Frigidaire GLRSF236J User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
GLRSF236JB1 GLRSF236J GALLERY black 115
GLRSF236JD1 GLRSF236J GALLERY almond 115
GLRSF236JW1 GLRSF236J GALLERY white 115
MARKET
North America
Publication No.
5995342945
000831
-EN/SERVICE/KHB
357
SIDE BY SIDE
REFRIGERATOR
Model No.
GLRSF236J
©2000 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
SIDE BY SIDE
REFRIGERATOR
WIRING DIAGRAM - # 218903201
OWNER’S GUIDE - # 218954000
SERVICE DATA SHEET - # 218909401
101 Masters Blvd.
Anderson, SC 29624

08/00 2
Publication No. GLRSF236J
5995342945
FREEZER DOOR

# = Fast-moving Parts 3 08/00
* = Non-Illustrated Parts
GLRSF236J Publication No.
5995342945
FREEZER DOOR
A = GLRSF236J (GLRSF236JB1)
B = GLRSF236J (GLRSF236JD1)
C = GLRSF236J (GLRSF236JW1)
POS. NO PART NO DESCRIPTION
1 # 215734323 A - - Gasket-frzr door,black ,magnetic
1 # 215734313 - B C Gasket-frzr door,white ,magnetic
5 5303288950 A B C Support-door rack,RH/LH
6 5303323484 A B C Support-door rack,white ,LH
6A 5303323485 A B C Support-door rack,white ,RH
8 218807030 A B C Rack-door,w/end caps
8A 215474054 A B C Rack-door
9 218510601 A B C Panel-inner door,frzr
11 5303918157 A - - Panel-ext frzr door, black, w/foam insulatn
11 5303918174 - B - Panel-ext frzr door, almond, w/foam insulatn
11 5303918155 - - C Panel-ext frzr door, white, w/foam insulatn
13 5303289522 A B C Door Stop
18 218762703 A - - Handle-door,black
18 218762704 - B - Handle-door,almond
18 218762701 - - C Handle-door,white
21A 218578600 A B C Screw-door stop mtg, phl truss hd, 10-16 x 3/4
22A 215615300 A B C Bushing-door,bronze
23 218958100 A B C Screw,flat hd ,#8-32D x 1/2
37 218811628 A - - Trim-handle, black, upper, w/gold band and snap lock
37 215867065 - B - Trim-handle, almond, upper, w/gold band and snap lock
37 215867064 - - C Trim-handle, white, upper, w/gold band and snap lock
37A 218811627 A - - Trim-handle, black, lower, w/gold band and snap lock
37A 215867062 - B - Trim-handle, almond, lower, w/gold band and snap lock
37A 215867061 - - C Trim-handle, white, lower, w/gold band and snap lock
37A* 215782300 A B C • Lock-handle trim,snap-in
37A* 218676003 A B C • Band-decorative,gold
47 218922901 A B C Wiring Harness,frzr door
58 218781100 A B C Screw,pan head ,8-18 x 0.625
68 218020600 A B C Chute-ice
140 218922801 A B C Elbow-water tube
141 218929601 A B C Tool-Push Connector
* 5303917276 A B C Insulation-door,fiberglass ,(bulk)

