Frigidaire FRT18P6C User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FRT18P6CQ3 FRT18P6C R134a bisque 115
FRT18P6CQ5 FRT18P6C R134a bisque 115
MARKET
North America
Publication No.
5995398954
031119
-EN/SERVICE/KHB
357
TOP MOUNT
REFRIGERATOR
Model No.
FRT18P6C
©2003 Electrolux Home Products, Inc.
All rights reserved
FACTORY
PARTS CATALOG
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
WIRING DIAGRAM - 240379012
OWNER’S GUIDE - 3 = 240400109 & 5 = 240400110
SERVICE DATA SHEET - 240379012

11/03 2
Publication No. FRT18P6C
5995398954
DOOR

# = Fast-moving Parts 3 11/03
* = Non-Illustrated Parts
FRT18P6C Publication No.
5995398954
A = FRT18P6C (FRT18P6CQ3)
B = FRT18P6C (FRT18P6CQ5)
POS. NO PART NO DESCRIPTION
1 # 240514605 A B Gasket,frzr door seal ,white ,magnetic
2 # 240514608 A B Gasket,seal ,white ,refr door ,magnetic
7 240337703 A B Door-dairy,w/o graphics ,clear
10 240381302 A B Plug-button,bisque ,hinge brg hole ,(2)
11 240476205 A B Panel-frzr door,bisque ,complete assy
12 240572601 A B Label-nameplate
13 240312407 A B Door Stop,bisque ,ref
13A 240312408 A B Door Stop,bisque ,frzr
14 240494002 A B Plug-button,bisque
14B 240383602 A B Plug-button,bisque ,door handle
15 240476305 A B Panel-refr door,bisque ,complete assy
18 240339204 A B Handle-door,bisque
18A 240339209 A B Handle-door,bisque
21 240383401 A B Screw,truss hd quad ,#10-16 x .500
21C 218252200 A B Screw,#8 truss hd ,10-32CA x 0.500
22 240527101 A B Bearing-hinge,natural color
48 240338101 A B Bin-door,pseudo ,bottom
48A 240337901 A B Bin-door,refr
48B 240338001 A B Bin-door,pseudo ,gallon ,refr
49 240495804 A B Bin-door,pseudo ,frzr
DOOR

