Frigidaire FRT21PRH User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
FRT21PRHB7 FRT21PRH R134a black 115
FRT21PRHD7 FRT21PRH R134a almond 115
FRT21PRHW7 FRT21PRH R134a white 115
MARKET
North America
Publication No.
5995349130
010130
-EN/SERVICE/KHB
357
REFRIGERATOR
Model No.
FRT21PRH
©2001 White Consolidated Industries, Inc.
All rights reserved
FACTORY PARTS CATALOG
REFRIGERATOR
WIRING DIAGRAM - # 193832
OWNER’S GUIDE - # 218989102
SERVICE DATA SHEET - # 218755000
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. Box 212378, Augusta, GA 30917

01/01 2
Publication No. FRT21PRH
5995349130
DOOR

# = Fast-moving Parts 3 01/01
* = Non-Illustrated Parts
FRT21PRH Publication No.
5995349130
DOOR
A = FRT21PRH (FRT21PRHB7)
B = FRT21PRH (FRT21PRHD7)
C = FRT21PRH (FRT21PRHW7)
POS. NO PART NO DESCRIPTION
1 # 215608923 A - - Gasket-frzr door,black ,magnetic
1 215608972 - B C Gasket-frzr door,white ,magnetic
2 # 218730622 A - - Gasket-refr door,black ,magnetic
2 # 218730609 - B C Gasket-refr door,white ,magnetic
3 215393201 A B C Panel-inner door,refr
4 218763644 A B C Rack-door,23.09" x 2.04"
4A 218763643 A B C Rack-door,22.51" x 2.04"
4B 218763642 A B C Rack-door,9.24" x 2.04"
5 218758601 A B C Support-door rack,RH/LH
5A 218809701 A B C Support-door rack,LH
5B 218809801 A B C Support-door rack,RH
7 5303304569 A B C Door-dairy, 12.96" wide, clear, no graphics
8 218763645 A B C Rack-door,23.47" x 2.04" ,(2)
9 215530301 A B C Panel-inner door,frzr
10 5303272397 A - - Plug-button,black ,hinge brg hole
10 5303001308 - B - Plug-button,almond ,hinge brg hole
10 5308000134 - - C Plug-button,white ,hinge brg hole
11 5303918031 A - - Panel-frzr door,black ,w/insulation
11 5303917827 - B - Panel-frzr door,almond ,w/insulation
11 5303917826 - - C Panel-frzr door,white ,w/insulation
12 218917603 A - - Label-nameplate,black
12 218917602 - B - Label-nameplate,almond
12 218917601 - - C Label-nameplate,white
13 218800300 A B C Door Stop, plated
13A 218249003 A - - Door Stop, black ,frzr section
13A 218249002 - B - Door Stop, almond ,frzr section
13A 218249001 - - C Door Stop, white ,frzr section
14 218915703 A - - Plug-button, black
14 218915702 - B - Plug-button, almond
14 218915701 - - C Plug-button, white
14B 218074001 A B C Plug-button, white, refr door front, lower
14B 218074002 A B C Plug-button, almond, refr door front,lower
14B 218074003 A B C Plug-button, black, refr door front, lower
15 5303918030 A - - Panel-refr door,black ,w/insulation
15 5303917829 - B - Panel-refr door,almond ,w/insul & brace
15 5303917828 - - C Panel-refr door,white ,w/insul & brace
18 218668003 A - - Handle-door,black
18 218668002 - B - Handle-door,almond
18 218668001 - - C Handle-door,white
21C 218252200 A B C Screw,#8 truss hd ,10-32CA x 0.500
22 218519300 A B C Bearing-hinge
37 218811623 A - - Trim-handle, black, upper, w/band & snap-on lock
37 218811622 - B - Trim-handle, almond, upper, w/band & snap-on lock
37 218811621 - - C Trim-handle, white, upper, w/band & snap-on lock
37* 218906701 A B C Lock-handle trim, stick-on
37A 218811626 A - - Trim-handle, black, lower, w/band,& snap-on lock
37A 218811614 - B - Trim-handle, almond, lower, w/band & snap-on lock
37A 218811613 - - C Trim-handle, white, lower, w/band,& snap-on lock
37A* 215782300 A B C Lock-handle trim,snap-in
37A* 218676004 A B C Band-decorative, satin aluminum, handle trim
58 218781100 A B C Screw,pan head ,8-18 x 0.625
* 5303917276 A B C Insulation-door,fiberglass ,(bulk)

