Welcome & Congratulations
Congratulationsonyourpurchaseofanewrefrigerator!We
here at Electrolux Home Products, Inc. are very proud of
our product and we are completly committed to providing
you with the best service possible. Your satisfaction is our
#1priority.
PleasereadthisUse&CareManualverycarefully.Itcontains
valuable information on how to properly maintain your new
refrigerator.
We know you’ll enjoy your new refrigerator and ThankYou
forchoosing ourproduct.Wehopeyouconsiderus forfuture
purchases.
PLEASE READ AND SAVE THESE INSTRUCTIONS
This Use & Care Manual provides specific operating
instructions for your model. Use your refrigerator only as
instructed in this manual. These instructions are not meant
to cover every possible condition and situation that may
occur. Common sense and cautionmust be practiced when
installing,operatingandmaintaininganyappliance.
Please record your model and serial numbers below for
futurereference. Thisinformation is foundon yourserial
plate located inside the refrigerator compartment.
NOTE: Useonly soap and water toclean serialplate.
ModelNumber:
SerialNumber:
PurchaseDate:
Questions?
1-800-944-9044
(UnitedStates)
1-866-213-9397
(Canada)
Please complete and mail in the Product
Registration Card included with your
refrigerator.
Please attach sales receipt
hereforfuturereference.
ExtendYourWarranty Protection
With An
Extended Service Contract
CALL 1-800-944-9044
To Enjoy These Benefits:
• Total freedom from repair bills so
unexpected repairs won’t upset your
budget.
• Fast, convenient toll-free service is just
a phone call away.
• Top-quality repairs by factory-trained
experts.
• Quick access to genuine replacement
parts so you can rest assured your
refrigerator is repaired with the proper
components.

3
Important Safety Instructions
WARNING: Please ReadAll Instructions Before Using This Refrigerator.
FOR YOUR SAFETY
• Donotstoreorusegasoline,orotherflammableliquids
in the vicinity of this or any other appliance. Read pro-
ductlabelsforwarningsregardingflammabilityand other
hazards.
• Donotoperate the refrigerator in the presense of
explosive fumes.
• Avoid contact with any moving parts of automatic ice
maker.
• Remove all stables from the carton. Staples can cause
severe cuts, and also destroy finishes if they come in
contactwithother appliances or furniture.
CHILD SAFETY
Destroyorrecyclethecarton,plasticbags,andanyexterior
wrapping material immediately after the refrigerator is
unpacked.ChildrenshouldNEVER usetheseitemstoplay.
Cartons covered with rugs, bedspreads, plastic sheets or
stretchwrap maybecomeairtight chambers,andcan quickly
causesuffocation.
These Guidelines Must Be Followed To Ensure That Safety Mechanisms In This Refrigerator
Will Operate Properly.
PROPER DISPOSAL OF YOUR REFRIGERATOR
OR FREEZER
Risk of child entrapment
Child entrapment and
suffocation are not problems of
thepast.Junked or abondoned
refrigeratorsorfreezersarestill
dangerous – even if they will sit
for “just a few days.” If you are
gettingridofyouroldrefrigerator
or freezer, please follow the
instructions below to help
preventaccidents.
Before you throw away your old refrigerator/ freezer:
• Removedoors.
• Leaveshelvesinplacesochildrenmaynoteasilyclimb
inside.
• Haverefrigerantremovedby a qualified service
technician.
ELECTRICAL INFORMATION
•The refrigerator must be plugged into its own
dedicated 115 Volt, 60 Hz.,AC only electric outlet.
The power cord of the appliance is equipped with a
three-pronggroundingplug for your protection against
electrical shock hazards. It must be plugged directly
intoa properly groundedthree-prongreceptacle.The
receptacle must be installed in accordance with local
codesandordinances.Consultaqualifiedelectrician.
Do not use an extension cord or adapter plug.
