MobileView MVC-9002 User manual

MobileView
© Safe Fleet | Aug 2018 | All rights reserved | Part #: 700-1138 R1
MVC-9002 Install Guide.
Product Overview
This is the Install Guide for MobileView camera models:
Installation Environment
When installing your product, consider the
following:
• Electrical: Install electrical wiring carefully.
This should be done by qualied service
personnel. Always use a proper PoE switch
or a 12 VDC power supply to power the
camera. Do not overload the power cord
or adapter. PoE and 12VDC power sources
should NOT be used together; choose only
one.
• Ventilation: Ensure that the location planned
for the installation of the camera is well
ventilated.
• Temperature: Do not operate the camera
beyond the specied temperature, humidity,
or power source ratings. The operating
temperature of the camera is between -30 to
+65°C.
• Servicing: Do not attempt to repair this
camera yourself. Any attempt to dismantle
this product, except as required for normal
installation, will negate the warranty and may
also result in injury. Refer all servicing to
qualied service personnel.
• Cleaning: Do not touch the lens with your
ngers. If cleaning is necessary, use a
clean cloth with ethanol and gently wipe the
camera.
Clean -G model cameras with non-abrasive,
solvent-free neutral soap or detergent with
water and soft cloth. Rinse well with clean
lukewarm water.
Package Contents
Check the package and contents for visible damage. If any
components are damaged or missing, do not attempt to use the
unit; contact the supplier immediately. If the unit is returned, it must
be shipped back in its original packaging.
Package contents:
• Camera
• Y Splitter cable (optionally used if 12VDC power is supplied
via Cat5)
• Hex wrench
• Quick Guide
• Drill Template
• Molex connector/pins
• Guard
Network and Streaming Conguration
• MVC-9002-28-WI
• MVC-9002-40-WI
• MVC-9002-28-WI-G
Cable Requirements
For proper operation, adhere to the following cable and power
requirements for the cameras. All network cabling must be installed
according to applicable codes and regulations.
The table below lists the requirements for the cables that connect
to the camera. The camera has two options to receive power; only
one should be used at a time.
Table 1: Recommended power
PoE(802.3af): Cat5, 24 AWG Stranded or better
12VDC: 18 AWG, or larger
In the web browser, click the Camera tab and then IP Advance Settings on the toolbar to display the conguration screen.
Customer Service
Technical Support: 1-844-899-7366
General Enquiries: 1-877-630-7366
Email: [email protected]
Product Information
For product information and documentation, please visit https://community.seon.com. Please contact Technical Support
if you do not have access credentials.
Name Description
Quick Stats: The top section of the screen displays camera model and number, date, time, rmware version,
serial number, HDD, IP address and Radio Frequency (RF) associated to the wireless network.
Logout: A button to Logout from the system is available in the upper-right section.
IP Channel Settings: Shows general settings for dened camera channel.
IP Advance Settings: Displays camera model, serial number, rmware version, IP address, and encoding version.
IP Video Adjustment: Allows conguration of special video modes, such as day/night, IR, image adjust or Analog
output.
IP Overlay Settings: Gives access to optional video overlay displays.
Stream Settings Displays recording parameters for video source device.
Audio Stream Settings Shows noise lter and recorded volume parameters.
Video Preview Allows live preview of each of the three streams, and audio (if enabled).

Fold Here
Mounting the Camera
1. Use the supplied template to mark out the mounting
area. Drill the screw holes on the surface. Rivnuts with
#8-32 machine screws (or larger) are recommended.
2. Loosen the cover screws to remove the cover from
the camera and x the mounting base to the ceiling
with the appropriate screws.
3. Loosen the adjusting screw to adjust the pan, tilt, and
rotation angle with the adjusting cap, then re-tighten
the screw.
4. Finally, re-install the cover using the cover screws.
Setting Up the Camera
1. Prepare the mounting surface.
2. Mount the camera using the appropriate fasteners. Refer to the Mounting the Camera section.
3. Set up the camera’s network and streaming parameters to control the camera over the network. Refer to the
Accessing the Camera over the Internet section.
4. Program the camera to suit its location.
Accessing the Camera over the Internet
Use the camera web browser to access and congure the camera over the Internet (Microsoft Internet Explorer). Only one
camera is accessible from a single web browser window. To access the camera online:
1. In the Web browser, enter the camera’s IP address (default is 192.168.1.70). The Login dialog box appears.
Note: Ensure that the Active X controls are enabled.
2. Enter your user name and password. Notice that user name is admin and default password is 1234.
3. Click Login. The web browser window appears in Live View mode.
Camera Description
1. Cover
2. Bubble
3. IR
4. Base
5. Lens
6. BNC cable
7. 12VDC Molex
connector
8. Ethernet RJ45 cable
9. Reset button
TIP: For More information 
Refer to the MobileView 9000 & 9100 Series Analog/
IP Camera User Manual.
This document can be found on the Safe Fleet Com-
munity at https://community.seon.com/documents.
Overview of the Camera Web Browser
Name Description
Quick Stats: In the top section, camera model and number, date, time, rmware version, serial number,
HDD, IP address and Radio Frequency (RF) associated to the wireless network are disclosed.
Logout: In the upper-right corner, a button to Logout from the system is available.
Audio Selector: Allows toggling audio on and off.
Primary/Alternate: Selects radio for video stream to display. Stream must be enabled to be seen.
Snapshot: Allows capturing and saving a single JPEG image.
Layout: Allows selecting number of camera views to be displayed at the same time .
Next Channel: Displays following video channel when clicked.
Full Screen: Displays full screen Live View mode.
Help Sidebar: Presents brief explanations of the available features.
5
4
1
3
2
7
6
8
9
The camera web browser displays the following features in Live View mode:
