Frigidaire GLMV169H User manual

Product No. GLMV169HBA GLMV169HQA GLMV169HSA
Market North America North America North America
Color black bisque white
Volts 120 120 120
Watts 1000 1000 1000
Wiring Diagram 5995518155 5995518155 5995518155
Owner's Guide TINSEB150WRRZ TINSEB150WRRZ TINSEB150WRRZ
Installation Instructions TINSEB151WRRZ TINSEB151WRRZ TINSEB151WRRZ
GLMV169 cover.eps GLMV169H Cabinet.eps GLMV169H Controls.eps
GLMV169H Wiring.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995518155
08/07/15
(EN/SERVICE/KC)
099
OVER-RANGE
MICROWAVE
Model No.
GLMV169H
Copyright ©2008 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995518155 GLMV169H
07/08 2
OVEN,CABINET

GLMV169H Publication No: 5995518155
# Functional Parts 3 07/08
* Non-Illustrated Parts
OVEN,CABINET
Model Index: AGLMV169H (GLMV169HBA)
BGLMV169H (GLMV169HQA)
CGLMV169H (GLMV169HSA)
POS. NO PART NO. DESCRIPTION
1 # 5304467670 A B C Rectifier, high voltage
2 # 5304467671 A B C Capacitor, high voltage
3 # 5304448488 A B C Motor, turntable
4 # 5304448489 A B C Motor, stirrer fan
5 # 5304440023 A B C Thermal Cutout, hood
6 # 5304468156 A B C Transformer, power
7 # 5304461353 A B C Magnetron
8 # 5304440026 A B C Switch, interlock, door sensor
9 # 5304467695 A B C Switch, monitor, w/ceramic fuse
10 # 5304440028 A B C Power Cord, electric
11 # 5304461117 A B C Socket, oven lamp
12 # 5304440029 A B C Motor, hood fan
13 # 5304448490 A B C Motor, cooling fan
14 5304440031 A B C Lamp, incandescent, 20 W, (3)
15 # 5304440032 A B C Thermal Cutout, oven cavity
16 # 5304440033 A B C Sensor, humidity, cook control
17 # 5303319550 A B C Fuse, magnetron
18 5304468158 A - - Grille, exhaust, black
18 5304468159 - B - Grille, exhaust, bisque
18 5304468157 - - C Grille, exhaust, white
19 5304468161 A B C Plate, base, right
20 5304468162 A B C Plate, rear stay
21 5304468164 A - - Cabinet, outer casing, black
21 5304468165 - B - Cabinet, outer casing, bisque
21 5304468163 - - C Cabinet, outer casing, white
22 5304468166 A B C Wiring Diagram, schematic, label
23 5303319573 A - - Lens/Frame Assy, lamp
23 5304451821 - B - Lens/Frame Assy, lamp, bisque
23 5304458209 - - C Lens/Frame Assy, lamp, white
24 5303319574 A - - Frame, lens holder
24 5304451822 - B - Frame, lens holder, bisque
24 5304458210 - - C Frame, lens holder, white
25 5303319575 A B C Lens, cooktop lamp, glass
26 5304468168 A - - Cover, unit base, black
26 5304468169 - B - Cover, unit base, bisque
26 5304468167 - - C Cover, unit base, white
27 5304468170 A B C Cushion, hood duct
28 5304468173 A B C Cushion, top panel, rubber
29 5304451500 A B C Cushion, magnetron
36 5304464343 A B C Damper Assembly, exhaust
37 5304467717 A B C Support Assy, turntable,roller
38 5304440285 A B C Tray, turntable, glass
39 5304468174 A B C Retainer, capacitor strap
40 5304468175 A B C Cover, stirrer fan
41 # 5304468176 A B C Stirrer Assembly
42 # 5304467698 A B C Filter, noise, electronic
43 5304467718 A B C Bushing, motor shaft, turntable
44 5304440289 A B C Latch Hook

