Frigidaire CPLMZ169GCC User manual

Installation
Instructions Overthe Range MicrowaveOven
BEFORE YOU BEGIN Read these instructions completely and carefully.
•IMPC RTANT- Savethese instructions for local
inspector's use.
•IMPORTANT- Observe all governing codes
and coordinates.
• Note to Installer- Be suretoleave these
instructions with the Consumer.
• Note to Consumer- Keep these instruc-
tions for future reference.
• Skill Level - Installation of this appliance
requires basic mechanical and electrical skills.
Proper installation is the responsibility of the installer.
Product failure due to improper installation is not cov-
ered under the Warranty.
Please read all instructions thoroughly before installing
the Over the Range Microwave Oven. Two people are
recommended to install this product.
If a new electrical outlet is required, its installation
should be completed by a qualified electrician before the
Microwave Oven is installed. See 3 ELECTRICAL
GROUNDING INSTRUCTIONS on page 2.
1MOUNTING SPACE
This Microwave Oven/Hood requires a mounting space on a
wall as shown in Figure 1. It is designed to be used with stan-
dard 12-inch wall cabinets.
l
Atleast2"
Backsplash.._,_<_ _ _,.
30"or morefrom
surface
66"or more
fromfloor
Figure 1
2 WALL CONSTRUCTION
This Microwave Oven/Hood should be mounted against and
supported by a flat vertical wall. The wall must be flat for prop-
er installation. If the wall is not flat, use spacers to fill in the
gaps. Wall construction should be a minimum of 2" x 4" wood
studding and 3/8" or more thick dry wall or plaster/lath. The
mounting surfaces must be capable of supporting weight of 110
pounds--the oven and contents--AND the weight of all items
which would normally be stored in the top cabinet above the
unit.
The unit should be attached to a minimum of one 2" x 4"
wall stud or two 2" x 3" wall studs.
To find the location of the studs, one of the following methods
may be used:
A. Use a stud finder, a magnetic device which locates the nails
in the stud.
B. Use a hammer to tap lightly across the mounting surface to
find a solid sound. This will indicate stud location.
The center of the stud can be located by probing the wall with a
small nail to find the edges of the stud and then placing a mark
halfway between the edges. The center of any adjacent studs
will normally be 16" or 24" to either side of this mark.
NEED HELP?
For customers in the United States, call: 1-800-944-9044
For customers in Canada, call: 1-800-213-9397 (English)
1-800-668-4606 ext.8199 (French)
READ CAREFULLY. KEEP THESE INSTRUCTIONS.
1 p/n316137234
TINSEB385MRR0

