Frigidaire FRT18QGFW3 User manual

Product Registration.................................. 2
Important Safety Instructions................... 2
Versión en Español ..................................... 2
First Steps................................................... 3
Energy Saving Ideas .................................. 4
Setting the Controls................................... 4
Temperatures ....................................... 4
Energy Saver Switch........................... 4
Moisture ............................................... 4
Fresh Food Storage................................. 5-6
Care and Cleaning ...................................7-8
Automatic Ice Maker................................. 9
Reversible Door Instructions..............10-12
Avoid Service Checklist .....................13-15
Normal Operating Sounds ....................... 15
Warranty (United States)........................ 16
Service Information (Canada)................. 17
Warranty (Canada) .................................. 18
P/N 218777700D (9903)

2
Record the Model Number and Serial Number of this refrigerator in the space
providedbelow.Thesenumbersarefoundontheserialplatelocatedonthetopleft
walloftherefrigeratorcompartment.
Model Number:
Serial Number:
Register Your Product
The self-addressed PRODUCT REGISTRATION CARD should be filled in completely,
signedandreturnedtoFrigidaire,orinCanada,FrigidaireCanada.
Readall instructionsbeforeusing thisrefrigerator.
For Your Safety
Donotstoreoruse gasoline orotherflammablevaporsandliquidsinthevicinity of
thisoranyotherappliance.Readproductlabelsforflammabilityandotherwarnings.
Child Safety
• Destroycarton, plastic bags,andanyexterior wrapping materialimmediately
aftertherefrigeratorisunpacked.Childrenshouldneverusetheseitemsforplay.
Cartons covered with rugs, bedspreads, plastic sheets or stretch wrap may
becomeairtight chambers andcanquickly cause suffocation.
• Remove all staples from the carton. Staples can cause severe cuts and destroy
finishesifthey comeincontactwithother appliancesorfurniture.
• Anempty,discardedicebox,refrigeratororfreezerisaverydangerousattraction
to children. Remove the door of any appliance that is not in use, even if
itis beingdiscarded.
ElectricalInformation
These guidelines must be followed to ensure that safety mechanisms in the
design of this refrigerator will operate properly.
•The refrigerator must be plugged into its own 115 Volt, 60 Hz, AC only
electrical outlet. The power cord of the appliance is equipped with a 3-prong
grounding plug for your protection against shock hazards. It must be plugged
directly into a properly grounded 3-prong receptacle. The receptacle must be
installed in accordance with local codes and ordinances. Consult a qualified
electrician. DO NOT USE AN EXTENSION CORD OR AN ADAPTER PLUG.
• Ifvoltagevariesby10percent ormore,performanceofyourrefrigeratormaybe
affected. Operating the refrigerator with insufficient power can damage the
compressor.Suchdamage is not covered underyourwarranty.Ifyoususpectyour
voltageishigh or low,consultyourpowercompany for testing.
• Topreventtherefrigeratorfrombeingturnedoffaccidentally,donotplugtheunit
intoanoutletcontrolled byawallswitchorpullcord.
• Do not pinch, knot, or bend the power cord in any manner.
Other Precautions
• Neverunplugtherefrigeratorbypullingon the power cord. Always grip the plug
firmlyandpullstraightoutfromthereceptacle.
• Toavoidelectrical shock, unplug therefrigeratorbeforecleaningandbefore
replacingalightbulb.Note:TurningthecontroltoOFFturnsoffthecompressor,but
doesnotdisconnectpowertothelightbulborotherelectricalcomponents.
• Donotoperate the refrigerator inthepresenceofexplosive fumes.
• Iftherefrigeratorhasanautomaticicemaker,avoidcontactwithanymovingparts.
Product Registration
Versión en español
Si desea obtener una copia en español
deeste Manual delUsuario,sírvase
escribirala direcciónqueseincluyea
continuación.SolicitelaP/N218777800.
Spanish Owner's Guides
FrigidaireHomeProducts
P.O. Box 212378
Augusta, GA 30917
Important Safety
Instructions
Avoid fire hazard or
electricshock.Do not use anextension
cord or an adapter plug. Do not remove
any prong from the power cord.
© 1999WhiteConsolidatedIndustries,Inc.
Allrightsreserved.
Proper Disposal of
Your Refrigerator/Freezer
Risk of child entrapment.
Child entrapment and suffocation are
not problems of the past. Junked or
abandonedrefrigeratorsorfreezersare
stilldangerous—eveniftheywillsitfor
"justafewdays."Ifyouaregettingridof
youroldrefrigeratororfreezer,please
follow the instructions below to help
preventaccidents.
BEFORE YOU THROW AWAY YOUR
OLD REFRIGERATOR/FREEZER:
Remove
doors.
Leave
shelvesin
placeso
children
may not
easilyclimb
inside.

