Frigidaire FRT21PRG User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FRT21PRGD1 FRT21PRG R134a System almond 115
FRT21PRGD2 FRT21PRG R134a System almond 115
FRT21PRGD3 FRT21PRG R134a System almond 115
FRT21PRGW1 FRT21PRG R134a System white 115
FRT21PRGW2 FRT21PRG R134a System white 115
FRT21PRGW3 FRT21PRG R134a System white 115
MARKET
North America
Publication No.
5995316345
981223
-EN/SERVICE /GS
357
REFRIGERATOR
Model No.
FRT21PRG
©1998 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
REFRIGERATOR
OWNER’S GUIDE - 218613700
SERVICE DATA SHEET - 218755000
101 Masters Blvd.
Anderson, SC 29624

12/98 2
Publication No. FRT21PRG
5995316345
DOOR

# = Fast-moving Parts 3 12/98
* = Non-Illustrated Parts
FRT21PRG Publication No.
5995316345
DOOR
A = FRT21PRG (FRT21PRGW1)
B = FRT21PRG (FRT21PRGD1)
C = FRT21PRG (FRT21PRGW2)
D = FRT21PRG (FRT21PRGD2)
E = FRT21PRG (FRT21PRGW3)
F = FRT21PRG (FRT21PRGD3)
POS. NO PART NO DESCRIPTION
1 215608903 - B - D - F Gasket-frzr door,almond ,magnetic
1 215608913 A - C - E - Gasket-frzr door,white ,magnetic
2 # 218730609 A - C - E - Gasket-refr door,white ,magnetic
2 # 218730610 - B - D - F Gasket-refr door,almond ,magnetic
3 5303275674 A B C D E F Panel-inner door,refr
5A 5303323480 A B C D E F Support-door rack,white ,RH
6A 5303323481 A B C D E F Support-door rack,white ,LH
7 5303308336 A B C D E F Door-dairy,12.25" wide
8 215474045 A B C D E F Rack-door,26.28" x 1.10"
9 5303206631 A B C D E F Panel-inner door,frzr
10 5303001308 - B - D - F Plug-button,almond ,hinge brg hole
10 5308000134 A - C - E - Plug-button,white ,hinge brg hole
11 5303917826 A - C - E - Panel-frzr door,white ,w/insulation
11 5303917877 - B - D - F Panel-frzr door,almond ,w/foam insulatn
12 218156512 A - C - E - Nameplate Assy,white ,with magnet
12 218156513 - B - D - F Nameplate Assy,almond ,with magnet
12* 215008607 A - C - E - Label-nameplate,white
12* 215008608 - B - D - F Label-nameplate,almond
12* 215518000 A B C D E F Magnet-nameplate
12* 218364001 A - C - E - Frame-nameplate,white
12* 218364002 - B - D - F Frame-nameplate,almond
13 218800300 A B C D E F Door Stop,plated
13A 218249001 A - C - E - Door Stop,white ,frzr section
13A 218249002 - B - D - F Door Stop,almond ,frzr section
14 5308000090 A - C - E - Plug-button,white
14 5308000181 - B - D - F Plug-button,almond
14A 215352201 A - C - E - Plug-button,white ,handle mtg ,refr door front
14A 215352211 - B - D - F Plug-button,almond ,handle mtg ,refr door front
14B 218074001 A B C D E F Plug-button,white ,refr door front ,lower
14B 218074002 A B C D E F Plug-button,almond ,refr door front ,lower
15 5303917828 A - C - E - Panel-refr door,white ,w/insul & brace
15 5303917829 - B - D - F Panel-refr door,almond ,w/insul & brace
18 218668001 A - C - E - Handle-door,white
18 218668002 - B - D - F Handle-door,almond
21C 218252200 A B C D E F Screw,#8 truss hd ,10-32CA x .5
21C 5308007097 A B C D E F Screw,cr truss head ,8-15A x 0.750
22 218519300 A B C D E F Bearing-hinge
37 215867058 A - C - E - Trim-handle,4.97" ,white ,w/band & lock
37 215867059 - B - D - F Trim-handle,4.97" ,almond ,w/band & lock
37A 215867070 A - C - E - Trim-handle,29.84" ,white ,w/band & locks
37A 215867071 - B - D - F Trim-handle,29.84" ,almond ,w/band & locks
37A* 215782300 A B C D E F Lock-handle trim,snap-in
37A* 215940700 A B C D E F Lock-handle trim,stick-on
37A* 218676001 A B C D E F Band-decorative,chrome
49 215441513 A B C D E F Bin-door,gallon
58 218749600 A B C D E F Screw,#10 pan hd ,8-18 x .5
61 5308017047 A B C D E F Nut,self-threading ,1/8
62 5303275673 A B C D E F Divider-dairy compt
* 5303207328 A B C D E F Screw,hex washer hd,8-15A x 1
* 5303917276 A B C D E F Insulation-door,fiberglass, (bulk)