01/01 4
Publication No. FRT21PRH
5995349130
CABINET

# = Fast-moving Parts 5 01/01
* = Non-Illustrated Parts
FRT21PRH Publication No.
5995349130
CABINET
A = FRT21PRH (FRT21PRHB7)
B = FRT21PRH (FRT21PRHD7)
C = FRT21PRH (FRT21PRHW7)
POS. NO PART NO DESCRIPTION
1 5304402655 A B C Cover-fan
2 5303307351 A B C Knob-damper control
3 5303001028 A B C Nut,push-on
4 218722200 A B C Damper-fan cover,black
5 # 218649000 A B C Fan Blade,black
8 5300157666 A B C Bushing-motor mtg,(2)
9 5304414684 A B C Bracket-motor mtg,front
10 218973801 A B C Cover-evap coil
10* 5303209814 A B C Nut,"U" type ,8-15A ,fan mtr mtg
11 5303208309 A B C Plug-hole,factory test
12 215079000 A B C Plug-harness hole,round
12 215079100 A B C Plug-wtr inlet tube,round
13 # 218878801 A B C Motor-evap fan
14 5303322992 A B C Bracket-motor mtg,rear
17 218974001 A B C Trough-drain
18 215245000 A B C Support-evap cover,(2)
19 5303001198 A B C Tube,rubber
20 5303001286 A B C Ferrule-inner
21 5303001287 A B C Ferrule-outer
22 215774918 A - - Plug-button,black ,upr hinge holes
22 215774911 - B - Plug-button,almond ,upr hinge holes
22 215774901 - - C Plug-button,white ,upr hinge holes
23 5303210377 A B C Tube-drain,w/seal ring
24 5303207353 A B C • Seal Ring,drain tube
25 215774100 A B C Spout-drain tube,w/mounting pins
26 218605103 A - - Base-cabinet,black
26 218605102 - B - Base-cabinet,almond
26 218605101 - - C Base-cabinet,white
27 5303212922 A B C Screw-leveling
28 5303271412 A B C Bolt-roller adj, hex hd sems, 1/4-28 x 2.750,(2)
29 218875801 A B C Washer,nylon ,0.245 ID w/nibs
30 218220203 A B C Bracket-lower hinge,zinc chromate
30* 218605200 A B C Tapping Plate/Gusset,RH
30* 218605300 A B C Tapping Plate/Gusset,LH
35 218998903 A - - Bracket-ctr hinge,black
35 218998902 - B - Bracket-ctr hinge,almond
35 218998901 - - C Bracket-ctr hinge,light gray
36 218251300 A B C Pin-center hinge
37 5303321083 A - - Trim-cabinet corner,black
37 5303321082 - B - Trim-cabinet corner,almond
37 5303321081 - - C Trim-cabinet corner,white
38 3206100 A B C Bracket-upper hinge
40 5304400454 A - - Cover-upper hinge,black
40 3206105 - B - Cover-upper hinge,almond
40 3206101 - - C Cover-upper hinge,white
41 5303001609 A B C Grommet, shelf mtg ,0.69" ,RH
41* 5308009759 A B C Grommet, shelf mtg ,1.25" ,LH
43 218703001 A B C Roller Assy, front ,(2)
44 218713600 A B C Roller Assy, rear ,(2)
45 218754500 A B C Screw, hex hd ser wshr, 8-18 x 0.375
46 5308009762 A B C Bolt-roller mtg,hex wshr hd, 1/4-28 x 0.500, (2)
47 218233300 A B C Channel-shelf mtg,side ,(2)
48 5303292395 A B C Channel-shelf mtg,center
49 218362500 A B C Screw,hex washer head ,8-18AB x 1.250
56 218220300 A B C Pin-lower hinge
59 218188000 A B C Screw, pan hd,10-32 x 0.625, hinge/mull,thrd forming
72 218916406 A - - Grille/Kickplate,black ,w/fasteners
72 218916405 - B - Grille/Kickplate,almond ,w/fasteners
72 218916404 - - C Grille/Kickplate,white ,w/fasteners
73 218896704 A B C Fastener-grille,clip ,(2)
78 5303274237 A B C Screw-bracket, hex wshr hd, 8-32CA x 0.500
81 5308016566 A B C Screw, hex wshr hd, 8-15A x 0.625, low profile
83 5308000107 A B C Bracket-connector
92 5303001479 A B C Screw-hinge mtg,hex hd ,1/4-20 x 0.875
98 215099718 A - - Plug-button,black
98 215099711 - B - Plug-button,almond
98 215099701 - - C Plug-button,white