3
FirstSteps
1"
1"
1/2"
1/2"
3" AIR SPACE
Clearance
Properaircirculationandlevelingwill
ensureefficientoperation.
Before starting the refrigerator, follow these important first steps:
Location
• Choose a place that is near a grounded electrical outlet. DO NOT use an
extensioncord or anadapter plug.
• Ifpossible, place the refrigeratoroutofdirect sunlight andawayfromthe
range,dishwasher or otherheatsources.
• Therefrigerator must beinstalledon afloorthat is levelandstrong enough
tosupportafullyloadedrefrigerator.
• Considerwater supply availability formodelsequippedwith an automatic ice
maker.
Installation
• Do not install the refrigerator where the temperature will drop below 60°F
(15°C)or rise above110°F(43°C).The compressor willnotbe able tomaintain
propertemperatures.
• Allow space around the unit for good air circulation. Leave a 1 inch (25 mm)
space behind and a 3 inch (75 mm) space above the refrigerator for adequate
circulation.
• In a recessed installation, allow an extra 1/2 inch (10-15 mm) on each side
foreaseofinstallation.
• Forbestcirculation,elevatetheunit1inch(25mm) fromthefloor,especially
iftheflooriscarpeted.
Door Opening
The doors should open to allow easy access to a counter when removing food.
• Do not position the refrigerator so you have to walk around the refrigerator
doors.
• Reversethedoorsif necessary.See"ReversibleDoorInstructions."
Leveling
All four corners of refrigerator must rest firmly on a solid floor. Some models
areequippedwithadjustablescrew-typelevelers.Othersareequippedwithrollers.
Ifyourrefrigeratordidnotcomewithrollers,theycanbepurchasedfromyourdealer.
•Toadjust screw-typelevelers (some models): Tip cabinet back slightly and
raiseadjustingboltsasneeded.
•To adjust front rollers (some models): Use a screwdriver, 3/8" socket
wrench,ornutdrivertoadjustrollersasshown.
RAISETHE FRONT of cabinet enough so doors will close freely when opened halfway.
Levelcabinetsidetoside.
Cleaning
• Wash the inside, all removable parts and the outside with mild detergent and
warm water. Wipe dry. DO NOT USE HARSH CLEANERS ON THESE
SURFACES.
• Do not use razor blades or other sharp instruments, which can scratch the
appliance surface, when removing adhesive labels. Any glue left from the
tape or energy label can be removed with a mixture of warm water and mild
detergent,or,touch the glue with thestickysideoftapealreadyremoved.
• DO NOT REMOVE THE SERIAL PLATE.
Sunken bolt (some models)
Exposed bolt (some models)

4
• Locatetherefrigeratorinthecoolestpartoftheroom,outofdirectsunlightand
awayfromheatingducts orregisters.Donotplacetherefrigerator nexttoheat-
producingappliancessuchasarange,ovenordishwasher.Ifthis isnotpossible,
a section of cabinetry or an added layer of insulation between the two
applianceswillhelptherefrigeratoroperatemoreefficiently.
• Leveltherefrigeratorsothedoorsclosetightly.
• RefertothisOwner's Guide for thesuggestedrefrigeratorsettings.
• Periodiccleaningofthecondenserwillhelptherefrigeratorrunmoreefficiently.
See Outside in the "Care and Cleaning" section.
• Do not overcrowd the refrigerator or block cold air vents. Doing so causes the
refrigeratortorunlonger and use more energy.Shelvesshouldnotbelinedwith
aluminum foil, wax paper or paper toweling. Liners interfere with cold air
circulation, making the refrigerator less efficient, which could cause food
spoilage.
• Cover foods and wipe containers dry before placing them in the refrigerator.
This cuts down on moisture build-up inside the unit.
• Organize the refrigerator to reduce door openings. Remove as many items as
needed at one time and close the door as soon as possible.
Setting the Controls
Energy Saving Ideas
G05C0065
RefrigeratorControl
G05C0066
eco
EnergySaver
G05C0061
FreezerControl
Cool Down Period
To ensure safe food storage, allow the refrigerator to operate with the doors
closed for at least 8 to 12 hours before loading with food.
Refrigerator and Freezer Controls
• Tostartout, set control dials tothemidpointforatrial period of 24 hours.
Temperatures
• After 24 hours, adjust the controls as needed. Adjust temperatures one
number at a time. For colder temperatures, turn the dial toward COLDEST.
For warmer temperatures, turn the dial toward COLD. The temperature will
increase or decrease, but not necessarily by 1, 2, or 3 degrees.
An adjustment made to one compartment may require an adjustment to the
other.
• Turning the refrigerator control will change the temperature in BOTH
compartments.If the refrigerator control is turned to OFF, cooling stops
in both compartments.
• Turning the freezer control will change only the temperature in the
freezer compartment.
To maintain temperatures, a fan circulates air in the refrigerator and freezer
compartments. For good circulation, do not block cold air ventswith food items.
Energy Saver Switch (some models)
If your refrigerator is equipped with an Energy Saver Switch, keep it set on
ENERGY SAVER for lowest energy usage.
Moisture
During humid weather, or if moisture appears on the cabinet between the doors,
set switch to REDUCE EXTERIOR MOISTURE. A heater will warm the surface and
allow moisture to evaporate.

