Frigidaire GLDB958J User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR
GLDB958JB0 GLDB958J GALLERY black
GLDB958JS0 GLDB958J GALLERY white
GLDB958JT0 GLDB958J GALLERY almond
MARKET
North America
Publication No.
5995337671
000509
-EN/SERVICE /ECL
821
24" BUILT IN
DISHWASHER
Model No.
GLDB958J
©2000 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
DISHWASHER
SERVICE DATA SHEET # - 154371501
OWNER’S GUIDE # - 154375101
WIRING DIAGRAM # - 154371501
101 Masters Blvd.
Anderson, SC 29624

05/00 2
Publication No. GLDB958J
5995337671
CONTROL PANEL

# = Fast Moving Part 3 05/00
* = Non-Illustrated Part
GLDB958J Publication No.
5995337671
CONTROL PANEL
A = GLDB958J (GLDB958JB0)
B = GLDB958J (GLDB958JS0)
C = GLDB958J (GLDB958JT0)
POS. NO PART NO DESCRIPTION
1 154370303 A - - Panel-control,black
1 154370301 - B - Panel-control,white
1 154370302 - - C Panel-control,almond
2 154370003 A - - Insert-control pnl,black
2 154370001 - B - Insert-control pnl,white
2 154370002 - - C Insert-control pnl,almond
3 # 154362803 A B C Control
3* 154200401 A B C Screw,6-10 x 3/8 ,pan plask
4 154287901 A B C Cover-control
18 154302303 A - - Nameplate Assy,black
18 154302301 - B - Nameplate Assy,white
18 154302302 - - C Nameplate Assy,almond
20 154228301 A B C Duct-dynamic
25 154229201 A B C Seal-chamber
26 154303901 A B C Gasket-vent
27 154226701 A B C Actuator-wax
28 154226901 A B C Valve-vent
29 154226403 A B C Gasket-valve
30 154226802 A B C Blower-crossflow
31 154228101 A B C Chamber-vapor
34 # 154369701 A B C Keypad,12pad
35 154362901 A B C Board-display
* 154227501 A B C Thermister
* 154283901 A B C Screw,#8-10 ,3/8 phillips
* 154365801 A B C Harness-wiring

05/00 4
Publication No. GLDB958J
5995337671
DOOR

# = Fast Moving Part 5 05/00
* = Non-Illustrated Part
GLDB958J Publication No.
5995337671
A = GLDB958J (GLDB958JB0)
B = GLDB958J (GLDB958JS0)
C = GLDB958J (GLDB958JT0)
POS. NO PART NO DESCRIPTION
1 154365701 A B C Spring-door,(2)
1A 154325201 A B C Spring linkage,(2)
2 154093301 A B C Screw-arm assy,(4)
3 154325304 A B C Arm Assy,LH
3A 154325303 A B C Arm Assy,RH
* 154211501 A B C Pin-arm
5 154079601 A B C Nut-arm assy,(4)
7 154299002 A B C Door-inner assy
7A 154226601 A B C Liner grate
9 154230102 A B C Dispenser-det/rinse aid,w/ level ind.
10 154103702 A B C Screw-latch mtg,(2)
12 # 154361203 A - - Latch assy,black
12 # 154361201 - B - Latch assy,white
12 # 154361202 - - C Latch assy,almond
20 154359003 A - - Door,black
20 154359001 - B - Door,white
20 154359002 - - C Door,almond
49 154297602 A B C Gasket-door,bottom
50 154211401 A B C Support-door hinge
* 154320301 A B C Clamp-wire,drip loop
* 154253201 A B C Insulation,door
DOOR

