Frigidaire GLRT183SB User manual

PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS
GLRT183SBQ1 GLRT183SB R134a bisque 115
GLRT183SBW1 GLRT183SB R134a white 115
MARKET
North America
Publication No.
5995370532
020419
-EN/SERVICE/DCS
357
TOP MOUNT
REFRIGERATOR
Model No.
GLRT183SB
©2002 Electrolux Home Products, Inc.
All rights reserved
FACTORY
PARTS CATALOG
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
WIRING DIAGRAM - # 240379009
OWNER’S GUIDE - # 240400105
SERVICE DATA SHEET -# 240379009

04/02 2
Publication No. GLRT183SB
5995370532
DOOR

# = Fast-moving Parts 3 04/02
* = Non-Illustrated Parts
GLRT183SB Publication No.
5995370532
A = GLRT183SB (GLRT183SBQ1)
B = GLRT183SB (GLRT183SBW1)
POS. NO PART NO DESCRIPTION
1 # 240514605 A B Gasket-frzr door,white ,magnetic
2 # 240514608 A B Gasket-refr door,white ,magnetic
7 240337703 A B Door-dairy,w/o graphics ,clear
10 240381302 A - Plug-button,bisque ,hinge brg hole ,(2)
10 240381301 - B Plug-button,white ,hinge brg hole ,(2)
11 240476202 A - Panel-frzr door,bisque ,complete assy
11 240476201 - B Panel-frzr door,white ,complete assy
12 240449702 A - Nameplate,bisque
12 240449701 - B Nameplate,white
13 240312407 A - Door Stop,bisque ,ref
13 240312403 - B Door Stop,white ,ref
13A 240312408 A - Door Stop,bisque ,frzr
13A 240312404 - B Door Stop,white ,frzr
14 240494002 A - Plug-button,bisque
14 240494001 - B Plug-button,white
14B 240383602 A - Plug-button,bisque ,door handle
14B 240383601 - B Plug-button,white ,door handle
15 240476302 A - Panel-refr door,bisque ,complete assy
15 240476301 - B Panel-refr door,white ,complete assy
18 240339204 A - Handle-door,bisque
18 240339201 - B Handle-door,white
18A 240339209 A - Handle-door,bisque
18A 240339206 - B Handle-door,white
21 240383401 A B Screw,truss hd quad ,#10-16 x .500
21C 218252200 A B Screw,#8 truss hd ,10-32CA x 0.500
22 240311201 A B Bearing-hinge,natural color ,(8)
48 240338101 A B Bin-door,pseudo ,bottom
48A 240337901 A B Bin-door,ref
48B 240338001 A B Bin-door,pseudo ,gallon ,refr
49 240495801 A B Bin-door,pseudo ,frzr
96 240345505 A B Plug,door foam hole ,white
DOOR

04/02 4
Publication No. GLRT183SB
5995370532
CABINET

# = Fast-moving Parts 5 04/02
* = Non-Illustrated Parts
GLRT183SB Publication No.
5995370532
A = GLRT183SB (GLRT183SBQ1)
B = GLRT183SB (GLRT183SBW1)
POS. NO PART NO DESCRIPTION
1 240355401 A B Cover-fan
2 240367001 A B Knob-damper control
3 5303001028 A B Nut,push-on
4 240367401 A B Damper-fan cover
5 # 5308000010 A B Fan Blade,red ,evaporator fan
8 5300157666 A B Bushing-motor mtg,(2)
9 5303292396 A B Bracket-motor mtg,front
10 240462008 A B Cover-evap coil
10* 240371302 A B Seal,insulation ,47.77 in. Long, foam, coil cover
10*# 240385401 A B Wiring Harness,freezer section
11 5303208309 A B Plug-hole,factory test
13 # 240369701 A B Motor-evap fan
13* 218931001 A B Clamp-motor wiring, nylon, w/adhesive tape
14 5303292397 A B Bracket-motor mtg,rear
14* 240433201 A B Screw,hex washer head ,8-18 x 0.375
18 240411901 A B Support-evap cover,(2)
21C 218252200 A B Screw,#8 truss hd ,10-32CA x 0.500
22 215774919 A - Plug-button,bisque ,upr hinge holes
22 215774901 - B Plug-button,white ,upr hinge holes
28 240335501 A B Bolt-roller adj,hex wshr hd, 1/4-20 x 4.020, (2), special
30 240314004 A - Bracket-lower hinge,bisque
30 240314002 - B Bracket-lower hinge,white
34 240311301 A B Washer,hinge ,nylon ,(2)
35 240313804 A - Bracket-ctr hinge,bisque
35 240313802 - B Bracket-ctr hinge,white
35A 240336801 A B Spacer-hinge,center
36 240516401 A B Pin-center hinge
37 240337604 A - Trim-cabinet corner,bisque ,(2)
37 240337601 - B Trim-cabinet corner,white ,(2)
38 240313701 A B Bracket-upper hinge
40 240354403 A - Cover-upper hinge,bisque
40 240354401 - B Cover-upper hinge,white
41 5303001609 A B Grommet,shelf mtg ,0.69" ,RH
41* 5308009759 A B Grommet,shelf mtg ,1.25" ,LH
42 240315301 A B Screw-hinge mtg,hex head ,1/4-20 x 0.75
43 240335003 A B Roller Assy,front ,(2)
56 240516501 A B Pin-lower hinge
58 5303001343 A B Screw,hex washer head ,8-15A x 0.500
59 240442704 A - Screw-#10-32 X 3/4,bisque
59 240442702 - B Screw-#10-32 X 3/4,white
72 240368202 A - Grille/Kickplate,bisque
72 240368201 - B Grille/Kickplate,white
81 5308016566 A B Screw,hex wshr hd, 8-15A x 0.625, low profile
82 5304418225 A B Roller,compressor base ,rear ,(2)
83 5303316859 A B Rivet,flat head ,1/4 OD x 1-3/4, roller pin
89 240326115 A B Cover-access,with label
89* 241500301 A B Screw,hex washer head ,8-18AB x 0.500
92 5303001479 A B Screw-hinge mtg,hex hd ,1/4-20 x 0.875
* 218990901 A B Clip-wire
* 5304414035 A - Paint,touch-up ,bisque
CABINET

