Frigidaire FRT21P6A User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FRT21P6BSB0 FRT21P6BS R134a black (right) 115
FRT21P6BSB1 FRT21P6BS R134a black (right) 115
MARKET
North America
Publication No.
5995369559
020405
-EN/SERVICE/DCS
357
TOP MOUNT
REFRIGERATOR
Model No.
FRT21P6A
©2002 Electrolux Home Products, Inc.
All rights reserved
FACTORY
PARTS CATALOG
ELECTROLUX HOME PRODUCTS, INC
P.O. Box 212378, Augusta, GA 30917
ENERGY GUIDE - 218791411
OWNER’S GUIDE - 240400105
SERVICE DATA SHEET - 240379009

04/02 2
Publication No. FRT21P6A
5995369559
DOOR

# = Fast-moving Parts 3 04/02
* = Non-Illustrated Parts
FRT21P6A Publication No.
5995369559
A = FRT21P6BS (FRT21P6BSB0)
B = FRT21P6BS (FRT21P6BSB1)
POS. NO PART NO DESCRIPTION
1 # 240514611 A B Gasket-frzr door,black ,magnetic
2 # 240514612 A B Gasket-refr door,black ,magnetic
4 240331401 A B Rack-door,20.27" x 1.72"
5 240311502 A B Support-door rack,2 liter ,RH
5A 240331502 A B Support-door rack,gallon ,RH
6 240311501 A B Support-door rack,2 liter ,LH
6A 240331501 A B Support-door rack,gallon ,LH
7 240337703 A B Door-dairy,w/o graphics ,clear
8 240331402 A B Rack-door,17.99" x 1.72"
11 240450331 A B Door-frzr, RH, stainless steel, complete assy
12 240415204 A B Label-nameplate,black
13 240312405 A B Door Stop,black ,ref
13A 240312406 A B Door Stop,black ,frzr
14B 240383603 A B Plug-button,black ,door handle
15 240450437 A B Door-refr,black ,complete assy
18 240339203 A B Handle-door,black
18A 240339208 A B Handle-door,black
21C 218252200 A B Screw,#8 truss hd ,10-32CA x 0.500
22 240311202 A B Bearing-hinge,black ,(8)
74 240383401 A B Screw,truss hd quad ,#10-16 x .500
96 240345506 A B Plug,door foam hole ,black
* 218490900 A B Cleaner,stainless steel
DOOR

