Frigidaire FRT18B6C User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FRT18B6CB1 FRT18B6C R134a black 115
FRT18B6CQ1 FRT18B6C R134a bisque 115
FRT18B6CW1 FRT18B6C R134a white 115
MARKET
North America
Publication No.
5995386678
030227
-EN/SERVICE /DCS
357
TOP MOUNT
REFRIGERATOR
Model No.
FRT18B6C
©2003 Electrolux Home Products, Inc.
All rights reserved
FACTORY
PARTS CATALOG
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
ENERGY GUIDE - 240572124
OWNER’S GUIDE - 240400108
SERVICE DATA SHEET - 240379010

02/03 2
Publication No. FRT18B6C
5995386678
DOOR

# = Fast-moving Parts 3 02/03
* = Non-Illustrated Parts
FRT18B6C Publication No.
5995386678
A = FRT18B6C (FRT18B6CB1)
B = FRT18B6C (FRT18B6CQ1)
C = FRT18B6C (FRT18B6CW1)
POS. NO PART NO DESCRIPTION
1 # 240514609 A - - Gasket,frzr door seal ,black ,magnetic
1 # 240514605 - B C Gasket,frzr door seal ,white ,magnetic
2 # 240514612 A - - Gasket,seal ,black ,refr door ,magnetic
2 # 240514608 - B C Gasket,seal ,white ,refr door ,magnetic
7 240337701 A B C Door-dairy,w/o graphics ,white
10 240381303 A - - Plug-button,black ,hinge brg hole
10 240381302 - B - Plug-button,bisque ,hinge brg hole ,(2)
10 240381301 - - C Plug-button,white ,hinge brg hole ,(2)
11 240476203 A - - Panel-frzr door,black ,complete assy
11 240476202 - B - Panel-frzr door,bisque ,complete assy
11 240476201 - - C Panel-frzr door,white ,complete assy
12 240415204 A - - Label-nameplate,black
12 240415203 - B - Label-nameplate,bisque
12 240415201 - - C Label-nameplate,white
13 240312405 A - - Door Stop,black ,refr
13 240312407 - B - Door Stop,bisque ,ref
13 240312403 - - C Door Stop,white ,ref
13A 240312406 A - - Door Stop,black ,frzr
13A 240312408 - B - Door Stop,bisque ,frzr
13A 240312404 - - C Door Stop,white ,frzr
14 240494003 A - - Plug-button,black
14 240494002 - B - Plug-button,bisque
14 240494001 - - C Plug-button,white
14B 240383603 A - - Plug-button,black ,door handle
14B 240383602 - B - Plug-button,bisque ,door handle
14B 240383601 - - C Plug-button,white ,door handle
15 240476303 A - - Panel-refr door,black ,complete assy
15 240476302 - B - Panel-refr door,bisque ,complete assy
15 240476301 - - C Panel-refr door,white ,complete assy
18 240339203 A - - Handle-door,black
18 240339204 - B - Handle-door,bisque
18 240339201 - - C Handle-door,white
18A 240339208 A - - Handle-door,black
18A 240339209 - B - Handle-door,bisque
18A 240339206 - - C Handle-door,white
21 240383401 A B C Screw,truss hd quad ,#10-16 x .500
21C 218252200 A B C Screw,#8 truss hd ,10-32CA x 0.500
22 240527102 A - - Bearing-hinge,black
22 240527101 - B C Bearing-hinge,natural color ,(8)
48 240338101 A B C Bin-door,pseudo ,bottom
48A 240337901 A B C Bin-door,refr
48B 240338001 A B C Bin-door,pseudo ,gallon ,refr
49 240495804 A B C Bin-door,pseudo ,frzr
DOOR