12/98 4
Publication No. FRT21PRG
5995316345
CABINET
17
19
18
24
23
25
45
30 92
P05B0385
56
47
48
47
81
49
22
92
10
83
14
8
13
37
38
40
12
58
5
11
9
8
78
4
98
36
59
35
20
21
45
46
44
43
26
28
100
29
41
2
3
1
81
6
27

# = Fast-moving Parts 5 12/98
* = Non-Illustrated Parts
FRT21PRG Publication No.
5995316345
CABINET
A = FRT21PRG (FRT21PRGW1)
B = FRT21PRG (FRT21PRGD1)
C = FRT21PRG (FRT21PRGW2)
D = FRT21PRG (FRT21PRGD2)
E = FRT21PRG (FRT21PRGW3)
F = FRT21PRG (FRT21PRGD3)
POS. NO PART NO DESCRIPTION
1 5304402655 A B C D E F Cover-fan
2 5303307351 A B C D E F Knob-damper control
3 5303001028 A B C D E F Nut,push-on
4 218722200 A B C D E F Damper-fan cover,black
5 # 218649000 A B C D E F Fan Blade,black
6 5303001388 A B C D E F Plug-button,white
8 5300157666 A B C D E F Bushing-motor mtg,(2)
8* 218754500 A B C D E F Screw,hex hd ser wshr ,#8-18 x 3/8
9 5303205118 A B C D E F Bracket-motor mtg,front
10 218802800 A B C D E F Cover-evap coil
10* 5303209814 A B C D E F Nut,"U" type ,8-15(A) ,fan mtr mtg
11 5303208309 A B C D E F Plug-hole,factory test
12 215079000 A B C D E F Plug-harness hole,round
12 215079100 A B C D E F Plug-wtr inlet tube,round
13 # 218718403 A B - - - - Motor-evap fan
13 # 218878801 - - C D E F Motor-evap fan
14 5303322992 A B C D E F Bracket-motor mtg,rear
17 5303001470 A B C D E F Trough-drain
18 215245000 A B C D E F Support-evap cover,(2)
19 5303001198 A B C D E F Tube,rubber
20 5303001286 A B C D E F Ferrule-inner
21 5303001287 A B C D E F Ferrule-outer
22 215774901 A - C - E - Plug-button,white ,upr hinge holes
22 215774911 - B - D - F Plug-button,almond ,upr hinge holes
23 5303210377 A B C D E F Tube-drain,w/seal ring
24 5303207353 A B C D E F Seal Ring,drain tube
25 215774100 A B C D E F Spout-drain tube,w/mounting pins
25* 5303001361 A B C D E F Pin-mounting,push-in ,plastic
26 218605101 A - C - E - Base-cabinet,white
26 218605102 - B - D - F Base-cabinet,almond
27 5303212922 A B C D E F Screw-leveling
28 5303271412 A B C D E F Bolt-roller adj,hex hd sems ,1/4-28 x 2.75,(2)
29 218666700 A B C D E F Washer,.28 x .62 x .03 ,nylon
29 218875801 A B C D E F Washer,nylon ,0.245 ID w/nibs
29* 5308011326 A B C D E F Washer,.34 x .62 x .02 ,nylon
30 218220200 A B C D E F Bracket-lower hinge
30* 218605200 A B C D E F Tapping Plate/Gusset,RH
30* 218605300 A B C D E F Tapping Plate/Gusset,LH
35 218220101 A - C - E - Bracket-ctr hinge,light grey
35 218220102 - B - D - F Bracket-ctr hinge,almond
36 218251300 A B C D E F Pin-center hinge
37 5303321081 A - C - E - Trim-cabinet corner,white
37 5303321082 - B - D - F Trim-cabinet corner,almond
38 3206100 A B C D E F Bracket-upper hinge
38* 5308012296 A B C D E F Tapping Plate,upper hinge ,(2)
40 3206101 A - C - E - Cover-upper hinge,white
40 3206105 - B - D - F Cover-upper hinge,almond
41 5303001609 A B C D E F Grommet,shelf/rod mtg ,RH
41* 5308009759 A B C D E F Grommet,shelf mtg ,LH
43 218703001 A B C D E F Roller Assy,front ,(2)
43* 5308009790 A B C D E F Spring-roller adj
44 218713600 A B C D E F Roller Assy,rear ,(2)
45 5303001343 A B C D E F Screw,hex wshr hd ,8-15A x .5 ,spec
45* 5303207328 A B C D E F Screw,hex wshr hd ,8-15A x 1
46 5308009762 A B C D E F Bolt-roller mtg,hex wshr hd ,1/4-28 x .5,(2)
47 218233300 A B C D E F Channel-shelf mtg,side ,(2)
48 5303292395 A B C D E F Channel-shelf mtg,center
49 218362500 A B C D E F Screw,hex washer head ,8-18AB x 1-1/4
56 218220300 A B C D E F Pin-lower hinge
58 5308002748 A B C D E F Screw,hex wshr hd ,8-15A x 0.500 ,special
59 218188000 A B C D E F Screw,pan hd ,10-32 x 0.625 ,
hinge/mullion,thread forming