05/00 6
Publication No. GLDB958J
5995337671
TUB

# = Fast Moving Part 7 05/00
* = Non-Illustrated Part
GLDB958J Publication No.
5995337671
A = GLDB958J (GLDB958JB0)
B = GLDB958J (GLDB958JS0)
C = GLDB958J (GLDB958JT0)
POS. NO PART NO DESCRIPTION
1 # 154209301 A B C Tub assy,w/frame parts
2 154211601 A B C Strike-door
3 # 154211801 A B C Gasket-tub
4 154200602 A B C Screw,10-16 x 3/8 ,hex
5 154333901 A B C Roller-tub
6 5303943103 A B C Screw w/washer,(8)
22 154239801 A B C Tubing-water inlet
23 5303318539 A B C Clamp-tubing,(2)
24 # 154225602 A B C Hose-drain
25 # 154209701 A B C Float
28 # 154225501 A B C Switch-float
28A 154209801 A B C Bracket-float switch
28A* 154333301 A B C Screw,bracket mtg ,ph truss head
29 # 154290204 A B C Thermostat,re-settable
30 154241101 A B C Retainer-thermostat
30* 154297701 A B C Screw,retainer-thermo
* 154041001 A B C Screw,plask #1 ,10-10 x 9/16
* 154238304 A B C Insulation,tub
* 154360201 A B C Insulation,blanket ,back
TUB

05/00 8
Publication No. GLDB958J
5995337671
MOTOR & PUMP

# = Fast Moving Part 9 05/00
* = Non-Illustrated Part
GLDB958J Publication No.
5995337671
A = GLDB958J (GLDB958JB0)
B = GLDB958J (GLDB958JS0)
C = GLDB958J (GLDB958JT0)
POS. NO PART NO DESCRIPTION
1 # 154247601 A B C Heater
1* 154106201 A B C Nut-heater,(2)
1* 154289801 A B C Shield-heater terminal
2 154359701 A B C Bracket-heater,(2)
7 154245901 A B C Macerator
10 154245501 A B C Cover-volute
12 154245801 A B C Impeller
12* 154282701 A B C Screw,ss impeller
13 154246801 A B C Gasket-sump
14 154365901 A B C Housing-sump
15 154246701 A B C Check valve
16 154246502 A B C Retainer,sump
24 154250801 A B C Spray arm-lower
24A 154313601 A B C Spray arm-center
24A* 154252001 A B C Nut-spray arm
32 154251701 A B C Tube-delivery
32A 154358901 A B C Gasket-delivery tube
34 154064901 A B C Washer-insulating
40 154348401 A B C Clamp,red ,pump
40 154348501 A B C Clamp,silver ,pump
40* 154106801 A B C Clamp-hose,(2)
54 154234401 A B C Hose-connector
55 154325701 A B C Bracket-motor
55* 5303316032 A B C Screw,truss ss ,8 .625
55A 154246201 A B C Bracket-motor,front
57 154246001 A B C Barrel,front
57* 154246101 A B C Barrel,rear
58 154246402 A B C Check ball
59 154246901 A B C O-ring,rear
59A 154247001 A B C O-ring,front
60 154247502 A B C Drain Pump Assy
60* 154234501 A B C Bracket-motor,drain
61 154359601 A B C Nozzle,3rd level ,spray arm
62 154294101 A B C Support-spray arm
63 154252201 A B C Base-soil director
64 154252301 A B C Filter-soil director
65 154283004 A B C Filter Assy
66 154252701 A B C Trap-glass
67 154246601 A B C Hose-drain,shunt
70 # 154291504 A B C Motor & Pump Assy,includes#7,#12 ,
#55A,#57,#59,,#59A
71 154366101 A B C Sensor,turbidity
71* 154376001 A B C O-ring,turbidity
* 154338601 A B C Clamp-P,nylon
MOTOR & PUMP

05/00 10
Publication No. GLDB958J
5995337671
FRAME

# = Fast Moving Part 11 05/00
* = Non-Illustrated Part
GLDB958J Publication No.
5995337671
FRAME
A = GLDB958J (GLDB958JB0)
B = GLDB958J (GLDB958JS0)
C = GLDB958J (GLDB958JT0)
POS. NO PART NO DESCRIPTION
3 # 154359801 A B C Valve-water
4 154208701 A B C Brace-front
8 154322903 A B C Toeplate-adjustable
9 154370703 A B C Kickplate/Baffle Assy,black
9* 154249301 A B C Insulation,kickplate
10 5300808658 A B C Screw,#8A x .375"
11 154200601 A B C Screw-#10-16 x 3/8
15 154210901 A B C Screw-leveling
20 154209601 A B C Cover-junction box
49 154227401 A B C Guard-motor
* 154321801 A B C Baffle-sound
* 154290001 A B C Insulation-baffle,side
* 154290101 A B C Guard-wire,baffle

05/00 12
