Frigidaire CFMV145BC User manual

PRODUCT NO. BASE MODEL NO. COLOR MARKET
FMV145BC1 FMV145B stainless steel North America
FMV145KB3 FMV145K black North America
FMV145KS3 FMV145K white North America
CFMV145BC1 CFMV145B stainless steel Canada
CFMV145KB2 CFMV145K black Canada
CFMV145KS2 CFMV145K white Canada
Publication No.
5995380689
021101
-EN/SERVICE /KC
099
MICROWAVE
OVEN
Model No.
FMV145B
FMV145K
CFMV145B
CFMV145K
©2002 Electrolux Home Products, Inc.
All rights reserved
FACTORY
PARTS CATALOG
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
MINI SERVICE MANUAL - # 316137224 = EN
WIRING DIAGRAM - # 316137224 = EN / 5304430484 = FR
OWNER’S GUIDE - # 316137205 = EN / 316137206 = FR
INSTALLATION INSTRUCTIONS -# 316137211 = EN / 316137212 = FR

11/02 2
Publication No. FMV145KB/S3, BC1 & CFMV145KB/S2, BC1
5995380689
DOOR

# = Fast-moving Parts 3 11/02
* = Non-Illustrated Parts
FMV145KB/S3, BC1 & CFMV145KB/S2, BC1 Publication No.
5995380689
A = FMV145K (FMV145KB3)
B = FMV145K (FMV145KS3)
C = FMV145B (FMV145BC1)
D = CFMV145K (CFMV145KB2)
E = CFMV145K (CFMV145KS2)
F = CFMV145B (CFMV145BC1)
POS. NO PART NO DESCRIPTION
2 5304408529 A B - D E - Screen,door ,glass ,front
2 5304430404 - - C - - F Screen,door ,glass ,front
3 5304408523 A - - D - - Handle,door ,black
3 5304408524 - B - - E - Handle,door ,white
3 5304408525 - - C - - F Handle,door ,black
4 5304430269 A - - D - - Frame,door ,black ,outer
4 5304430270 - B - - E - Frame,door ,white ,outer
4 5304429402 - - C - - F Frame,door ,black ,outer
5 5304429405 A B C D E F Spring,door latch
6 5304429406 A - C D - F Pawl,door latch
6 5304429484 - B - - E - Pawl,door latch
7 5304429407 A B C D E F Pin,hinge
9 5304429408 A - C D - F Panel,inner door assy ,black
9 5304429409 - B - - E - Panel,inner door assy ,white
10 5304409136 A B C D E F Seal,door ,film
11 5304430271 A - - D - - Frame,choke cover ,black ,inner door
11 5304430272 - B - - E - Frame,choke cover ,white ,inner door
11 5304429411 - - C - - F Frame,choke cover ,black ,inner door
101 5304430273 A - - D - - Door,black ,complete assy
101 5304430274 - B - - E - Door,white ,complete assy
101 5304430275 - - C - - F Door,stainless steel ,complete assy
DOOR

11/02 4
Publication No. FMV145KB/S3, BC1 & CFMV145KB/S2, BC1
5995380689
CONTROL PANEL

# = Fast-moving Parts 5 11/02
* = Non-Illustrated Parts
FMV145KB/S3, BC1 & CFMV145KB/S2, BC1 Publication No.
5995380689
A = FMV145K (FMV145KB3)
B = FMV145K (FMV145KS3)
C = FMV145B (FMV145BC1)
D = CFMV145K (CFMV145KB2)
E = CFMV145K (CFMV145KS2)
F = CFMV145B (CFMV145BC1)
POS. NO PART NO DESCRIPTION
12 # 5304430276 A B C D E F Control Board,printed circuit
44 5304429422 A B - D E - Wire,PCB ground
44 # 5304430277 - - C - - F Wire,PCB ground
105 5304430278 A - - - - - Control Panel Assy,black ,less PCB
105 5304430279 - B - - - - Control Panel Assy,white ,less PCB
105 5304430280 - - C - - - Control Panel Assy,stainless/black ,less PCB
105 5304430281 - - - D - - Control Panel Assy,black ,less PCB
105 5304430282 - - - - E - Control Panel Assy,white ,less PCB
105 5304430283 - - - - - F Control Panel Assy,stainless/black ,less PCB
CONTROL PANEL

11/02 6
Publication No. FMV145KB/S3, BC1 & CFMV145KB/S2, BC1
5995380689
FUNCTIONAL PARTS