08/00 4
Publication No. GLRSF236J
5995342945
REFRIGERATOR DOOR

# = Fast-moving Parts 5 08/00
* = Non-Illustrated Parts
GLRSF236J Publication No.
5995342945
A = GLRSF236J (GLRSF236JB1)
B = GLRSF236J (GLRSF236JD1)
C = GLRSF236J (GLRSF236JW1)
POS. NO PART NO DESCRIPTION
2 # 215734324 A - - Gasket-refr door,black ,magnetic
2 # 215734314 - B C Gasket-refr door,white ,magnetic
3 215390401 A B C Panel-inner door,refr
4 218807029 A B C Rack-door,w/end caps
5 5303288950 A B C Support-door rack,RH/LH
7 5303304563 A B C Door-dairy
12 218364006 A - - Frame-nameplate,black
12 218364005 - B - Frame-nameplate,almond
12 218364004 - - C Frame-nameplate,white
12* 215008606 A - - • Label-nameplate,black
12* 215008605 - B - • Label-nameplate,almond
12* 215008604 - - C • Label-nameplate,white
12* 5315340712 A B C • Tape,adhesive, 12" long, foam, double-faced
13 5303289522 A B C Door Stop
15 5303918158 A - - Panel-ext ref door, black, w/foam insulatn
15 5303918173 - B - Panel-ext refr door, almond, w/foam insulatn
15 5303918156 - - C Panel-ext ref door, white, w/foam insulatn
18 218762703 A - - Handle-door,black
18 218762704 - B - Handle-door,almond
18 218762701 - - C Handle-door,white
21A 218578600 A B C Screw-door stop mtg, phl truss hd, 10-16 x 3/4
22 5303289320 A B C Bearing-hinge
37 218811628 A - - Trim-handle, black, upper, w/gold band and snap lock
37 215867065 - B - Trim-handle, almond, upper, w/gold band and snap lock
37 215867064 - - C Trim-handle, white, upper, w/gold band and snap lock
37A 218811627 A - - Trim-handle, black, lower, w/gold band and snap lock
37A 215867062 - B - Trim-handle, almond, lower, w/gold band and snap lock
37A 215867061 - - C Trim-handle, white, lower, w/gold band and snap locks
37A* 215782300 A B C • Lock-handle trim,snap-in
37A* 218676003 A B C • Band-decorative,gold
49 218592327 A B C Bin-door,gallon
58 218781100 A B C Screw,pan head ,8-18 x 0.625
* 5303917276 A B C Insulation-door,fiberglass ,(bulk)
REFRIGERATOR DOOR

08/00 6
Publication No. GLRSF236J
5995342945
CABINET

# = Fast-moving Parts 7 08/00
* = Non-Illustrated Parts
GLRSF236J Publication No.
5995342945
A = GLRSF236J (GLRSF236JB1)
B = GLRSF236J (GLRSF236JD1)
C = GLRSF236J (GLRSF236JW1)
POS. NO PART NO DESCRIPTION
10 215637602 A B C Cover-air duct
10* 5303209814 A B C Nut,"U" type ,8-15A ,fan mtr mtg
10A 215637402 A B C Cover-evap coil,lower
10A* 5308009617 A B C Washer,ext tooth lock ,#10 ,grounding
11 5303208309 A B C Plug-hole,factory test
12 215230400 A B C Plug-harness hole
18 5303289043 A B C Support-air duct cvr,2.55" long
18* 5303289044 A B C Support-air duct cvr,1.83" long
28 5303289062 A B C Bolt-roller adj,hex head ,5/16-24 x 7/8
29 215314301 A B C Washer,.40 x .75 x .06 ,nylon
29* 215598900 A B C Washer-flat, .691x1x.05, zinc, I&W hinge brkt
29* 218871201 A B C Washer,nylon ,0.363 ID w/nibs
30 218993701 A B C Bracket-lower hinge,RH ,w/hinge pin
30* 218979701 A B C Tapping Plate,lower hinge
30A 218993901 A B C Bracket-lower hinge,LH ,w/hinge pin
30A* 218979601 A B C Tapping Plate,lower hinge
37 5303321083 A - - Trim-cabinet corner,black
37 5303321082 - B - Trim-cabinet corner,almond
37 5303321081 - - C Trim-cabinet corner,white
38 218215242 A - - Bracket-upper hinge, with closer, black, RH
38 218215244 A - - Bracket-upper hinge, with closer, black, LH
38 218215249 - B - Bracket-upper hinge, with closer, almond, RH
38 218215251 - B - Bracket-upper hinge, with closer, almond, LH
38 218215241 - - C Bracket-upper hinge, with closer, white, RH
38 218215243 - - C Bracket-upper hinge, with closer, white, LH
40 5303323268 A - - Cover-upper hinge,black
40 5303318774 - B - Cover-upper hinge,almond
40 5303318773 - - C Cover-upper hinge,white
41 5303001609 A B C Grommet,shelf mtg ,0.69" ,RH
41* 5308009759 A B C Grommet,shelf mtg ,1.25" ,LH
43 218615300 A B C Roller Assy,front ,(2)
43* 5308017044 A B C Screw-roller mtg, spcl ind hex hd, 5/16-18(23)x7/8
44 218738300 A B C Roller Assy,rear ,(2)
45 5303001343 A B C Screw,hex washer head ,8-15A x 0.500
47 218659500 A B C Channel-shelf mtg,side ,(2)
52 215454600 A B C Tube-water,ice mold fill ,elbow
66 215050201 A B C Damper-meat keeper
66A 218171301 A B C Cover-meat kpr dmpr
72 218359609 A - - Grille/Kickplate,black
72 218359605 - B - Grille/Kickplate,almond
72 218359601 - - C Grille/Kickplate,white
77 5303001216 A B C Washer-nylon,3/16 x 5/8 OD
78 5303274237 A B C Screw-bracket,hex wshr hd, 8-32CA x 0.500
80 218249802 A B C Seal-coil cover,(2)
81 5308016566 A B C Screw, hex wshr hd, 8-15A x 0.625, low profile
85 218922705 A - - Cover-lower hinge,black
85 218922703 - B - Cover-lower hinge,almond
85 218922701 - - C Cover-lower hinge,white
89 218871501 A B C Cover-machine compt
90 215022602 A B C Seal-foam
90* 5303322647 A B C Tape-foam
91 218964701 A B C Deflector-air,air duct cover
92 5303001479 A B C Screw-hinge mtg,hex hd ,1/4-20 x 0.875
100 5303288973 A B C Support-pan cover
101 215305702 A B C Seal-foam
101* 218663103 A B C Gasket-air duct cvr
* 5303305345 A - - Paint,touch-up ,black
* 5303305325 - B - Paint,touch-up ,almond
* 5303305324 - - C Paint,touch-up ,white
* 218902101 A B C Cap-protector, lower hinge
CABINET