• Ifthepowercordisdamaged,itshouldbereplacedbythe
manufacturer, servicetechnicianora qualifiedpersonto
prevent any risk.
• Neverunplugtherefrigeratorbypullingonthepower
cord.Always grip the plug firmly, and pull straight out
fromthereceptacletopreventdamagingthepowercord.
• Unplugtherefrigerator before cleaning andbefore
replacing a light bulb to avoid electrical shock.
• Performance may be affected if the voltage varies by
10%ormore.Operating the refrigerator with insufficient
powercandamagethecompressor. Such damage is
notcoveredunderyourwarranty.
• Do not plug the unit into an outlet controlled by a wall
switchorpullcordtopreventtherefrigeratorfrombeing
turned off accidentally.
• AvoidconnectingrefrigeratortoaGroundFaultInterruptor
(GFI)circuit.
IMPORTANT: Turning the Freezer and Fresh Food
Controlsto“0”turnsoffthe compressor and prevents
yourrefrigerator fromcooling,butdoes notdisconnect
the power to the light bulb and other electrical
components.Toturnoffpowertoyourrefrigerator you
must unplug the power cord from the wall outlet.

4
This Use & Care Manual provides specific operating
instructions for your model. Use the refrigerator only as
instructed in this Use & Care Manual. Before starting the
refrigerator, follow these important first steps.
LOCATION
• Chooseaplace that is near agroundedelectricaloutlet.
Do Not use an extension cord or an adapter plug.
• If possible, place the refrigerator out of direct sunlight
andawayfromtherange, dishwasher or other heat
sources.
• Therefrigeratormust be installed on a floorthat is level
andstrongenoughto support a fully loaded refrigerator.
• Considerwatersupplyavailabilityformodelsequipped
with an automatic ice maker.
INSTALLATION
Do Not install the refrigerator where
thetemperaturewilldropbelow55°F(13°C)orriseabove
110°F(43°C).Thecompressorwillnotbeabletomaintain
propertemperaturesinside the refrigerator.
Do Not block the toe grille on the
lower front of your refrigerator. Sufficient air
circulation is essential for the proper operation of
yourrefrigerator.
InstallationClearances
• Allow the following clearances for ease of installation,
properaircirculation,andplumbingandelectrical
connections:
Sides&Top --------------- 3/8”
Back------------------------ 1”
NOTE: Ifyousee black coils/tubing on the backof your
refrigerator(air-cooled condenser) leave3”clearanceat
topofrefrigerator.
DOOR OPENING
NOTE: If your refrigerator is placed with the door hinge
side against a wall, you may have to allow additional
spaceso the door can be openedwider.
Your refrigeratorshould be positioned toallow easy access
toacounter when removing food.Tomakethis possible, the
directionin which thedoorsopen can bereversed.SeeDoor
Removal&Reversal Instructions onpage6.
Installation
LEVELING
All four corners of your refrigerator must rest firmly on a
solidfloor.Yourrefrigerator is equipped with adjustablefront
rollers to help level your unit.
To LevelYour Refrigerator:
1. Removetoegrille.
2. Useflat-bladescrewdriveror3/8”socketwrench
to adjust front rollers.
NOTE: Raisethefrontoftherefrigerator enough so the
doorsclosefreelywhen openedhalfway.Therefrigerator
shouldslope¼”to½”from front-to-back.Thenlevelthe
refrigeratorfrom side to side.

5
Installation - Connecting Optional Ice Maker To Water Supply
To avoid electric shock, which can cause death or severe personal injury, disconnect the
refrigerator from electrical power before connecting a water supply line to the refrigerator.
ToAvoid Property Damage:
•Copper tubing is recommended for the water supply line. Water supply tubing made of ¼” plastic is not
recommendedsince it greatly increasesthe potential forwater leaks. Manufacturer willnot be responsiblefor
any damage if plastic tubing is used for supply line.
• DO NOT install water supply tubing in areas where temperatures fall below freezing.
