what is controlled by commands.
5.2.1 MX card routing
MX card routing is about interconnection of LCMX card internal A and C buses to main back-plane BUS 1 - 4
.

MX2400 Programmer's Manual
14 FPC s.r.o. 2021Rev. 2021.4.22
Bus 1
Bus 2
Bus 3
Bus 4
Backplace buses
TP31
(A16)
L H
TP3
(A2)
TP1
(A1)
Bus AL Bus AH
TP32
(C16)
L H
TP4
(C2)
TP2
(C1)
Bus CL Bus CH
MX card routing
L
HSW AH-1
SW AL-1 SW AH-2
SW AL-2 SW AH-3
SW AL-3 SW AH-4
SW AL-4
SW CH-1
SW CL-1 SW CH-2
SW CL-2 SW CH-3
SW CL-3 SW CH-4
SW CL-4
Full diagram of MX card routing
LCMX card has internally two split buses: A and C. Each bus consists of L and H line.
A/C and L/H results to 4 signal lines in total:
AL - bus A, line LOW
AH - bus A, line HIGH
CL - bus C, line LOW
CH - bus C, line HIGH
Routing is electrically controlled by set of routing switches SW AL-* (for bus A, line LOW), SW AH-* (A/
HIGH), SW CL-* (C/LOW) and SW CH-* (C/HIGH).
Using routing switches above you can connect them to corresponding (L/H) main back-plane buses: AL to
BUS 1-4 L, AH to BUS 1-4 H and so on.
L line of the card is possible to connect only to L line of main bus (and the same for H line). Routing does
not allow to connect i.e. AL to BUS 1 H.
Because of impossibility to interconnect different lines (L to H), it is possible to simplify the routing schematic
of every card to following matrix:

MX2400 Programmer's Manual
15 FPC s.r.o. 2021Rev. 2021.4.22
AL AH CL CH
Bus 1
Bus 2
Bus 3
Bus 4
Simplified MX card routing matrix
Any cross-point of Bus 1-4 and AL/AH/CL/CH represents a corresponding switch. Cross-points of AL and Bus
1-4 means switches SW AL-* and so on.
5.2.2 Master routing
Master routing is about interconnection of Connection card inputs/outputs to main back-plane buses.
Bus 1
Bus 2
Bus 3
Bus 4
Backplace buses
Master
routing
CH-1 CH-2 CH-3 CH-4 SENS MEAS I-MEAS PS-1 PS-2
Bus multiplex Multimeter Power supplies
IM IM
PS1O PS2O
PS ON/OFF
SW MUX
SW MM
SW PS
Full diagram of master routing/Connection card
Connection card controls routing of following signals:
Bus multiplex (CH-1 to CH-4) general inputs/outputs
Multimeter (SENS/MEAS/I-MEAS) for full external measurement (2W/4W resistance, voltage, current)
Power supplies inputs (PS-1/PS-2) for power supplies connection
Power supplies outputs (PS1O/PS2O)
Each line L/H of these signals can be interconnected with corresponding line of any Bus 1 - 4. Except Power
supplies, it is possible to connect L/H separately to different busses (for example CH-1 L to Bus 1 L and CH-1

MX2400 Programmer's Manual
16 FPC s.r.o. 2021Rev. 2021.4.22
H to Bus 3 H). Power supply L and H lines can be connected to Bus 1 - 4 only both at once.
Current measurement block:
I-MEAS (IM) to measure current of PS-1/2 using the external multimeter
IM block enables to route PS-1 or PS-2 current directly or through an amper-meter (I-MEAS lines). See
equivalent schematic of IM block below:
I-MEAS
IM
I-MEAS
PS PS
Bus Bus
SW SW-B
Equivalent circuit of IM (current measure) block
SW - main switch to put the
current directly or through the
amper-meter
SW-B - bypass switch, closed for
necessary time of during
switching the main switch SW
(=> current is not interrupted),
controlled automatically by the
hardware
The I-MEAS signal is not multiplexed to the main bus 1 - 4, it is connected always to both IM blocks (=
equivalent switches of current measure).
Typically, both L and H of any signal are connected to the same bus and because power supplies can be
connected only this way, we can simplify the schematic to following:
CH-1
Bus 1
Bus 2
Bus 3
Bus 4
CH-2 CH-3 CH-4 SENS MEAS I-MEAS
IM
SW
PS-1
IM
SW
PS-2
Bus multiplex Multimeter Power supplies
Simplified schematic of master routing
Any cross of any signal and bus represents a corresponding switch. For bus multiplex and multimeter signals
it is possible to connect L or H only.
5.3 Commands
Commands to control test-points and routing of Matrix. Chaining of commands is supported.
Tip
Routing commands can be copied from plugin's GUI control - both from MX card routing and also for Master
routing. The command below the routing schematic for every MX and routing card will configure the routing like
configured using the schematic.