5
G05I0134
Fresh Food Storage
CantileverShelf
SlidingShelf
CombinationCantilever/Sliding Shelfwith
PlasticClip
Remove Shipping Clips
Bin
Bin Snugger
Micro-Serve Dishes
Shelf Adjustment
Refrigeratorshelvesareeasilyadjustabletosuitindividualneeds.Beforeadjusting
shelves,removeallfood.Theshippingclips,whichstabilizetheshelvesforshippingmay
beremoved and discarded.
Toadjustslidingshelves, removebypullingforwardtothe
stopposition,thenliftthefrontedgeupandpullout.Replace
onanypairofrailsbyreversingthisprocedure.
Toadjustcantilevershelves (shelvessupportedattherearof
therefrigerator),liftthebackoftheshelfupandout.Replace
shelfbyinsertinghooksatrearintowallbracket.Lowerand
lockintoposition.
Toadjustcombination cantilever/slidingshelves, remove
shelfbyliftinghooksupandoutofrearwallbracket.Then
flexplasticcliptowardscenterofrefrigeratorandpullshelf
straightout.Replaceshelfbyslidingplasticclippastside
wallsupport. Thenlockhooksatrearinto wall bracket.
Note: Plasticclipwillautomaticallyfitsecureagainstside
wall.
Spillsafe glassshelves(somemodels) catchandholdaccidentalspills.Insome
models,the Spillsafe shelvesslideoutforeasyaccesstofoodandfastcleaning.
Theshelvesslideoutindependentlyofthecantileverbrackets.Justpullfrontofshelf
forward.Shelfcanbeextendedasfarasstopperwillallowand is not removable from
thecantileverbracket.
Door Storage
Doorbinsandshelvesareprovidedforconvenientstorageofjars,bottles, andcans.
Itemsusedoftenareavailableforquickselection.
Some models have adjustable door bins which can be moved to suit individual
needs.Tomovethebins,removeby lifting straight up. Place the bin in thedesired
positionandlowerover supports.
The Dairy Compartment is warmer than the general food storage section and is
intendedforshort termstorageofcheese,spreads,orbutter.
Micro-Serve Dishes (some models)
Food can be stored, cooked*, and served in Micro-Serve Dishes provided in some
models.Thesedishesslideeasilyintotheirowntray,whichhangsbelowadoorgallon
bin,convenientlyfreeingshelfspaceforotheritems. Seeillustration. *Removeplastic
lidbefore cooking. Lidisintendedfor storageonly.
Crispers
Thecrispers,locatedunderthebottomrefrigeratorshelf,aredesignedforstoring
fruits,vegetables, and otherfreshproduce.Wash items inclearwaterand remove
excesswaterbefore placinginthecrispers.Itemswithstrongodorsorhighmoisture
shouldbewrappedbeforestoring.Insomemodels,thecrispersaredrawers,inothers,
theyaretilt-outbins.
Tilt-OutCrisper(some models)

6
Fresh Food Storage
(continued)
FRESH FRUITS & VEGETABLES
LOWER
FRUITS
HIGHER
HUMIDITY CONTROL
VEGETABLES
AdjustableHumidity Control
The Humidity Control (some models with Crisper drawers) allows you to adjust the
humiditywithintheCrisper.Thiscan extend thelifeoffreshvegetableswhichkeep
best in high humidity. Leafy vegetables, however, keep best when stored with the
HumidityControlseton HIGH, or in adrawerwithoutaHumidityControl.Thiskeeps
incoming air to a minimum and maintains maximum moisture content.
Deli Drawer (some models)
Some models are equipped with a Deli Drawer for storage of luncheon meats,
spreads,cheeses,and otherdeliitems.
Meat Pan (some models)
Some models are equipped with a Meat Pan that can be positioned below any
refrigeratorshelf.Usethispanforshorttermstorageofbulkmeatitems.Ifmeats
are to be kept longer than 1 or 2 days, they should be frozen.
The Chilled Air Duct can also switch sides, should you wish to move the split
cantilever shelf. To change sides:
• Remove Meat Keeper drawer and shelf. Remove screw. Grasp air duct, push
and tip back to "unlock" it from the air outlet box.
• Move air duct to the other side, and push into place. Reinstall screw.
• Replace shelf and insert drawer.
Wine Rack (some models)
Thewinerackstores bottles of wine, orsingle2-literplasticbottlesofjuiceor
soda pop. To install, slide wine rack onto the shelf with the curve facing in. To
remove, slide wine rack out. Install on either side of a Spillsafe™ shelf.
Meat Keeper (some models)
The temperature in the Meat Keeper drawer can be made colder than the rest
of the refrigerator compartment by adjusting the Chilled Air Control. Meatwill
bepartially frozen, andmaybe kept freshlongerthan if storedona refrigerator
shelf.
Before placing items in Meat Keeper, follow these steps to keep meat fresh.
1. Carefully handle meat with clean hands, and always keep compartment clean.
2. Store meat in its original wrapper. If necessary, overwrap in plastic wrap, or
foiltopreventdrying. Wrapfishtightlytopreventodortransfertootherfoods.
3.Ifspoilageever occurs, disinfect the compartmentwithliquidchlorinebleach
followinglabel directions.Then,rinsewithasolutionofbakingsoda,andwater.
Rinse with clear water, and dry.
ChilledAirControl
Wine Rack
Adjustingthe ChilledAirDuct

7
Care and Cleaning Keepyourrefrigeratorandfreezercleantopreventodorbuild-up.Wipeupanyspills
immediately and clean both sections at least twice a year. Never use metallic
scouringpads,brushes,abrasivecleanersorstrongalkalinesolutionsonanysurface.
Do not wash any removable parts in a dishwasher.
Always unplug the power cord from the wall outlet before cleaning. Turning
thecontrol to OFFdoesnot disconnect powertothe controls, lightbulb,or other
electricalcomponents.
Inside
Washinsidesurfacesoftherefrigeratorandfreezerwithasolutionof2 tablespoons
baking soda in 1 quart warm water. Rinse and dry thoroughly. Be sure to wring
excess water out of sponge or cloth before cleaning around the controls,
lightbulb, or anyelectricalparts.
Washremovable parts suchasshelvesand drawers withbakingsodasolution or mild
detergent and warm water. DO NOT USE HARSH CLEANERS ON THESE SUR-
FACES. Rinseand dry thoroughly.Cleanthedoor gaskets withmildsuds,rinse with
clearwater and wipedry.Do not userazorblades or othersharpinstruments which
canscratchtheappliancesurfacewhenremovingadhesive labels. Any glue leftfrom
the tape or energy label can be removed with a mixture of warm water and mild
detergent, or, touch the residue with the sticky side of tape already removed. DO
NOT REMOVE THE SERIAL PLATE.
Damp objects stick to cold
metal surfaces. Do not touch
refrigeratedsurfaces with wetordamp
hands.
Outside
Washthe cabinet and handleswithwarmwater and mildliquiddetergent.Rinsewell
andwipe drywitha clean softcloth.
Whenmovingtherefrigerator,pull straight out.Donotshifttherefrigeratorfrom
sidetosideasthismaytearorgouge the floor covering. If the refrigerator has an
automatic ice maker, be careful not to move the refrigerator beyond plumbing
connections.
Periodically clean the condenser (black tubes and wires on the back of the
refrigerator).Usingavacuumwith its dustingtoolattachment,vacuumthecoilsto
remove dust build-up. Do not allow lint or dust to accumulate on the coils.
Thedefrostwaterpanislocatedatthebottomrear of the refrigerator on top of the
compressor (shown left). The pan should be cleaned periodically. Wipe clean with
a damp cloth.
Replacing the Light Bulb
To replace the light bulb:
1. Unplugtherefrigerator.
2. Wearglovesasprotectionagainstpossiblebrokenglass.
3. Replace old bulb with an appliance bulb of the same wattage.
4. Remember to plug the refrigerator back in.
To avoid damage and help
therefrigerator run asefficientlyas
possible, clean the condenser
periodically.