Installation Instructions
3 ELECTRICAL GROUNDING
INSTRUCTIONS
This appliance must be grounded. This oven is equipped with a
cord having a grounding wire with a grounding plug. It must be
plugged into a wall receptacle that is properly installed and
grounded in accordance with the National Electrical Code and
local codes and ordinances. In the event of an electrical short
circuit, grounding reduces risk of electric shock by providing an
escape wire for the electric current.
WARNING - Improper use of the grounding plug can result in a
risk of electric shock.
ELECTRICAL REQUIREMENTS
The oven is equipped with a 3-prong grounding plug. DO NOT
UNDER ANY CIRCUMSTANCES CUT OR REMOVE THE
GROUNDING PIN FROM THE PLUG.
The Power Supply Cord and plug must be connected to a sep-
arate 120 Volt AC, 60 Hz, 15 Amp, or more branch circuit, sin-
gle grounded receptacle. The receptacle should be located
inside the cabinet directly above the Microwave Oven mounting
location as shown in Figure 2.
NOTE:
1. If you have any questions about the grounding or electrical
instructions, consult a qualified electrician or serviceperson.
2. Neither Electrolux nor the dealer can accept any liability for
damage to the oven or personal injury resulting from failure
to observe the correct electrical connection procedures.
Ground
Receptacle 1_
Openingfor
PowerCord
Figure 2
4 HOOD EXHAUST DUCT
When the hood is vented to the outside, a hood exhaust duct is
required. All ductwork must be metal; absolutely do not use
plastic duct. Check that all connections are made securely.
Please read the following carefully:
Exhaust connection: The hood exhaust has been designed to
connect to a standard 3-1/4" X 10" rectangular duct. If round
duct is required, a rectangular-to-round adapter must be used.
Rear exhaust: If a rear or horizontal exhaust is to be used, care
should be taken to align the exhaust with the space between the
studs, or wall should be prepared at the time it is constructed by
leaving enough space between wall studs to accommodate
exhaust.
Maximum duct length: For satisfactory air movement, the total
duct length of 3-1/4" X 10" rectangular or 6" diameter round duct
should not exceed 140 feet.
Elbows, adapters, wall caps, roof caps, etc. present additional
resistance to air flow and are equivalent to a section of straight
duct which is longer than their actual physical size. When calcu-
lating the total length, add the equivalent lengths of all transi-
tions and adapters plus the length of all straight duct sections.
Figure 3 shows the approximate feet of equivalent length of
some typical ductwork parts. Use the values in parentheses for
calculating air flow resistance equivalent, which should total
less than 140 feet.
90" ELBOW (10 FT.)
90" ELBOW (25 FT.)
45° ELBOW (5 FT.)
45_ ELBOW (5 FT.)
ADAPTOR (5 FT.)
WALL CAP (40 FT.)
10"WIDE ELBOW{10 FT.)
ROOF GAP (24 FT,)
Figure 3

Installation Instructions
5 TOOLS RECOMMENDED FOR
INSTALLATION
•Phillips Screwdriver
• Electric Drill
• 1/2", 5/8" and 3/32" Drill Bits
• 1-1/2" Wood Bit or Metal Hole Cutter
(if metal cabinet is used)
• Saw to cut exhaust opening (if needed)
• Protective Drop Cloth for product and range -
you may also use carton for protection
• Scissors
• Pencil
• Measure
• Tape
6 INSTALLATION HARDWARE
The INSTALLATION HARDWARE (items _1_ - (_) packed with
the oven should contain the following:
Item Name Quantity
@Wood Screw 5 X 30 mm 6
® Toggle Bolt 3/16 inch 4
(_ Top Cabinet Screw 5 X 60 mm 2
@Flat Washer 30 mm diameter 2
Power Cord Hanger 1
Grommet 1
(_ Tapping Screw 4 x 12 mm 4
(_ Exhaust Damper Assembly 1
(_ Charcoal Filter 1
Sr_ruln_%_ tin rlr_n_%_ tin ru_/_oL_ _
_/ Use with metal cabinets. Surround (_ _
epowercordopening.Cuttofit.
® ®
Figure4
Parts shown not to common scale.
7PREPARATION OF THE OVEN
1. Open the bottom of the carton, bend the carton flaps back
and tilt the oven over to rest on plastic foam pad. Lift carton
off oven and remove all packing materials, Installation
Instructions, Wall Template, Top Template, Charcoal Filter,
Turntable and Turntable Support; however, DO NOT
REMOVE THE WAVEGUIDE COVER, which is located on
the ceiling in the oven cavity. SAVE THE CARTON AS IT
MAY MAKE INSTALLATION EASIER.
2. CHECK THE OVEN.
Check the oven for any damage, such as misaligned or bent
door, damaged door seals and sealing surfaces, broken or
loose door hinges and latches and dents inside the cavity or
on the door. If there is any damage, do not operate the oven
and contact your dealer or ELECTROLUX AUTHORIZED
SERVICER.
3. Remove and save Screws (A) as shown in Figure 5.
4. Pull the louver away from the unit and set aside.
5. Loosen the two Mounting Screws (D) which secure the
Mounting Plate to the rear side of the oven. Remove the
Mounting Plate. See Figure 6.
j (A)
Mounting
Plate
Control
Side
Figure 5
MountingPlate
f
(D) J
Figure 6

