Frigidaire FRT21B4J Instruction Manual

N05L00004.eps N05DBDCKA0.eps N05BBAABA17.eps N05SADEDA21.eps
N05CAAAAA27.eps W241582401.eps S241582801.eps
Product No. FRT21B4JW1
Series R134a
Color white
Volts 115
Wiring Diagram 241582401
Owner's Guide 241857201
Market North America
Energy Guide 241615470
Service Data Sheet 241588203
Installation Instructions 240568303
P.O. BOX 212378
AUGUSTA, GA 30917
Publication No.
5995523031
08/08/29
(EN/SERVICE/DCS)
137
TOP-MOUNT
REFRIGERATOR
Model No.
FRT21B4J
Copyright ©All rights reserved.

Publication No: 5995523031 FRT21B4JW1
08/08 2
DOOR
10
22
22
11
12
73
74
21A
18A
21
22
14
22
22
13A
13
21C
21C
10
22 18A
14
22
1
2
22
15
73
74
21A
N05DBDCKA0
8
4
4
4B
7

FRT21B4JW1 Publication No: 5995523031
# Functional Parts 3 08/08
* Non-Illustrated Parts
DOOR
POS. NO PART NO. DESCRIPTION
1 241872505 Gasket-frzr door, white, magnetic
2 # 241872513 Gasket, refr door seal, white, magnetic
4 240534901 Rack-door
4B 240534701 Rack-door, 4B
7 240337703 Door-dairy, w/o graphics, clear
8 240534801 Rack-door
10 240381301 Plug-button, white, hinge brg hole, (2)
11 241798401 Door-frzr, white, complete assy
12 241808601 Label-nameplate
13 240312403 Door Stop, white, ref
13A 240312404 Door Stop, white, frzr
14 240494001 Plug-button, white
15 241798501 Door-refr, white, complete assy
18A 218428101 Handle-door, white, w/block & screw
21 240383406 Screw, truss hd quad, #10-16 x .500, zinc
21A 240521303 Screw, #10-16 x 1/2
21C 218252201 Screw, #8 truss hd, 10-32CA x 0.500
22 240527101 Bearing-hinge, natural color
73 218396700 Block-handle mtg, dovetail
74 215503203 Screw, cr pan hd, 10-16 x 0.500

Publication No: 5995523031 FRT21B4JW1
08/08 4
CABINET

FRT21B4JW1 Publication No: 5995523031
# Functional Parts 5 08/08
* Non-Illustrated Parts
CABINET
POS. NO PART NO. DESCRIPTION
1 240355402 Cover-fan
2 240367001 Knob-damper control
3 5303212803 Nut
4 241523701 Damper-fan cover
5 5308000010 Fan Blade, red, evaporator fan
8 5300157666 Bushing-motor mtg, (2)
9 5303292396 Bracket-motor mtg, front
10 240313612 Cover-evap coil, w/o light
10* 240568606 Seal-coil cover
10*# 240524701 Wiring Harness, freezer section
11 5303208309 Plug-hole, factory test
12 241557601 Plug-ice maker harness, rectangular
12A 240374401 Plug-wtr inlet tube, round, 1"
12A* 241586701 Plug-foam-wtr-inlet, round
13 # 241854401 Motor-fan
13* 215474201 Washer, "slinger", nylon, evap fan shaft
14 5303292397 Bracket-motor mtg, rear
14* 240433204 Screw, hex washer head, 8-18 x 5/16
21C 218252201 Screw, #8 truss hd, 10-32CA x 0.500
22 215774901 Plug-button, white, upr hinge holes
28 240335502 Bolt-roller adj, hex washer head, 1/4-20 x 4.020, (2), special
30 240314011 Bracket-lower hinge, zinc
34 240311303 Washer, hinge, nylon, (2)
35 240313806 Bracket-ctr hinge, zinc
35A 240336802 Spacer-hinge, center
36 240516402 Pin-center hinge
37 240337608 Trim-cabinet corner, white, (2)
38 240313701 Bracket-upper hinge
40 240354401 Cover-upper hinge, white
41 5308009759 Grommet, shelf mtg, 1.25", LH, (4)
42 240578902 Screw, hex head, 1/4-20 x 5/8
43 240335006 Roller Assy, front, (2)
56 240516502 Pin-lower hinge
58 5304456287 Screw, hex washer head, 8-15A x 0.500
59 240442706 Screw-#10-32 X 3/4, zinc
72 241839405 Grille/Kickplate, white
81 5304455650 Screw, hex washer head, 8-15A x 0.625, low profile
82 5304418225 Roller, compressor base, rear, (2)
83 5304455655 Rivet, flat head, 1/4 OD x 1-3/4, roller pin
89 241733907 Cover-access, with label
89* 241500303 Screw, hex washer head, 8-18AB x 0.500
92 241710601 Screw, hex washer hd, 1/4 x 7/8, hinge mtg
* 240479601 Plug, button, cab liner holes
* 5303321319 Paint, touch-up, white

