frameo Feelcare HN-DPF1008 User manual

Before connecting, operating or adjusting this product, please
read this user’s manual carefully and completely.
ENGLISH
Feelcare
Social Photo Frame
For any question please email to: [email protected]
USER MANUAL
HN-DPF1008

Feelcare
This micro USB port is for uploading photos from USB drive only, it is not for
connecting computer. Photos in the USB drive can’t be displayed directly in the
frame, you have to upload/import photos from USB drive to the frame first. You
can export/copy photos from the frame to USB drive. Remarks: The usb flash
drive is recognized as “SD card” when it was inserted in the frame.
2. USB
3. RESET
Use a needle or paper clip to reset unit.
1.POWER
Use power adapter to power on the frame.
When it is on, press and hold power button for approximately 3 seconds to
access reboot or power off menu. Short press on power button will turn
off/onscreen (but leave the photo frame in on position).
Power off: To avoid any possible damage to the frame, please do not
unplug the power adapter from the frame directly, please always press
the power button for 2 seconds and tap “Power off” .
1
5
2
4
3

5. DC
Connect DC adapter to power on the device.
Load external micro SD memory cards here. Photos in the micro SD card
can’t be displayed directly in the frame, you have to upload/import photos
from micro SD card to the frame first. You can export/ copy photos from
the frame to micro SD card. If you want to backup the photos in the frame,
please follow the below steps: step 1: get a micro SD card(maximum
32GB), and put it in the micro SD card slot. step 2: tap the screen and go to
“Settings”
step 3: go to “Backup and Restore”
step 4: tick “ Automatic backup”
step 5: tap “Backup frame to SD card”
Then you will see a sentence “Last successful backup: 29 December...”
under “Backup frame to SD card”.
4. Micro SD (Support maximum 32G micro SD card)
Feelcare

1
Contents
FeelcareFeelcare
Contents 1
Getting started 4
Frameo app
Connecting a new friend 6
Add friend 7
Settings 7
Power menu 7
Hide photo 7
Gallery 7
Fit to frame/Fill frame 7
Adjust photo 8
Interacting with videos 8
Power menu 9
Settings 9
My frame 9
Frame name 9
Frame location 9
Set language 9
Set time zone 9
Enable/Disable 24-hour format 10
Manage photos 10
Show/hide photos 10
Delete photos 10
Start using Feelcare
Feelcare quick setup
4
5
6
Navigating your Feelcare 7

Feelcare
2
Import photos 10
Export photos 11
My Friends 11
Change options for a friend 11
Add person 11
Display 11
Brightness level 11
Sleep mode 11
Slideshow 12
Timer 12
Show caption 12
Fill frame 12
Photo display order 12
Autoplay 12
Video playback 12
Video volume 12
Wi-Fi 13
Wi-Fi details 13
Reset Wi-Fi 13
Notifications 13
Show notifications 13
Notification volume 13
Storage space 13
Backup 13
Network connection 13
New photos 13
New friends 14
Software update 14
Feature news 14

Backup and Restore 14
Backup frame to external storage (e.g. microSD card) 14
Automatic backup 14
Restore from backup 14
Reset frame 15
Help 15
Open source libraries 15
Share anonymous analytics data 15
Guide 15
About 15
Android version 15
Peer ID 15
MAC 15
Frameo version 16
Uptime 16
Check for update 16
Beta program 16
Feelcare
3
Support 16
Warranty, Compliance, Support and Safety information 17

Feelcare
4
Getting started
Congratulations with your brand new Feelcare photo frame!
If you are new to using Feelcare then start by following the Feelcare quick
setup or follow the on-screen guide when powering it on for the first time.
Once you have set up your Feelcare frame, you can start connecting it to
your friends and family.
Frameo app
To send photos to your frame, use the Frameo app for iOS or Android.
Find the Frameo app by scanning this code:
For Android:
Search for “Frameo” on Google Play.
For iOS:
Search for “Frameo” on App Store.

Feelcare
5
Feelcare quick setup
When starting your frame for the first time, you will need to setup the frame.
●Select alanguage. This will be the language used on the Feelcare.
●Connect your frame to the internet by connecting it to aWi-Fi.
●Frameo may ask you to update to the latest version. It is
recommended to update your frame before continuingifasked to.
●Enter your name, and the location where you have placed your frame e.g.
“John Doe” and “Living room”, “Kitchen” or “Office”. Finally set the
timezone if not already correct.