02/03 4
Publication No. FRT18B6C
5995386678
CABINET

# = Fast-moving Parts 5 02/03
* = Non-Illustrated Parts
FRT18B6C Publication No.
5995386678
A = FRT18B6C (FRT18B6CB1)
B = FRT18B6C (FRT18B6CQ1)
C = FRT18B6C (FRT18B6CW1)
POS. NO PART NO DESCRIPTION
1 240355401 A B C Cover-fan
2 240367001 A B C Knob-damper control
3 5303001028 A B C Nut,push-on
4 240367401 A B C Damper-fan cover
5 # 5308000010 A B C Fan Blade,red ,evaporator fan
8 5300157666 A B C Bushing-motor mtg,(2)
9 5303292396 A B C Bracket-motor mtg,front
10 240462010 A B C Cover-evap coil
10* 218843800 A B C Screw,hex wshr hd ,8-15A x 0.500
10* 240371302 A B C Seal,insulation ,47.77 in. long ,foam ,coil cover
10*# 240524701 A B C Wiring Harness,freezer section
11 5303208309 A B C Plug-hole,factory test
12 240366801 A B C Plug-ice maker harness,rectangular
12A 240374401 A B C Plug-wtr inlet tube,round ,1"
13 # 240369701 A B C Motor-evap fan
13* 218931001 A B C Clamp-motor wiring,nylon ,w/adhesive tape
14 5303292397 A B C Bracket-motor mtg,rear
18 240411901 A B C Support-evap cover,(2)
21C 218252200 A B C Screw,#8 truss hd ,10-32CA x 0.500
22 215774918 A - - Plug-button,black ,upr hinge holes
22 215774919 - B - Plug-button,bisque ,upr hinge holes
22 215774901 - - C Plug-button,white ,upr hinge holes
28 240335501 A B C Bolt-roller adj,hex washer head ,1/4-20 x 4.020,(2) ,special
30 240314003 A - - Bracket-lower hinge,black
30 240314004 - B - Bracket-lower hinge,bisque
30 240314002 - - C Bracket-lower hinge,white
34 240311301 A B C Washer,hinge ,nylon ,(2)
35 240313803 A - - Bracket-ctr hinge,black
35 240313804 - B - Bracket-ctr hinge,bisque
35 240313802 - - C Bracket-ctr hinge,white
35A 240336801 A B C Spacer-hinge,center
36 240516401 A B C Pin-center hinge
37 240337603 A - - Trim-cabinet corner,black ,(2)
37 240337604 - B - Trim-cabinet corner,bisque ,(2)
37 240337601 - - C Trim-cabinet corner,white ,(2)
38 240313701 A B C Bracket-upper hinge
40 240354404 A - - Cover-upper hinge,black
40 240354403 - B - Cover-upper hinge,bisque
40 240354401 - - C Cover-upper hinge,white
41 5303001609 A B C Grommet,shelf mtg ,0.69" ,RH
41* 5308009759 A B C Grommet,shelf mtg ,1.25" ,LH
42 240578901 A B C Screw-hinge mtg,hex head ,1/4-20 x 5/8
43 240335003 A B C Roller Assy,front ,(2)
56 240516501 A B C Pin-lower hinge
58 5303001343 A B C Screw,hex washer head ,8-15A x 0.500
59 240442703 A - - Screw-#10-32 X 3/4,black
59 240442704 - B - Screw-#10-32 X 3/4,bisque
59 240442702 - - C Screw-#10-32 X 3/4,white
72 240368207 A - - Grille/Kickplate,black
72 240368206 - B - Grille/Kickplate,bisque
72 240368205 - - C Grille/Kickplate,white
81 5308016566 A B C Screw,hex washer head ,8-15A x 0.625 ,low profile
82 5304418225 A B C Roller,compressor base ,rear ,(2)
83 5303316859 A B C Rivet,flat head ,1/4 OD x 1-3/4 ,roller pin
89 240326115 A B C Cover-access,with label
89* 241500301 A B C Screw,hex washer head ,8-18AB x 0.500
92 216850900 A B C Screw,hex washer hd ,1/4 x 7/8 ,hinge mtg
* 240433201 A B C Screw,hex washer head ,8-18 x 0.375
* 240479601 A B C Plug,button ,cab liner holes
* 5303305345 A - - Paint,touch-up ,black
* 5304414035 - B - Paint,touch-up ,bisque
* 5303305324 - - C Paint,touch-up ,white
CABINET

02/03 6
Publication No. FRT18B6C
5995386678
SHELVES

# = Fast-moving Parts 7 02/03
* = Non-Illustrated Parts
FRT18B6C Publication No.
5995386678
A = FRT18B6C (FRT18B6CB1)
B = FRT18B6C (FRT18B6CQ1)
C = FRT18B6C (FRT18B6CW1)
POS. NO PART NO DESCRIPTION
10 215667501 A B C Tray,ice cube ,plastic
11 5303282284 A B C Shelf-freezer,"table type"
12 240362502 A B C Diffuser,air ,top
13 240362601 A B C Diffuser,air ,bottom
14 240505801 A B C Switch,light/lamp
15 240436702 A B C Light Bulb/Lamp,A-15 ,clear ,40 W ,120 V,miniature
16 241500701 A B C Socket-light/lamp
17 240352701 A B C Control Box
17*# 240388701 A B C Wiring Harness,control box
18 240360801 A B C Knob,temp control
21 # 5304421256 A B C Control,temperature
22A 5303916855 A B C Tube,sensor sleeve ,plastic ,clear
23 # 215846606 A B C Timer,defrost ,60 Hz ,0.25 W ,120 V ,10 hour/30 min
23* 5303001259 A B C Screw-timer mtg,pan hd ,6-20 x 0.438 ,(2)
24 240360905 A B C Shelf,sliding ,wire
25 240364701 A B C Cover-crisper pan,w/ beam ,less insert
26 240337101 A B C Pan-crisper,white ,(2) ,no graphics
30 240361801 A B C Cover,meat pan hanger ,drop through
31 240530801 A B C Pan-meat,w/o graphics ,white
47 240350608 A B C Insert-pan cover,23.82" x 15.50" ,glass
81 5308016566 A B C Screw,hex washer head ,8-15A x 0.625 ,low profile
* 240572124 A B C Label-energy
SHELVES