08/00 8
Publication No. GLRSF236J
5995342945
SHELVES

# = Fast-moving Parts 9 08/00
* = Non-Illustrated Parts
GLRSF236J Publication No.
5995342945
A = GLRSF236J (GLRSF236JB1)
B = GLRSF236J (GLRSF236JD1)
C = GLRSF236J (GLRSF236JW1)
POS. NO PART NO DESCRIPTION
2 5303298147 A B C Trim-basket
11 218298001 A B C Shelf-freezer,sliding ,wire
11* 218159700 A B C Spacer-shelf
11A 5304408038 A B C Shelf-freezer,fixed wire
11C 240324101 A B C Shelf-pizza
24 215406140 A B C Shelf-"Spill-Safe",fixed ,(3)
25 215124343 A B C Cover-storage pan
25* 5303301393 A B C • Control-humidity
25* 5304412757 A B C • Trim-storage pan cvr, upper, w/humidity hole
25A 218015302 A B C Trim-storage pan cvr,snap-on ,front
25C 218015402 A B C Trim-storage pan cvr,snap-on ,rear
26 5303289500 A B C Pan-storage,upper
26A 5303289501 A B C Pan-storage,lower
28 08013638 A B C End Cap-shelf, protector, lower fzr shelf
39 215217543 A B C Trim-frzr shelf
39A 215217558 A B C Trim-frzr shelf
42 215002301 A B C Hanger-pan/tray,LH
42* 215002401 A B C Hanger-pan/tray,RH
46 218278207 A B C Front-storage pan,upper & lower
47 218498182 A B C Insert-pan cover,glass
47A 215723552 A B C Insert-pan cover,16.31" x 17.32" ,glass
49 5303289521 A B C Basket-sliding
51 5303288960 A B C Hanger-basket,RH
52 215162501 A B C Hanger-basket,LH,with/spring
57 5303271653 A B C Ferrule-inner
62 218285701 A B C Tray-deli
67 218278504 A B C Front-deli tray
81 5308016566 A B C Screw, hex wshr hd, 8-15A x 0.625, low profile
96 215192600 A B C Support-water tank
97 241500101 A B C Water Tank
100A 218015501 A B C Support-pan cover,LH
100B 218015601 A B C Support-pan cover,RH
101 215005000 A B C Screw, hex wshr hd, 8-18AB x 0.750, gusset/hanger
123 215005100 A B C Screw-roller/hanger,8-10 x 0.438
126 218867401 A B C Channel,auger mtg ,LH
126 218867402 A B C Channel,auger mtg ,RH
* 215328300 A B C Clip-shelf
SHELVES

