FS MS100-DEU User manual

2562325A
REV. A 107
Printed in U.S.A.
INSTALLATION INSTRUCTIONS
FOR
MS100-DEU SPEAKER
SAFETY MESSAGE TO INSTALLERS OF SIREN SPEAKERS
The lives of people depend on your proper installa-
tion and servicing of Federal products. It is important
to read and follow all instructions shipped with the
products. In addition, listed below are some other
important safety instructions and precautions you
should follow:
Before Installation
Qualifications
• To properly install an electronic siren: you must have a
good understanding of automotive electrical procedures
and systems, along with proficiency in the installation
and service of safety warning equipment. Always refer
to the vehicle’s service manuals when performing equip-
ment installations on a vehicle.
Sound Hazards
• Your hearing and the hearing of others, in or close to
your emergency vehicle, could be damaged by loud
sounds. This can occur from short exposures to very
loud sounds or from longer exposures to moderately
loud sounds. For hearing conservation guidance, refer
to federal, state, or local recommendations. OSHA
Standard 1910.95 offers guidance on “Permissible Noise
Exposure.”
• All effective sirens and horns produce loud sounds
(120dB) that may cause permanent hearing loss. Always
minimize your exposure to siren sound and wear hear-
ing protection. Do not sound the siren indoors or in en-
closed areas where you and others will be exposed to the
sound.
• Federal Signal siren amplifiers and speakers are de-
signed to work together as a system. Combining a siren
and speaker from different manufacturers may reduce
the warning effectiveness of the siren system and may
damage the components. You should verify or test your
combination to make sure the system works together
properly and meets federal, state and local standards or
guidelines.
During Installation
• DO NOT get metal shavings inside the product. Metal
shavings in the product can cause the system to fail. If
drilling must be done near the unit, place an ESD ap-
proved cover over the unit to prevent metal shavings
from entering the unit. Inspect the unit after mounting
to be sure there are no shavings present in or near the
unit.
• DO NOT connect this system to the vehicle battery until
ALL other electrical connections are made, mounting of
all components is complete, and you have verified that
no shorts exist. If wiring is shorted to vehicle frame,
high current conductors can cause hazardous sparks
resulting in electrical fires or flying molten metal.
• Be sure the siren amplifier and speaker(s) in your in-
stallation have compatible wattage ratings.
• In order for the electronic siren to function properly, the
ground connection must be made to the NEGATIVE bat-
tery terminal.
• Sound output will be severely reduced if any objects are
in front of the speaker. If maximum sound output is re-
quired for your application, you should ensure that the
front of the speaker is clear of any obstructions.
• Install the speaker(s) as far forward on the vehicle as
possible, in a location which provides maximum signal-
ing effectiveness and minimizes the sound reaching the
vehicle’s occupants. Refer to the National Institute of
Justice guide 500-00 for further information.
• Mounting the speakers behind the grille will reduce the
sound output and warning effectiveness of the siren sys-
tem. Before mounting speakers behind the grille, make
sure the vehicle operators are trained and understand
that this type of installation is less effective for warning
others.
• Sound propagation and warning effectiveness will be
severely reduced if the speaker is not facing forward.
Carefully follow the installation instructions and always
install the speaker with the projector facing forward.
• DO NOT install the speaker(s) or route the speaker
wires where they may interfere with the operation of air
bag sensors.
• Installation of two speakers requires wiring speakers in
phase.
• Never attempt to install aftermarket equipment, which
connects to the vehicle wiring, without reviewing a vehi-
cle wiring diagram - available from the vehicle manufac-
turer. Insure that your installation will not affect vehicle
operation and safety functions or circuits. Always check
vehicle for proper operation after installation.
• DO NOT install equipment or route wiring or cord in
the deployment path of an air bag.
• Locate the control head so the vehicle, controls, and mi-
crophone can be operated safely.
• When drilling into a vehicle structure, be sure that both
sides of the surface are clear of anything that could be
damaged.
After Installation
• After installation, test the siren system and light system
to ensure that it is operating properly.
• Test all vehicle functions, including horn operation,
vehicle safety functions and vehicle light systems, to en-
sure proper operation. Ensure that installation has not
affected vehicle operation or changed any vehicle safety
function or circuit.