04/02 4
Publication No. FRT21P6A
5995369559
CABINET

# = Fast-moving Parts 5 04/02
* = Non-Illustrated Parts
FRT21P6A Publication No.
5995369559
A = FRT21P6BS (FRT21P6BSB0)
B = FRT21P6BS (FRT21P6BSB1)
POS. NO PART NO DESCRIPTION
1 240355402 A B Cover-fan
2 240367001 A B Knob-damper control
3 5303001028 A B Nut,push-on
4 240367401 A B Damper-fan cover
5 # 5308000010 A B Fan Blade,red ,evaporator fan
8 5300157666 A B Bushing-motor mtg,(2)
9 5303292396 A B Bracket-motor mtg,front
10 240313606 A B Cover-evap coil
10* 240371303 A B Seal, insulation, 53.23 in. long, foam, coil cover
10*# 240385402 A B Wiring Harness,freezer section
11 5303208309 A B Plug-hole,factory test
12 240366801 A B Plug-ice maker harness,rectangular
12A 240374401 A B Plug-wtr inlet tube,round ,1"
13 # 240369701 A B Motor-evap fan
13* 218931001 A B Clamp-motor wiring, nylon, w/adhesive tape
14 5303292397 A B Bracket-motor mtg,rear
14* 240433201 A B Screw,hex washer head ,8-18 x 0.375
18 240411901 A B Support-evap cover,(2)
21C 218252200 A B Screw,#8 truss hd ,10-32CA x 0.500
22 215774918 A B Plug-button,black ,upr hinge holes
28 240335501 A B Bolt-roller adj,hex wshr hd, 1/4-20 x 4.020, (2), special
30 240314003 A B Bracket-lower hinge,black
34 240311301 A B Washer,hinge ,nylon ,(2)
35 240313803 A B Bracket-ctr hinge,black
35A 240336801 A B Spacer-hinge,center
36 240516401 A B Pin-center hinge
37 240337603 A B Trim-cabinet corner,black
38 240313701 A B Bracket-upper hinge
40 240354404 A B Cover-upper hinge,black
41 5303001609 A B Grommet,shelf mtg ,0.69" ,RH
41* 5308009759 A B Grommet,shelf mtg ,1.25" ,LH
42 240315301 A B Screw-hinge mtg,hex head ,1/4-20 x 0.75
43 240335003 A B Roller Assy,front ,(2)
47 218233300 A B Channel-shelf mtg,side ,(2)
48 5303292395 A B Channel-shelf mtg,center
49 218362500 A B Screw,hex washer head ,8-18AB x 1.250
56 240516501 A B Pin-lower hinge
58 5303274237 A B Screw, hex wshr hd, 8-32CA x 0.500, motor bracket
59 240442703 A B Screw-#10-32 X 3/4,black
72 240368203 A B Grille/Kickplate,black
81 5308016566 A B Screw, hex wshr hd, 8-15A x 0.625, low profile
82 5304418225 A B Roller, compressor base, rear, (2)
83 5303316859 A B Rivet, flat head,1/4 OD x 1-3/4, roller pin
89 240326115 A B Cover-access,with label
89* 241500301 A B Screw,hex washer head ,8-18AB x 0.500
92 5303001479 A B Screw-hinge mtg,hex hd ,1/4-20 x 0.875
* 218990901 A B Clip-wire
* 240479601 A B Plug,button ,cab liner holes
* 5303305345 A B Paint,touch-up ,black
CABINET

04/02 6
Publication No. FRT21P6A
5995369559
SHELVES

# = Fast-moving Parts 7 04/02
* = Non-Illustrated Parts
FRT21P6A Publication No.
5995369559
A = FRT21P6BS (FRT21P6BSB0)
B = FRT21P6BS (FRT21P6BSB1)
POS. NO PART NO DESCRIPTION
10 215667501 A B Tray-ice,plastic
11 240358003 A B Shelf-freezer
11* 5303299664 A B Spacer,shelf
12 240380202 A B Diffuser-air,top
13 240362601 A B Diffuser,air ,bottom
14 # 240505801 A B Switch,light/lamp
15 240436701 A B Light Bulb/Lamp, A-15, 40 W,120 V, miniature
16 241500701 A B Socket-light/lamp
17 240368101 A B Control Box
17*# 240388701 A B Wiring Harness,control box
18 240360801 A B Knob,temp control
21 # 5304421256 A B Control,temperature
22A 5303916855 A B Tube,sensor sleeve ,plastic ,clear
23 # 215846606 A B Timer, defrost, 60 Hz, 0.25 W, 120 V, 10 hour/30 min
23* 5303001259 A B Screw-timer mtg,pan hd, 6-20 x 0.438, (2)
24 240373105 A B Frame-shelf,cantilever ,full width
25 240364717 A B Cover-crisper pan
25B 240361202 A B Control-humidity
25C 240361301 A B Damper,humidity cont.
26 240343803 A B Pan-crisper,(2)
28 3201150 A B End Cap,freezer shelf ,protector
29 240357701 A B Trim-shelf,24.48" ,front
31 240530903 A B Pan-meat,w/o graphics ,clear
36 240373106 A B Frame-half shelf,cantilever ,(2)
37 240357702 A B Trim-shelf,11.95" ,front
40 240443323 A B Glass-shelf,24.45" x 17.60" ,full shelf
41 240357801 A B Trim-shelf,24.48" ,rear
42 240530601 A B Hanger-meat pan,LH
42 240530701 A B Hanger-meat pan,RH
43 240443318 A B Glass-shelf,11.92" x 17.60" ,half shelf
44 240357802 A B Trim-shelf,11.95" ,rear
47 240350654 A B Insert-pan cover,glass
81 5308016566 A B Screw, hex wshr hd, 8-15A x 0.625, low profile
123 215005100 A B Screw-roller/hanger,8-10 x 0.438
* 3205266 A B Edge Protector,wiring harness
SHELVES