08/00 10
Publication No. GLRSF236J
5995342945
CONTROLS

# = Fast-moving Parts 11 08/00
* = Non-Illustrated Parts
GLRSF236J Publication No.
5995342945
A = GLRSF236J (GLRSF236JB1)
B = GLRSF236J (GLRSF236JD1)
C = GLRSF236J (GLRSF236JW1)
POS. NO PART NO DESCRIPTION
2 215028605 A B C Knob-damper control
5 # 5308000010 A B C Fan Blade,red
7 5308000124 A B C Ring-fan orifice
8 5300157666 A B C Bushing-motor mtg,(2)
9 5303205118 A B C Bracket-motor mtg,front
12 215809600 A B C Diffuser-air
13 # 215426200 A B C Motor-evap fan
13* 215474201 A B C Washer,"slinger" ,nylon ,evap fan shaft
14 5303205119 A B C Bracket-motor mtg,rear
15 5303001179 A B C Light Bulb/Lamp,40 W
16 5303289050 A B C Socket-light/lamp
17 5303296805 A B C Control Box,refr
17A 5303296581 A B C Control Box,frzr
17A* 215188300 A B C Screw-control box mtg, hex hd, 8-15A x 1.000,refr/frzr
18 5303308568 A B C Knob-temp control,frzr
20 5304411663 A B C Label-control box,refr
20A 5303308611 A B C Label-control box,frzr
21 # 5303300027 A B C Control-temperature
22 5303319683 A B C Housing-temp sensor,plastic
22* 218731102 A B C Tube, insulator, PVC, white, on temp sensor
23 # 215846602 A B C Timer-defrost, 60 Hz, 120 V, 8 hour/30 min
23* 215277000 A B C Cover-defrost timer,top
23* 5303001259 A B C Screw-timer mtg, pan hd, 6-20 x 0.438, (2)
23* 5303289058 A B C Shield-defrost timr,btm
41 5303001343 A B C Screw,hex washer head ,8-15A x 0.500
41* 5303209814 A B C Nut,"U" type ,8-15A ,fan mtr mtg
53 215809512 A B C Box-damper control
65 5303001361 A B C Pin-mounting,push-in ,plastic
75 218465101 A B C Shield-light,refr
76 218225800 A B C Cover-light socket
78 5308000039 A B C Screw,hex wshr hd, 8-32CA x 0.500, (7), serrated hd
81 5308016566 A B C Screw, hex wshr hd, 8-15A x 0.625, low profile
83 5308000107 A B C Bracket-connector
111 5303289024 A B C Wireway,frzr
114# 5303289051 A B C Switch-light/lamp,white
115 215011505 A B C Damper Assy,w/seal
116 215011400 A B C Seal-damper,foam
125 215334201 A B C Switch-auger kill,white
137 218904602 A B C Filter-water,carbon ,with o’ ring
138 218893301 A B C Cup-water filter
* 218904301 A B C O-ring,wtr filter cup
139 218893201 A B C Housing-wtr filter
140 218518700 A B C Elbow-water tube
141 218832401 A B C Valve-water,dual solenoid ,115 V ,w/nut
141* 215290100 A B C Screw-solenoid valve, hx hd-slot wshr, 12-24 x 3/4
143 218696700 A B C Heater-water filter
* 218646000 A B C Wiring Harness,filter heater
CONTROLS