01/01 6
Publication No. FRT21PRH
5995349130
CABINET

# = Fast-moving Parts 7 01/01
* = Non-Illustrated Parts
FRT21PRH Publication No.
5995349130
A = FRT21PRH (FRT21PRHB7)
B = FRT21PRH (FRT21PRHD7)
C = FRT21PRH (FRT21PRHW7)
POS. NO PART NO DESCRIPTION
100 5303288973 A B C Support-pan cover
110 215363501 A B C Support-crisper rod
116 215426703 A B C Rod-crisper support
* 218905701 A B C Cover-sound insul,pressboard/foam, machine compt
* 5303321321 A - - Paint,touch-up ,black
* 5303305325 - B - Paint,touch-up ,almond
* 5303305324 - - C Paint,touch-up ,white
* 5308016571 A B C Plug-button,cab liner holes
CABINET

01/01 8
Publication No. FRT21PRH
5995349130
SHELVES

# = Fast-moving Parts 9 01/01
* = Non-Illustrated Parts
FRT21PRH Publication No.
5995349130
SHELVES
A = FRT21PRH (FRT21PRHB7)
B = FRT21PRH (FRT21PRHD7)
C = FRT21PRH (FRT21PRHW7)
POS. NO PART NO DESCRIPTION
1 218651902 A - - Mullion,black
1 218651901 - B - Mullion,almond
1 218651900 - - C Mullion,white
5 # 218781002 A B C Heater-mullion
6 218845602 A B C Tapping Plate,mullion mtg ,(2)
7 218866101 A B C Top Panel-refr
8 218909706 A B C Divider,styrofoam ,w/foil tape
8* 218878600 A B C Wiring Harness,control/divider
9 218865900 A B C Bottom Panel-frzr
10 215667501 A B C Tray-ice,plastic
11 5303288243 A B C Shelf-freezer, fixed/flat, full width, wire
11* 5303299664 A B C Spacer-shelf
12 218730000 A B C Deflector-air
13 218631001 A B C Cover-air deflector
14 # 5309918806 A B C Switch-light/lamp
15 5303001179 A B C Light Bulb/Lamp,40 W
16A 218906801 A B C Socket-light/lamp
17 5304414816 A B C Control Box
17* 5308016567 A B C Nut-anchor
18 5303311079 A B C Knob-temp control
19 # 5303286905 A B C Switch-energy saver,rocker type
21 # 5304403736 A B C Control-temperature
21* 5303001260 A B C Screw-control mtg,pan hd ,6-32 x 0.250
22A 5303916855 A B C Tube,sensor sleeve ,plastic ,clear
22B 218731104 A B C Tube, PVC, white, @ air deflector, insulator
23 # 215846606 A B C Timer-defrost, 60 Hz, 120 V, 10 hour/30 min
23* 5303001259 A B C Screw-timer mtg, pan hd, 6-20 x 0.438, (2)
24 215919117 A B C Frame-full shelf,cantilever
25 215363203 A B C Cover-crisper pan,less insert
25A 5304412423 A B C Trim-crisper cover
25A* 5303301393 A B C Control-humidity
26 215363301 A B C Pan-crisper,tilt-out
28 3201150 A B C End Cap-shelf,protector ,frzr shelf
29 215919405 A B C Trim-glass shelf,26.80" ,front
31 215742602 A B C Pan-meat
34 5303212918 A B C Container-ice
36 215919115 A B C Frame-half shelf,cantilever
36A 215919173 A B C Frame-half shelf,cantilever
37 215919411 A B C Trim-half shelf,front
40 218498176 A B C Glass-shelf,26.76" x 14.57"
41 215919805 A B C Trim-glass shelf,26.80" ,rear
42 218971202 A B C Hanger-meat pan,LH
42 218971302 A B C Hanger-meat pan,RH
43 218498175 A B C Glass-shelf,13.03" x 14.57"
44 215919811 A B C Trim-glass shelf,13.07" ,rear
46 215412106 A B C Front-crisper pan,(2)
47 218498178 A B C Insert-pan cover,glass
59 218188000 A B C Screw, pan hd,10-32 x 0.625, hinge/mull,thrd forming
60 5308016566 A B C Screw, hex wshr hd, 8-15A x 0.625, low profile
61 215781501 A B C Shelf-ice tray,wire
67 215357813 A B C Front-meat pan
81 218362500 A B C Screw,hex washer head ,8-18AB x 1.250
123 215005100 A B C Screw-roller/hanger,8-10 x 0.438
145 218660800 A B C Clip,plastic ,temp sensor mtg ,snap-in
* 3205266 A B C Edge Protector,wiring harness