Installation Instructions
8 VENTILATION SYSTEM
(PREPARING OVEN FOR INSTALLATION)
This Microwave Oven/Hood is designed for adaptation to three
types of hood ventilation systems. Select the type required for
your installation.
Recirculating -- non-vented, ductless. Follow installation
procedure (A). Recirculating requires the use of the Charcoal
Filter, which has been installed in the oven.
Horizontal Exhaust -- outside ventilation.
Follow installation procedure (B).
Vertical Exhaust -- outside ventilation.
Follow installation procedure (C).
(A) RECIRCULATING: Non-Vented, Ductless Operation
1. The unit is shipped assembled for recirculating.
2. The Exhaust Damper Assembly is not required for recirculat-
ing exhaust.
3. Charcoal Filter, included with the unit, is required for recircu-
lating exhaust. Attach the Charcoal Filter to the upper side of
the oven by sliding into the tabs. See Figure 7. The Charcoal
Filter should be replaced every 6 to 12 months, depending
on use.
Figure 7
(B) HORIZONTAL EXHAUST: OUTSIDE VENTILATION
1. Remove and save 2 screws from back edge and 1 screw
from the top center of Fan Cover Bracket. Remove Fan
Cover Bracket by sliding it in the opposite direction of the
arrow on the Fan Cover Bracket, as shown in Figure 8.
2. Withdraw Hood Fan Unit carefully and slip wires out of Wire
Box. See Figure 9.
CAUTION: Do not pull or stretch hood fan wiring.
3. Rotate the Hood Fan Unit and turn end-over-end so that the
fan blade openings are facing the back of the oven. Replace
Hood Fan Unit into the oven. Be careful not to pinch the lead
wire between the inner bracket and the Hood Fan Unit. See
Figure 10.
4. Put the lead wire into Wire Box. See Figure 11.
5. Replace the Fan Cover Bracket by sliding it into the slits in
the same direction as the arrow on the Fan Cover Bracket.
Make sure the fan blades are visible through the rear open-
ings in the oven before proceeding. Attach Fan Cover
Bracket to unit with 3 screws, which were removed in Step 1
above. See Figure 11. The Hood Fan Unit is now rotated for
horizontal exhaust operation.
6. Attach the Exhaust Damper Assembly to the back of the
Mounting Plate by sliding it into the slits in the same direction
as the arrow. See Figure 12. Use Tapping Screw 4 X 12 from
the INSTALLATION HARDWARE and tighten into place.
FanCoverBracket
/
Figure 8
Figure 9
Figure 10
4