08/00 12
Publication No. GLRSF236J
5995342945
SYSTEM

# = Fast-moving Parts 13 08/00
* = Non-Illustrated Parts
GLRSF236J Publication No.
5995342945
A = GLRSF236J (GLRSF236JB1)
B = GLRSF236J (GLRSF236JD1)
C = GLRSF236J (GLRSF236JW1)
POS. NO PART NO DESCRIPTION
1 218787800 A B C Condenser
1* 5303208866 A B C Spacer-cond tube,black
1* 5303289026 A B C Spacer-tube
1* 5304406721 A B C Spacer-cond tube,round ,5/8 OD x .81"lg
2 5303289029 A B C Clip-cond mtg,(4)
3 218679608 A B C Block-evap coil,styrofoam ,(1)
3* 218679605 A B C Block-evap coil, 2.05 wide, styrofoam, (2)
4 # 218944001 A B C Drier-filter,R134a System
5 218959901 A B C Wiring Harness,main
5* 215005200 A B C Wiring Harness,refr controls
5* 218815101 A B C Wiring Harness,frzr controls
6 218960201 A B C Wiring Harness,machine compt
7 215459201 A B C Cord-electric power
8 218803400 A B C Cover-wiring
13 # 215006701 A B C Heat Exchanger,suction line
14 # 218169805 A B C Heater-defrost
15 # 218955802 A B C Evaporator,bundy
15* 3206414 A B C Tube-inlet
16 5308000110 A B C Strap-evap/heater,aluminum ,(2)
17 5304415956 A B C Insulator-evap
19 218631200 A B C Tube,rubber
21 # 218969902 A B C Thermostat-defrost
22 218811100 A B C Base-compressor mtg,(drain pan)
23 218513300 A B C Grommet-compr mtg,(4)
25 218773500 A B C Screw-compressor mtg,hex wshr hd, 10Bx11/4
29 # 218894801 A B C Compressor,R134a ,w/o electricals
30 # 218721109 A B C Starter-PTC
32 216649100 A B C Clamp,elec cont mtg ,compressor
41 5308000039 A B C Screw, hex wshr hd, 8-32CA x 0.500, (7),serrated hd
43 215174700 A B C Clamp-service cord, strain relief, galv steel
43* 5303001199 A B C Clamp-wiring harness, strain relief, galv steel
43* 5308000133 A B C Clamp,nylon ,.625 ID
45 5303001343 A B C Screw,hex washer head ,8-15A x 0.500
45* 218769200 A B C Screw,hx wshr hd spec ,#6-32 x .5
45* 5300141713 A B C Screw,hex wshr hd ,8-32 x 0.625 ,spec
49 218990801 A B C Bracket-evap/cvr mtg
54 5303289027 A B C Rail-cabinet base,rear
54A 5303289311 A B C Rail-compr support
54A* 215732700 A B C Screw,pan head ,10-12A x 0.50
54B 5303289292 A B C Rail-cabinet base,front
55 # 218909901 A B C Capacitor-run,220 VAC ,15 microfarad
56 218769300 A B C Insert-compressor mtg
57 218247300 A B C Clip-wiring harness
58 218956901 A B C Screw-cond fan mtr, hex hd, #8-36 x 7/16
59 218956601 A B C Shroud-cond fan mtr
60 # 218956401 A B C Motor-condenser fan
61 218956501 A B C Blade-condenser fan
61* 218956701 A B C Nut,speed ,fan blade
61* 218956801 A B C Grommet-silencer
62 215048703 A B C Trough-drain, w/shield assy & #17 insulator
64 5303289063 A B C Tube-drain
65 5303289301 A B C Spacer-tube
70 5303289041 A B C Bracket-evap/cvr mtg
81 5308016566 A B C Screw,hex wshr hd ,8-15A x 0.625, low profile
* 5303917214 A B C Hot Tube Repair Kit,Service
SYSTEM