•Chemicals from a malfunctioning softener can damage the ice maker. If the ice maker is connected to soft
water, ensure that the softener is maintained and working properly.
IMPORTANT: Ensure that your water supply line connections comply with all local plumbing codes.
NOTE: Waterlinekitnumber 5303917950, availablefromyourappliance dealer atadditionalcost,contains25 feet (7.6
meters)of¼inch ODcoppertubing,asaddletypeshutoffvalve(nonpiercing),(2)¼inchbrasscompressionnuts,(2)
ferrules/sleeves, and instructions for installing a water supply line.
Before Installing The Water Supply Line,You Will Need
•Basic Tools: adjustablewrench, flat-blade screwdriver,andPhillipsTM screwdriver
• Access to a household cold water line with water pressure between 20 and 120 psi.
• Awater supply line made of ¼ inch (6.4 mm) OD, copper tubing.To determine the length of copper tubing needed,
you will need to measure the distance from the ice maker inlet valve at the back of the refrigerator to your cold water
pipe.Then add approximately 7 feet(2.1 meters), so therefrigerator can bemoved out for cleaning(as shown).
• Ashutoff valve to connect the water supply line to your household water system. DO NOT use a self-piercing type
shutoff valve.
• A compression nut and ferrule (sleeve) for connecting the water supply line to the ice maker inlet valve.
IMPORTANT: It takes approximately 24 hours for the ice maker to begin producing ice. Air in new plumbing lines may
causeice maker tocycletwoor three timesbeforemakinga full trayofice.New plumbing maycauseiceto bediscolored
or have poorflavor. Discard icemade during the first24 hours.
To Connect Water Supply Line To Ice Maker Inlet Valve
1. Disconnectrefrigeratorfromelectricpowersource.
2. Place end of water supply line into sink or bucket. Turn ON water supply
and flush supply line until water is clear. Turn OFF water supply at shut
off valve.
3. Unscrew plastic cap from water valve inlet and discard cap.
4. Slide brass compression nut, then ferrule (sleeve) onto water supply line,
asshown.
5. Push water supply line into water valve inlet as far as it will go (¼ inch).
Slide ferrule (sleeve) into valve inlet and finger tighten compression nut
ontovalve.Tightenanother half turn with a wrench;DO NOT over tighten.
6. With steel clamp and screw, secure water supply line to rear panel of
refrigeratorasshown.
7. Coilexcesswatersupply line (about 2½ turns) behind refrigeratoras shown
and arrange coils so they do not vibrate or wear against any other surface.
8. Turn ON water supply at shutoff valve and tighten any connections that
leak.
9. Reconnectrefrigeratortoelectricalpowersource.
10. Toturn ice makeron, lower wire signalarm (see icemaker front cover forON/
OFF position of arm).

6
Door Removal and Reversal Instructions
NOTE: Ifyouhave stainless steel doors --gototheRemoving Stainless
Steel Doorsand Handles Sectiononpage9.
NOTE:The direction inwhichyourrefrigeratordoorsopen(doorswing)
can be reversed, from left to right or right to left, by moving the door
hinges from one side to the other. Reversing the door swing should be
performedbyaqualifiedperson.
IMPORTANT: Before youbegin,turn therefrigeratortemperaturecontrol
to“0”and remove theelectricalpowercord from the walloutlet.Remove
any food from door shelves.
1. Removetoegrille and top hinge cover.
2. Remove top hinge with 3/8” hex driver and lift freezer door off of
centerhingepin. Set door aside.
3. Unscrewcenterhingepin using adjustable wrench and save for
reassembly. Ensure plastic washer stays on hinge pin.
4. Lift refrigerator door off of bottom hinge and set aside.
5. Remove center hinge and shim by removing inside screw and
loosening two outside screws enough to allow hinge and shim to
slideout.Tightenscrews.
6. Loosentwooutsidescrews on opposite side of refrigerator,remove
insidescrewand install center hinge.