04/02
Publication No. GLRT183SB
5995370532
SHELVES

# = Fast-moving Parts 7 04/02
* = Non-Illustrated Parts
GLRT183SB Publication No.
5995370532
A = GLRT183SB (GLRT183SBQ1)
B = GLRT183SB (GLRT183SBW1)
POS. NO PART NO DESCRIPTION
11 240358002 A B Shelf-freezer,full width
11* 5303299664 A B Spacer,shelf
12 240362502 A B Diffuser,air ,top
13 240362601 A B Diffuser,air ,bottom
14 240505801 A B Switch,light/lamp
15 240436701 A B Light Bulb/Lamp, A-15, 40 W, 120 V, miniature
16 241500701 A B Socket-light/lamp
17 240352701 A B Control Box
17*# 240388701 A B Wiring Harness,control box
18 240360801 A B Knob,temp control
21 # 5304421256 A B Control,temperature
22A 5303916855 A B Tube,sensor sleeve ,plastic ,clear
23 # 215846606 A B Timer, defrost, 60 Hz, 0.25 W, 120 V, 10 hour/30 min
23* 5303001259 A B Screw-timer mtg,pan hd ,6-20 x 0.438, (2)
24 240358918 A B Shelf-"Spill-Safe",sliding
24A 240358917 A B Shelf-"Spill-Safe",sliding
25 240364714 A B Cover-crisper pan
25B 240361201 A B Control-humidity
25C 240361301 A B Damper,humidity cont.
26 240337103 A B Pan-crisper,clear ,(2) ,no graphics
28 3201150 A B End Cap,freezer shelf ,protector
31 240530803 A B Pan-meat,w/o graphics ,clear
34 240385201 A B Container-ice
47 240350650 A B Insert-pan cover,glass
58 5308016566 A B Screw, hex wshr hd, 8-15A x 0.625, low profile
SHELVES

04/02 8
Publication No. GLRT183SB
5995370532
SYSTEM

# = Fast-moving Parts 9 04/02
* = Non-Illustrated Parts
GLRT183SB Publication No.
5995370532
A = GLRT183SB (GLRT183SBQ1)
B = GLRT183SB (GLRT183SBW1)
POS. NO PART NO DESCRIPTION
1 # 240444401 A B Condenser,dynamic
4 # 218944001 A B Drier-filter,R134a System
6 # 240496101 A B Wiring Harness,machine compt, w/electric cord
6* # 240385401 A B Wiring Harness,freezer section
6* # 240388701 A B Wiring Harness,control box
14 # 5303918208 A B Defrost Heater Kit
15 # 5303918250 A B Evaporator Kit
16 5308000110 A B Strap-evap/heater,aluminum ,(2)
17 240434002 A B Trough-drain
18 240362301 A B Insulation Block,RH
20 240362401 A B Insulation Block,LH
21 # 5303918202 A B Thermostat-defrost,kit
22 240330006 A B Plate-compr mtg
22* 218252200 A B Screw,#8 truss hd ,10-32CA x 0.500
23 218513300 A B Grommet-compr mtg,(4)
25 240491501 A B Screw-compr mtg,1/4-28 x 1.16,shoulder,typ CF
26 240332601 A B Pan-defrost drain
29 # 5303918264 A B Compressor,w/electricals
30 # 218721120 A B Starter,PTC
32 240493301 A B Clamp,elec cont mtg, compressor, bale wire
34 240405201 A B Grommet,rubber ,black ,cond tube/wire
41 218897001 A B Screw,hex washer head ,8-32 x 1/4
44 215174700 A B Clamp-service cord, strain relief, galv steel
45 5308016566 A B Screw,hex washer head ,8-15A x 0.625, low profile
55 # 218909901 A B Capacitor-run,220 VAC ,15 microfarad
55* 218897002 A B Screw,hex washer head ,8-32 x 0.375
57 240403601 A B Clip-wiring harness
58 215004600 A B Screw,hx wshr hd ,8-36 x 7/16, cond fan motor,(2)
59 240315501 A B Shroud-cond fan
59* 240346701 A B Tape-foam seal,shroud
59* 240359401 A B Screw-fan shroud,(2)
59A 240346501 A B Bracket-support,cond mtr ,(3)
59B 240346601 A B Grommet-bracket,(3)
60 # 240334001 A B Motor,condenser fan
61 # 240315401 A B Fan Blade,galv steel ,condenser fan
61A 215004700 A B Nut,speed
61B 215004800 A B Grommet-silencer
82 5304418225 A B Roller,compressor base ,rear ,(2)
83 5303316859 A B Rivet, flat hd, 1/4 OD x 1-3/4, roller pin
84 240500801 A B Tube-drain,lower
85 240493101 A B Tube-connector,suction
86 240409302 A B Spacer-cond tube,black
* 3205266 A B Edge Protector,wiring harness
* 218843800 A B Screw,hex wshr hd ,8-15A x 0.500
* 240396801 A B Clamp,tube/wiring ,nylon ,black/natural
* 5303918222 A B Hot Tube Repair Kit,Service
* # 5303918207 A B Heat Exchanger Kit,suction line
SYSTEM