01/01 10
Publication No. FRT21PRH
5995349130
SYSTEM

# = Fast-moving Parts 11 01/01
* = Non-Illustrated Parts
FRT21PRH Publication No.
5995349130
SYSTEM
A = FRT21PRH (FRT21PRHB7)
B = FRT21PRH (FRT21PRHD7)
C = FRT21PRH (FRT21PRHW7)
POS. NO PART NO DESCRIPTION
1 # 218657100 A B C Condenser
1* 5304406039 A B C Spacer-tube,5/8 OD x 3" lg
1* 5304406040 A B C Spacer-tube,5/8 OD x 12" lg
1* 5304406721 A B C Spacer-cond tube,round ,5/8 OD x .81"lg
1* 5304406722 A B C Spacer-tube,5/8 OD x 2" lg
2 5308000296 A B C Bracket,condenser mtg ,(4)
2* 5308009617 A B C Washer,ext tooth lock ,#10 ,grounding
4# 218944001 A B C Drier-filter,R134a System
5 # 218878600 A B C Wiring Harness,control/divider
6 # 215257001 A B C Wiring Harness,compressor
7 # 5316254901 A B C Cord-electric power
8 5303001197 A B C Cover-wiring
13 # 215076408 A B C Heat Exchanger,suction line
14 # 5304419040 A B C Heater-defrost
15 # 218955701 A B C Evaporator,bundy
16 5308000110 A B C Strap-evap/heater,aluminum ,(2)
17 218973901 A B C Insulator-evap,plastic
18 218998101 A B C Block-evap coil,styrofoam insul ,RH
20 218821201 A B C Insulation Block,LH
21 # 218969902 A B C Thermostat-defrost
22 5308013663 A B C Plate-compr mtg
23 218254500 A B C Grommet-compr mtg,(4)
24 5308003633 A B C Washer-compr mtg
25 5308003596 A B C Clip-compressor mtg
26 215372500 A B C Pan-defrost drain
26* 5308017610 A B C Sound Tape,defrost pan
27 5303001348 A B C Nut-lock,1/4-20 ,drain pan mtg
28 5303916001 A B C Pan Retainer Kit,Service
29 218973601 A B C Compressor,w/o electricals
30 # 218721108 A B C Starter-PTC
32 218973501 A B C Clamp,elec cont mtg ,compressor
41 5308000039 A B C Screw, hex wshr hd, 8-32CA x 0.500, (7),serrated hd
43 5303001199 A B C Clamp-wiring harness, strain relief, galv steel
43* 5308000133 A B C Clamp,nylon ,.625 ID
44 218974101 A B C Clamp,nylon ,1.00 OD tube
45 5303001343 A B C Screw,hex washer head ,8-15A x 0.500
45* 218754500 A B C Screw,hex hd ser wshr ,8-18 x 0.375
45* 5300141713 A B C Screw,hex wshr hd ,8-32 x 0.625 ,spec
55 218909901 A B C Capacitor-run,220 VAC ,15 microfarad
* # 5300189383 A B C Hot Tube Repair Kit,Service
* 218905701 A B C Cover-sound insul, pressboard/foam, machine compt

01/01 12
Publication No. FRT21PRH
5995349130
WIRING SCHEMATIC

# = Fast-moving Parts 13 01/01
* = Non-Illustrated Parts
FRT21PRH Publication No.
5995349130
WIRING DIAGRAM
W193832
