FRENETIK Spik 3 User manual
2-way 3" powered speakers,
Dante™ PoE+
V1.3 - 01/2021
User’s manual
Spik 3
User’s manual - Spik 3 V1.3 01/2021 2/8
User’s manual - Spik 3 V1.3 01/2021 3/8
Spik 3 - USER MANUEL Page
1. Carton Contents 4
2. Connection 4
3. Setting up a Dante™ network 4
4. Routing with the Dante controller 5
5. Control and monitoring software 5
6. Technical Specications 6
7. Dimensions 6
User’s manual - Spik 3 V1.3 01/2021 4/8
1. Carton Contents
- 2 Spik 3 speakers
- 2 brackets with clamping screws (mounting key supplied)
- 1 user manual
2. Connection
For connection to a Dante™ network, connect the RJ45 socket, with a Cat 5 or Cat 6 network
cable, to an Ethernet Switch, accepting a minimum 100 Mbit/s Fast Ethernet link speed.
The connection is also used to power the speaker via the network using PoE (Power over
Ethernet) technology. A PoE switch or PoE injector must therefore be used. To achieve full
power, a PoE power supply according to the IEEE 802.3at-2009 «PoE+» standard must be
used.
3. Setting up a DanteTM network
1) Start the Dante Controller software.
2) Wait until the devices visible on the network appear in the software matrix.
Note: If a device does not appear, there are several possible reasons, including:
- the device is not powered on / powered up
- the device is in another subnetwork
- the device cannot be synchronized with other Dante™ devices
For either of the last two reasons, the Dante™ device must at least be visible in the Network
View under the «Device Info» or «Clock Status» tab. Stopping and then restarting the speaker
could be a quick x to the problem. Additional information can be found in the Audinate
Dante Controller manual.
3) From the Dante™ Controller menu bar, select «Device / Device View» or press the Ctrl+D
key combination. The «Device View» window will appear.
4) From the drop-down menu below the menu bar, select the speaker to be congured.
5) In the third «status» tab, various information about the device is available.
6) Click the «Device Cong» tab. If necessary, adapt the «Sample Rate» to that used in the
Dante™ network (all devices must have the same sample rate to work together).
7) In the «Rename Device» eld, it is possible to modify the name used for the device in
the Dante network, for better identication. Conrm any changes by pressing the «Apply»
button.
8) From the «Network Cong» tab you can, if necessary, change the network settings for the
Dante™ interface of the speaker.
User’s manual - Spik 3 V1.3 01/2021 5/8
4. Routing with the Dante™ Controller
In order to congure the audio streams you need to :
1) In the main window, in the «Routing» tab, open the channels of the transmitter device
on the right «Dante™ Transmitters» and the channels of the receiver device under «Dante™
Receivers» by clicking on the + buttons.
2) Click on the intersection point between the transmitter channel and the receiver channel.
3) Wait until the eld displays a green circle with a white check mark.
For other connections, repeat these three points. On the Audinate site, it is possible to
download a User Guide for the Dante Controller in English:
https://www.audinate.com/resources/technical-documentation
5. Control and monitoring software
The Frenetik Dante™ PoE+ loudspeaker control and monitoring software is available for
download. Frenetik software allows you to monitor the temperature and level of the
amplier, adjust the loudspeaker level and apply treble or bass equalization. To save these
settings, press the «SAVE» button. The «RECALL» button allows you to return to the original
conguration.
The software only works on Windows 7 and higher.
User’s manual - Spik 3 V1.3 01/2021 6/8
6. Technical Specications
Ref. SPCX30DP / SPCX30DP-W
Type / number of channels 2-channel loudspeaker
Amplication 25 W (classe D)
Dante™ Receiver 1 (16 / 24 / 32 bit - 44,1 to 96 kHz)
Speaker size 1 woofer 3"
1 tweeter 3"
Peak SPL capacity (1 m) 109 dB
Bandwidth (-10 dB) 145 Hz - 20 kHz
Directivity (H x V) 100° x 100°
Connection system 1 x RJ45
Insert 2 x M10
Dimensions (H x L x P) 205 x 95 x 117 mm
Weight 2,4 Kg
Power supply PoE+ (IEEE 802.3 at)
Certication CE
7. Dimensions
Spik 3 Speaker
94,5 mm
94,5 mm
116,5 mm
205 mm
205 mm
M10 M10
Spik 3 Mounting pole
User’s manual - Spik 3 V1.3 01/2021 7/8
R15,3
R15,3
Ø 8
Ø 8
Ø 11
31 mm
85 mm
12 mm
27 mm
85 mm
31 mm
40 mm
29 mm
213 mm
207 mm
213 mm
100 mm
Ø 10
FRENETIK - 1 Allée d’Eat - Le Parc de l’Événement - Bât. H
91160 Longjumeau - France
+33 (0)1 69 10 50 81
frenetik.fr