• After testing is complete, provide a copy of these in-
structions to the instructional staff and all operating
personnel.
• File these instructions in a safe place and refer to them
when maintaining and/or reinstalling the product.
Failure to follow all safety precautions and instructions
may result in property damage, serious injury, or death to you
or others.

IMPORTANT
This speaker complied with SAE J1849 EVS3 and CCR
Title 13 Class A requirements when used with Federal
Signal Corporation electronic sirens.
A. UNPACKING.
After unpacking the kit, carefully check all envelopes,
shipping labels, and tags before removing or destroying them.
Ensure that the parts listed in the KIT CONTENTS LIST are
contained in the packing carton.
B. KIT CONTENTS LIST.
Qty. Description Part Number
2 Screw, 5/16-18 x 3/4” 7002A005-12
2 Lock washer, 5/16” 7074A020
1 Speaker, MS 100-DEU Assembly 8567171
2 Socket Solid Contact 233313
1 Wedgelock 139502
1 2 Pin Female Deutsch Connector 139501
C. INSTALLATION.
To avoid reduction of sound output and damage
to speaker, ensure that speaker is mounted with
wires protruding from the right side of the speaker
when viewing it from the front.
Before drilling holes in ANY part of a vehicle, be sure
that both sides of the mounting surface are clear of parts
that could be damaged; such as brake lines, fuel lines,
electrical wiring or other vital parts. Note that the two
rear bracket hole locations MUST be protected during the
drilling operation.
1. Select an appropriate mounting location which provides
both adequate support and sufficient clearance for the speaker
assembly. In addition, the mounting location should provide
maximum signaling effectiveness while minimizing the sound
reaching the vehicle’s occupants.
To avoid reduction of sound output, ensure that
the speaker is mounted with the sound opening
facing directly in the direction intended to warn.
290A5725
Figure 1.
NOTE
Because of the variety of vehicles and possible mounting
arrangements, installation details and mounting bracket
fabrication must be determined by the installer.
2. Using the components in the accessory kit, the female
deutsch connector should be wired in the following manner: using
16 or 18 gage wire, 1/4” of the wire should be inserted into the solid
contact pins. After the wire has the contact pins, the ground wire
should be placed in position 2 of the female deutsch connector and
the second wire should go in position 1.
3. See figure 1. After the speaker mounting and the mating
component assembly is completed, connect the deutsch connector
from the speaker to the electronic siren’s speaker mating deutsch
connector. The numbering scheme should line up accordingly
where the second position of the female deutsch connector should
line up with the second position of the male deutsch connector.
All effective sirens produce loud sounds which may
cause, in certain situations, permanent hearing
loss. You should take appropriate precautions such
as wearing hearing protection.
4. Test the system for proper operation.
-2-

D. OPERATION.
SAFETY MESSAGE TO OPERATORS OF
FEDERAL SIGNAL ELECTRONIC SIRENS AND
LIGHT/SOUND SYSTEMS
The lives of people depend on your safe operation
of Federal products. It is important to read and
follow all instructions shipped with the products.
In addition, listed below are some other important
safety instructions and precautions you should
follow:
Qualifications
• To properly use an electronic siren and speaker(s):
you must have a good understanding of general
vehicle operation, a high proficiency in the use of
safety warning equipment, and thorough knowledge
of state and federal UNIFORM TRAFFIC CODES.
Sound Hazards
• Your hearing and the hearing of others, in or close to
your emergency vehicle, could be damaged by loud
sounds. This can occur from short exposures to very
loud sounds, or from longer exposures to moderately
loud sounds. For hearing conservation guidance, re-
fer to federal, state, or local recommendations. OSHA
Standard 1910.95 offers guidance on “Permissible
Noise Exposure.”
• All effective sirens and horns produce loud sounds
(120 dB) that may cause permanent hearing loss.
Always minimize your exposure to siren sound, roll
up your windows and wear hearing protection. Do
not sound the siren indoors or in enclosed areas
where you and others will be exposed to the sound.
Only use the siren for emergency response situa-
tions.
Sound Limitations
• Before using the vehicle, check to see if the siren
speakers are concealed from view. If the siren speak-
er is not in clear view on the front of the vehicle,
use extra caution when operating the vehicle. A con-
cealed siren speaker installation is less effective at
warning others.