Publication No: 5995523031 FRT21B4JW1
08/08 6
SHELVES

FRT21B4JW1 Publication No: 5995523031
# Functional Parts 7 08/08
* Non-Illustrated Parts
SHELVES
POS. NO PART NO. DESCRIPTION
12 240545901 Diffuser-air, top
13 240362601 Diffuser, air, bottom
14# 241554901 Switch-light/lamp
15 241555401 Light Bulb
16 241559801 Socket-light
17 240368102 Control Box
17*# 240388701 Wiring Harness, control box
18 240360801 Knob, temp control
21 # 5304445058 Control-temperature
22A 240468201 Tube, sensor sleeve, 31 inch, plastic, white
23 # 215846606 Timer, defrost, 60 Hz, 0.25 W, 120 V, 10 hour/30 min
23* 5304455649 Screw, pan hd, 6-20 x 0.438
24 240360904 Shelf, sliding, wire
25 240364716 Cover-crisper pan
26 240343801 Pan-crisper, (2)
47 240350609 Insert-pan cover, glass
81 5304455650 Screw, hex washer head, 8-15A x 0.625, low profile
* 241615470 Energy Guide

Publication No: 5995523031 FRT21B4JW1
08/08 8
SYSTEM
17 21
15
20
14
20
16
60
59
61
58
1
34
34
83
44
41
82
83
82
N05CAAAAA27
22
23
23
30
32
85
55
4
6
29
26
45
57
25
25

FRT21B4JW1 Publication No: 5995523031
# Functional Parts 9 08/08
* Non-Illustrated Parts
SYSTEM
POS. NO PART NO. DESCRIPTION
1 # 241964901 Condenser
4 # 218944001 Drier-filter, R134a System
6 # 241607001 Harness-wiring, machine compt
6* # 240388701 Wiring Harness, control box
14 # 241940103 Heater-defrost
15 # 5303918274 Evaporator Kit
16 5308000110 Strap-evap/heater, aluminum, (2)
17 241801301 Trough-drain
20 241551902 Insulation Block
21 # 5303918202 Thermostat-defrost, kit
22 241602010 Base-compressor
22* 218252201 Screw, #8 truss hd, 10-32CA x 0.500
22* 218709101 Screw, hex head, 10-32 x 0.500
23 241659701 Grommet, compressor
25 240491503 Screw-compressor mtg, 1/4-28 x 1.16, (4)
26 241637401 Pan-defrost
29 # 5303918352 Compressor Kit
30 241707705 Starter-PTC
32 216954300 Clip, controller
34 240405201 Grommet, rubber, black, cond tube/wire
41 240555002 Screw-#8-32 X 3/8
44 215174700 Clamp-service cord, strain relief, galv steel
45 5304455650 Screw, hex washer head, 8-15A x 0.625, low profile
55 218909913 Capacitor, run, 220 VAC, 15 microfarad
57 240542601 Clip-wiring harness
58 218897004 Screw, hex washer head, 8-32 x 0.375
59 241681101 Shroud-cond fan
59* 240346701 Tape-foam seal, shroud
59* 240359403 Screw-fan shroud, (2)
60 # 241696602 Motor-condenser fan
61 # 240524101 Fan Blade, galv steel, condenser fan
82 5304418225 Roller, compressor base, rear, (2)
83 5304455655 Rivet, flat head, 1/4 OD x 1-3/4, roller pin
85 241844501 Tube-connector, suction
* 240396801 Clamp, tube/wiring, nylon, black/natural
* # 5303918330 Heat Exchanger Kit, suction line, service
* # 5304421289 Hot Tube Repair Kit, service

Publication No: 5995523031 FRT21B4JW1
08/08 10
WIRING SCHEMATIC

FRT21B4JW1 Publication No: 5995523031
# Functional Parts 11 08/08
* Non-Illustrated Parts
WIRING DIAGRAM