Start using Feelcare
Next step is to connect Feelcare with your friends and family by providing
them with a code from your frame.
If you want to be able to send photos to the frame yourself, start by downloading
the app for iOS or Android on App Store or Google Play. Then use the code to
connect your frame and app as described below.
Connecting a new friend
Make sure that your friend has downloaded and installed the Frameo app.
Click the add friend icon on your frame . A dialog will appear showing
a connection code, which is valid for 12 hours.
Now share this code in whatever fashion you prefer e.g. SMS, E-Mail, IM,
phone call, to your friend.
Once your friends have added the code in their Frameo app, they will
automatically appear on your frame and be able to send you photos.
Read chapter Change options for a friend to allow connected friends, to retrieve
and share the connection code via the smartphone app.
Feelcare
6

Feelcare
7
Navigating your Feelcare
Swipe left or right to go through your photos.
To access the menu, simply tap once on the screen.
In the menu you will find the most used features.
Add friend
This will generate a code that you can share with your friends and family so they can
connect and send photos to your frame.
Settings
Opens the Settings.
Power menu
Opens the Power menu
Hide photo
Hides the current photo. This means that the photo will no longer be shown in the
slideshow. If needed the photo can be shown again through the settings menu.
Gallery
Opens a gallery which allows for easy and fast navigation through your photos.
Fit to frame/Fill frame
This toggles how the photo is shown.
The Fill frame  option is the default. The photo is scaled so that it fills the whole
screen. It will be centered around what is selected as the most important part. See
the first picture below.

Feelcare
8
Fit to frame will make sure that the entire photo is shown on the screen. See the
second picture below.
Adjust photo
Allows you to adjust the position of the photo in the frame for an even
better fit. Here you can also use to rotate your photo.
Interacting with videos
When a video is shown two additional controls are shown. One for play/
pause of the video and one to control the volume level for video sounds.
Press to start the video playback. Pressing will pause the video
Press to open the volume slider. Use the slider to adjust the volume level
Pressing will mute the video while pressing will unmute the video.
playback.
for video sounds.

Power menu
Tap the power icon to access the power menu. Here you can power off
using , restart your frame using or enter sleep mode using .
NB. Make sure to always use the power off button on the device or in the
power menu to turn Frameo off. Never disconnect power when Frameo is
running.
Settings
Through the settings, you can personalize your frame to your needs.
My frame
Frame name
Changes the name of your frame. This is also the name that connected friends
and family will see in their list of connected frames in the smartphone app.
Frame location
Changes the location of your frame. This is the location displayed on your
friends' and family's list of connected frames which can help to distinguish
frames from each other.
Set language
Sets the language used on the frame.
Set time zone
Sets the time zone used on the frame.
Feelcare
9

Feelcare
10
Enable/Disable 24-hour format
Enables, and disables, 24-hour time format.
Manage photos
In the manage photos menu you can see how many photos are on your frame
and the storage they use. You can also see the amount of storage left available
on your device for storing new photos.
Show/hide photos
Select which photos to hide by tapping them. Hidden photos will NOT be deleted
from your frame and you can always select them to be shown again.
Use to hide or show all photos.
Delete photos
Select photos that you want to permanently delete from your frame by tapping
the photo.
Use to select or deselect all and to permanently delete the selected
photos.
Import photos
Allows you to import photos from an external storage (e.g. microSD card).
Before you try to import photos, make sure you have an external storage
(e.g. microSD card) inserted into your frame with the photos you wish to
import.
Start by selecting the photos that you want to import onto your frame. Once
selected tap the import button to start the import process.
Use to select or deselect all photos on the external storage (e.g. microSD
card).
Use to set the sort order of photos before import and to order by
ascending/descending.
It is currently not possible to add a caption or define the most important part
of the photo when using the import function. An alternative for this is to add
yourself to your friend list and send the photos using the app.

Feelcare
11
Export photos
Allows you to export photos from the frame to external storage (e.g. microSD
card). The export function will export all photos on the frame as well as
profile pictures.
My Friends
This list contains all the connected friends that are allowed to send photos to
your frame.
Change options for a friend
Click the options icon to open the friend options menu. From here you can
allow / disallow if a friend may share the code to the frame. If this is enabled
the friend can retrieve and share the code to the frame from his/her app.
From the options menu you can also delete a friend, by pressing the DELETE
FRIEND button. This will remove the friend from the list and thereby remove
their permission to send photos to the frame. You will then be asked to
confirm the removal and if you would like to remove all photos previously
received from this friend.
Add person
To allow a new person to send you photos, simply tap the add friend button
and share the presented code in whatever way you prefer.
Display
Brightness level
Adjust the brightness level of the screen.
Sleep mode
Frameo offers a sleep mode which turns off the screen to reduce power consump-
tion. The default setting is to turn off the screen at 23:00 and turn on the screen
again at 07:00. To change this just set the sleep mode start/end time.
Your frame is not powered down or in standby, so you will still be able to receive
photos during sleep mode.