11/03 4
Publication No. FRT18P6C
5995398954
CABINET

# = Fast-moving Parts 5 11/03
* = Non-Illustrated Parts
FRT18P6C Publication No.
5995398954
A = FRT18P6C (FRT18P6CQ3)
B = FRT18P6C (FRT18P6CQ5)
POS. NO PART NO DESCRIPTION
1 240355401 A B Cover-fan
2 240367001 A B Knob-damper control
3 5303001028 A B Nut,push-on
4 240367401 A B Damper-fan cover
5 # 5308000010 A B Fan Blade,red ,evaporator fan
8 5300157666 A B Bushing-motor mtg,(2)
9 5303292396 A B Bracket-motor mtg,front
10 240462010 A B Cover-evap coil
10* 240568605 A B Seal-coil cover
10*# 240524701 A B Wiring Harness,freezer section
11 5303208309 A B Plug-hole,factory test
12 240366801 A B Plug-ice maker harness,rectangular
12* 218843800 A B Screw,hex wshr hd ,8-15A x 0.500
12A 240374401 A B Plug-wtr inlet tube,round ,1"
13 # 240369701 A B Motor-evap fan
13* 218931001 A B Clamp-motor wiring, nylon, w/adhesive tape
14 5303292397 A B Bracket-motor mtg, rear
14* 240433201 A B Screw, hex washer head, 8-18 x 0.375
18 240411901 A B Support-evap cover, (2)
21C 218252200 A B Screw, #8 truss hd, 10-32CA x 0.500
22 215774919 A B Plug-button, bisque, upr hinge holes
28 240335501 A B Bolt-roller adj,hex washer head, 1/4-20 x 4.020, (2), special
30 240314004 A B Bracket-lower hinge, bisque
34 240311303 A B Washer, hinge, nylon, (2)
35 240313804 A B Bracket-ctr hinge, bisque
35A 240336802 A B Spacer-hinge,center
36 240516401 A B Pin-center hinge
37 240337604 A B Trim-cabinet corner, bisque, (2)
38 240313701 A B Bracket-upper hinge
40 240354403 A B Cover-upper hinge, bisque
41 5303001609 A B Grommet, shelf mtg, 0.69" ,RH
41 5308009759 A B Grommet, shelf mtg, 1.25" ,LH
42 240578901 A B Screw-hinge mtg,hex head ,1/4-20 x 5/8
43 240335003 A B Roller Assy, front, (2)
47 218233300 A B Channel-shelf mtg, side, (2)
48 5303292395 A B Channel-shelf mtg, center
49 218362500 A B Screw, hex washer head, 8-18AB x 1.250
56 240516501 A B Pin-lower hinge
58 5303001343 A B Screw, hex washer head ,8-15A x 0.500
59 240442704 A B Screw-#10-32 X 3/4,bisque
72 240368206 A B Grille/Kickplate, bisque
81 5308016566 A B Screw, hex washer head, 8-15A x 0.625, low profile
82 5304418225 A B Roller, compressor base ,rear ,(2)
83 5303316859 A B Rivet, flat head, 1/4 OD x 1-3/4, roller pin
89 240326115 A B Cover-access, with label
89* 241500301 A B Screw, hex washer head ,8-18AB x 0.500
92 216850900 A B Screw, hex washer hd ,1/4 x 7/8, hinge mtg
* 240479601 A B Plug, button, cab liner holes, (2)
* 5304414035 A B Paint, touch-up, bisque
CABINET

11/03 6
Publication No. FRT18P6C
5995398954
SHELVES
25
25B
25C
26
47
N05SAAAFE10
26
11
10
10
31
42
42
123
123
37
36
43
44
24
29
40
41
37
36
43
44
23
21
22A
13
12
14
18
17
15
16
81
81
25B
25C

# = Fast-moving Parts 7 11/03
* = Non-Illustrated Parts
FRT18P6C Publication No.
5995398954
A = FRT18P6C (FRT18P6CQ3)
B = FRT18P6C (FRT18P6CQ5)
POS. NO PART NO DESCRIPTION
10 215667501 A B Tray,ice cube ,plastic
11 240358002 A B Shelf-freezer,full width
11* 5303299664 A B Spacer,shelf
12 240362502 A B Diffuser,air ,top
13 240362601 A B Diffuser,air ,bottom
14 # 240505801 A B Switch,light/lamp
15 240436702 A B Light Bulb, A-15, clear, 40 W, 120 V, miniature
16 # 241500701 A B Socket-light/lamp
17 240352701 A B Control Box
17*# 240388701 A B Wiring Harness, control box
18 240360801 A B Knob, temp control
21 # 5304421256 A B Control, temperature
22A 5303916855 A B Tube, sensor sleeve ,plastic ,clear
23 # 215846606 A B Timer, defrost, 60 Hz, 0.25 W, 120 V, 10 hour/30 min
23* 5303001259 A B Screw-timer mtg,pan hd ,6-20 x 0.438, (2)
24 240373102 A B Frame-full shelf, cantilever
25 240364714 A B Cover-crisper pan
25B 240361201 A B Control-humidity
25C 240361301 A B Damper, humidity cont.
26 240337103 A B Pan-crisper, clear ,(2) ,no graphics
29 240357701 A B Trim-shelf, 24.48" ,front
31 240530803 A B Pan-meat, w/o graphics ,clear
36 240373103 A B Frame-half shelf,cantilever
37 240357702 A B Trim, shelf, 11.95" ,front
40 240443908 A B Glass-shelf, 24.45" x 15.92" ,full width
41 240357801 A B Trim-shelf, 24.48" ,rear
42 240530601 A B Track, meat pan hanger ,LH
42 240530701 A B Track, meat pan hanger ,RH
43 240443905 A B Glass-shelf, 11.92" x 15.92", half shelf
44 240357802 A B Trim, shelf, 11.95", rear
47 240350643 A B Insert-pan cover, glass
81 5308016566 A B Screw, hex washer head, 8-15A x 0.625, low profile
123 215005100 A B Screw, hanger/rlr mtg, 8-10 x 0.438
SHELVES

