FrontRow LessonCam User manual

4. Download
Download and install FrontRow LessonCam software on the teacher’s
computer. LessonCam software is free and can be found at:
PC:https://www.gofrontrow.com/products/frontrow-software/lesson
cam-software-win
Mac: https://www.gofrontrow.com/products/frontrow-software/
lessoncam-software-mac
If the camera is connected properly and you receive an error code upon
startup, click “Tutorials” to access the LessonCam User Guide and
additional installation tips and troubleshooting.
1. Place
There are two key considerations for placement that must
be balanced:
• Sound distribution
Juno should be placed as centrally as possible to the student
seating area to ensure even sound coverage.
• Viewing Angle
Camera should be placed far back enough in the room, so that
the primary teaching area is as front facing as possible.
For most standard classrooms, the ideal spot will be centered at the
back of the room. This allows the most even sound distribution and
ideal viewing angle for most teaching.
The camera can pan/tilt/zoom, so consider how secondary teaching
areas will be viewed when placing the Juno.
If the teacher microphone frequently cuts off when moving about the
room, an external ceiling/wall sensor may be required. The sensor
plugs into the back of the Juno and should be placed above/near the
primary teaching location. Area in green is a good balance of sound distribution and viewing
angle. Additional ceiling or wall sensor may be required.
LessonCam™Installation Guide
2. Mount
Juno may be placed on a sturdy surface or mounted to the wall
using a VESA 100 x 100mm compatible mount.
Camera height should provide the most unobstructed view possible.
Typically, between 54in (137cm) and 84in (213cm) from floor.
54in (137cm)
84in (213cm)
3. Connect
The LessonCam cable harness must connect to the teacher’s
computer via USB-B to USB-A cable. A 50ft (15m) cable is provided.
Cable lengths longer than 50ft (15m) are not recommended.
Important: Disconnect all other USB cameras from the teacher’s
computer during LessonCam installation and initial power-up.
Connect
to teacher’s
computer
Connect
to cable on
LessonCam
bracket
Teacher
Computer
Primary Teaching Area
Secondary
Teaching Area
Secondary
Teaching Area
Ideal
Placement
Ceiling
Sensor
Wall
Sensor
Juno

Installation Instructions
1. Attach camera platform to bracket
using enclosed screws.
2. Verify cables are fully inserted into
USB hub.
3. Remove two screws from back of Juno.
4.a Attach camera bracket to back of Juno
using enclosed screws.
4.b Attach camera bracket to back of Juno using the top two screws only, then attach
entire Juno with camera bracket to VESA mount.
If NOT using a VESA mount: If using a VESA mount:
5. Place camera on top of platform with
front facing the same direction as the
speakers and tighten camera screw.
6. IMPORTANT: Connect RS232 cable to
IN only. Make sure pins align correctly
before inserting. Connect USB and
power to camera.
7. Connect 3.5mm cable, RCA cable and
USB cable as shown. Set “Audio Out”
to 6. Connect USB-B to USB-A cable to
Teacher Computer.
8. Connect Juno tower to power
supply, as shown.
9. Check camera LED Status.
NOTE: There is no on/off button.
The camera is controlled via the
FrontRow LessonCam software only.
• No LED = no power
• Red = standby mode.
Video stream is off.
• Green = video stream is on
DO NOT OVER-TIGHTEN DO NOT OVER-TIGHTEN
Use for
VESA Mount
© 2021 FrontRow Calypso LLC FrontRow, Calypso and the names of FrontRow products are trademarks or registered trademarks of FrontRow Calypso LLC in the U.S. and other countries. All other brand or product names are
trademarks or registered trademarks of their respective owners. 1530-00071/RevA 0321
Teacher
Computer
Before you begin
Unplug Juno power cord from the base of the tower and remove Juno from VESA mount (if applicable).
OFF ON