MX2400 Programmer's Manual
17 FPC s.r.o. 2021Rev. 2021.4.22
MX card routing equivalent command
Master routing (Connection card) equivalent command
5.3.1 clr|set|cset (Test-point control)
clr:
set:
cset:
<low>:<high>
-or-
L:<L1>{:<L2>:...:<LN>}:H:<H1>{:<H2>:...:<HN>}

MX2400 Programmer's Manual
18 FPC s.r.o. 2021Rev. 2021.4.22
Connect (set, cset) or disconnect (clr) a pair of TP to/from LOW/HIGH or a set of TP to/from LOW and set
of TP to/from HIGH bus. The "cset" does almost the same like "set", but "cset" disconnects all previously
connected TPs first.
Parameters
low
LN
[int]
TP number (1 to N) to be connected to LOW bus.
high
HN
[int]
TP number (1 to N) to be connected to HIGH bus.
Return value
No return value.
Examples
cset:10:15
Disconnect all TPs and connect TP10 to LOW and TP15 to HIGH bus.
set:10:15
Leave currently connected TPs and connect moreover TP10 to LOW and TP15 to HIGH.
clr:10:15
Disconnect TP10 from LOW and TP15 from HIGH bus. Any other connected TP is leaved untouched.
cset:l:10:12:14:h:15:17:19
Disconnect all TPs and connect TPs 10, 12 and 14 to LOW and TPs 15, 17 and 19 to HIGH bus.
clr:l:10:12:h:15:17
Disconnect TPs 10 and 12 from LOW and TPs 15 and 17 from HIGH bus.
clr:l:10:12:set:l:8:9
Chaining example. Disconnect TPs 10 and 12 from LOW and connect TPs 8 and 9 to LOW. Any other TP
is leaved untouched.
clr:*
clr:all
Disconnect all TPs from any bus.
Parameters
No parameters.
Return value
No return value.
5.3.2 route|croute (MX card routing)
route:
croute:<loc>{:<card-bus>}:<main-bus>
Interconnection of internal MX card's buses (or lines) to any main bus 1 - 4. The "croute" clears all previous
routing before applying new (like cset/set of test-point control). The "route" clears only settings of passed
main-bus.

MX2400 Programmer's Manual
19 FPC s.r.o. 2021Rev. 2021.4.22
The pair <card-bus>:<main-bus> can be several times in the one route|croute command - see examples.
Parameters
loc
#[int] or *
MX card location 1 to N. If number is passed, it must be
prefixed by a sharp-character (#).
To set routing of all MX cards, pass an asterisk (*) as a
location.
card-bus
[enum]
Card's internal bus or line:
al = A, low
cl = C, low
ah = A, high
ch = C, high
l = A + C, low (LOW lines of A and C)
h = A + C, high (HIGH lines of A and C)
a = A, low + high (both LOW + HIGH lines of A bus)
c = C, low + high (both LOW + HIGH lines of C bus)
ac = A + C, low + high (all card's buses)
If this parameter is not passed, the default is "ac" (all card
buses).
See MX card routing description for details about lines/buses.
main-bus
[enum]
Main bus:
b1 = Bus 1
b2 = Bus 2
b3 = Bus 3
b4 = Bus 4
H/L of main bus is defined by card-bus parameter. L of card-bus
is connect to L of main-bus (and the same for H).
Return value
No return value.
Examples
croute:*:b1
Clear all previous routing of all cards and connect both card's internal buses to main bus 1 for all cards.
This is the most used command for most of the systems.
AL AH CL CH
Bus 1
Bus 2
Bus 3
Bus 4

MX2400 Programmer's Manual
20 FPC s.r.o. 2021Rev. 2021.4.22
route:#3:a:b1:c:b3
Only for card at location 3. Clear previous routings of b1 and b3 and connect card's A bus (L + H) to main
bus 1 and card's C bus (L + H) to main bus 3. Previous routing to b2 and b4 (if exists) is leaved
untouched.
AL AH CL CH
Bus 1
Bus 2
Bus 3
Bus 4
5.3.3 route|croute (Master routing)
route:
croute:mux{:<main-bus>:<mux-ch0>{:<mux-ch1>:...:<mux-chN>}}
Interconnection of main bus and Connection card input/output signals.
Parameters
main-bus
[enum]
Main bus definition:
b1 to b4, bus 1 - 4, low + high
b1l to b4l, bus 1 - 4, low only
b1h to b4h, bus 1 - 4, high only
mux-ch
[enum]
Signal to be connected to the main-bus:
ch1 to ch4 or y1 to y4 (master card with older firmware
version accepts y1-y4 only), Bus Multiplex block (SW MUX
switches)
sens and meas, Multimeter block (SW MM switches)
ps1 and ps2, represents PS-1 and PS-2 PSU inputs, Power
supplies block (SW PS switches)
See Master routing description for details about blocks and
signals.
Return value
No return value.