02/03 8
Publication No. FRT18B6C
5995386678
SYSTEM

# = Fast-moving Parts 9 02/03
* = Non-Illustrated Parts
FRT18B6C Publication No.
5995386678
A = FRT18B6C (FRT18B6CB1)
B = FRT18B6C (FRT18B6CQ1)
C = FRT18B6C (FRT18B6CW1)
POS. NO PART NO DESCRIPTION
1 240444401 A B C Condenser,dynamic
4 # 218944001 A B C Drier-filter,R134a System
6 # 240496101 A B C Wiring Harness,machine compt ,w/electric cord
6* # 240388701 A B C Wiring Harness,control box
6* # 240524701 A B C Wiring Harness,freezer section
14 # 5303918208 A B C Defrost Heater Kit
15 # 5303918274 A B C Evaporator Kit
16 5308000110 A B C Strap-evap/heater,aluminum ,(2)
17 240434002 A B C Trough-drain
18 240362301 A B C Insulation,evap block ,foam ,RH
20 240518401 A B C Insulation,evap block ,foam ,LH/RH
21 # 5303918202 A B C Thermostat-defrost,kit
22 240330006 A B C Plate-compr mtg
22* 218252200 A B C Screw,#8 truss hd ,10-32CA x 0.500
23 218513300 A B C Grommet-compr mtg,(4)
25 240491501 A B C Screw-compressor mtg,1/4-28 x 1.16,shoulder,typ CF
26 240332601 A B C Pan-defrost drain
29 # 5303918264 A B C Compressor,w/electricals
30 # 218721120 A B C Starter,PTC
32 240493301 A B C Clamp,elec cont mtg ,compressor ,bale wire
34 240405201 A B C Grommet,rubber ,black ,cond tube/wire
41 240555001 A B C Screw-#8-32 X 3/8
44 215174700 A B C Clamp-service cord,strain relief ,galv steel
45 5308016566 A B C Screw,hex washer head ,8-15A x 0.625 ,low profile
55 # 218909901 A B C Capacitor,run ,50/60 Hz ,220 VAC ,15 microfarad
57 240542601 A B C Clip-wiring harness
58 215004600 A B C Screw,hx serr wshr hd ,8-36 x 7/16 ,cond fan motor,(2)
59 240315501 A B C Shroud-cond fan
59* 240346701 A B C Tape-foam seal,shroud
59* 240359401 A B C Screw-fan shroud,(2)
59A 240346501 A B C Bracket-support,cond mtr ,(3)
59B 240346601 A B C Grommet-bracket,(3)
60 # 240334001 A B C Motor,condenser fan
61 # 240315401 A B C Fan Blade,galv steel ,condenser fan
61A 215004700 A B C Nut,speed
61B 215004800 A B C Grommet-silencer
82 5304418225 A B C Roller,compressor base ,rear ,(2)
83 5303316859 A B C Rivet,flat head ,1/4 OD x 1-3/4 ,roller pin
84 240500801 A B C Tube-drain,rubber ,lower
85 240493101 A B C Tube-connector,suction
86 240409302 A B C Spacer-cond tube,black
* 3205266 A B C Edge Protector,wiring harness
* 240396801 A B C Clamp,tube/wiring ,nylon ,black/natural
* 5308000039 A B C Screw,hex washer head ,8-32CA x 0.500 ,serrated head
* # 5303918207 A B C Heat Exchanger Kit,suction line
* # 5303918222 A B C Hot Tube Repair Kit,Service
SYSTEM

02/03 10
Publication No. FRT18B6C
5995386678
WIRING SCHEMATIC

# = Fast-moving Parts 11 02/03
* = Non-Illustrated Parts
FRT18B6C Publication No.
5995386678
WIRING DIAGRAM
