FPEC3085K S 30" Electric
Signature Features
Over-The-Range
Product Dimensions
Height 16-13/32"
Width 29-7/8"
Depth 15-1/32"
More Easy-To-Use Features
Two-Speed Ventilation
Over-the-range microwave doubles
as a hood with two fan speeds.
Extra-Large 13-1/2" Diameter
Glass Turntable
10 Cooking Power Levels
Auto-Reheat Options
Control Lock Option
Multiple-Stage Cooking Option
Electronic Clock & Timer
Vent Filters
Dishwasher-safe.
Auto-Start Heat Sensor Vent Fan
Ductless Vent Installation
Option Included
Attractive Stainless Steel Exterior1
Available in:
1Select models only.
Eortless™ Reheat
Reheat almost anything with the touch
of a button.
Ready-Select™ Controls
Easily select options with the touch
of a button.
Fits-More™ Capacity
Extra-large microwave provides 1.6 Cu. Ft.
of cooking space and will hold almost
any dish — even a 13" x 9" baking dish.
One-Touch Options
Our microwaves feature easy-to-use
one-touch buttons so you can cook
baked potatoes, popcorn, or even add
30 seconds with the touch of a button.
Microwaves
FFMV162L S / M / W/ B /Q
Stainless
(S)
Bisque
(Q)
Black
(B)
White
(W)
SilverMist™
(M)

Specifications
subject to change.
Features
Oven Cavity (Cu. Ft.)
Watts (IEC-705 Test Procedure)
Power Levels
Electronic Clock & Timer
Digital Cooking Display
Touch Pad Controls (# Pads)
Auto Reheat Options
Time Cooking
Add-Thirty Seconds
Control Lock Option
Glass Turntable (Diameter)
Cooktop Light
Ventilation System
Hood Fan
Ducted / Ductless
Vent Installation
Exhaust Fan (CFM)
Charcoal / Grease Filter
(Ductless Installation)
Power Ratings
Frequency (Mhz)
Watts @ 120 Volts
Amps @ 120 Volts
Optional Accessories
36" Filler Panel Kit (Stainless Steel)
36" Filler Panel Kit (White)
36" Filler Panel Kit (Black)
Specifications
Oven Interior ( H x W x D )
Power Supply Connection Location
Voltage Rating
Connected Load
(kW Rating) @ 120 Volts1
Shipping Weight (Approx.)
Product Dimensions
A - Height
B - Width
C - Depth
16-13/32"
29-7/8"
15-1/32"
1.6
1000
10
Yes
4 Digit
23
Yes
2 Stage
Yes
Yes
13-1/2"
Yes
Yes
Yes
2 Speed
300 / 170
Yes
2450
1550
13
PN # MWFILKTSS
PN # MWFILKTWH
PN # MWFILKTBK
9-1/4" x 20-1/4" x 14-13/32"
Right Top Rear
120V / 60Hz / 15A
1.55
70 Lbs.
NOTE: Always consult local and national electric codes. Refer to Product Installation
Guide for detailed installation instructions on the web at frigidaire.com.
Over-the-Range Microwave Oven
Frigidaire Baseline
B
A
C
USA
•
250 Bobby Jones Expressway
•
Martinez, GA 30907
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
FFMV162L 03/10 © 2010 Electrolux Home Products, Inc. Printed in the U.S.A.
Microwaves
FFMV162L S / M / W/ B /Q Over-The-Range
Cutout Dimensions
Height (Min.)
Height (Max.)
Width
Depth (Min.)
Depth (Max.)
16-3/4"
17"
30"
12"
14"
1For use on adequately wired 120V, dedicated circuit having 2-wire
service with a separate ground wire. Appliance must be grounded for
safe operation.
