897N100094A (006-203-40) 2006.10
DICOM Conformance Statement
Print Management Service Class
FUJI NETWORK PRINT SERVER
FN-PS551
Copyright FUJIFILM Corporation, Japan
October 2006
5th Edition

FUJI NETWORK PRINT SERVER FN-PS551
006-203-40 2006.10
Revision History
Revision Date Author Reason for Change
5th Edition October, 2006 The corporate name was changed.

FUJI NETWORK PRINT SERVER FN-PS551
006-203-30 2001.05 i
CONTENTS
1Introduction ................................................................................................................................................ 1
2Implementation Model ............................................................................................................................... 1
2.1 Data Flow Diagram.......................................................................................................................................... 1
2.2 Functional Definitions of Application Entities................................................................................................. 1
2.3 Sequencing of Real World Activities ............................................................................................................... 1
3Application Entity Specification................................................................................................................ 2
4Association................................................................................................................................................... 3
4.1 Association Establishment Policies.................................................................................................................. 3
4.2 Association Initiation ....................................................................................................................................... 3
4.3 Association Acceptance Policy ........................................................................................................................ 3
5Verification SOP Class (1.2.840.10008.1.1) ............................................................................................... 5
6Basic Film Session SOP Class (1.2.840.10008.5.1.1.1).............................................................................. 6
6.1 N-CREATE ...................................................................................................................................................... 6
6.2 N-SET .............................................................................................................................................................. 7
6.3 N-DELETE ...................................................................................................................................................... 8
6.4 N-ACTION ...................................................................................................................................................... 8
7Basic Film Box (1.2.840.10008.5.1.1.2).................................................................................................... 10
7.1 N-CREATE .................................................................................................................................................... 10
7.2 N-SET ............................................................................................................................................................ 12
7.3 N-DELETE .................................................................................................................................................... 13
7.4 N-ACTION .................................................................................................................................................... 14
8Basic Grayscale Image Box (1.2.840.10008.5.1.1.4) ...............................................................................15
8.1 N-SET ............................................................................................................................................................ 15
9Print JOB SOP Class (1.2.840.10008.5.1.1.14) ....................................................................................... 18
9.1 Overview........................................................................................................................................................ 18
9.2 N-EVENT-REPORT ...................................................................................................................................... 18
9.3 N-GET ........................................................................................................................................................... 19
10 Printer SOP Class (1.2.840.10008.5.1.1.16)............................................................................................. 20
10.1 Overview........................................................................................................................................................ 20
10.2 N-EVENT-REPORT ...................................................................................................................................... 20
10.3 N-GET ........................................................................................................................................................... 20
11 Presentation LUT (1.2.840.10008.5.1.1.23) ............................................................................................. 22
11.1 N-CREATE .................................................................................................................................................... 22
11.2 N-DELETE .................................................................................................................................................... 23
12 Basic Annotation Box SOP Class (1.2.840.10008.5.1.1.15) .................................................................... 24
12.1 N-NET ........................................................................................................................................................... 24
13 Print Queue Management SOP Class (1.2.840.10008.5.1.1.26)............................................................. 26
13.1 Overview........................................................................................................................................................ 26
13.2 N-EVENT-REPORT ...................................................................................................................................... 26
13.3 N-GET ........................................................................................................................................................... 26
13.4 N-ACTION .................................................................................................................................................... 28
14 Communication Profiles........................................................................................................................... 29
14.1 Supported Communication Stacks ................................................................................................................. 29
15 Extensions / Specializations / Privatizations........................................................................................... 29
16 Configuration ............................................................................................................................................ 29
Appendix A ........................................................................................................................................................ 31
Appendix B ........................................................................................................................................................ 47
Appendix C ........................................................................................................................................................ 48
Appendix D ........................................................................................................................................................ 49