Installation Instructions
ExhaustDamper
Figure 11 t
__Mounting Plate
(BackSide)
Figure 12
8 VENTILATION SYSTEM
(PREPARING OVEN FOR INSTALLATION) cont.
(C) VERTICAL EXHAUST: OUTSIDE VENTILATION
1. Remove and save 2 screws from back edge and 1 screw
from the top center of the Fan Cover Bracket. Remove Fan
Cover Bracket by sliding it in the opposite direction of the
arrow on the Fan Cover Bracket as shown in Figure 8.
2. Withdraw Hood Fan Unit carefully and slip wires out of Wire
Box. See Figure 9.
CAUTION: Do not pull or stretch hood fan wiring.
3. Turn the Hood Fan Unit end-over-end. Rotate the Hood Fan
Unit 90° so that the fan blade openings are facing upward.
Replace Hood Fan Unit into the oven. Be careful not to pinch
the lead wire between the inner bracket and the Hood Fan
Unit. See Figure 13.
4. Put the lead wire into Wire Box. See Figure 13.
5. Replace the Fan Cover Bracket by sliding it into the slits in
the same direction as the arrow on the Fan Cover Bracket.
Make sure the fan blades are visible through the top open-
ings in the oven before proceeding. Attach the Fan Cover
Bracket to unit with 3 screws, which were removed in Step 1
above. See Figure 11. The Hood Fan Unit is now rotated for
vertical exhaust operation.
6. Attach the Exhaust Damper Assembly to the fan cover on the
top of the outercase cabinet after mounting the oven. To
attach the Exhaust Damper Assembly, refer to MOUNTING
OVEN TO THE WALL, page 6.
Rotate90°
Figure 13
9 OVEN INSTALLATION
THIS OVEN CANNOT BE PROPERLY INSTALLED WITHOUT
REFERRING TO THE MOUNTING INSTRUCTIONS FOUND
ON BOTH TEMPLATES.
THE NEXT STEP IS TO READ AND FOLLOW MOUNTING
INFORMATION ON BOTH TOP CABINET AND WALL TEM-
PLATES.
NOTE: THIS OVEN SHOULD BE ATTACHED TO AT LEAST
ONE WALL STUD.
MOUNTING PLATE
1. Separate 4 Toggle Bolts, packed in the INSTALLATION
HARDWARE, from the Toggle Nuts.
2. Use wood screws to attach mounting plate to the stud or
studs. Use Toggle Bolts to attach mounting plate through the
holes at A, B, C and D UNLESS THOSE HOLES ARE
LOCATED ON THE STUD. Insert one Toggle Bolt into A, B,
C and D where appropriate (these correspond to holes of the
Wall Template) and put the Toggle Nuts onto the Toggle
Bolts. Figure 14.
Refer to instructions in Wall Template.
3. Position the Mounting Plate with the Toggle Bolts attached at
the wall location and insert Toggle Nuts and Bolts through
the holes in the wall with the Toggle Nuts closed. Figure 15.
Use Wood Screws to attach the Mounting Plate to studs.
NOTE: Before insertion, be sure you leave a space more
than the thickness of the wall between the Mounting Plate
and the end of each of the Toggle Nuts (in the closed posi-
tion). If you do not leave enough space, the Toggle Nut will
not be able to open on the other side of the wall. Also, once
a Toggle Nut opens, it cannot be withdrawn from the hole;
therefore make sure all of the Toggles are in the correct posi-
tion before insertion.
4. Align the Mounting Plate carefully and hold in position while
tightening Toggle Bolts. Pull Toggle Bolt toward you and turn
clockwise to tighten. Figure 16.

Installation Instructions
9 OVEN INSTALLATION cont.
ToggleNut _--_j/.,I _,_01t
MountingPlate ,)l)
Figure 14
Spacemore
thanwall
thickness
Wall
Figure 15
Figure 16
MOUNTING OVEN TO THE WALL
Two people are recommended to attach the Microwave
Oven/Hood to the Mounting Plate.
1. Thread the power supply cord through the hole made in the
bottom of the top cabinet.
2. Install the oven by sliding it onto the arms of the Mounting
Plate. Push it all the way to the wall. See Figure 17.
3. Tighten two Mounting Screws (D) located in the oven face-
plate. See Figure 17.
4. Attach louver with screws (A) and tighten (removed in
Section 7 on page 3). See Figure 18.
5. Use the two Top Cabinet Screws and two Flat Washers, sup-
plied in the INSTALLATION HARDWARE, to attach the unit
to the top cabinet. See Figure 19.
6. (For Vertical Exhaust Only)
Attach the Exhaust Damper Assembly to the fan cover on the
top of the outercase cabinet by sliding it into the slits in the
same direction as the arrow. Use Tapping Screw 4 X12 mm
from the INSTALLATION HARDWARE and tighten into
place. See Figure 19.
7. Make a bundle of the power supply cord and attach it to the
inside of the cabinet using the Power Cord Hanger. See
Figure 19.
Figure 17
Figure 18
Figure 19

Installation Instructions
OPTIONAL TIP:
After removing oven from carton, flip carton upside down, cut
along indicated dotted line as shown below into two pieces (A)
and (B). See Figure 20. This will assist in positioning the oven
before placing oven on the Mounting Plate. See Figure 21.
/_\ //
\/
TopSide CuttingLine
(A)
(B)
Figure 20
(a)
Figure 21
CHECKLIST FOR INSTALLATION
1. Make sure the unit has been installed according to all of
the Installation Instructions and the Wall and Top Cabinet
Templates.
2. Plug in the power cord.
3. Keep the Operation Manual.

Installation Instruction Notes
