Frigidaire PLRU1777DS User manual

Product No. PLRU1777DS0
Series 134A
Color white
Volts 115
Wiring Diagram 297005300
Owner's Guide 297005500
Market North America
Energy Guide 216697904
P08F0080.eps P08D0403.eps P08C0760.eps P08S0369.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Publication No.
5995417085
04/09/24
(EN/SERVICE/MLR)
365
REFRIGERATOR
Model No.
PLRU1777DS
Copyright ©2004 Electrolux Home Products, Inc.
All rights reserved.

Publication No: 5995417085 PLRU1777DS0
09/04 2
DOOR

PLRU1777DS0 Publication No: 5995417085
# Functional Parts 3 09/04
* Non-Illustrated Parts
DOOR
POS. NO PART NO. DESCRIPTION
1 216522311 Gasket-door, black
7 240338303 Door, dairy, clear
9 216953600 Panel-inner door, refr
11 216526551 Panel-outer door, stainless steel
12 240558802 Label-nameplate
13 5303271076 Door Stop
18 240536801 Handle-door, stainless steel, with insert
* 218755503 Screw-shoulder, #10 AB, handle mounting
* 218755402 Screw-set, 10-32 x 0.375
21A 5303271077 Screw, flat head, #1/4-20, door stop/hng
22 216970800 Bearing, hinge, top
26 216524200 Gasket, secondary
27 5303212828 Clip, panel mtg
32 5309950074 Valve, breather, door base
48B 240338001 Bin-door, pseudo, gallon, refr
49 216959800 Bin-door, 2-liter, (4)
59 216974500 Bearing, door closer
64 216403700 Plug-button, hole filler, door base
93 5303161215 Screw, ph truss head, 8-18AB x 0.500

Publication No: 5995417085 PLRU1777DS0
09/04 4
CABINET

PLRU1777DS0 Publication No: 5995417085
# Functional Parts 5 09/04
* Non-Illustrated Parts
CABINET
POS. NO PART NO. DESCRIPTION
3 216503100 Screen-drain
5 # 216325600 Fan Blade
6 216604200 Breaker Kit w/corners
9 216603300 Breaker Kit w/corners, 32", top or bottom
10 216741000 Heater-Drain Pan Assy, tubing, formed
10* 216504500 Screw, AB, 8-18x.500, (4)
10A 216710400 Bracket, (2), top drain pan
10B 216710500 Bracket, (2), btm. drain pan
13 # 216934100 Motor, fan, 115 V
14 216922800 Switch, light/lamp, ramp
15 216988000 Light Bulb/Lamp, long, frosted, 40 W, 120V, (2)
16 241507803 Socket-light
16* 297002600 Gasket, light socket
18 216707200 Knob, temp control
19 216204902 Gasket-evap cover
20 216230300 Cover, temp control
21 # 216715500 Control temperature
22 216823500 Clamp, cap tube, cold control
22A 5303916855 Tube, sensor sleeve, plastic, clear
24 5300052943 Screw-clamp, truss hd cr, control
25 216949705 Cover-evaporator
26 216959900 Pan-crisper, (2)
28 216978200 Hinge, bracket, lower, RH
29 216313503 Hose-drain
31 216732400 Pan-drain
31A 240530803 Pan-meat, w/o graphics, clear
32 5308005500 Drain
34 216979500 Shield-light
35 216629700 Clip
38 216939100 Hinge-upper
40 216809001 Cover-upper hinge, black
41 216936800 Screw-hinge, 12-24x.700 HWH, btm
42 216983101 Glass-shelf, full shelf
47 216661601 Baffle-plate
47A 240350650 Insert-pan cover, glass
50 216394000 Bracket, fan motor mount
62 131420300 Screw, cr truss head, 8-18AB x 0.750
62* 216742701 Screw, 8-18 x 9/16, black, (4)
63 216396900 Screw, leveling foot, plastic, adjustable
71A 5304416289 Screw, ph truss head, 8-18AB x 0.47, EVAP PANEL
72 216946601 Grille/Kickplate, 32", black
80 06594601 Bracket, control
93A 216629600 Screw, hex washer head, 10-16 x 0.500, tapping
93B 216036600 Screw, ph washer head, 8-32CA x 0.500, thread forming
93D 216912400 Screw, hex washer head, #8-32 x .500, bracket fan mtr, (2)
131 216971200 Channel-shelf mtg, back, (2)
132 5303283898 Screw, 6-20AB x 3/8
137 216983300 Frame-shelf, cantilever
137A 216983301 Frame-shelf, cantilever
138 216983400 Trim-shelf, front
138A 216983600 Trim-shelf, side

Publication No: 5995417085 PLRU1777DS0
09/04 6
CABINET

PLRU1777DS0 Publication No: 5995417085
# Functional Parts 7 09/04
* Non-Illustrated Parts
CABINET
POS. NO PART NO. DESCRIPTION
138B 216983401 Trim-shelf, front
139 216983500 Trim-shelf, rear
139A 216983501 Trim-shelf, rear
148 216995501 Cover-crisper pan
149 240361301 Damper, humidity cont.
150 240361202 Knob, humidity cont.
151 216988200 Support-crspr cover, RH
151 216988201 Support-crspr cover, LH
152 216974600 Bearing, hinge closer
* 09948773 Insulation, drain tube
* 216697904 Energy Guide

Publication No: 5995417085 PLRU1777DS0
09/04 8
SYSTEM

PLRU1777DS0 Publication No: 5995417085
# Functional Parts 9 09/04
* Non-Illustrated Parts
SYSTEM
POS. NO PART NO. DESCRIPTION
1 # 297015500 Condenser, dynamic
2 5308000110 Strap-evap/heater, aluminum, (2)
4 # 216938600 Drier-filter
5 # 216993700 Harness-main
14 216730700 Heater-defrost
15 # 216737300 Evaporator
15A 216751100 Heat Exchanger
18 216727600 Insulator-evap, styrofoam
19 216727700 Insulator-evap, styrofoam
20 216731000 Thermostat, defrost
22 216970300 Base, condenser
23 216744400 Timer, defrost, 12 hour
24 216968500 Bracket-timer
27 5308002681 Grommet, compressor
29 # 216966300 Compressor, w/o electricals
30 216954200 Controller, compressor, 5 speed
32 216954300 Clip, controller
34 5306594529 Sleeve-compressor, (3)
35 5303272328 Screw, Ind hex sems, 1/4-28 unfx, compressor, (3)
43A 5303212614 Clip, harness mount
50A 240524001 Bracket, fan motor mount
55 218909911 Capacitor-run
58 218897002 Screw, hex washer head, 8-32 x 0.375
60 # 240525401 Motor-condenser fan
61 # 240524101 Fan Blade, galv steel, condenser fan
86 216036600 Screw, ph washer head, 8-32CA x 0.500, thread forming
87 08037849 Screw, ph truss head, 6-32(T) x 0.500, thread cutting
107 297001900 Shield, compressor, Compartment
130 216486800 Support, evaporator mtg
136 240405201 Grommet, rubber, black, cond tube/wire
146 216970200 Shroud-fan orfice
147 240560001 Ring-compression
* 216502500 Sleeve, suction line