12/98 6
Publication No. FRT21PRG
5995316345
17
19
18
24
23
25
45
30 92
P05B0385
56
47
48
47
81
49
22
92
10
83
14
8
13
37
38
40
12
58
5
11
9
8
78
4
98
36
59
35
20
21
45
46
44
43
26
28
100
29
41
2
3
1
81
6
27
CABINET

# = Fast-moving Parts 7 12/98
* = Non-Illustrated Parts
FRT21PRG Publication No.
5995316345
CABINET
A = FRT21PRG (FRT21PRGW1)
B = FRT21PRG (FRT21PRGD1)
C = FRT21PRG (FRT21PRGW2)
D = FRT21PRG (FRT21PRGD2)
E = FRT21PRG (FRT21PRGW3)
F = FRT21PRG (FRT21PRGD3)
POS. NO PART NO DESCRIPTION
78 5308000039 A B C D E F Screw,hex wshr hd ,8-32CA x 0.500 ,
serrated head
81 5308016566 A B C D E F Screw,hex wshr hd ,8-15A x 0.625 ,low profile
83 5308000107 A B C D E F Bracket-connector
92 5303001479 A B C D E F Screw-hinge mtg,hex hd ,1/4-20 x 0.875
98 215099701 A - C - E - Plug-button,white ,ctr hinge hole
98 215099711 - B - D - F Plug-button,almond ,ctr hinge hole
100 5303288973 A B C D E F Support-pan cover
* 215005000 A B C D E F Screw,hex wshr hd ,8-18AB x 0.750 ,
gusset/hanger
* 218601201 A B C D E F Plug-button,white ,cabinet base
* 5303305324 A - C - E - Paint,touch-up ,white
* 5303305325 - B - D - F Paint,touch-up ,almond
* 5308016571 A B C D E F Plug-button,cabinet liner ,icemaker holes