8
Care and Cleaning
(continued)
Vacation and Moving Tips
Shortvacations: Leavetherefrigeratoroperating during vacationsof1to3weeks.
Useupallperishableitemsfromtherefrigeratorsection.Wrapandstoreotheritems
inthefreezer. If the unithasanautomaticicemaker, turn off theicemaker.
Long vacations: Remove all food and ice if you will be gone 1 month or more. Turn
thecontroltoOFFanddisconnectthepower.Iftheunithasanautomaticicemaker,
turnofftheicemakerandturnthewatersupplyvalvetotheclosedposition.Defrost
andcleantheinteriorthoroughly.Leavebothdoorsopentopreventodorandmold
buildup.Blockopenifnecessary.
Moving: When moving the refrigerator, follow these guidelines to prevent
damage:
• Remove all food and other items from refrigerator and freezer
compartments. Empty the ice storage bin. Defrost and clean the
interiorthoroughly.
• Ifahandtruckisused in moving,loadtherefrigeratorfromtheside.
• Turnfrontrollersasfarupaspossible(somemodels).Thiswillprotectthem
duringslidingormoving.
• The cabinet should be well padded and handled with care. DO NOT DROP.

9
Automatic Ice Maker Ifyourrefrigeratorhasanautomaticicemaker,itwillprovideacontinuoussupplyof
ice for normal use. The automatic ice maker is an optional accessory which may be
installedinmostmodelsatanytime.Callyourlocaldealerforinstallation.
After the plumbing connections have been completed, the water supply valve must
be opened. Place the ice container under the ice maker, pushing it as far back as
possible. Lower the wire signal arm to its "down" or ON position. Because of new
plumbingconnections, the firstproductionofice cubes maybediscoloredor have
an odd flavor. Throw the ice away until the cubes made are free of discoloration
andtaste. Remember,waterqualitydeterminesyouricequality. Itis
besttoconnecticemakertowater that is NOT soft. Softening chemicals can damage
icemaker. Ifice makerisconnectedtosoftwater,makesuresoftenerismaintained,
andworkingproperly.
Tostoptheicemaker, lift the wiresignalarmuntilitclicks and locks inthe"up"
orOFFposition.Theicemakerturnsoffautomaticallywhentheicecontainerisfull.
Ifyourmodelhasanadjustablefreezershelf,placetheshelfsothe wire signal arm
willhittheicewhentheicecontainerisfull.
Ice Maker Tips
1. Ice stored too long may develop an odd flavor. Empty the container and be sure
the wire signal arm is in its "down" or ON position. The ice maker will then
produce more ice.
2. Occasionallyshakethecontainer to keep ice separated.
3. Keepthewiresignalarminits"up"orOFFpositionuntilrefrigeratorisconnected
tothe water supply orwheneverwatersupply is turned off.
4. Certain sounds are normal when the ice maker is operating. They are:
Motor operation
Ice being loosened from the tray
Icebeing dropped intothecontainer
Running water
Water valve opening and closing
For more information on these operations, see "Normal Operating Sounds."
5. Wash ice container in warm water with mild detergent. Rinse well and dry.
6. Stopthe icemakerwhen cleaning thefreezer or forshortvacations.
7. Iftheicemaker willbeturnedoffforalong periodoftime,turnthewatersupply
valvetotheclosedposition.

10
or
4. Remove hinge pin, hinge, and the two
screws attaching the lower hinge. Save
the hinge, hinge pin, washer (some
models) and screws for reassembly
later.
G05I0101
FreezerDoor
G05I0090
6. After the handles are removed (see
steps 7 and 8), remove door stop from
bottomof freezer and refrigeratordoor
andreinstallonoppositeside.
RefrigeratorDoor
G05I0103 new
G05I0106 new
2. Open the freezer door enough to
allowittobeliftedoffthecenterhinge. 3. With the refrigerator door closed,
remove center hinge pin. (Note the
arrangement of the upper and lower
washers (some models) on the hinge pin.
Thewashersmustbeassembledlaterinthe
same manner.) Open refrigerator door
enough to allow door to be lifted off the
lower hinge. Remove the two screws
attaching the center hinge. The third
outermost screw under the center hinge
should be left in place. Savehinge, pin,
and washers (some models) for
reassembly later. Reinstall screws in
originalholes.
5. Carefullyremove theholeplugs from
thehingeholesinthecentermullionand
top of cabinet and reinstall in the
oppositesetofholes.
Yourrefrigeratorisequippedwithconvertibledoorhinges.Hingingof the door can
be changed to the opposite side any time you wish. An envelope containing extra
plasticholeplugsisincludedinsomemodels.TurntherefrigeratorcontroltoOFF.
Remove all food, bottles, and other items from the door. Beginwith freezerdoor.
Completely remove one door before beginning the other.
Reversible Door
Instructions
1.RefertotheInstructionSheet,packed
with the Toe Grille, to remove the Toe
Grille (some models). Snap off hinge
cover at top of cabinet (some models).
With the freezer door closed, remove
the two screws attaching upper hinge to
cabinet. Lift the hinge up and off. Be
sure to save screws and hinge for
reassembly later.

