Frigidaire FRT18HP7D User manual

Product No. FRT18HP7DB0 FRT18HP7DB2 FRT18HP7DW2
Series R134a R134a R134a
Color black black white
Volts 115 115 115
Wiring Diagram 240398801 240398801 240398801
Owner's Guide 240400112 240400112 240400112
Market North America North America North America
Energy Guide 241607511 241607511 241607511
Service Data Sheet 240379015 240379015 240379015
Installation Instructions 240568300 240568300 240568300
N05L00006.eps N05DAACBA0.eps N05BBAABD4.eps N05SAAAFH1.eps
N05CAAAAA8.eps 240398801.eps 240398601.eps
u x Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995433686
05/04/11
(EN/SERVICE/WC)
390
TOP-MOUNT
REFRIGERATOR
Model No.
FRT18HP7D
Copyright ©2005 Home Pr oducts, Inc.
All rights reserved.

Publication No: 5995433686 FRT18HP7D
04/05 2
DOOR
22
11
12
22
22
13A
13
48A
48A
48A
21C
21C
22
1
7
2
N05DAACBA0
15
48
18
21
37
21
10
22
22
10
22
22
21
37
18
8
14
14

FRT18HP7D Publication No: 5995433686
# Functional Parts 3 04/05
* Non-Illustrated Parts
DOOR
Model Index: AFRT18HP7D (FRT18HP7DB0)
BFRT18HP7D (FRT18HP7DB2)
CFRT18HP7D (FRT18HP7DW2)
POS. NO PART NO. DESCRIPTION
1 240542109 A B - Gasket-frzr door, black, magnetic
1 240542103 - - C Gasket-frzr door, white, magnetic
2 240542112 A B - Gasket-refr door, black, magnetic
2 240542106 - - C Gasket-refr door, white, magnetic
7 240338303 A B C Door, dairy, clear
8 240534801 A B C Rack-door
10 240381303 A B - Plug-button, black, hinge brg hole
10 240381301 - - C Plug-button, white, hinge brg hole, (2)
11 240410203 A B - Door-frzr, black, complete assy
11 240410201 - - C Door-frzr, white, complete assy
12 240415204 A B - Label-nameplate, black
12 240415201 - - C Label-nameplate, white
13 240312405 A B - Door Stop, black, refr
13 240312403 - - C Door Stop, white, ref
13A 240312406 A B - Door Stop, black, frzr
13A 240312404 - - C Door Stop, white, frzr
14 240494003 A B - Plug-button, black
14 240494001 - - C Plug-button, white
15 240410304 A B - Door, refr, black
15 240410303 - - C Door, refr, white, completeassy
18 218668003 A B - Handle-door, black
18 218668001 - - C Handle-door, white
21 240383401 A B C Screw, truss hd quad, #10-16 x .500
21C 218252200 A B C Screw, #8 truss hd, 10-32CA x 0.500
22 240527102 A B - Bearing-hinge, black
22 240527101 - - C Bearing-hinge, natural color
37 215870636 A B - Trim-handle, 2.47", black, w/satin AL band
37 215870629 - - C Trim-handle, 2.47", white, w/satin AL band
37* 218676004 A B C Band-decorative, satin aluminum, handle trim
48 240338101 A B C Bin-door, pseudo, bottom
48A 240338201 A B C Bin-door, gallon

Publication No: 5995433686 FRT18HP7D
04/05 4
CABINET
49
49
49
49
49
47
47
48
83
82
89
11
10
1
12
12A
81
58
40
92
38
37
13
5
58
35A 36
34
35
59
59
56
42
30
72
N05BBAABD4
43
28
21C
21C
41
41
22
41
8
8
9
14
34
4
2
3

