Frigidaire FDB435RF User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR
FDB435RFR7 FDB435RF 24" Built-in black
FDB435RFS5 FDB435RF 24" Built-in white
MARKET
North America
Publication No.
5995374831
020624
-EN/SERVICE /ECL
821
24" Built-In
DISHWASHER
Model No.
FDB435RF
All rights reserved
FACTORY PARTS CATALOG
DISHWASHER
SERVICE DATA SHEET # - 154415001
OWNER’S GUIDE # - 154392901
INSTALLATION INSTRUCTIONS # - 154415901
ENERGY GUIDE LABEL # - 154399002
P.O. Box 212378, Augusta, GA 30917

06/02 2
Publication No. FDB435RF
5995374831
CONTROL PANEL

# = Fast Moving Part 3 06/02
* = Non-Illustrated Part
FDB435RF Publication No.
5995374831
CONTROL PANEL
A = FDB435RF (FDB435RFS5)
B = FDB435RF (FDB435RFR7)
POS. NO PART NO DESCRIPTION
1 154368204 A - Panel,control ,white
1 154368206 - B Panel,control ,black
2 154236601 A - Insert,control panel ,white
2 154236603 - B Insert,control panel ,black
3 # 154408901 A B Timer
3* 154095701 A B Screw,thread rolling ,(2) ,timer
3* 154131203 A B Shield,timer
8 # 154215101 A B Switch,selector ,4 pad
8* 154248601 A B Shield,switch
8* 5303318719 A B Screw,mtg.
13 154239501 A - Knob,timer ,white
13 154239503 - B Knob,timer ,black
20 154345101 A B Vapor Chamber Assy,w/vent gasket
25 154229201 A B Seal,chamber
27 154226701 A B Actuator,wax
28 154226901 A B Valve,vent
29 154226403 A B Gasket,valve
* 154394401 A B Wiring Harness,main
* 154399002 A B Label,energy guide
* 154283901 A B Screw,#8-10 ,3/8 phillips

06/02 4
Publication No. FDB435RF
5995374831
DOOR

# = Fast Moving Part 5 06/02
* = Non-Illustrated Part
FDB435RF Publication No.
5995374831
A = FDB435RF (FDB435RFS5)
B = FDB435RF (FDB435RFR7)
POS. NO PART NO DESCRIPTION
1 154365701 A B Spring,door ,(2)
1A 154325201 A B Linkage,door spring ,(2)
2 154093301 A B Screw,arm assy ,(4)
3 154325304 A B Arm Assy,LH
3A 154325303 A B Arm Assy,RH
* 154400601 A B Pin,arm assy
5 154079601 A B Nut,arm assy ,(4)
7 154299002 A B Door,inner assy
7A 154226601 A B Grate,liner
9 154230101 A B Dispenser,det/rinse aid ,includes #22
9* 154294701 A B Screw,#7 plas .375 ,(6) ,disp. assy.
10 154103702 A B Screw,latch mtg ,(2)
12 # 154361201 A - Latch assy,white
12 # 154361203 - B Latch assy,black
20 154359105 A - Door,white
20 154359107 - B Door,black
20* 5304428306 A B Screw,door mtg. ,(2)
22 154388801 A B Cap,Rinse aid
49 154297602 A B Gasket,door ,bottom
50 154211401 A B Support,door hinge
51 154320301 A B Clamp,drip loop ,wire
* # 154227806 A B Thermostat,temp boost
* 154200601 A B Screw,#10-16 x 3/8
DOOR