04/02 8
Publication No. FRT21P6A
5995369559
SYSTEM

# = Fast-moving Parts 9 04/02
* = Non-Illustrated Parts
FRT21P6A Publication No.
5995369559
A = FRT21P6BS (FRT21P6BSB0)
B = FRT21P6BS (FRT21P6BSB1)
POS. NO PART NO DESCRIPTION
1 # 240444401 A B Condenser,dynamic
4 # 218944001 A B Drier-filter,R134a System
6 # 240496101 A B Wiring Harness,machine compt, w/electric cord
6* # 240385402 A B Wiring Harness,freezer section
6* # 240388701 A B Wiring Harness,control box
14 # 5303918247 A B Defrost Heater Kit
15 # 5303918250 A B Evaporator Kit
16 5308000110 A B Strap-evap/heater,aluminum ,(2)
17 240434002 A B Trough-drain
18 240362301 A B Insulation Block,RH
20 240362401 A B Insulation Block,LH
21 # 5303918202 A B Thermostat-defrost,kit
22 240330006 A B Plate-compr mtg
22* 218252200 A B Screw,#8 truss hd ,10-32CA x 0.500
23 218513300 A B Grommet-compr mtg,(4)
25 240491501 A B Screw-compressor mtg,1/4-28 x 1.16,shoulder,typ CF
26 240332602 A B Pan-defrost drain
29 # 5303918264 A - Compressor,w/electricals
29 # 5303918251 - B Compressor,w/electricals
30 # 218721120 A - Starter,PTC
30 # 218721119 - B Starter,PTC
32 240493301 A - Clamp, elec cont mtg, compressor, bale wire
32 218973501 - B Clamp, elec cont mtg, compressor
34 240405201 A B Grommet, rubber, black, cond tube/wire
41 218897001 A B Screw, hex washer head, 8-32 x 1/4
44 215174700 A B Clamp-service cord, strain relief, galv steel
45 5308016566 A B Screw, hex wshr hd, 8-15A x 0.625, low profile
55 # 218909901 A - Capacitor-run,220 VAC ,15 microfarad
55 # 216787800 - B Capacitor-run
55* 218897002 A B Screw,hex washer head, 8-32 x 0.375
57 240403601 A B Clip-wiring harness
58 215004600 A B Screw,hx serr wshr hd, 8-36 x 7/16, cond fan motor,(2)
59 240315501 A B Shroud-cond fan
59* 240346701 A B Tape-foam seal,shroud
59* 240359401 A B Screw-fan shroud,(2)
59A 240346501 A B Bracket-support,cond mtr ,(3)
59B 240346601 A B Grommet-bracket,(3)
60 # 240334001 A B Motor,condenser fan
61 # 240315401 A B Fan Blade,galv steel ,condenser fan
61A 215004700 A B Nut,speed
61B 215004800 A B Grommet-silencer
82 5304418225 A B Roller,compressor base, rear, (2)
83 5303316859 A B Rivet,flat head, 1/4 OD x 1-3/4, roller pin
84 240500801 A B Tube-drain,lower
85 240493101 A - Tube-connector,suction
85 240346201 - B Tube-connector,suction
86 240409302 A B Spacer-cond tube,black
* 3205266 A B Edge Protector,wiring harness
* 240396801 A B Clamp,tube/wiring ,nylon ,black/natural
* 5308000039 A B Screw,hex wshr hd, 8-32CA x 0.500, serrated head
* # 5303918210 A B Heat Exchanger Kit,suction line
* # 5304421289 A B Hot Tube Repair Kit,Service
SYSTEM

04/02 10
Publication No. FRT21P6A
5995369559
WIRING SCHEMATIC

# = Fast-moving Parts 11 04/02
* = Non-Illustrated Parts
FRT21P6A Publication No.
5995369559
WIRING DIAGRAM