FRT18HP7D Publication No: 5995433686
# Functional Parts 5 04/05
* Non-Illustrated Parts
CABINET
Model Index: AFRT18HP7D (FRT18HP7DB0)
BFRT18HP7D (FRT18HP7DB2)
CFRT18HP7D (FRT18HP7DW2)
POS. NO PART NO. DESCRIPTION
1 240355401 A B C Cover-fan
2 240367001 A B C Knob-damper control
3 5303001028 A B C Nut, push-on
4 241523701 A B C Damper-fan cover
5 # 5308000010 A B C Fan Blade, red, evaporator fan
8 5300157666 A B C Bushing-motor mtg, (2)
9 5303292396 A B C Bracket-motor mtg, front
10 240462010 A B C Cover-evap coil
10* 240568601 A B C Seal-coil cover
10* 241520701 A B C Harness-wiring, freezer
11 5303208309 A B C Plug-hole, factory test
12 241557601 A B C Plug-ice maker harness, rectangular
12A 240374401 A B C Plug-wtr inlet tube, round, 1"
12A* 241586701 A B C Plug-foam-wtr-inlet, round
13 240369702 A B C Motor-evap fan
13* 215474201 A B C Washer, "slinger", nylon, evap fan shaft
13* 218931001 A B C Clamp-motor wiring, nylon, w/adhesive tape
14 5303292397 A B C Bracket-motor mtg, rear
14* 240433201 A B C Screw, hex washer head, 8-18 x 0.375
21C 218252200 A B C Screw, #8 truss hd, 10-32CA x 0.500
22 215774918 A B - Plug-button, black, upr hinge holes
22 215774901 - - C Plug-button, white, upr hinge holes
28 240335501 A B C Bolt-roller adj, hex washer head, 1/4-20 x 4.020, (2), special
30 240314003 A B - Bracket-lower hinge, black
30 240314001 - - C Bracket-lower hinge, zinc
34 240311303 A B C Washer, hinge, nylon, (2)
35 240313803 A B - Bracket-ctr hinge, black
35 240313801 - - C Bracket-ctr hinge, zinc
35A 240336802 A B C Spacer-hinge, center
36 240516401 A B C Pin-center hinge
37 241611303 A B - Trim-cabinet corner, black, (2)
37 241611301 - - C Trim-cabinet corner, white, (2)
38 240313701 A - - Bracket-upper hinge
38 241622603 - B - Hinge-up-plastic-blk, plastic, black
38 241622601 - - C Hinge-up-plastc-wht, plastic, white
40 240354404 A - - Cover-upper hinge, black
41 5308009759 A B C Grommet, shelf mtg, 1.25", LH, (4)
42 240578901 A B C Screw-hinge mtg, hex head, 1/4-20 x 5/8
43 240335003 A B C Roller Assy, front, (2)
47 218233300 A B C Channel-shelf mtg, side, (2)
48 5303292395 A B C Channel-shelf mtg, center
49 218362500 A B C Screw, hex washer head, 8-18AB x 1.250, spacer, (2)
56 240516501 A B C Pin-lower hinge
58 5303001343 A B C Screw, hex washer head, 8-15A x 0.500
59 240442703 A B - Screw-#10-32 X 3/4, black
59 240442701 - - C Screw-#10-32 X 3/4, zinc
72 240368207 A B - Grille/Kickplate, black
72 240368205 - - C Grille/Kickplate, white

Publication No: 5995433686 FRT18HP7D
04/05 6
CABINET
49
49
49
49
49
47
47
48
83
82
89
11
10
1
12
12A
81
58
40
92
38
37
13
5
58
35A 36
34
35
59
59
56
42
30
72
N05BBAABD4
43
28
21C
21C
41
41
22
41
8
8
9
14
34
4
2
3

FRT18HP7D Publication No: 5995433686
# Functional Parts 7 04/05
* Non-Illustrated Parts
CABINET
Model Index: AFRT18HP7D (FRT18HP7DB0)
BFRT18HP7D (FRT18HP7DB2)
CFRT18HP7D (FRT18HP7DW2)
POS. NO PART NO. DESCRIPTION
81 5308016566 A B C Screw, hex washer head, 8-15A x 0.625, low profile
82 5304418225 A B C Roller, compressor base, rear, (2)
83 5303316859 A B C Rivet, flat head, 1/4 OD x 1-3/4, roller pin
89 241574607 A B C Cover-access, w/label
89* 241500302 A B C Screw, hex washer head, 8-18AB x 0.625
92 5303001479 A B C Screw-hinge mtg, hex hd, 1/4-20 x 0.875
* 240479601 A B C Plug, button, cab liner holes, (2)
* 5303321321 A B - Paint, touch-up, black
* 5303305324 - - C Paint, touch-up, white

Publication No: 5995433686 FRT18HP7D
04/05 8
SHELVES
25
25B
25B
25C
25C
26
47
N05SAAAFH1
26
11
31
24
42
42
123
123
24
24B
81
81
23
21
22A
13
12
14
18
17
15
16
10
10
15

