Drop-In Cooktop
FPEC3085K S 30" Electric
Signature Features
Over-The-Range
Microwave
FFMV164L S
Product Dimensions
Height 16-13/32"
Width 29-7/8"
Depth 15-1/32"
More Easy-To-Use Features
Two-Speed Ventilation
Over-the-range microwave doubles
as a hood with two fan speeds.
Extra-Large 13-1/2" Diameter
Glass Turntable
10 Cooking Power Levels
Auto-Reheat Options
Control Lock Option
Electronic Clock & Timer
Vent Filters
Dishwasher-safe.
Auto-Start Heat Sensor Vent Fan
Ductless Vent Installation
Option Included
Attractive Stainless Steel Exterior
Available in:
Stainless
(S)
Multi-Stage Cooking
Our Multi-Stage Cooking option allows
you to program power levels and
cooking times in advance, so you can
program it to defrost, cook and keep a
meal warm all at once.
Ready-Select™ Controls
Easily select options with the touch
of a button.
Fits-More™ Capacity
Extra-large microwave provides 1.6 Cu. Ft.
of cooking space and will hold almost
any dish — even a 13" x 9" baking dish.
One-Touch Options
Our microwaves feature easy-to-use
one-touch buttons so you can cook
baked potatoes, popcorn, or even add
30 seconds with the touch of a button.

Accessories information available
on the web at frigidaire.com
Specifications
subject to change.
USA
•
10200 David Taylor Drive
•
Charlotte, NC 28262
•
1-800-FRIGIDAIRE
•
frigidaire.com
CANADA
•
5855 Terry Fox Way
•
Mississauga, ON L5V 3E4
•
1-800-265-8352
•
frigidaire.ca
FFMV164L 07/10 © 2010 Electrolux Home Products, Inc. Printed in the U.S.A.
Microwave
FFMV164L S Over-The-Range
Product Dimensions
A - Height
B - Width
C - Depth
16-13/32"
29-7/8"
15-1/32"
Over-the-Range Microwave Oven
Frigidaire Baseline
B
A
C
Cutout Dimensions
Height (Min.)
Height (Max.)
Width (Min.)
Depth (Min.)
Depth (Max.)
16-3/4"
17"
30"
12"
13"
Features
Control / Timing System
Exterior Door Finish
Handle Design
Microwave Capacity (Cu. Ft.)
Convection
Watts (IEC-705 Test Procedure)
Interior Light
Interior Color
Turntable Diameter
Turntable On / O
Control Lock
Clock
Touch Pad Buttons
Power Levels
Accessory Metal Rack
Microwave Control Options
Popcorn Button
Chicken Nugget Button
Baked Potato Button
Sensor Reheat Button
Snack Button
Beverage
Auto Melt / Soften Options
Auto Reheat Options
Snack Menu Options
Auto Cook Options
Auto Defrost Options
Multi-Stage Cooking Option
Keep Warm
Add-30-Seconds
Sensor Cooking Options
Vegetable Cook Sensor
Delay Start
User Preferences
Ventilation System
Ducted / Ductless
Installation Option
Exhaust Fan (CFM)
Cooktop Light
Auto-Start Heat Sensor
Dishwasher-Safe Vent Filter
(Ductless Installation)
Power Ratings
Frequency (Mhz)
Watts @ 120 Volts
Amps @ 120 Volts
Optional Accessories
36" Stainless Steel Trim Kit
36" White Trim Kit
36" Black Trim Kit
Specifications
Oven Interior (HxWxD)
Power Supply Connection Location
Voltage Rating
Connected Load
(kW Rating) @ 120 Volts1
Minimum Circuit Required (Amps)
Shipping Weight (Approx.)
Ready-Select™
Stainless Steel
Stainless Steel
1.6
1,000
Yes
White
13-1/2"
Yes
Yes
23
High (1 – 9)
Yes
Yes
Yes
3
Weight / Time
Yes
Yes
Yes
2-Speed
170 / 300
Yes
Yes
Yes
2,450
1,550
13
PN # MWFILKTSS
PN # MWFILKTWH
PN # MWFILKTBK
9-1/4" x 20-1/4" x 14-13/32"
Right Top Rear
120V / 60Hz / 15A
1.55
15
69
1For use on adequately wired 120V, dedicated circuit having 2-wire
service with a separate ground wire. Appliance must be grounded for
safe operation.
NOTE: For planning purposes only. Always consult local and national electric codes.
Refer to Product Installation Guide for detailed installation instructions on the web at frigidaire.com.