# = Fast-moving Parts 7 11/02
* = Non-Illustrated Parts
FMV145KB/S3, BC1 & CFMV145KB/S2, BC1 Publication No.
5995380689
A = FMV145K (FMV145KB3)
B = FMV145K (FMV145KS3)
C = FMV145B (FMV145BC1)
D = CFMV145K (CFMV145KB2)
E = CFMV145K (CFMV145KS2)
F = CFMV145B (CFMV145BC1)
POS. NO PART NO DESCRIPTION
17 5304429455 A B C D E F Bracket,lamp mtg ,bottom
18 # 5304424251 A B C D E F Receptacle,lamp
19 5304408949 A B C D E F Lamp,incandescent
24 # 5304429456 A B C D E F Wiring Harness,D
26 # 5304408941 A B C D E F Capacitor,motor
27 # 5304417433 A B C D E F Thermostat,thermal cutout ,hood ,40/70 deg C
28 5304429457 A B C D E F Latch Body,switch Housing
29 # 5304430284 A B C D E F Switch,interlock ,door/primary
30 # 5304430285 A B C D E F Switch,interlock ,monitor
31 5304408963 A B C D E F Lever,switch ,bottom
39 5304423381 A B C - - F Support,rack-A
39 5304430405 - - - D E - Support,rack-A
43 # 5304408980 A B C D E F Motor,turntable
45 5304408961 A B C D E F Bracket,air guide
46 # 5304423382 A B C - - - Receptacle,fuse
46 # 5304417434 - - - D E F Filter,noise ,assembly
47 # 5304423383 A B C D E F Fuse,cartridge ,20 Amp
49 # 5304423378 A B C D E F Capacitor,high voltage
50 # 5304417430 A B C D E F Diode,high voltage
51 5304408946 A B C D E F Bracket,capacitor mtg
57 # 5304408947 A B C D E F Power Cord,electric
59 # 5304408943 A B C D E F Fan Assy,ventilator ,with motor
60 # 5304408944 A B C D E F Motor,stirrer fan
61 # 5304423690 A B C D E F Thermostat,thermal cutout ,oven cavity
69 5304408962 A B C D E F Nut,flange
73 # 5304423374 A B C D E F Magnetron
74 # 5304408936 A B C D E F Thermostat,thermal cutout ,magnetron
75 # 5304408933 A B C D E F Transformer,high voltage
76 5304423377 A B C D E F Plate,xfmr base
77 # 5304408935 A B C D E F Thermostat,thermal cutout ,bottom ,120/0 deg C
78 5304423384 A B C D E F End Cap,xfmr base ,bottom
79 # 5304423385 A B C D E F Fan Assy,cooling ,with motor
87 # 5304423386 A B C D E F Wiring Harness,C
88 # 5304429459 A B C - - - Wiring Harness,A
88 # 5304423388 - - - D E - Wiring Harness,A
88 # 5304430286 - - - - - F Wiring Harness,A
89 5304423527 A B C D E F Screw,washer head
90 5304408964 A B C D E F Screw,special
92 5304423390 A B C - - F Support,rack-B
92 5304430406 - - - D E - Support,rack-B
FUNCTIONAL PARTS