FUJI NETWORK PRINT SERVER FN-PS551
006-203-40 2006.10 1
1 Introduction
This document provides the DICOM conformance statement for the FUJIFILM FN-PS551 Print Server product..
2 Implementation Model
The FUJIFILM FN-PS551 Print Server is a single or dual (depending on configuration) Application Entities
which provide the services of a DICOM Print Management Service Class.
2.1 Data Flow Diagram
The FUJIFILM FN-PS551 Print Server receives images from a DICOM Print Management Service Class User,
and prints them on FUJIFILM Printer
2.2 Functional Definitions of Application Entities
The FUJIFILM FN-PS551 Print Server provides the DICOM Print Management Service Class support required to
print images from one or more SCUs to attached FUJIFILM Laser imagers. The following functionality is
supported:
•DICOM Association Management
•Management of DICOM Film Sessions, Film Boxes and Image
•Boxes
•Print Job Status Tracking
•Image Bufferring
•Printing
•Printer Status Tracking
2.3 Sequencing of Real World Activities
Not applicable for Real World Activities.
FUJIFILM
Print Server
FUJIFILM
Printer SCU
DICOM Interface

FUJI NETWORK PRINT SERVER FN-PS551
006-203-30 2001.05 2
3 Application Entity Specification
As the SCP, the FN-PS551 conforms to the following DICOM SOP Classes1.
SOP Class Name SOP Class UID
Verification SOP Class 1.2.840.10008.1.1
Basic Grayscale Print Management Meta SOP Class 1.2.840.10008.5.1.1.9
Print Job SOP Class 1.2.840.10008.5.1.1.14
Basic Annotation Box SOP Class 1.2.840.10008.5.1.1.15
Presentation LUT SOP Class (Supplement 22) 1.2.840.10008.5.1.1.23
Print Queue Management SOP Class (Supplement 13) 1.2.840.10008.5.1.1.26
1The following Correction Proposals are applied: CP16, 19, 20, 35, 49, 55, 56, 80, 81, 85, 94, 108

FUJI NETWORK PRINT SERVER FN-PS551
006-203-30 2001.05 3
4 Association
4.1 Association Establishment Policies
♦General
•The SCU AE attempts to initiate a new Association for each print session.
•Only the SCU AE shall release an Association.
•The Association may be aborted by the SCU or the SCP.
•The Maximum PDU Size for the PDUs offered by the SCP equals 32Kbytes.
♦Number of Associations
•Maximum 6 associations at a time. Further associations will be rejected with the reason ‘busy’.
♦Asynchronous Nature
•Not support negotiation of multiple outstanding transactions.
♦Implementation ID information
•Implementation Class UID is 1.2.392.200036.9125.5422.1
4.2 Association Initiation
This application does not initiate any DICOM associations.
4.3 Association Acceptance Policy
This application accepts an association.
♦Associated Real-World Activity
When an association is established, one of the following activities may occur.
1) The SCU instructs the printing of a set of images. The SCP prints the set of images.
2) The SCU requires the status of print job or the printer. The SCP will respond it.
3) The SCU sends a verification request. The SCP will respond it.
♦Proposed Presentation Contexts
The following transfer syntax is acceptable. Table-1
Name UID
DICOM Implicit VR Little Endian 1.2.840.10008.1.2
The following presentation contexts are acceptable.
Abstract Syntax Transfer
syntax Role Extended
Negotiation
No.
Name UID
1 Verification SOP Class 1.2.840.10008.1.1 Table-1 SCP None
2 Basic Grayscale Print
Management Meta SOP
Class
1.2.840.10008.5.1.1.9 Table-1 SCP None
3 Print Job SOP Class 1.2.840.10008.5.1.1.14 Table-1 SCP None
4 Printer SOP Class 1.2.840.10008.5.1.1.16 Table-1 SCP None
5 Presentation LUT SOP
Class
1.2.840.10008.5.1.1.23 Table-1 SCP None