7. Removebottomhingewith3/8” hexdriver.Reinsert twooutsidescrews
inholes and tighten. Inside screw will go to opposite side in step 8.
8. Removetwooutside screwsonoppositesideof refrigerator andinstall
bottom hinge. Insert and tighten screw saved from step 7.
9. Unscrewbottomhingepinusingadjustablewrench.Movehinge pin
toother hole in hinge and tighten withadjustable wrench.
10. Reverse doorhandles (see instructions on nextpage).
11. Move freezerand refrigerator door stops toopposite side. Before
starting screws, use an awl to puncture the foam.
12. Positionrefrigeratordoorontobottomhingepinandscrewcenter
hingepinthrough center hinge into top ofdoor.Closerefrigeratordoor
tohelp align hinge hole.
13. Tightencenterhingepinwithadjustablewrench.
14. Remove cabinet and hinge hole plugs and move to opposite side.
15. Lowerfreezerdoorontocenterhingepin.
16. Close freezer door. Have an assistant lift up on opposite side of door
while tightening screws to install top hinge.
17. Replace toegrille and top hingecover.
18. Pluginelectricalpowercordandturnrefrigeratortemperaturecontrol
to center position.Adjust setting as necessary.
DOOR REMOVAL AND REVERSAL INSTRUCTIONS:

7
Door Removal and Reversal Instructions (continued)
NOTE: Somemodelshave“pocket”handles,whicharerecessedintothesidesofthedoor. On these models, only the
hingeswill need to bereversed.
TO REMOVE FREEZER HANDLE:
(Handles may be easier to reverse while doors are off.)
1. Removetwoscrewsattachinghandle to bottom of freezer door.
2. Remove short trim piece by sliding trim straight up and off of handle
bracket.
3. Remove screw attaching top of handle to door.
4. MagneticNameplate Models:Gently prymagneticnameplate framefrom
door. Remove nameplate from its frame, turn frame upsidedown and
install in old handle holes. Insert magnetic nameplate into frame.
Self-Adhesive Nameplate Models: Gentlypeel off nameplate from door
andreapplyoveroldhandleholes.
TO ATTACH FREEZER HANDLE:
1. Reinstall handle on opposite side, using same hole as nameplate.
2. Attach handle to bottom of door.
3. Slide trim piece straight down onto handle bracket.
TO REMOVE FREEZER HANDLE:
(Handles may be easier to reverse while doors are off.)
1. Removetwoscrewsattachinghandle to bottom of freezer door.
2. Swing bottom of handle away from the door and slide handle straight up
and off of dovetail button.
3. Remove screw and dovetail button and install on other side, using the
same holes as nameplate.
4. Magnetic Nameplate Models: Use putty knife to gently pry magnetic
nameplateframefromdoor. Remove nameplate from its frame, turn frame
upside down and install in old handle holes. Insert magnetic nameplate
intoframe.
Self-AdhesiveNameplate Models: Useputtyknifeto gentlypeeloffname
platefromdoorand reapply over old handle holes.
TO ATTACH FREEZER HANDLE:
1. Start with handle offset away from door. Place top of handle over dovetail
button,swing handle into an uprightposition and pulldownward, locking it
into place.
2. Securebottomofhandle with two screws removed earlier.
TO REMOVE FREEZER HANDLE:
(Handles may be easier to reverse while doors are off.)
1. Removetwoscrewsattachinghandle to bottom of freezer door.
2. Remove button plug using edge of putty knife.
3. Removescrewonsideof freezer door and remove handle.
TO ATTACH FREEZER HANDLE:
1. Secure side of handle to door and replace button plug.
2. Securehandleto bottom of door.
NOTE:To remove freezer handle, refer to figure 3on page 9.