04/02 10
Publication No. GLRT183SB
5995370532
ICE MAKER

# = Fast-moving Parts 11 04/02
* = Non-Illustrated Parts
GLRT183SB Publication No.
5995370532
A = GLRT183SB (GLRT183SBQ1)
B = GLRT183SB (GLRT183SBW1)
POS. NO PART NO DESCRIPTION
1 218976901 A B Tube-water inlet,inlet valve to ice maker
2 5304420650 A B Spring,shut-off arm
2* 5308000039 A B Screw, hex washer head, 8-32CA x 0.500, serrated head
3 3206299 A B Label,ID plate
4 3206301 A B Gear
5 3206303 A B Plate-mounting
6 3206305 A B Screw-ground wire,8-32 x 0.250
7 # 3206306 A B Motor-ice maker
8 3206312 A B Spacer-hold switch
9 3206313 A B Cam
10 3206315 A B Clamp
11 # 3206319 A B Thermal Cutoff,ice maker, complete assy
12 # 5304420651 A B Wiring Harness,ice maker, internal, with plug
13 # 3206322 A B Thermostat Assy,ice maker
14 5304420652 A B Screw,4 x 0.750 ,switch mtg.
15 # 3206324 A B Switch,(3)
16 5304420653 A B Support,phenolic
17 # 5303320545 A B Mold-ice maker,Radius Cube ,with heater
18 3206328 A B Ejector-ice
19 3206330 A B Bearing & Inlet
20 5304408581 A B Screw,8-32 x 0.375
21 3206332 A B Ice Stripper
22 3206333 A B Shut-off Arm
23 5304408582 A B Screw, 8-32 x 0.875, mold-to-support, (3)
24 3206335 A B Lever Arm
25 3206336 A B Screw,8-18 x 0.562 ,lever arm/sprt
26 5304420654 A B Screw-thermo/sprt,4-24 x 0.375 ,(4)
27 3206338 A B Screw,4-40 x 1.000 ,hold switch mtg, (2)
28 3206339 A B Screw-timing stop,4-40 x 0.375
29 3206323 A B Screw,4-24 x 0.750 ,(6)
30 3206341 A B Screw-timing adj,8-32 x 1.000
31 3206342 A B Insulator
32 3206343 A B Plate-valve switch
33 5304408583 A B Spring-timing adj
34 5304420655 A B Screw,plazscrew ,8-10 ,(3)
35 5304408585 A B Screw
36 3206347 A B Cover-ice maker
45 5308016566 A B Screw,hex washer head, 8-15A x 0.625, low profile
45* 218843800 A B Screw,hex wshr hd ,8-15A x 0.500
51 240387101 A B Tube-water,ice mold fill ,extension
55 # 240380301 A B Valve-water, single solenoid, 50/60 Hz, 105/120 V
60 218362500 A B Screw,hex washer head ,8-18AB x 1.250
61 218721500 A B Bracket-leveling,ice maker
62 218737900 A B Screw-IM brkt mtg,hex washer head, 8-32D x 0.375
64 5303001549 A B Clamp,0.31 ID ,steel ,copper wtr line
* 218888001 A B Adapter-water supply, nut & sleeve, compression ftg
* 240352403 A B Ice Maker, Radius Cube, 115 V, no instl parts

04/02 12
Publication No. GLRT183SB
5995370532
WIRING SCHEMATIC

# = Fast-moving Parts 13 04/02
* = Non-Illustrated Parts
GLRT183SB Publication No.
5995370532
WIRING DIAGRAM
