Frigidaire FFC25C8CW0 User manual

CHEST FREEZER
Model number:
FFC25C8CW0
©2003 Electrolux Home Products, Inc.
All rights reserved
FACTORY PARTS CATALOG
FREEZER
WIRING DIAGRAM - # 216901200
OWNER’S GUIDE - # 216802800 / ENERGY GUIDE - # 216794606
SERVICE DATA SHEET - # 216901200
PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FFC25C8CW0 FFC25C8CW 134A white 115
MARKET
North America
Publication No.
5995390290
030508
-EN/SERVICE /MLR
365
ELECTROLUX HOME PRODUCTS, INC.
P.O BOX 212378, AUGUSTA , GA 30917

05/03 2
Publication No FFC25C8CW0
5995390290
DOOR

# = Fast-moving Parts 3 05/03
* = Non-Illustrated Parts
FFC25C8CW0 Publication No.
5995390290
DOOR
POS. NO PART NO DESCRIPTION
1 216469301 Gasket-door,white
2 5303925107 Lock Assy
5 # 216702900 Key,lock
9 216912900 Panel-lid,white
10 216141101 Plug button,white
11 216032422 Lid,white
14 216822900 Switch,light/lamp ,ramp
15 216846400 Light Bulb/Lamp
16 216817600 Socket,light/lamp ,25 W
18 216897600 Handle,white
27 5303212828 Clip,panel mtg
34 216578502 Shield,light
40 5309948647 Fastener,handle
47 # 216889600 Harness-lid
57 216899500 Overlay,white
79 # 216898700 Control Board,electronic
* 216905300 Screw,control board ,#3-24 x .25
* 5303925098 Insulation

05/03 4
Publication No FFC25C8CW0
5995390290
CABINET

# = Fast-moving Parts 5 05/03
* = Non-Illustrated Parts
FFC25C8CW0 Publication No.
5995390290
POS. NO PART NO DESCRIPTION
1 216909800 Catch-lock,white
1A 216818900 Support,lock catch clip
3 216502600 Plug,drain ,interior
6 216111400 Breaker-hinge side,white
7 216112000 Breaker-lock side,white
11 216110800 Breaker,chest end ,(2)
18 216707200 Knob,temp control
21 # 216844500 Control-temperature
27 216629600 Screw,hex washer head ,10-16 x 0.500 ,tapping
28 216035400 Hinge
30 216110700 Breaker,corners
59 216867300 Basket,upper ,(2)
59A 216867400 Basket,lower ,(2)
62A 131420300 Screw,cr truss head ,8-18AB x 0.750
73 216128200 Divider/drain pan
74 216486700 Support,divider ,(4)
75 216034301 Panel,access ,white
93 5303161215 Screw,ph truss head ,8-18AB x 0.500
100 216205100 Track,basket
* 216794606 Energy Guide
* 5303305324 Paint,touch-up ,white
CABINET

05/03 6
Publication No FFC25C8CW0
5995390290
SYSTEM

# = Fast-moving Parts 7 05/03
* = Non-Illustrated Parts
FFC25C8CW0 Publication No.
5995390290
SYSTEM
POS. NO PART NO DESCRIPTION
1 # 5303925320 Condenser
4 216634500 Drier-filter
5 # 216890300 Harness-main
5 * 216890200 Harness,low voltage- ,w/thermistor
22 216056400 Clip,compressor mtg ,SPRING
27 5308002681 Grommet,compressor
28 5303212615 Support,compressor
29 # 216784700 Compressor,w/o electricals
30 216649300 Controller-regulator LP
32 216649100 Clamp,elec cont mtg ,compressor
42 216232700 Washer,flat ,1"OD x 0.531"ID
43A 5303212614 Clip,harness mount
47 216629600 Screw,hex washer head ,10-16 x 0.500 ,tapping
55 # 218909901 Capacitor,run ,50/60 Hz ,220 VAC ,15 microfarad
78 216893100 Assy-High Voltage
86 216036600 Screw,ph washer head ,8-32CA x 0.500 ,thread forming
* 5303298960 Spacer-tube,0.237" ID