11/03 8
Publication No. FRT18P6C
5995398954
SYSTEM

# = Fast-moving Parts 9 11/03
* = Non-Illustrated Parts
FRT18P6C Publication No.
5995398954
A = FRT18P6C (FRT18P6CQ3)
B = FRT18P6C (FRT18P6CQ5)
POS. NO PART NO DESCRIPTION
1 240444401 A B Condenser,dynamic
4 # 218944001 A B Drier-filter,R134a System
6 # 240581701 A B Harness-wiring,machine compt
6* # 240581801 A B Harness-wiring,compressor
6* # 240388701 A B Wiring Harness,control box
6* # 240524701 A B Wiring Harness,freezer section
14 # 5303918208 A B Defrost Heater Kit
15 # 5303918274 A B Evaporator Kit
16 5308000110 A B Strap-evap/heater,aluminum ,(2)
17 240434004 A B Trough-drain
20 240518402 A B Insulation,evap block ,foam ,LH/RH
21 # 5303918202 A B Thermostat-defrost,kit
22 240330001 A B Plate-compr mtg
22* 218252200 A B Screw, #8 truss hd, 10-32CA x 0.500
23 218513300 A B Grommet-compr mtg, (4)
25 240491501 A B Screw-compressor mtg,1/4-28 x 1.16, shoulder, typ CF
26 240332601 A B Pan-defrost drain
29 # 5303918297 A B Compressor, w/electricals
30 # 5304433579 A B Relay
31 # 5304433578 A B Overload Protector
34 240405201 A B Grommet, rubber, black, cond tube/wire
41 240555001 A B Screw-#8-32 X 3/8
44 215174700 A B Clamp-service cord, strain relief, galv steel
45 5308016566 A B Screw,hex washer head, 8-15A x 0.625, low profile
56 240582001 A B Cover-terminal
57 240542601 A B Clip-wiring harness
58 215004600 A B Screw,hx serr wshr hd ,8-36 x 7/16, cond fan motor, (2)
59 240315501 A B Shroud-cond fan
59* 240346701 A B Tape-foam seal, shroud
59* 240359401 A B Screw-fan shroud, (2)
59A 240346501 A B Bracket-support, cond mtr ,(3)
59B 240346601 A B Grommet-bracket, (3)
60 # 240334001 A B Motor,condenser fan
61 # 240315401 A B Fan Blade, galv steel, condenser fan
61A 215004700 A B Nut, speed
61B 215004800 A B Grommet-silencer
82 5304418225 A B Roller,compressor base ,rear ,(2)
83 5303316859 A B Rivet,flat head ,1/4 OD x 1-3/4, roller pin
84 240500801 A - Tube-drain, rubber, lower
85 240493101 A B Tube-connector, suction
86 240409302 A B Spacer-cond tube, black
* 3205266 A B Edge Protector, wiring harness
* 240396801 A B Clamp, tube/wiring, nylon, black/natural
* # 5303918207 A B Heat Exchanger Kit, suction line
* # 5303918222 A B Hot Tube Repair Kit,Service
SYSTEM

11/03 10
Publication No. FRT18P6C
5995398954
WIRING SCHEMATIC

# = Fast-moving Parts 11 11/03
* = Non-Illustrated Parts
FRT18P6C Publication No.
5995398954
WIRING DIAGRAM
