Frigidaire FFC15C8BB0 User manual

FREEZER
Model numbers:
FFC15C8BB0
©2002 Electrolux Home Products, Inc
All rights reserved
FACTORY PARTS CATALOG
FREEZER
WIRING DIAGRAM - 216803900
OWNER’S GUIDE - 216802800
SERVICE DATA SHEET - 216803900
PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FFC15C8BB0 FFC15C8BB 134A black 115
MARKET ENERGY GUIDE
North America 216794206
Publication No.
5995375580
020710
-EN/SERVICE /GHS
365
ELECTROLUX HOME PRODUCTS, INC.
P.O BOX 212378, AUGUSTA , GA 30917

07/02 2
Publication No FFC15C8BB0
5995375580
DOOR

# = Fast-moving Parts 3 07/02
* = Non-Illustrated Parts
FFC15C8BB0 Publication No.
5995375580
DOOR
POS. NO PART NO DESCRIPTION
1 216481204 Gasket,black ,door
2 5303925107 Lock Assy
5 # 216702900 Key,lock
9 216829104 Panel-lid
10 216141100 Plug-foam hole,black
11 216129929 Lid,black
14 216822900 Light/Lamp,ramp
15 216846400 Light Bulb/Lamp
16 216817600 Light/Lamp,indicator
18 216853301 Handle
23 216205300 Light-signal
27 5303212828 Clip,panel
34 216160400 Shield-light
35 216205400 Washer,signal light
44 216823300 Switch-rocker
47 216792700 Harness-lid/defrost
53 # 5303208483 Buzzer,alarm
55 216140206 Handle,recessed ,black
56 216164002 Housing-switch
57 216873500 Overlay,decorative
62 131420300 Screw,cr truss head ,8-18AB x 0.750
93 5303161215 Screw
* 5303925098 Insulation

07/02 4
Publication No FFC15C8BB0
5995375580
CABINET

# = Fast-moving Parts 5 07/02
* = Non-Illustrated Parts
FFC15C8BB0 Publication No.
5995375580
POS. NO PART NO DESCRIPTION
1 216873900 Latch-door
1A 216818900 support-lock
3 216502600 Plug-drain,interior ,interior
4 216073906 Plug-drain,exterior
6 216111005 Breaker,hinge side
7 216111605 Breaker,lock side
11 216110805 Breaker,black ,ends
18 216873600 Knob-control
21 # 216714600 Control-temperature
27 216629600 Screw-hinge
28 216035202 Hinge
30 216110705 Breaker,black ,corners
59 216080300 Basket
71 5303302714 Screw,8-18x3/4 ,(2)
75 216034303 Panel-access,black
* 216802800 Owners guide
CABINET

07/02 6
Publication No FFC15C8BB0
5995375580
SYSTEM

FFC15C8BB0 Publication No.
5995375580
# = Fast-moving Parts 7 05/02
* = Non-Illustrated Parts
SYSTEM
POS. NO PART NO DESCRIPTION
1 5303925238 Condenser
4 216634500 Drier-filter
5 # 216808200 Harness-main
22 216056400 Clip-spring mtg
27 5308002681 Grommet,compressor
28 5303212615 Support-compressor
29 # 216784300 Compressor,w/o electricals
30 216649313 Controller
32 216649200 Clip,controller
42 216232700 Washer-flat
47 216629600 Screw-hinge
55 # 216787800 Capacitor-run
85 216533500 Wire,ground
86 216036600 Screw,rwhd (gx-ca) ,8-32 x 1/2
* 5303212614 Clip-harness