• Maximum sound output will be severely reduced if
any objects are in front of the speaker. If your instal-
lation has obstructions in front of the speaker, drive
even more cautiously.
• Frequently inspect the speaker to ensure that it is
clear of any obstruction, such as mud or snow, which
will reduce maximum sound output.
-3-
Signaling Limitations
• Be aware that the use of your visual and audible
signaling devices does not give you the right to force
your way through traffic. Your emergency lights, si-
ren, and actions are REQUESTING the right-of-way.
• Although your warning system is operating properly,
it may not alert everyone. People may not hear, see,
or heed your warning signal. You must recognize this
fact and continue driving cautiously.
• Situations may occur which obstruct your warning
signal when natural or man-made objects are be-
tween your vehicle and others. This can also occur
when you raise your hood or trunk lid. If these situa-
tions occur, be especially careful.
Driving Limitations
• At the start of your shift, you should ensure that the
light/sound system is securely attached to the ve-
hicle and operating properly.
• If the unique combination of emergency vehicle
equipment installed in your vehicle has resulted
in the siren controls being installed in a position
that does not allow you to operate them by touch
only, OPERATE CONTROLS ONLY WHILE YOUR
VEHICLE IS STOPPED.
• If driving conditions require your full attention, you
should avoid operating the siren controls while the
vehicle is in motion.
Continuing Education
• File these instructions in a safe place and refer to
them periodically. Give a copy of these instructions
to new recruits and trainees.
Failure to follow these safety precautions may result
in property damage, serious injury, or death to you, to
passengers, or to others. Refer to the instructions packed
with the electronic siren for operation.

E. SERVICE.
SAFETY MESSAGE TO PERSONNEL SERVICING FEDERAL
SIGNAL SIREN SPEAKERS
The lives of people depend on your proper servic-
ing of Federal products. It is important to read and
follow all instructions shipped with the products.
In addition, listed below are some other safety
instructions and precautions you should follow:
• Read and understand all instructions in this manual
before servicing the electronic siren or speaker.
• To properly service an electronic siren or speaker:
you must have a good understanding of automotive
electrical procedures and systems, along with profi-
ciency in the installation and service of safety warn-
ing equipment. Always refer to the vehicle’s service
manuals when performing service on a vehicle.
• Electronic circuit and speaker repairs must be per-
formed by a qualified and competent electronic tech-
nician.
• Your hearing and the hearing of others, in or close to
your emergency vehicle, could be damaged by loud
sounds. This can occur from short exposures to very
loud sounds, or from longer exposures to moderately
loud sounds. For hearing conservation guidance, re-
fer to federal, state, or local recommendations. OSHA
Standard 1910.95 offers guidance on “Permissible
Noise Exposure.”
• All effective sirens and horns produce loud sounds
(120 dB) that may cause permanent hearing loss.
Always minimize your exposure to siren sound and
wear hearing protection. Do not sound the siren in-
doors or in enclosed areas where you and others will
be exposed to the sound.
• DO NOT connect this system to the positive termi-
nal of the battery until servicing is complete, and
you have verified that there are no short circuits to
ground.
• In order for the electronic siren to function prop-
erly, the ground connection must be made to the
NEGATIVE battery terminal.
• After repair, test the electronic siren and speaker
system to ensure that it is operating properly.
• Federal Signal siren amplifiers and speakers are
designed to work together as a system. Combining a
siren and speaker from different manufacturers may
reduce the warning effectiveness of the siren system
and may damage the components. You should verify
or test your combination to make sure the system
works together properly and meets both federal,
state and local standards and guidelines.
Failure to follow all safety precautions and
instructions may result in property damage, serious injury,
or death to you or others.
Opening the unit will void the warranty. This speaker itself
has no field serviceable parts. The factory can and will service your
speaker. If you are experiencing problems with the speaker, send it
to:
Service Department
Federal Signal Corporation
2645 Federal Signal Drive
University Park, IL 60466
F. REPLACEMENT PARTS.
Description Part No.
Socket Solid Contact 233313
Wedgelock 139502
Two Pin Female Deutsch Connector 139501
Copyright 2007 Federal Signal Corporation
-4-