08/00 14
Publication No. GLRSF236J
5995342945
DISPENSER

# = Fast-moving Parts 15 08/00
* = Non-Illustrated Parts
GLRSF236J Publication No.
5995342945
A = GLRSF236J (GLRSF236JB1)
B = GLRSF236J (GLRSF236JD1)
C = GLRSF236J (GLRSF236JW1)
POS. NO PART NO DESCRIPTION
1 218832301 A B C Tube-water inlet, inlet valve ,to filter
1* 218949201 A B C Tube-water inlet, formed, plastic, dispenser
1A 218859901 A B C Tube-water inlet,inlet valve ,to filter
2 218505303 A - - Deflector-ice disp,black
2 218505302 - B - Deflector-ice disp,almond
2 218505301 - - C Deflector-ice disp,white
3 # 215484300 A B C Heater-door housing
4 218852403 A - - Housing-dispenser,black
4 218852402 - B - Housing-dispenser,almond
4 218852401 - - C Housing-dispenser,white
7 # 218284800 A B C Switch-actuator,micro
8 218874901 A B C Module-dispenser
10 218209800 A B C Spring,dispenser door
12 218836203 A - - Knob-selector,black
12 218836202 - B - Knob-selector,almond
12 218836201 - - C Knob-selector,white
12A 218925403 A - - Knob-selector,black
12A 218925402 - B - Knob-selector,almond
12A 218925401 - - C Knob-selector,white
12A* 218925501 A B C Spring-knob
14 218903732 A - - Label-module cover,black
14 218903744 - B - Label-module cover,almond
14 218903730 - - C Label-module cover,white
15 218284900 A B C Light Bulb/Lamp,4 W ,115 V
16 215284900 A B C Socket-light/lamp
17 215794400 A B C Screw,#6 x 1/4
17A 215840700 A B C Screw,truss head ,6-20 x 3/8
17A* 215923400 A B C Washer-flat
23 5303299660 A - - Drip Tray,black
23 5303297845 - B - Drip Tray,almond
23 5303297844 - - C Drip Tray,white
24 218921303 A - - Actuator,black
24 218921302 - B - Actuator,almond
24 218921301 - - C Actuator,white
26 215503200 A B C Screw,cr pan hd ,10-16 x 0.500
27 218432600 A B C Cam-slide
27A 218814901 A B C Rocker-switch
28 218906203 A - - Cover-module,black
28 218906202 - B - Cover-module,almond
28 218906201 - - C Cover-module,white
30 215753600 A B C Door Assy-ice chute,w/gasket,insul
33 # 218870201 A B C Heater-disp throat
35 # 218740005 A B C Heat Motor,115 V
36 218906001 A B C Cover-selector sw
38 # 218905901 A B C PC Board
38A# 218479900 A B C Switch-micro,single pole ,double throw
38B# 218835401 A B C Switch-micro,single pole ,single throw
39 218284600 A B C Wire-ice door
40 218284500 A B C Yoke-heat motor
41 215917800 A B C Spring-actuator
43 215760300 A B C Screw,#4 x 3/8
49 215794000 A B C Bracket-heat motor
56 218434300 A B C Screw-micro switch, pan head, 4-24 x 9/16
56A 218927401 A B C Screw, pan head, 4-24 x 1.125, microswitch mtg
82 215296300 A B C Screw,plask h/l ,#6 x 3/8
84 218906401 A B C Switch-membrane
85 218948201 A B C Transformer-dispenser
* 218863111 A B C Wiring Harness,disp
DISPENSER

08/00 16
Publication No. GLRSF236J
5995342945
ICE CONTAINER

# = Fast-moving Parts 17 08/00
* = Non-Illustrated Parts
GLRSF236J Publication No.
5995342945
A = GLRSF236J (GLRSF236JB1)
B = GLRSF236J (GLRSF236JD1)
C = GLRSF236J (GLRSF236JW1)
POS. NO PART NO DESCRIPTION
2 5304404344 A B C Auger-ice
3 5304404343 A B C Cam-drive
4 218815300 A B C Container-ice
6 5304404346 A B C Drum-ice disp
7 218815400 A B C Front-ice container
10 5304404337 A B C Bar-drive
13 5304404359 A B C Gate
15 5303001179 A B C Light Bulb/Lamp,40 W
16 5303289050 A B C Socket-light/lamp
17 5304404345 A B C Drive Blade
18 # 218980601 A B C Motor-auger
18* 5304404335 A B C Wiring Harness,auger motor
20 5304404332 A B C Cover-motor
21 215285100 A B C Nut-drive
23 5304404347 A B C Plate-front
25 5304404362 A B C Screw,hex washer head ,8-32T x 0.375
26 215503200 A B C Screw,cr pan hd ,10-16 x 0.500
33 5304404351 A B C Spacer
34 5304404349 A B C Spacer
35A 5304404353 A B C Fixed Blade,round
35B 5304404352 A B C Fixed Blade,square
37A 5304404348 A B C Blade-crusher,#1
37B 5304404350 A B C Blade-crusher,#2
37C 5304404356 A B C Blade-crusher,#3
39 5304404365 A B C Screw
41 5304404358 A B C Housing-crusher
44 218359200 A B C Screw,pan head ,8-32 x 0.250
45 # 5304404333 A B C Solenoid Assy
45A 5304406816 A B C Spring-solenoid
45B 5304406817 A B C E-Ring-solenoid
45C 5304406818 A B C Actuator-solenoid
45D 5304406819 A B C Solenoid
46 5304404341 A B C Control Rod
47 5304404342 A B C Spring-control rod
48 5304404340 A B C Bracket-control rod
48* 5304404364 A B C Screw-bracket
49 5304404329 A B C Rail Assy
50 5304404334 A B C Guide-solenoid
51 5304404336 A B C Rotation Stop
52 5304404354 A B C Spacer-fixed blades
53 5304404355 A B C Pin-spiral,fixed blades
54 5304404357 A B C Nut-auger
55 5304404360 A B C Washer
56 5304404361 A B C E-ring
57 5304404363 A B C Door-access
58 5304404331 A B C Screw-solenoid
* 215781700 A B C Clip-tube
* 218842802 A B C Ice Container Assy
ICE CONTAINER