Feelcare
12
Slideshow
Timer
Set the duration that a photo should be displayed before showing the next
photo.
Show caption
Sets whether or not to display the captions that your friends have sent with
the photo. Check to display captions. Uncheck to hide captions.
Fill frame
Sets the default frame photo setting. Check to set default to fill which makes
the photos fit the device screen according to the most important part of the
photo. Uncheck to make the photo fit inside the screen of the device, adding
blurred bars on the sides or top/bottom
Photo display order
Sets the order in which your photos are displayed on the frame.
●By date: Photos are shown newest to latest.
●Shuffle: Photos are shuffled and shown in a random order.
Autoplay
Enables/disables autoplay of videos in the slideshow. Videos can always be
manually started regardless of this setting.
Video playback
Determines how videos should be played when autoplay is enabled.
●Loop videos: The video will loop until the slideshow timer is up.
●Play once: The video will play once and show it’s thumbnail until the
timer is up.
●Play once and continue: The video will play once and continue to the
next photo, or video, once it completes.
Video volume
Adjust the volume level for video sounds on the frames.

Feelcare
13
Wi-Fi
Set which Wi-Fi the frame connects to. If you are connecting to a network
with a captive portal
Connection status will say that Wi-Fi login is required and show . Tap
this to open a login screen where you can enter credentials to access the
network.
Wi-Fi details
Use to show details about the current connected Wi-Fi.
Reset Wi-Fi
Use to delete all Wi-Fi information and restart your frame.
Notifications
Show notifications
Enables/disables whether notifications are shown in the slideshow (e.g.
when a new photo is received).
Notification volume
Adjust the volume level for notification sounds.
Storage space
Enables/disables notifications shown when frame storage is low.
Backup
Enables/disables notifications shown if automatic backup has failed.
Network connection
Enables/disables notifications showing network connection status.
New photos
Enables/disables notifications shown when receiving new photos.

Feelcare
14
New friends
Enables/disables notifications shown when new friends are added.
Software update
Enables/disables notifications shown when a software update has been
installed.
Feature news
Enables/disables notifications shown when new exciting features are added.
Backup and Restore
Backup frame to external storage (e.g. microSD
card)
Tap to make a backup of your photos, friends and settings. The time of the
latest successful backup is also displayed here.
Any existing backup on the external storage will be overridden!
Automatic backup
If checked, your frame will automatically take a backup within 30 hours of
receiving new photos or making changes to your frame.
Restore from backup
Before you attempt to restore your frame, start by confirming that your
backup is up-to-date. This is done by confirming the date under “Backup frame
to external storage (e.g. microSD card)”. If e.g. the last backup is too old or if
no backup is made, then press the “Backup frame to external storage (e.g.
microSD card)” button to make a new backup.
NB: To keep both the old and the new frame operational at the same time
after restoring from backup, please make sure that both frames are updated
to the latest version beforehand.
If you wish to restore a backup on a frame that has already been setup, then
you must first reset the frame. This is done by pressing the “Reset frame”
button. This will delete all data on the Frameo and reset the Frameo to its
setup screen.
On the setup screen you can select the “Restore from backup” button
which will restore your frame according to the backup.

Feelcare
15
If the “Restore from backup” button isn’t visible, then confirm that the
external storage (e.g. microSD card) is correctly mounted.
Reset frame
Removes all data from your frame.
This will permanently remove all your photos, friends/connections and settings.
Help
Open source libraries
Opens a list of open source libraries used in the app and their licenses.
Share anonymous analytics data
Sharing anonymous analytics data helps us tremendously to improve the
Frameo software. We understand if you do not wish to share this data with
us. Keep it checked if you wish to help us improve Frameo. Set unchecked to
deny the sharing of anonymous analytics data.
Guide
Opens the quick start guide, that was shown when you first started the frame.
About
Android version
See what version of Android that is installed on the frame.
Peer ID
This is a unique ID for your photo frame. When contacting our support, please
provide this ID with your message.
MAC
Shows the MAC address of your frame.

Feelcare
16
Frameo version
Shows what version of the Frameo software is currently installed on your
frame.
Up time
Shows how long the photo frame has been powered on.
Check for update
Check if an update is available for your frame.
Beta program
If checked the device will join the Beta program where it will receive updates
more frequently and before normal release devices.
Support
Please visit www.feelcaregroup.com for FAQ, for support please email to:
[e-mail]

Warranty, Compliance, Support and Safety information
We offer 1 year warranty for our customers, if any help you need please contact us
via Amazon message or email to: [e-mail]
Electric and electronic equipment contains materials, components and substances
that can be hazardous to your health and the environment, if the waste material
(discarded electric and electronic equipment) is not handled correctly.
Electric and electronic equipment is marked with the crossed out trash can symbol,
seen below. This symbol signifies that electric and electronic equipment should not
be disposed of with other household waste, but should be disposed of separately.
All cities have established collection points, where electric and electronic
equipment can either be submitted free of charge at recycling stations and
other collection sites, or be collected from the households. Additional
information is available at the technical department of your city.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications.
However, there is no guarantee that interference will not occur in a particular
installation. If this equipment does cause harmful interference to radio or television
reception, which can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the following
measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which
thereceiver is connec-ted.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions :
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that
may cause undesired operation.
This equipment complies with FCC radiation exposure limits setforth for an
uncontrolled environment. This equipment should be installedand operated with
minimum distance 20cm between the radiator & your body.
Feelcare
17