11
G05I0111
G05I0118
RefrigeratorDoor
FreezerDoor
Reversible Door
Instructions (continued)
8. Trim Removal (Full-Length Trim models only)
Insomemodels,therefrigerator door has a fulllength trim
piece which continues from the bottom of the handle to the
bottom of the door. The top of the trim attaches to the
handlebracket.Anadhesive"trimlock"ispositionedabout
half-way down. The bottom of the trim is held in place by
eitheran adhesive trimlock,ora trim lock withtwoprongs
insertedintoa hole on thefaceofthedoor. Remove the trim
by gently pulling the trim lock areas out and away from the
door. When the trim is free from the door, slide the trim
straight down and away from the handle bracket.
For models with short handle trim, remove by sliding the
trim straight down and off of handle bracket.
To remove handles: Remove the three screws attaching
thehandle to the refrigeratordoor.Carefullyremove hole
plugs from corresponding holes on opposite side of doors
andreattach handle.
Toreattachtrim: Slidebothtrim locks outoftrim. Insert
the new adhesive trim locks contained in your literature
pack. NOTE: Trim lock must be removed and installed by
sliding OVER the two donut shaped areas. Install trim to
handlebyslidingupover bottom of handle. Carefullyalign
trim and press down at trim lock locations. Replace hole
plug on opposite side. Use rubbing alcohol to remove any
adhesiveresiduefromoldtrimlocklocation(s).
Formodelswithshorthandletrim, slidethetrimstraightup
ontohandlebracket.
7. Magnetic Nameplate (some models)
Reverse handles while doors are off. Remove the two screws
attaching the handle to the bottom of the freezer door. Remove
shorttrimpiecebyslidingthetrimstraight up and off of handle
bracket. Remove the screw attaching the top of the handle to
door, and reinstall on other side, using the same holes as the
nameplate. To move nameplate to other side, remove the
magnetic nameplate from its frame, turn frame upside down
andinstall in oldhandleholes.Insert magnetic nameplateinto
frame. Reattach handle to bottom of door. Slide the trim piece
straight down onto handle bracket.
Self-adhesive Nameplate (some models)
Reverse handles while doors are off. Remove the two screws
attaching the handle to the bottom of the freezer door. Remove
shorttrimpiecebyslidingthetrimstraight up and off of handle
bracket. Remove the screw attaching the top of the handle to
door,and reinstall on other side, using the holes found behind
the self-adhesive nameplate. To move nameplate to the other
side, peel off the nameplate and reapply over the old handle
holes. Reattach handle to bottom of door. Slide the trim piece
straight down onto handle bracket.

12
Reversible Door
Instructions (continued)
G05I0105
11. Place original washer (some models)
overholeinrefrigeratordoorandlineup
hole in center hinge. Insert hinge pin
through both holes. Place washer (some
models) on hinge pin, then position
freezer door on center hinge.
Bearing Plug
12. Remove plug from upper bearing
ofdoor and reinstallonopposite side.
G05I0104 new
13. Assembleupperhingetotopofcabinet
anddoor.Useoppositesetofholes.Donot
completelytightenscrews.
Align doors so there is a parallel gap
between doors. Adjust doors to cabinet so
gaskets seal but do not bind. Tighten
upper and lower hinge screws.
Additional adjustment may be necessary
after loading the door shelves. Return
food,bottles,andotherarticlesto doors.
Turn the refrigerator control on and to
the previous setting.
Refer to the Toe Grille Assembly
InstructionSheetin theliteraturepack to
replacetheToeGrille(somemodels).
or
9.Ifyourrefrigeratordoes not have a Toe
Grille, use a putty knife to remove the
plasticplug(notshown) from front ofbase
and reinstall in the opposite set of lower
hinge holes. Assemble lower hinge to
cabinet.Installhingepininoppositehinge
holefromwhichit was removed. Installthe
washer (some models) on the lower hinge
pin and insert hinge screws, but do not
tighten. Hinges will have to remain loose
againstcabinettoaligndoor.
10. Turn center hinge upside down and
secure to cabinet as shown, using the
screws which are in the new holes. Install
refrigeratordooron lowerhingepin.Align
door with edge of cabinet. Hold the door
onfrontofcabinet.