08/00 18
Publication No. GLRSF236J
5995342945
ICE MAKER

# = Fast-moving Parts 19 08/00
* = Non-Illustrated Parts
GLRSF236J Publication No.
5995342945
A = GLRSF236J (GLRSF236JB1)
B = GLRSF236J (GLRSF236JD1)
C = GLRSF236J (GLRSF236JW1)
POS. NO PART NO DESCRIPTION
1 218832301 A B C Tube-water inlet, inlet valve, to filter
1* 218949201 A B C Tube-water inlet, formed, plastic, dispenser
1A 218859901 A B C Tube-water inlet, inlet valve, to filter
2 3206348 A B C Spring,shut-off arm
3 3206299 A B C Label,ID plate
4 3206301 A B C Gear
5 3206303 A B C Plate-mounting
6 3206305 A B C Screw-ground wire, 8-32 x 0.250
7 # 3206306 A B C Motor-ice maker
8 3206312 A B C Spacer-hold switch
9 3206313 A B C Cam
10 3206315 A B C Clamp
11 # 3206319 A B C Thermal Cutoff, ice maker, complete assy
12 # 3206349 A B C Wiring Harness, ice maker, internal, with plug
12* 3206321 A B C • Connector Plug,wiring harness
13 # 3206322 A B C Thermostat Assy,ice maker
15 # 3206324 A B C Switch,(3)
16 3206326 A B C Support,phenolic
17 # 5303320545 A B C Mold-ice maker,Radius Cube ,with heater
18 3206328 A B C Ejector-ice
19 3206330 A B C Bearing & Inlet
20 5304408581 A B C Screw,8-32 x 0.375
21 3206332 A B C Ice Stripper
22 3206333 A B C Shut-off Arm
23 5304408582 A B C Screw, 8-32 x 0.875, mold-to-support, (3)
24 3206335 A B C Lever Arm
25 3206336 A B C Screw,8-18 x 0.562 ,lever arm/sprt
26 3206337 A B C Screw-thermo/sprt,4-24 x 0.375 ,(4)
27 3206338 A B C Screw, 4-40 x 1.000, hold switch mtg, (2)
28 3206339 A B C Screw-timing stop,4-40 x 0.375
29 3206323 A B C Screw,4-24 x 0.750 ,(6)
30 3206341 A B C Screw-timing adj,8-32 x 1.000
31 3206342 A B C Insulator
32 3206343 A B C Plate-valve switch
33 5304408583 A B C Spring-timing adj
34 5304408584 A B C Screw,plascrew ,#6 ,(3)
35 5304408585 A B C Screw
36 3206347 A B C Cover-ice maker
44 5308000133 A B C Clamp,nylon ,.625 ID
45 5303001343 A B C Screw,hex washer head ,8-15A x 0.500
46 5303001193 A B C Clamp,.50 ID ,steel ,water tube
51 218947201 A B C Tube-water fill,extension ,with notch
55# 218859701 A B C Valve-water, single solenoid, 115 V, w/nut
55* 218873001 A B C • Cap-water valve
59 5303001191 A B C Sleeve-tube insert
60 5303207328 A B C Screw,hex washer hd, 8-15A x 1.000, (2)
61 218721500 A B C Bracket-leveling,ice maker
62 218737900 A B C Screw-IM brkt mtg, hex wshr hd, 8-32D x 0.375
64 5303001549 A B C Clamp,0.31 ID ,steel ,copper wtr line
141 218832401 A B C Valve-water,dual solenoid ,115 V ,w/nut
141* 215290100 A B C Screw-solenoid valve,hx hd-slot wshr, 12-24 x 3/4
* 218699501 A B C Ice Maker, Radius Cube, 115 V, no instl parts
ICE MAKER

08/00 20
Publication No. GLRSF236J
5995342945
WIRING SCHEMATIC
