Frigidaire PLEB30S8C User manual

PRODUCT NO. BASE MODEL NO. FACTORY NO. COLOR MARKET
PLEB30S8CCA PLEB30S8A 38257393H10S1 stainless North America
Publication No.
5995378170
020913
-EN/SERVICE /ECL
377
ELECTRIC
WALL OVEN
Model No.
PLEB30S8C
©2002 Electrolux Home Products, Inc.
All rights reserved
FACTORY PARTS CATALOG
RANGE
WIRING DIAGRAM - # 318046208
OWNER’S GUIDE - # 318200919
TIMER INSTRUCTION SHEET - # 318200181
INSTALLATION INSTRUCTIONS - # 318201507
ELECTROLUX HOME PRODUCTS, INC.
P.O. BOX 212378, Augusta, GA 30917

09/02 2
Publication No. PLEB30S8CCA
5995378170
CONTROL PANEL

# = Functional Parts 3 09/02
* = Non-Illustrated Parts
PLEB30S8CCA Publication No.
5995378170
CONTROL PANEL
POS. NO PART NO DESCRIPTION
19 318030215 Panel,control ,black ,back
19A 318192812 Panel,control ,stainless ,front
20 # 318010700 Clock/Timer,EOC
21 318029700 Trim,top ,stainless
23 318111602 Bracket,clock & relay
42 318027409 Trim,vent ,black
80 # 318111501 Relay,convection ,oven light ,(2)
99 5303300265 Screw,8-18 x 0.500 ,chrome
* 218490900 Cleaner,stainless steel
* 3201861 Screw,6 x 0.375
* 5303211311 Screw,8 x 0.500

09/02 4
Publication No. PLEB30S8CCA
5995378170
BODY

# = Functional Parts 5 09/02
* = Non-Illustrated Parts
PLEB30S8CCA Publication No.
5995378170
BODY
POS. NO PART NO DESCRIPTION
1 318066402 Panel,main back
2 318102101 Shield,oven top
2A 318071703 Shield,oven top
6 318025304 Rack,oven
6A 318219500 Rack,broiler pan
9 5303317977 Pan,broiler
10 5303317976 Insert,broiler pan
12 # 318089913 Switch,light
14 5308011085 Receptacle,oven light
15 5303013071 Bulb/Lamp,oven light
16 3201911 Cover,oven light ,glass
17 5304400195 Retainer,light cover
37 # 316111203 Sensor,oven temp probe
41 5303310526 Cover,hinge cutout
54 5303310514 Housing,oven light
56 318029101 Trim,side ,stainless ,outer,RH
56A 318029100 Trim,side ,stainless ,outer,LH
58A 318133744 Insulation,oven wrapper
58B 318133769 Insulation,oven back
59 318072504 Tube,oven vent
62 # 5303310518 Terminal Block
62* 5303323144 Nut,10-32
66 # 5303310513 Element,broil ,2750 W
67 # 5303310512 Element,bake ,3000 W
68 5304403015 Support,element hanger
70 5303300142 Shield,insulation
71 318071201 Shield,wire
76 318056202 Front,oven
80 5303320846 Plate,oven mtg
81 318192400 Spring,oven
82 318072302 Shield,oven bottom
83 318089609 Liner,oven
86 5303310524 Receptacle,hinge
88 5303311222 Rod,latch
89 # 318095934 Motor,latch assy ,w/brkt & switch
89* 318120711 Switch
99 318055420 Support,adjustable
102 318090900 Support,oven front ,(2)
103 318028500 Trim,base ,black
103A 318027700 Trim,base ,stainless ,outer
107 318119600 Cover,fan
108# 318073001 Motor,fan
109 5303311203 Blade,fan
111 5303311205 Nut,fan retainer
119# 318004900 Switch,thermal
124 318076903 Box,vent
125# 5303311202 Motor,convection
125* 318142100 Washer,motor ,convection
127 5303310542 Adapter,vent tube ,with converter
128 5303311163 Bushing
129 5303311164 Spring
131 318102301 Cover,control housing
132 318101704 End,cover ,RH ,control housing
132A 318101705 End,cover ,LH ,control housing
150 318072205 Bracket,support ,LH
150A 318072204 Bracket,support ,RH
177 318053800 Gasket,vent
185 318014700 Spacer,oven shield
188 08007817 Spacer,(6)
222 318080000 Plate,oven temp probe
263 5303322885 Spacer,fan blade
264 318143813 Shield,wire
* # 318078511 Box & wires assy
* 5303311207 Tube,protector
* 3015722 Clip-wire
* 3201861 Screw,6 x 0.375
* 5303211311 Screw,8 x 0.500
* 5303302745 Screw,10-16x1-1/8 ,square drive
* 5303323277 Screw (8-18X13/32)
* 5303300265 Screw,8-18 x 0.500 ,chrome

09/02 6
Publication No. PLEB30S8CCA
5995378170
DOOR

# = Functional Parts 7 09/02
* = Non-Illustrated Parts
PLEB30S8CCA Publication No.
5995378170
DOOR
POS. NO PART NO DESCRIPTION
6 318056811 Shield,air wash
7 318133754 Insulation,oven door
9 318048612 Liner,oven door
10 5303311174 Screw,10-24 x 3/8
12 318053103 Gasket,oven door seal
13 318187933 Stainless Panel,oven door ,w/ glass/nmplt
15 318172903 Stiffener,glass
16 318041603 Panel,glass ,inner oven door
17 318042102 Spacer,glass
18 318053001 Seal,window
23 318024700 Hinge,oven door
31 318065102 Latch,door
39 318197901 Handle,oven door ,stainless
56 5303300265 Screw,8-18 x 0.500 ,chrome
* 218490900 Cleaner,stainless steel
* 5303211311 Screw,8 x 0.500
* 5303302745 Screw,10-16x1-1/8 ,square drive
* 5303323277 Screw (8-18X13/32)

09/02 8
Publication No. PLEB30S8CCA
5995378170
WIRING DIAGRAM