13
Beforecallingforservice,reviewthis list.Itmaysaveyoubothtimeand expense.
Thislistincludescommonoccurrencesthatarenottheresultof defectiveworkman-
shipormaterialsinthisappliance.
Avoid Service Checklist
RUNNING OF REFRIGERATOR
OCCURRENCE
Refrigerator compressor does not run. Refrigeratorcontrol isoff.Setrefrigeratorcontrol. SeeSettingtheControls.
Refrigeratorisindefrostcycle.Thisisnormalforafullyautomaticdefrostingrefrigerator.Thedefrost
cycleoccurs periodically,lastingabout 20minutes.
Plugat wall outletis disconnected.Make sureplugis tightlypushed intooutlet.
House fuse has blown or circuit breaker has tripped. Check and/or replace fuse with a 15 amp time-
delayfuse.Resetcircuitbreaker.
Power outage. Check house lights. Call local electric company.
Roomor outsideweather ishot. Itis normalfor therefrigerator toworklongerunderthese conditions.
Refrigerator has recently been disconnected for a period of time. It takes about 8-12 hours for the
refrigeratorto cool downcompletely.
Automatic ice maker is operating (some models). Operation of the ice maker causes the refrigerator
torunslightly more.
Doorsare opened toofrequently ortoo long. Warmair enteringthe refrigeratorcauses it torun more.
Open the doors less often.
Refrigerator or freezer door may be slightly open. Make sure refrigerator is level. Keep food and
containers from blocking door. See Occurrence section OPENING/CLOSING OF DOORS/DRAWERS.
Refrigeratorcontrol (foundinrefrigeratorsection)is settoo cold.Setthe refrigeratorcontrol toa
warmersetting untilthe refrigeratortemperature issatisfactory.Allow24hoursforthetemperature
tostabilize.Then,ifthe freezertemperatureis notright,set thefreezercontrol toacolder setting.
Refrigeratoror freezergasketisdirty,worn, cracked,or poorlyfitted.Clean orchange gasket.Leaks
indoor seal willcause refrigeratorto runlongerin orderto maintaindesired temperatures.
Thermostatis keepingtherefrigeratorata constanttemperature.This isnormal. Refrigeratorgoeson
and off to keep temperature constant.
Freezercontrolissettoocold.Setthe freezercontroltoawarmer settinguntilthefreezertemperature
issatisfactory.Allow24hoursforthetemperaturetostabilize.
Refrigeratorcontrol isset toocold. Settherefrigeratorcontrolto awarmer setting.Allow 24hours
fortemperatures tostabilize.Then, ifthefreezer temperatureis notright, setthefreezercontrolto
acoldersetting.
Refrigeratorcontrol issettoocold.See abovesolution.
Doors are opened too frequently or too long. Warm air enters the refrigerator whenever the door is
opened. Open the door less often.
Door is open slightly. See Occurrence section OPENING/CLOSING OF DOORS/DRAWERS.
Condenser is dirty. Clean condenser. See "Outside" in Care and Cleaning.
Freezercontrolissettoowarm.Setthe freezercontroltoacolder settinguntilthefreezertemperature
issatisfactory.Allow24hoursforthetemperaturetostabilize.
Refrigeratorcontrol issettoowarm. Refrigeratorcontrol hassome effectonfreezer temperature.Set
therefrigeratorcontroltoacoldersetting.Allow24 hoursforthetemperatureto stabilize.Then,ifthe
freezer temperature is not right, set the freezer control to a warmer setting. Refer to Setting the
Controls.
SOLUTION
Refrigerator runs too much or too
long.
Refrigerator compressor goes on and
offfrequently.
Temperature in the freezer is too cold
and the refrigerator temperature is
satisfactory.
Temperature in the refrigerator is too
cold and the freezer temperature is
satisfactory.
Food stored in drawers freezes.
Temperature in the freezer or
refrigerator is too warm.
Temperature in the freezer is too warm.
Temperature in the refrigerator is too
warm and the freezer temperature is
satisfactory.
TEMPERATURES ARE TOO WARM
TEMPERATURES ARE TOO COLD

14
SOLUTION
OCCURRENCE
AUTOMATIC ICE MAKER (some models)
BRASS FITTING
SCREEN
INLET, WATER LINE
OUTLET TO ICE MAKER
Weatheris hotand humidwhich increasesrate offrost buildupand internalsweating. Thisis normal.
Door is slightly open. See Occurrence section OPENING/CLOSING OF DOORS/DRAWERS.
Door is opened too often or too long. Open the door less often.
Vegetables contain and give off moisture. It is not unusual to have moisture on the bottom side of
thecover.
Washed vegetables and fruits drain while in the drawer. Dry items before putting them into drawer.
Water collecting in bottom of drawer is normal.
Weather is humid. This is normal in humid weather. When humidity is lower, the moisture should
disappear. Set Energy Saver switch to the Reduce Exterior Moisture position.
Door is slightly open, causing cold air from inside the refrigerator to meet warm air from outside.
See Occurrence section OPENING/CLOSING OF DOORS/DRAWERS.
Icemaker wiresignalarm isin "up"or OFFposition. Move wire signal arm to "down" or ON position.
Household water line valve is not open. Turn on household water line valve.
Watersupply valvein refrigerator isbeing blockedby foreignmaterial. Unplugthe refrigeratorand
turn off water supply. Slide refrigerator out and locate where water is connected to the valve.
Unscrew the brass fitting and pull out the screen from inside the valve mesh. Clean the screen of
foreignmaterial. Replacescreen andbrassfittingandturn thewater supplyon;checkforleaks. Plug
inrefrigeratorandslideintoplace.
Freezer is not cold enough. See Occurrence section TEMPERATURES ARE TOO WARM.
Saddlevalve oncold waterpipeis blockedor restrictedby foreignmaterial.Turnoffhousehold water
linevalve. Remove,clean orreplace valve.
Ice maker is producing less ice than you expect. Ice maker should produce approximately
2 1/2 to 4 pounds of ice every 24 hours.
Freezer is not cold enough. See Occurrence section TEMPERATURES ARE TOO WARM.
Household water line valve is not completely open. Turn on household water line valve.
Watersupply valve inrefrigerator isbeing blocked byforeign material.See Occurrence, "Icemaker
is not making any ice" above.
Ice maker wire arm is being held down by an item in the freezer. Remove item and release arm.
Remove any ice cubes which are frozen together over arm.
Ice cubes are not being used frequently enough. Remove and shake ice bucket to separate cubes.
Icehaspickedup odororflavorfromstrongfood storedinrefrigeratororfreezer.Cover foodstightly.
Discardstale ice. Icemaker willproducefresh supply.
Water running to ice maker has poor taste or odor. Add filter to ice maker. Consult a water
purifying company.
Interior needs to be cleaned. Clean interior with sponge, warm water and baking soda.
Foodwith strongodor isinrefrigerator. Coverfood tightly.
Door is not designed to swing shut automatically. Close door securely.
Door was closed too hard, causing other door to open slightly. Close both doors gently.
Refrigeratorisnotlevel.Itrocksonthefloorwhenitismovedslightly.Besureflooris levelandsolid
andcan adequately supportrefrigerator. Adjustrollers asneeded.
WATER/MOISTURE/FROST OUTSIDE REFRIGERATOR
Ice maker is not making enough ice.
Ice maker will not stop making ice.
Ice maker is not separating the cubes.
Ice has bad odor and taste.
Door(s) will not close.
OPENING/CLOSING OF DOORS/DRAWERS
Moisture collects on inside of refrigerator
walls.
Water collects on bottom side of drawer
cover.
Water collects in bottom of drawer.
Moisture forms on outside of refrigerator
or between doors.
Ice maker is not making any ice.
WATER/MOISTURE/FROST INSIDE REFRIGERATOR
ODORS IN REFRIGERATOR