12/98 8
Publication No. FRT21PRG
5995316345
SHELVES

# = Fast-moving Parts 9 12/98
* = Non-Illustrated Parts
FRT21PRG Publication No.
5995316345
SHELVES
A = FRT21PRG (FRT21PRGW1)
B = FRT21PRG (FRT21PRGD1)
C = FRT21PRG (FRT21PRGW2)
D = FRT21PRG (FRT21PRGD2)
E = FRT21PRG (FRT21PRGW3)
F = FRT21PRG (FRT21PRGD3)
POS. NO PART NO DESCRIPTION
1 218651900 A - C - E - Mullion,white
1 218651901 - B - D - F Mullion,almond
5 # 218781002 A B C D E F Heater-mullion
6 218845600 A B - - - - Tapping Plate,mullion mtg ,(2)
6 218845602 - - C D E F Tapping Plate,mullion mtg ,(2)
7 218866101 A B C D E F Top Panel-refr
7* 5303001380 A B C D E F Screw,truss head ,8-10 x 1.750
8 218866000 A B C D E F Divider,styrofoam
8* 218767600 A B - - - - Harness-wiring,control/divider
8* # 218878600 - - C D E F Harness-wiring,control/divider
9 218865900 A B C D E F Bottom Panel-frzr
10 215667501 A B C D E F Tray-ice,plastic
11 5303288243 A B C D E F Shelf-freezer,fixed/flat ,full width ,wire
11* 218159700 A B C D E F Spacer-shelf
11* 5303299664 A B C D E F Spacer-shelf
12 218730000 A B C D E F Deflector-air
13 218631001 A B C D E F Cover-air deflector
14 # 5309918806 A B C D E F Switch-light/lamp
15 5303001179 A B C D E F Light Bulb/Lamp,40 W
16A# 5308000815 A B - - - - Socket-light/lamp
16A 218906801 - - C D E F Socket-light/lamp
17 5303321455 A B C D E F Control Box
17* 5308016567 A B C D E F Nut-anchor
18 5303311079 A B C D E F Knob-temp control
19 # 5303286905 A B C D E F Switch-energy saver,rocker type
21 # 5304403736 A B C D E F Control-temperature
21* 5303001260 A B C D E F Screw-control mtg,pan hd ,6-32 x 0.250
22A 5303916855 A B C D E F Tube,plastic ,clear ,sensor sleeve
22B 218731104 A B C D E F Tube,PVC ,white ,@ air deflector ,insulator
23 # 5303321915 A B C D E F Timer-defrost,10 hr ,115V
24 215919117 A B C D E F Frame-full shelf,cantilever
25 5303206538 A B C D E F Cover-crisper pan
25A 5303311411 A B C D E F Trim-crisper cover
25B 5303311404 A B C D E F Control-humidity
26 5303323459 A B C D E F Pan-crisper,14.34" wide
27 5303205987 A B C D E F Support-crisper cvr,adjustable
28 3201150 A B C D E F End Cap-shelf,protector ,upper fzr shelf
29 215919405 A B C D E F Trim-glass shelf,26.80" ,front
31 5303323460 A B C D E F Pan-meat
33 5303200329 A B C D E F Gasket-pan cover,13.25" ,RH
34 5303212918 A B C D E F Container-ice
36 215919115 A B C D E F Frame-half shelf,cantilever
36A 215919167 A B C D E F Frame-meat kpr shlf,cantilever
37A 215919411 A B C D E F Trim-half shelf,front
40 218390524 A B C D E F Glass-shelf,26.76" x 14.57"
41 215919805 A B C D E F Trim-glass shelf,26.80" ,rear
42 5303298718 A B C D E F Hanger-pan/tray,LH
42 5303298719 A B C D E F Hanger-pan/tray,RH
43 218390525 A B C D E F Glass-shelf,13.03" x 14.57"
44 215919811 A B C D E F Trim-glass shelf,13.07" ,rear
47 218390523 A B C D E F Insert-pan cover,glass
59 218188000 A B C D E F Screw,pan hd ,10-32 x 0.625 ,
hinge/mullion,thread forming
60 5308010253 A B C D E F Screw
61 215781501 A B C D E F Shelf-ice tray,wire
81 5308016566 A B C D E F Screw,hex wshr hd ,8-15A x 0.625 ,low profile
123 215005100 A B C D E F Screw-roller/hanger,8-10 x .438
145 218660800 A B C D E F Clip,plastic ,temp sensor mtg ,snap-in
* 3205266 A B C D E F Edge Protector,wiring harness
* 218755000 A B C D E F Service Data Sheet

12/98 10
Publication No. FRT21PRG
5995316345
45
45
6
43
7
45
43
4
27
26
29
25
24
23
22
55
32
30
28
P05C0101
44
45
13
17
16
21
20
14
19
15
18
1
85
41 2
SYSTEM
