Frigidaire FFC15C4CW0 User manual

CHEST FREEZER
Model number:
FFC15C4CW0
©2003 Electrolux Home Products, Inc.
All rights reserved
FACTORY PARTS CATALOG
FREEZER
WIRING DIAGRAM - # 216908200, SERVICE DATA - # 216908200
OWNER’S GUIDE - # 216802800
ENERGY GUIDE - # 216794209
PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FFC15C4CW0 FFC15C4CW 134A white 115
MARKET
North America
Publication No.
5995391983
030618
EN/SERVICE /MLR
365
ELECTROLUX HOME PRODUCTS, INC.
P.O BOX 212378, AUGUSTA , GA 30917

06/03 2
Publication No FFC15C4CW0
5995391983
5
2
47
27
34
16
15
9
1
10
11
P08D0365
40
40
18
57
14
DOOR

# = Fast-moving Parts 3 06/03
* = Non-Illustrated Parts
FFC15C4CW0 Publication No.
5995391983
DOOR
POS. NO PART NO DESCRIPTION
1 216481201 Gasket-door,white
2 5303925107 Lock Assy
5 # 216702900 Key,lock
9 216829104 Panel-lid
10 216141101 Plug button,white
11 216129937 Panel-outer lid,white
14 216822900 Switch,light/lamp ,ramp
15 216846400 Light Bulb/Lamp
16 216817600 Socket,light/lamp ,25 W
18 216897600 Handle,white
27 5303212828 Clip,panel mtg
34 5303296969 Shield,lid lamp
40 5309948647 Fastener,handle
47 # 216898800 Harness-lid
57 216899503 Overlay,white
* 5303917276 Insulation-door,fiberglass ,(bulk)

06/03 4
Publication No FFC15C4CW0
5995391983
CABINET

# = Fast-moving Parts 5 06/03
* = Non-Illustrated Parts
FFC15C4CW0 Publication No.
5995391983
POS. NO PART NO DESCRIPTION
1 216909800 Catch-lock,white
1A 216818900 Support,lock catch clip
3 216502600 Plug,drain ,interior
4 216073905 Plug-drain,exterior
6 216111000 Breaker,Plain ,white
7 216111600 Breaker,lock side
11 216110800 Breaker,chest end ,(2)
18 216707200 Knob,temp control
21 # 216714601 Control temperature
27 216629600 Screw,hex washer head ,10-16 x 0.500, tapping
28 216035200 Hinge
30 216110700 Breaker,corners
59 216867300 Basket,upper ,(2)
62A 131420300 Screw,cr truss head ,8-18AB x 0.750
75 216034301 Panel,access ,white
* 216794209 Energy Guide
* 5303305324 Paint,touch-up ,white
CABINET

06/03 6
Publication No FFC15C4CW0
5995391983
SYSTEM

# = Fast-moving Parts 7 06/03
* = Non-Illustrated Parts
FFC15C4CW0 Publication No.
5995391983
SYSTEM
POS. NO PART NO DESCRIPTION
1 5303925238 Condenser
4 216634500 Drier-filter
5 # 216906200 Harness-main
22 216056400 Clip,compressor mtg ,SPRING
27 5308002681 Grommet,compressor
28 5303212615 Support,compressor
29 # 216888100 Compressor,w/o electricals
30 216596800 Starter,relay
31 # 216100106 Overload Protector
42 216232700 Washer,flat ,1"OD x 0.531"ID
43 5303212614 Clip,harness mount
47 216629600 Screw,hex washer head ,10-16 x 0.500, tapping
53 216347800 Cover terminal,cover-comp term
86 216036600 Screw,ph washer head ,8-32CA x 0.500, thread forming