15
SOLUTION
OCCURRENCE
OPENING/CLOSING OF DOORS/DRAWERS
Drawers are difficult to move.
Floorisunevenorweak.Refrigeratorrocksonthefloorwhenitismovedslightly.Besurefloorislevel
andcanadequately supportrefrigerator.Contact carpentertocorrectsagging orslopingfloor.
Refrigerator is touching the wall or cabinets. Be sure floor is level and can adequately support
refrigerator. Contactcarpenter tocorrectsagging orslopingfloor.
Food is touching shelf on top of drawer. Keep less food in drawer.
Trackthatdrawers slidesonis dirty. Cleandrawer and track.
Light bulb is burned out. See "Replacing the Light Bulb" in Care and Cleaning.
Lightswitch isstuck. Lightswitch islocatedontheceiling ofthe refrigeratorcompartment near
the temperature control box. Push in light switch to release.
No electriccurrent is reachingrefrigerator. See Occurrence section RUNNING OF
REFRIGERATOR.
LIGHT BULB IS NOT ON
EVAPORATOR
The flow of refrigerant through the
evaporator may create a boiling
or gurgling sound.
AUTOMATIC ICE MAKER *
Occasionally you will hear ice
cubes dropping into the ice bin.
COLD CONTROL & DEFROST TIMER
These parts can produce a snapping
sound when turning the refrigerator
on or off. The timer also produces
sounds similar to an electric clock.
INSULATION
Rigid foam insulation has excellent
insulating capabilities. It is very
energy efficient; however, it does
have a tendency to amplify sound.
EVAPORATOR FAN
You may hear air being forced
through the cabinet by the fan.
DEFROST HEATER
During defrost cycles, water dripping
onto the heater may cause a hissing
or sizzling sound. After defrosting, a
popping sound may occur.
WATER VALVE *
When the ice maker fills with
water, you will hear a buzzing
sound and water running.
COMPRESSOR
Modern, high efficiency compressors
operate much faster than older models.
The compressor may have a high-
pitched hum or pulsating sound.
* On models equipped with an Automatic Ice Maker.
Normal Operating
Sounds

16
FRIGIDAIRE, THROUGH ITS AUTHORIZED
SERVICERS, WILL:
Pay all costs for repairing or replacing any parts of this appliance
which prove to be defective in materials or workmanship.
Repairorreplace any parts in the cabinet liner or Sealed Refrigeration
System (compressor, condenser, evaporator, drier and tubing)
which prove to be defective in materials or workmanship.
All of the provisions of the full warranties above and the exclusions
listed below apply.
THE CONSUMER WILL BE
RESPONSIBLE FOR:
Costs of service calls that are listed under NORMAL
RESPONSIBILITIES OF THE CONSUMER.*
Costs for pick up and delivery of the appliance
required because of service. Costs for labor, parts
and transportation other than with respect to the
cabinet liner or Sealed Refrigeration System.
Costs of the technician's travel to the home and any
costs for pick up and delivery of the appliance
required because of service.
FULL ONE-YEAR
WARRANTY
LIMITED 2ND - 5TH
YEAR WARRANTY
(Cabinet Liner and
Sealed System)
LIMITED
WARRANTY
(Applicable to the
State of Alaska)
FRIGIDAIRE GALLERY REFRIGERATOR WARRANTY
YourFrigidaireproductisprotectedbythiswarranty
*NORMAL
RESPONSIBILITIES
OF THE CONSUMER
EXCLUSIONS
IF YOU NEED
SERVICE
This warranty applies only to products in ordinary household use, and the consumer is responsible for the
items listed below:
1. Proper use of the appliance in accordance with instructions provided with the product.
2. Proper installation by an authorized servicer in accordance with instructions provided with the appliance and in
accordance with all local plumbing, electrical and/or gas codes.
3. Proper connection to a grounded power supply of sufficient voltage, replacement of blown fuses, repair of loose
connections or defects in house wiring.
4. Expenses for making the appliance accessible for servicing, such as removal of trim, cupboards, shelves, etc., which
are not a part of the appliance when it was shipped from the factory.
5. Damages to finish after installation.
6. Replacement of light bulbs and/or fluorescent tubes (on models with these features).
This warranty does not cover the following:
1. CONSEQUENTIAL OR INCIDENTAL DAMAGES SUCH AS PROPERTY DAMAGE AND INCIDENTAL EXPENSES RESULTING
FROM ANY BREACH OF THIS WRITTEN OR ANY IMPLIED WARRANTY.
Note: Some states do not allow the exclusion or limitation of incidental or consequential damages, so this limitation
or exclusion may not apply to you.
2. Service calls which do not involve malfunction or defects in workmanship or material, or for appliances not in ordinary
household use. The consumer shall pay for such service calls.
3. Damages caused by services performed by servicers other than Frigidaire or its authorized servicers; use of parts other
than genuine Frigidaire Home Products parts; obtained from persons other than such servicers; or external causes
such as abuse, misuse, inadequate power supply or acts of God.
4. Products with original serial numbers that have been removed or altered and cannot be readily determined.
Keep your bill of sale, delivery slip, or some other appropriate payment record. The date on the bill establishes the warranty
period should service be required. If service is performed, it is in your best interest to obtain and keep all receipts. This
written warranty gives you specific legal rights. You may also have other rights that vary from state to state. Service under
this warranty must be obtained by contacting Frigidaire Home Products:
800•944•9044
Frigidaire Home Products
P.O. Box 212378
Augusta, GA 30917
Product features or specifications as described or illustrated are subject to change without notice. All warranties are made
by White Consolidated Industries, Inc. This warranty applies only in the 50 states of the U.S.A. and Puerto Rico.
Your appliance is warranted by White Consolidated Industries, Inc. We authorize no person to change or add to any of our obligations under this
warranty. Our obligations for service and parts under this warranty must be performed by Frigidaire or an authorized Frigidaire servicer.
WARRANTY
PERIOD
One year from
original purchase
date.
Second through
fifth years from
original purchase
date.
Time periods
listed above.