FRT18HP7D Publication No: 5995433686
# Functional Parts 9 04/05
* Non-Illustrated Parts
SHELVES
Model Index: AFRT18HP7D (FRT18HP7DB0)
BFRT18HP7D (FRT18HP7DB2)
CFRT18HP7D (FRT18HP7DW2)
POS. NO PART NO. DESCRIPTION
10 215667501 A B C Tray, ice cube, plastic
11 240358005 A B C Shelf, freezer, full-width, wire
11* 5303299664 A B C Spacer, shelf
12 241542001 A B C Diffuser, air, top
13 240362601 A B C Diffuser, air, bottom
14 # 241554901 A B C Switch-light/lamp
15 240436702 A B C Light Bulb/Lamp, A-15, clear, 40 W, 120 V, miniature
16 240364202 A B C Socket-light/lamp, dual
17 240352701 A B C Control Box
17* 240568607 A B C Seal
17*# 240388701 A B C Wiring Harness, control box
18 240360801 A B C Knob, temp control
21 # 5304421256 A B C Control, temperature
22A 240468201 A B C Tube, sensor sleeve, 31 inch, plastic, white
23 241621501 A B C Timer-defrost
23* 5303001259 A B C Screw-timer mtg, pan hd, 6-20 x 0.438, (2)
24 241616602 A B C Shelf, fixed, Spill Safe
24B 240408804 A B C Shelf-"Spill-Safe", cantilever fixe
25 240364713 A B C Cover-crisper pan, with beam, humid cont
25B 240361202 A B C Knob, humidity cont.
25C 240361301 A B C Damper, humidity cont.
26 240337107 A B C Pan-crisper, clear, (2), no graphics
31 240530810 A B C Pan, meat bin
42 240356501 A B C Track, meat pan hanger, RH
42 240365401 A B C Track, meat pan hanger, LH
47 240350643 A B C Insert-pan cover, glass
81 5308016566 A B C Screw, hex washer head, 8-15A x 0.625, low profile
123 215005100 A B C Screw, hanger/rlr mtg, 8-10 x 0.438

Publication No: 5995433686 FRT18HP7D
04/05 10
SYSTEM

FRT18HP7D Publication No: 5995433686
# Functional Parts 11 04/05
* Non-Illustrated Parts
SYSTEM
Model Index: AFRT18HP7D (FRT18HP7DB0)
BFRT18HP7D (FRT18HP7DB2)
CFRT18HP7D (FRT18HP7DW2)
POS. NO PART NO. DESCRIPTION
1 # 240444401 A B C Condenser, dynamic
4 # 218944001 A B C Drier-filter, R134a System
6 240496101 A B C Wiring Harness, machine compt, w/electric cord
6* 241520701 A B C Harness-wiring, freezer
6* # 240388701 A B C Wiring Harness, control box
14 # 5303918208 A B C Defrost Heater Kit
15 # 5303918274 A B C Evaporator Kit
16 5308000110 A B C Strap-evap/heater, aluminum, (2)
17 241551801 A B C Trough-drain
20 241551901 A B C Insulation Block
21 # 5303918202 A B C Thermostat-defrost, kit
22 241602001 A B C Base-compressor
22* 218252200 A B C Screw, #8 truss hd, 10-32CA x 0.500
23 218513300 A B C Grommet-compr mtg, (4)
25 240491501 A B C Screw-compressor mtg, 1/4-28 x 1.16, shoulder, typ CF
26 240332608 A B C Pan-defrost drain
29 # 5303918299 A B C Compressor, w/electricals
30 # 241527802 A B C Starter
32 241527901 A B C Clamp, elec cont mtg, compressor
34 240405201 A B C Grommet, rubber, black, cond tube/wire
41 240433202 A B C Screw, hex washer head, 8-18 x 5/16
44 5303001199 A B C Clamp-wiring harness, strain relief, galv steel
45 5308016566 A B C Screw, hex washer head, 8-15A x 0.625, low profile
55 218909915 A B C Capacitor-run, 220 VAC, 15 microfarad
57 240542601 A B C Clip-wiring harness
58 218897002 A B C Screw, hex washer head, 8-32 x 0.375
59 5304430246 A B C Bracket-cond motor assy
59* 240346701 A B C Tape-foam seal, shroud
59* 240359401 A B C Screw-fan shroud, (2)
60 240525402 A B C Motor, condensor fan
61 # 240524101 A B C Fan Blade, galv steel, condenser fan
82 5304418225 A B C Roller, compressor base, rear, (2)
83 5303316859 A B C Rivet, flat head, 1/4 OD x 1-3/4, roller pin
84 240500801 A B C Tube-drain, rubber, lower
85 240553501 A B C Tube-connector, suction
* 240396801 A B C Clamp, tube/wiring, nylon, black/natural
* # 5303918263 A B C Heat Exchanger Kit, suction line
* 5303918222 A B C Hot Tube Repair Kit, service

Publication No: 5995433686 FRT18HP7D
04/05 12
WIRING SCHEMATIC

FRT18HP7D Publication No: 5995433686
# Functional Parts 13 04/05
* Non-Illustrated Parts
WIRING DIAGRAM