Publication No: 5995518155 GLMV169H
07/08 4
OVEN,CABINET

GLMV169H Publication No: 5995518155
# Functional Parts 5 07/08
* Non-Illustrated Parts
OVEN,CABINET
Model Index: AGLMV169H (GLMV169HBA)
BGLMV169H (GLMV169HQA)
CGLMV169H (GLMV169HSA)
POS. NO PART NO. DESCRIPTION
45 5304468135 A B C Bracket, mounting plate, rear
46 # 5304468177 A B C Fan Blade, mag cooling fan
47 5304467721 A B C Bushing, grommet, power cord
48 5304468178 A B C Cover, oven lamp
49 5304468179 A B C Duct, hood intake, right side
50 5304468180 A B C Cushion, intake duct, seal
51 5304467727 A B C Lens, lamp filter
52 5304468181 A B C Support, chassis, left side
53 5304468182 A B C Support, chassis, right side
54 5304468183 A B C Duct, exhaust hood
55 5304467733 A B C Support, rack, front
61 5304467762 A B C Support, rack, left rear
62 5304467763 A B C Support, rack, right rear
83 5304451550 A B C Screw, 4 mm x 8 mm
90 5304467770 A B C Label, Caution-DHHS
91 5304468187 A B C Label, Caution-monitor
92 5304440335 A B C Filter, inside exhaust, charcoal
93 5303319568 A B C Filter, grease, (2)
94 5304467773 A B C Clip, canoe type, stirrer cover
96 # 5304467828 A B C Wire, ground
97 5304451552 A B C Screw, 4 mm x 8 mm, white
97A 5304467777 A - - Screw, 4 mm x 8 mm, black
98 5304462315 A B C Screw, 4 mm x 12 mm, ground
99 5304467780 A B C Screw, 4 mm x 8 mm, Tap Tight
100 5303319641 A B C Screw
101 5304467778 A B C Screw, 3 mm x 8 mm
102 5304467781 A B C Screw, 3 mm x 6 mm
103 5304468189 A - - Screw, black
103 5304468190 - B - Screw, bisque
103 5304468188 - - C Screw, white
106 5304468191 A B C Label, Caution-DHHS
108 5304467769 A B C Cushion, latch hook, pad

Publication No: 5995518155 GLMV169H
07/08 6
CONTROL PANEL,DOOR,MISC.

GLMV169H Publication No: 5995518155
# Functional Parts 7 07/08
* Non-Illustrated Parts
CONTROL PANEL,DOOR,MISC.
Model Index: AGLMV169H (GLMV169HBA)
BGLMV169H (GLMV169HQA)
CGLMV169H (GLMV169HSA)
POS. NO PART NO. DESCRIPTION
30 # 5304468192 A B C Control Board, printed circuit
31 # 5304461358 A - - Control Panel Assy, black
31 # 5304468194 - B - Control Panel Assy, bisque
31 # 5304468193 - - C Control Panel Assy, white
31A# 5304461362 A - - Touch Control, key pad, black
31A# 5304461363 - B - Touch Control, key pad, bisque
31A# 5304461364 - - C Touch Control, key pad, white
31B 5304468195 A B C Panel, control mount
31C 5304456930 A B C Screw, 3 mm x 10 mm
31D 5304468197 A - - Frame, control panel, black
31D 5304468198 - B - Frame, control panel, bisque
31D 5304468196 - - C Frame, control panel, white
35 5304467710 A B C Screw, 3 mm x 8 mm
56 5304468199 A B C Door Stop
63 # 5304441374 A - - Door Assy, black, w/handle
63 # 5304468201 - B - Door Assy, bisque, w/handle
63 # 5304468200 - - C Door Assy, white, w/handle
65 5304468203 A - - Frame Assembly, door, black
65 5304468204 - B - Frame Assembly, door, bisque
65 5304468202 - - C Frame Assembly, door, white
67 5304440314 A B C Latch, door
69 5304440316 A B C Spring, door latch
71 5304440320 A B C Frame, choke cover, inner door
72 5304468205 A B C Seal, door, film
73 5304468207 A - - Handle, door, black
73 5304468208 - B - Handle, door, bisque
73 5304468206 - - C Handle, door, white
74 5304451517 A B C Screw, 4 mm x 8 mm
75 5304468209 A B C Screw, 4 mm x 30 mm
76 5304467765 A B C Hardware Kit, installation
77 5303318761 A B C Sleeve, power cord, grommet
78 5303318762 A B C Screw, toggle
79 5304453895 A B C Screw, 5mm x 85mm
80 5304451552 A B C Screw, 4 mm x 8 mm, white
81 5304453723 A B C Screw, 5mm x 35mm
82 5304453724 A B C Washer
86 5304468216 A B C Template, installation, top
87 5304468217 A B C Template, installation, wall
89 5304468215 A B C Wiring Harness, main
95 5304440338 A B C Rack, microwave oven, wire

Publication No: 5995518155 GLMV169H
07/08 8
WIRING SCHEMATIC