17
Service Information
(Canada)
To avoid unnecessary cost and inconvenience, make a few simple checks
before calling for service. Common occurrences and their solutions can be
foundin the AvoidServiceChecklist.Be sure you havefollowedthe instructions
inthis manual.
If you are unable to locate the cause of a problem, call for service. Insist on
factory service by an authorized FRIGIDAIRE PARTS AND SERVICE depot.
FRIGIDAIRE PARTS AND SERVICE
All Frigidaire appliances are backed by FRIGIDAIRE PARTS AND SERVICE, one
of Canada's largest parts and service networks.
The Frigidaire reputation means you can enjoy complete professional service
from one of our hundreds of trained technicians across the country.
FRIGIDAIRE PARTS AND SERVICE
7075 Ordan Drive
Mississauga,Ontario
L5T 1K6
Place the name, address and telephone number of your service depot in
the spaces below.
Product and feature specifications as described or illustrated are subject
to change without notice.

18
WARRANTOR:
FRIGIDAIRE HOME PRODUCTS
7075 Ordan Drive
Mississauga,Ontario
L5T 1K6
ThisrefrigeratorisabrandedproductofFrigidaireCanada.
WARRANTY PERIOD:
For two years after purchase by the original consumer/
owner:
For ten years after purchase by the original consumer/
owner:
Forservice under thiswarranty, contact yourdealer/re-
tailer, authorized FRIGIDAIRE PARTS AND SERVICE depot,
or:
FRIGIDAIRE HOME PRODUCTS
PARTS AND SERVICE
7075 Ordan Drive
Mississauga,Ontario
L5T 1K6
Phone: [phone]
Fax: [phone]
WARRANTOR WILL THROUGH ITS AUTHORIZED
SERVICE DEPOT:
Paycosttorepairorreplaceanydefectiveparts(including
serviceandlabour charge).
Paycost(includingserviceandlabourcharge)torepair or
replacedefectivepartsofthesealedrefrigeration system
consisting of the compressor, evaporator, condenser,
interconnectingtubingdrierandrefrigerationcharge.
WARRANTY APPLIES TO:
a) Productspurchased and installedin Canada forpersonalsingle family householduse.
b) Defectsresultingor arising outofthemanufacturingprocess.
c) Productsbearing legible manufacturer’smodeland serial numbers.
d) Replacementpartsonly for theremainderof the originalwarranty.
WARRANTY DOES NOT APPLY TO:
a) Transportationdamage.
b) Supplyandreplacementofporcelain,fuses,glassandlightbulbs.
c) Parts and service supplied or obtained from other than FRIGIDAIRE PARTS AND SERVICE or FRIGIDAIRE PARTS SERVICE
authorizeddepots.
d) Properinstallation,controlsettingandcareoffinish.
CONSUMER/OWNER RESPONSIBILITY:
a) To provide proof of the original date of purchase by means of a bill of sale or payment.
b) Supplyandreplacementofporcelain,fuses,glassandlightbulbs.
c) To ensure proper power supply and connection of the appliance to same.
d) Properinstallation,controlsettingandcareoffinish.
Thiswarrantyisinadditiontoany statutory warranties containedinanyapplicablelegislation. Thetermsandconditions
ofthiswarrantyarenotintendedtoexclude or limit your rights under those statutes. The warrantorhoweverreservesthe
right to charge transportation and travelling costs for distances in excess of 48kilometres (30 miles) from the nearest
FRIGIDAIRE PARTS AND SERVICE authorized service depot.
Thiswarrantyplusthestatutorywarrantiesmentionedarethe only warranties given totheconsumer/ownerforthisproduct.
FRIGIDAIRE GALLERY WARRANTY
(CANADA)
REFRIGERATORS (FROST FREE)

19
Notes
