FrontRow FR User manual
Quick Start Guide
1
Introduction
Thank you for purchasing the FrontRow Camera. This Quick Start
Guide is designed to guide you through installation and also
includes warranty terms.
Package Contents
FrontRow Camera Magnetic Clip USB Cable with
Adapter
Adjustable
Lanyard
MicroFiber Cloth Documentation Sticker
2
Hardware Overview
Display Side
Feb 24 Tuesday
AM
Facebook Live
Reverse Camera
Home Button
Touchscreen
Media Button
Power Button
Chain Adapter
3
Chain Adapter The Chain Adapter can be used to wear your
FrontRow on your favorite necklace. It is removable so that you
can connect the included lanyard, clip, or optional accessories
such as the car mount and coil mount.
Reverse Camera The Reverse Camera incorporates a lens with an
85° viewing angle.
Media Button Press the Media Button to take a photo or hold it
down to begin video recording.
Power Button Use the Power Button to power on the FrontRow
Camera. When the FrontRow Camera is powered on, pressing the
Power Button will enter or exit sleep mode. Press and hold the
Power Button to access the Reboot and Power o options.
Touchscreen Use the Touchscreen to navigate between the
various modes. Tap the touchscreen in the center on the home
page to hide/view the main icons.
Home Button The Home button returns you to the home screen.
It can also be used to hide/show the icons on the main screen.
4
Front
The Main Camera has a 147.5° viewingangle sheye lens.
The LED behavior is described below:
LED Description
Solid Blue Fully Charged
Blinking Blue Charging
Blinking Red Recording
Main Camera LED
5
Connecting Accessories
FrontRow can be used with the included adjustable lanyard,
magnetic clip, third party chain adapter, optional car adapter, or
optional coil adapter for mounting exibility. Simply attach the
desired accessory (Magnetic Clip shown below).
The Magnetic Clip can be tilted for use as a stand,
used as a clip, or used on a magnetic surface.
6
Disconnecting Accessories
Press and hold the Release Button while you remove the
connected accessory.
Before You Begin
Remove the protective lm covering
the touchscreen on the FrontRow.
7
Adjusting the Lanyard
To tighten, press and hold
the adjustment buttons and
slide outwards.
To loosen, pull outwards on the
cord from both sides.
8
Installation
1 Connect the USB Cable to the USB Port.
9
2 Connect the other end of the USB Cable to your power
adapter, laptop, power bank, or mobile phone.
USB Adapter
(Included)
For versatility, it can be charged using the included
USBAdapter or remove the adapter to use the USB
TypeC connector.
10
3 Press the Power Button on
the side of your FrontRow.
4 Select your language.
100%
English
日本語
繁体中文
Françai
s
100%
1:59:40
00:53
00:1300:45
01:20
100%
Language
English
Deutsch
日本語
繁体中文
Français
11
5 Select your wireless network.
100%
English
日本語
繁体中文
Françai
s
100%
UBNT_Test
AmpliFi-OC
UBNT-OC
Wi-Fi
6 Enter your password and
tap OK.
Password
q w e r t y u i o p
a s d f g h j k
z x
?123
c v b n m
l
Done
OK
12
7 Tap Set Up Now to set up a
security pattern.
100%
SET UP NO
W
SKI
P
Security Paer
n
8 Draw a security pattern and
conrm it.
100%
Draw Again
13
FrontRow App
Download and install the FrontRow app from the App Store or
Google Play™ Store. The FrontRow app connects your FrontRow
Camera to your mobile device for video review, editing, and
remote access. Preview the video feed, remotely start, and stop
recording without disrupting the cameraview.
14
Touchscreen Features
Tap the Home button or the center of the screen to show/hide
the icons. Swipe left or right over the App icons to navigate to
apps and tap the icon to launch. Swipe towards the center of the
touchscreen from the Gallery icon to view recordings and photos.
Swipe to the center from the Camera icon to enter Camera mode.
Camera
Feb 24 Tuesday
AM
Facebook Live
Home Button
App Icons
Gallery
App Icons
15
Story Mode
Story Mode captures a photo every few moments and creates a
condensed video of your activities.
100%
Draw Again
100%
16
Live Mode
Livestream to your social media accounts by connecting to a Wi-Fi
network or tethering from your mobile device. To connect, simply
sign in to your social media account at the specied web address
from a computer or smartphone and enter the code provided.
17
Camera Mode
Record HD video or take high-resolution photos. Press and hold
the media button to begin video recording or tap the record
button in the bottom center on the screen. To take a photo, press
the media button or tap the button on the bottom right.
18
Settings
On the Home screen, swipe from the top down towards the center
to access settings. Adjust the volume, display brightness, check
Wi-Fi status, and access additional settings.
100%
Draw Again