11/02 8
Publication No. FMV145KB/S3, BC1 & CFMV145KB/S2, BC1
5995380689
BODY

# = Fast-moving Parts 9 11/02
* = Non-Illustrated Parts
FMV145KB/S3, BC1 & CFMV145KB/S2, BC1 Publication No.
5995380689
BODY
A = FMV145K (FMV145KB3)
B = FMV145K (FMV145KS3)
C = FMV145B (FMV145BC1)
D = CFMV145K (CFMV145KB2)
E = CFMV145K (CFMV145KS2)
F = CFMV145B (CFMV145BC1)
POS. NO PART NO DESCRIPTION
20 5304429460 A - C D - F Panel,base plate ,black ,bottom
20 5304429461 - B - - E - Panel,base plate ,white ,bottom
21 5304408977 A B C D E F Filter,air ,(2)
22 5304430287 A B C D E F Lens,cooktop lamp ,glass ,(2)
23 5304429462 A - C D - F Frame,lens holder ,black
23 5304429463 - B - - E - Frame,lens holder ,white
37 5304408986 A B C D E F Cover,stirrer/antenna
38 5304408979 A B C D E F Rivet,push mount ,plastic ,stirrer cover
40 5304429464 A B C D E F Coupler,shaft bushing ,turntable/motor
41 # 5304408515 A B C D E F Wire Saddle
42 5304408990 A B C D E F Cover,front
54 5304417437 A B C D E F Bracket,motor mtg ,turntable/vent ,wrpr top plate
55 5304423504 A B C D E F Holder Nut,assy
58 5304429465 A - C D - F Casing,wrapper ,black ,outer panel
58 5304429466 - B - - E - Casing,wrapper ,white ,outer panel
65 5304429468 A B C D E F Duct,exhaust vent ,upper
68 5304408982 A B C - - - Bracket,duct assy ,upper
68 5304423508 - - - D E F Bracket,duct assy ,upper
70 5304430288 A - - D - - Grille Assy,black
70 5304430289 - B - - E - Grille Assy,white
70 5304429469 - - C - - F Grille Assy,black
71 5304408994 A B C D E F Screw,grille mtg ,black ,(2)
80 5304409641 A B C D E F Filter,air ,charcoal
82 5304430290 A B C D E F Rack,microwave oven ,wire
84 5304417414 A B C D E F Support,turntable tray ,with rollers
85 5304423399 A B C D E F Tray,turntable ,glass
91 5304429472 A B C D E F Bracket-barrier,filter
93 5304423531 A B C D E F Label,cooking guide
93 5304423532 - - - D E F Label,cooking guide
100# 5304429473 A B C D E F Stirrer Assembly
106 5304430291 A B C D E F Hardware,assembly
109 5304429474 A B C D E F Bracket,grille
110 5304429475 A B C D E F Bracket,grille ,left side
111 5304423529 A - - D - - Grille,exhaust ,black
111 5304423530 - B - - E - Grille,exhaust ,white
111 5304429476 - - C - - F Grille,exhaust ,black
9999 316137224 A B C - - - Technical Guide,mini-manual ,with wiring dia

11/02 10
Publication No. FMV145KB/S3, BC1 & CFMV145KB/S2, BC1
5995380689
INSTALLATION

# = Fast-moving Parts 11 11/02
* = Non-Illustrated Parts
FMV145KB/S3, BC1 & CFMV145KB/S2, BC1 Publication No.
5995380689
INSTALLATION
A = FMV145K (FMV145KB3)
B = FMV145K (FMV145KS3)
C = FMV145B (FMV145BC1)
D = CFMV145K (CFMV145KB2)
E = CFMV145K (CFMV145KS2)
F = CFMV145B (CFMV145BC1)
POS. NO PART NO DESCRIPTION
54 5304417437 A B C D E F Bracket,motor mtg ,turntable/vent ,wrpr top plate
56 5304408997 A B C D E F Bracket,power cord
83 5304429479 A B C D E F Panel,mounting plate ,rear
86 5304429480 A B C D E F Installation Hardware
104 5304429482 A B C D E F Hood & Damper Assy
9999 316137222 A B C D E F Instructions,installation ,English
9999 316137223 - - - D E F Instructions,installation ,French
9999 316137213 A B C D E F Template,cab top instl
9999 316137221 A B C D E F Template,rear wall instl
9999 5304430292 A B C D E F Instructions,filler kit
9999 5304423401 A B C D E F Instructions,charcoal filter
9999 316137205 A B C D E F Use & Care Guide,English
9999 316137206 - - - D E F Use & Care Guide,French
9999 316137224 A B C - - - Technical Guide,mini-manual ,with wiring dia
9999 5304430484 - - - D E F Wiring Diagram,microwave

11/02 12
Publication No. FMV145BC1, FMV145KB3 & FMV145KS3
5995380689
PLMV168KC4, GLMV168KB4,
GLMV168KQ4, GLMV168KS4,
FMV14
MODEL NO. :
MODULARITY-OTR-FRIGIDAIRE
WIRING SCHEMATIC

# = Fast-moving Parts 13 11/02
* = Non-Illustrated Parts
FMV145BC1, FMV145KB3 & FMV145KS3 Publication No.
5995380689
PLMV168KC4, GLMV168KB4,
GLMV168KQ4, GLMV168KS4,
FMV14
MODEL NO. :
MODULARITY-OTR-FRIGIDAIRE
WIRING DIAGRAM

11/02 14
Publication No. CFMV145BC1, CFMV145KB2 & CFMV145KS2
5995380689
MODEL NO. :
WIRING SCHEMATIC

# = Fast-moving Parts 15 11/02
* = Non-Illustrated Parts
CFMV145BC1, CFMV145KB2 & CFMV145KS2 Publication No.
5995380689
MODEL NO. :
Printed in Malaysia
WIRING DIAGRAM