06/02 6
Publication No. FDB435RF
5995374831
TUB

# = Fast Moving Part 7 06/02
* = Non-Illustrated Part
FDB435RF Publication No.
5995374831
A = FDB435RF (FDB435RFS5)
B = FDB435RF (FDB435RFR7)
POS. NO PART NO DESCRIPTION
1 # 154209301 A B Tub assy,w/frame parts
2 154211601 A B Strike,door
3 # 154211801 A B Gasket,tub
4 154200602 A B Screw,10-16 x 3/8 ,hex
5 154333901 A B Roller,tub
6 5303943103 A B Screw,w/washer ,(8)
22 154239801 A B Tubing,water inlet
23 5303318539 A B Clamp,tubing ,(2)
24 # 154411002 A B Hose,drain
25 # 154209701 A B Float
28 154408701 A B Switch assy,float
29 # 154290204 A B Thermostat,re-settable
30 154241101 A B Retainer,thermostat
30* 154297701 A B Screw,retainer-thermo
* 154238304 A B Insulation,tub
* 154360201 A B Insulation,blanket ,back
* 154041001 A B Screw,plask #1 ,10-10 x 9/16
* 5300807270 A B Screw,(2) ,countertop mtg.
* 154200601 A B Screw,#10-16 x 3/8
TUB

06/02 8
Publication No. FDB435RF
5995374831
MOTOR & PUMP

# = Fast Moving Part 9 06/02
* = Non-Illustrated Part
FDB435RF Publication No.
5995374831
A = FDB435RF (FDB435RFS5)
B = FDB435RF (FDB435RFR7)
POS. NO PART NO DESCRIPTION
1 # 154247601 A B Heater
1* 154106201 A B Nut,heater ,(2)
1* 154289801 A B Shield,heater terminal
2 154359701 A B Bracket,heater ,(2)
10 154245501 A B Cover,volute
13 154246801 A B Gasket,sump
14 154365902 A B Housing,sump
16 154246502 A B Retainer,sump
24 154414101 A B Spray arm,lower ,w/heat shield
24A 154313601 A B Spray arm,center
24A* 154252001 A B Nut,spray arm ,center
32 154406601 A B Tube,delivery
32A 154406401 A B Gasket,delivery tube
40 154348401 A B Clamp,red ,pump
40 154348501 A B Clamp,silver ,pump
40* 154106801 A B Clamp,hose ,(2)
54 154234401 A B Hose,connector
55 154362301 A B Bracket,motor ,askoll
55* 5303316032 A B Screw,truss ss ,8 .625
58 154246402 A B Check ball
59 154246901 A B O-ring,rear
59A 154247001 A B O-ring,front
60 154407401 A B Drain Pump Assy
60* 154234501 A B Bracket,motor ,drain
61 154406501 A B Nozzle,3rd level ,spray arm
62 154294101 A B Support,spray arm ,lower
63 154252201 A B Base,soil director
64 154252301 A B Filter,soil director
65 154252401 A B Filter,polypro
66 154252701 A B Trap,glass
70 # 154395402 A B Motor assembly,circulation ,w/o o’rings
* 154380601 A B Clamp,hose ,(1)
* 154200601 A B Screw,#10-16 x 3/8
MOTOR & PUMP

06/02 10
Publication No. FDB435RF
5995374831
FRAME

# = Fast Moving Part 11 06/02
* = Non-Illustrated Part
FDB435RF Publication No.
5995374831
FRAME
A = FDB435RF (FDB435RFS5)
B = FDB435RF (FDB435RFR7)
POS. NO PART NO DESCRIPTION
3 # 154373301 A B Valve,water
4 154208701 A B Brace,front frame
8 154322903 A B Toeplate,adjustable ,black
9 154397203 A B Kickplate Assy,black ,w/foam
10 5300808658 A B Screw,#8A x .375" ,black
11 154200601 A B Screw,#10-16 x 3/8
15 154419301 A B Screw,leveling
20 154209601 A B Cover,junction box

06/02 12
Publication No. FDB435RF
5995374831
RACKS

# = Fast Moving Part 13 06/02
* = Non-Illustrated Part
FDB435RF Publication No.
5995374831
RACKS
A = FDB435RF (FDB435RFS5)
B = FDB435RF (FDB435RFR7)
POS. NO PART NO DESCRIPTION
1 154319706 A B Rack assy,lower
2 154295201 A B Basket,silverware
3 154319506 A B Rack assy,upper
4 5304407064 A B Wheel & bushing assy,upper rack
5 5300809927 A B Cap,slide ,(4)
6 154232701 A B Slide,rack ,(2)
7 154174501 A B Wheel & bracket assy,lower rack
8 154304001 A B Base,funnel
9 154251801 A B Funnel
15 154254001 A B Handle,basket ,silverware
