Frigidaire FMV156E Instruction Manual

FMV156D.tif FMV156EMA Cabinet.eps FMV156D Controls.eps FMV156EMA
wiring schematic.eps
Product No. FMV156EMA
Market North America
Color silver
Volts 120
Watts 950
Wiring Diagram 5995457826
Owner's Guide TINSEB445MRR0
Installation Instructions 316137333
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995457826
06/01/10
(EN/SERVICE/KC)
099
OVER-RANGE
MICROWAVE
Model No.
FMV156E
Copyright ©2006 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995457826 FMV156EMA
01/06 2
OVEN,CABINET

FMV156EMA Publication No: 5995457826
# Functional Parts 3 01/06
* Non-Illustrated Parts
OVEN,CABINET
POS. NO PART NO. DESCRIPTION
1 # 5304441844 Rectifier, high voltage
2 # 5304440342 Capacitor, high voltage
3 # 5304448488 Motor, turntable
4 # 5304440032 Thermal Cutout, oven cavity
5 # 5304440023 Thermal Cutout, hood
6 # 5304453726 Transformer, power
7 # 5304441846 Magnetron
8 # 5304440026 Switch, interlock, door sensor
9 # 5303319559 Switch, monitor, with CT fuse
10 # 5304440028 Power Cord, electric
11 # 5303319561 Receptacle, lamp socket, oven
12 # 5304441847 Motor, hood fan
13 # 5304441848 Motor, cooling fan
14 5304440031 Lamp, incandescent, 20 W, (3)
15 5304441849 Plate, rear stay
16 5304453717 Grille, exhaust louver, silver
17 5304441853 Base, transformer mtg, right side
18 5304453718 Panel, front trim, silver, LS
19 5304441858 Cabinet, outer casing, black
20 5304451814 Wiring Diagram, schematic, label
21 5303319573 Lens/Frame Assy, lamp
22 5304451815 Cover, unit base, black
30 5304440284 Support Assy, turntable
31 5304441872 Tray, turntable, glass
32 5304441873 Retainer, capacitor strap
33 5304441874 Duct, magnetron
34 # 5304451818 Filter, noise, electronic
35 5303322975 Bracket, noise filter, angle
36 5304440288 Bushing, motor shaft, turntable
37 5304440289 Latch Hook
38 5304441833 Bracket, unit mtg plate, rear
39 # 5304440843 Fan Blade, cooling fan
40 5303319605 Bushing, power cord
41 5304441875 Lever, unit mounting, release
42 5304441876 Duct, hood intake, right side
43 5304440845 Cover, waveguide
44 5304440316 Spring, door latch
45 5304441877 Support, chassis
46 5304441878 Duct, hood intake, right side
47 5304441879 Duct, exhaust hood, left side
48 5304451819 Duct, cooling fan
49 5304441881 Ring, fan orifice
50 5304441882 Cushion, transformer pad
74 5304441900 Label, Caution-DHHS
75 5304440334 Label, Caution-monitor
76 5304440333 Label, Caution-DHHS
77 5304441901 Filter, inside exhaust, charcoal
78 5303319568 Filter, grease, (2)
79 5304440283 Damper Assy, exhaust
80 5303319640 Screw, vent grille, black
81 5304451553 Screw, 4 mm x 12 mm
82 5304453725 Screw, 3mm x 8mm
83 5304450253 Screw, 4 mm x 8 mm
84 5303319641 Screw
85 5303319636 Screw
86 # 5303319550 Fuse, magnetron

Publication No: 5995457826 FMV156EMA
01/06 4
CONTROL PANEL,DOOR,MISC.

FMV156EMA Publication No: 5995457826
# Functional Parts 5 01/06
* Non-Illustrated Parts
CONTROL PANEL,DOOR,MISC.
POS. NO PART NO. DESCRIPTION
23 # 5304441863 Control Board, printed circuit
24 5304453719 Frame, control panel, silver
25 # 5304441868 Switch, touch pad, black
26 5304440281 Panel, control mount
27 5303319584 Screw, control panel, 3mm x 10mm
28 5304440282 Screw, control board, 3mm x 10mm
29 5304441871 Door Stop
51 5304453720 Door Assy, silver, w/handle
52 5304441887 Panel, inner door, black
53 5304453721 Frame, outer door, silver
54 5304440314 Latch, door
55 5304440316 Spring, door latch
56 5304441894 Frame, choke cover, inner door
57 5304440860 Seal, door, film
58 5304440323 Handle, door, black
59 5303319634 Screw, 4mm x 8mm
60 5304441895 Screw
61 5304441832 Hardware, installation, kit
62 5303318761 Sleeve, power cord, grommet
63 5303318762 Screw, toggle
64 5303322979 Hook, screw-in, cord holder
65 5304453722 Screw, 5mm x 60mm
66 5304451553 Screw, 4 mm x 12 mm
67 5304453723 Screw, 5mm x 35mm
68 5304453724 Washer
69 5304441896 Bracket, scale plate
71 5304441897 Template, installation, top
72 # 5304441898 Wire, high voltage-A
73 # 5304451820 Wiring Harness, main

Publication No: 5995457826 FMV156EMA
01/06 6
WIRING SCHEMATIC