8
Door Removal and Reversal Instructions (continued)
TRIM REMOVAL(FULL-LENGTH TRIM MODELS ONLY)
In some models, the refrigerator door has a full length trim piece which
continuesfromthebottomofthe handle to the bottom of the door.The top
ofthetrimattaches to the handle bracket (Figure 1) orfitsaroundthebase
ofthe handle(Figure2). Anadhesive“trim lock”ispositionedabouthalfway
down.Thebottomof the trimisheldin place byeitheranadhesive trim lock,
or a trim lock with two prongs inserted into a hole on the face of the door.
TO REMOVE TRIM:
1. Remove trim by gently pulling trim lock areas out and away from door.
2. When trim is free from door, slide the trim straight down and away
from base of handle.
NOTE:Formodelswithshorthandletrim,removebyslidingtrimstraight
down and off of handle bracket.
TO REMOVE REFRIGERATOR HANDLE:
(Handles may be easier to reverse while doors are off.)
Figure 1 Style Handles
1. Removetwoscrewsattachinghandleto top of refrigerator door.
2. Removescrewattaching bottom of handleto door.
3. Remove two hole plugs and hinge pin plug on top of door and install
on opposite side. Use Phillips head screwdriver to remove plastic
screw plug from front of door and install on opposite side
Figure 2 Style Handles
1. Removetwoscrewsattachinghandle to top of refrigerator door.
2. Swingtopof handle away from doorand slidehandle downand off of
dovetailbutton.
3. Remove screw and dovetail button and install on other side, moving
holeplugsfrom corresponding holes to opposite side.
TO ATTACH REFRIGERATOR HANDLE:
Figure 1 Style Handles
1. Securebottomof handle with screws.
2. Secure top of handle with screws.
Figure 2 Style Handles
1. Start with handle offset away from door. Place bottom of handle over
dovetailbutton,swinghandle into an upright position and pull upward,
locking it into place.
2. Secure top of handle with screws.
TO ATTACH TRIM:
1. Slide both trim locks out of trim.
2. Insert new adhesive trim locks contained in your literature pack.
NOTE: Trim lock must be removed and installed by sliding over the
twodonutshapedareas.
3. Install trim to handle by sliding under base of handle. Carefully align
trimand press down at trim lock locations.
4. Use rubbing alcohol to remove any adhesive residue from old trim
lock locations.
Figure 1
Figure 2

9
Door Removal and Reversal Instructions (continued)
TO REMOVE REFRIGERATOR HANDLE:
(Handles may be easier to reverse while doors are off.)
1. Removetwoscrewsattachinghandleto top of refrigerator door.
2. Remove button plug using edge of putty knife.
3. Removescrewonsideofrefrigeratordoorandremove handle.
4. Reversefreezerandrefrigeratorhandlesas shown in figure 3.
TO ATTACH REFRIGERATOR HANDLE:
1. Secure side of handle to door and replace plug button.
2. Secure handle to top of door.
REMOVING STAINLESS STEEL DOORS AND HANDLES
Use care when using tools near surface of stainless steel doors to avoid scratching.
To Remove Doors
Stainlesssteeldoorsarenot reversible. Follow these steps to remove doors.
1. Removetoegrille and top hinge cover.
2. Remove top hinge and lift freezer door off of center hinge pin. Set door
aside.
3. Unscrewcenterhingepin using adjustable wrench and save for
reassembly. Ensure plastic washer stays on hinge pin.
4. Lift refrigerator door off of bottom hinge and set aside.
5. Removecenterhingeandshim by removing inside screw and loosening
two outside screws enough to allow hinge to slide out.
6. Remove bottom hinge. Reinserttwooutsidescrewsinholesandtighten.
7. Reverse steps 1 - 6 to reinstall doors
To Remove Handles
1. Firmlyholdfreezerhandlewhile loosening set screws with 3/32” allen
wrench.Remove freezer handle.
2. Repeatstep1forrefrigeratordoor.
Figure 3 - Handle Reversal
Refrigerator Door Without Trim
Typical Handle

10
Features At A Glance
Features may vary according to model