FUJI NETWORK PRINT SERVER FN-PS551
006-203-30 2001.05 4
6 Print Queue Management
SOP Class
1.2.840.10008.5.1.1.26 Table-1 SCP None
7 Basic Annotation Box
SOP Class
1.2.840.10008.5.1.1.15 Table-1 SCP None
The 3rd and 4th SOP Classes that have been negotiated so far only by combined with the 2nd SOP
Class are now permitted to be negotiated with no combination. The 3rd and 4th SOP Classes may
inhibit SCP's resource consumption rather than when negotiated being combined with the 2nd SOP
Class, resulting in improving SCP's processing speed (CP-81). The 6th SOP Class can be negotiated
solely with no combination or being combined with any other.
♦SOP Specific Conformance
•The FN-PS551 may return the following error codes in response to any message received.
Code Status Meaning
0122H Failure SOP class not supported
0211H Failure Unrecognized operation : the command is not supported for the SOP
class (e.g. N_CREATE for Image Box SOP class)
•For 0107H, 0116H and B604H Warning Status, it is possible to disregard them and individually
specify so that they are processed same as the “Success: (0000H).”
•It is possible to specify so that the N-EVENT-REPORT message is not issued.
•The maximum number of Print Job is 64.
•When the same Image Position (2020,0010) has been specified one or more times by N-SET in Basic
Grayscale Image BOX, the Image Position specified the last will be effective. N-ACTION for Basic
Film Session or Basic Film Box will quit normally, not resulting in C604H error (CP-80).
•In Failure status, no message will be returned by "Attribute List."
•In Success/Warning status when in N-CREATE, all supported attributes included in the instance that
has been created as the "Attribute List" will be returned.
•In Success/Warning when in N-SET, items that have been properly updated in the items specified by
the SCU will be returned as the "Attribute List." However, Preformatted grayscale image sequence in
the Basic Grayscale Image Box will not be returned.
•When Status (0000,0900) = 0107H (Attribute list error), the Attribute Identifier List (0000,1005) will
not be returned.
•In certain Failure/Warning status, the Error Comment (0000,0902) will be returned.
See Appendix D.

FUJI NETWORK PRINT SERVER FN-PS551
006-203-30 2001.05 5
5 Verification SOP Class (1.2.840.10008.1.1)
The FN-PS551 provides standard conformance to the DICOM Verification Service Class as an SCP.
Upon receipt from an SCU of a verification of communication request, the FN-PS551 will issue a confirmation.

FUJI NETWORK PRINT SERVER FN-PS551
006-203-30 2001.05 6
6 Basic Film Session SOP Class (1.2.840.10008.5.1.1.1)
The following DIMSE services are supported.
•N-CREATE
•N-SET
•N-DELETE
•N-ACTION
6.1 N-CREATE
♦Description
•Creates a Basic Film Session SOP instance and initializes it using the value sent from the SCU
(default if no value is sent from the SCU).
•Creating instance of this SOP is required before creating the Basic Film Box SOP instance.
•An Association may have only one Basic Film Session SOP instance at a time. To use several Basic
Film Session SOP instances, delete older ones and create new ones.
♦Attribute Information
Tag Name Usage Supported Default
(2000,0010) Number of Copies U/M 1-99 Config
(2000,0020) Print Priority U/M HIGH,
MED
LOW
LOW
(2000,0030) Medium Type U/M CLEAR FILM,
BLUE FILM
Config
(2000,0040) Film Destination U/M PROCESSOR
BIN_i
PROCESSOR
(2000,0050) Film Session Lable U/U Up to 64 characters Null string
(2000,0060) Memory Allocation U/U 1-131072 None
(2050,0500) Referenced Presentation
LUT Sequence
U/MC None
(0008,1150) >SOP Class UID U/MC None
(0008,1155) >SOP Instance UID U/MC None
(2100,0160) Owner ID U/U None
* (2000,0040) "BIN_i" specifies sorter bins on the printer provided with sorter. "i" is the pin number,
ranging from 1 to the number of bins (max.30). If the printer is not provided with sorter, "BIN_i" is
not effective and is substituted by PROCESSOR.
* (2000,0060) is used for reserving Disk space in KByte.
♦Status
•Use defaults and return "Success:0000H" if no element values have been specified.
•Create a UID using SCP and return "Success:0000H" if there is no Affected SOP Instance UID
(0000,1000) or it has been sent in length 0.
•If element values exceed specified ranges, use defaults and return "Warning:0116H."

FUJI NETWORK PRINT SERVER FN-PS551
006-203-30 2001.05 7
•Warning will not be returned if a film type that is not loaded in the Laser Imager for output has been
specified using Medium Type (2000,0030) and film output will be rendered in the type loaded in the
Laser Imager2.
•Basic Film Session SOP instance is created even with Warning and processing is possible
continuously.
•Basic Film Session SOP instance will not be created in Failure status.
Code Status Meaning
0000H Success Film session successfully created.
The actual values assigned to attributes are returned.
0107H Warning Attribute list error.
Attributes not applicable to the Basic Film Session SOP instance have been
specified.
0110H Failure Processing failure.
An attempt was made to create the 2nd Basic Film Session SOP instance.
0110H Failure Printer is off-line3.
0116H Warning Attribute Value Out of Range.
0117H Failure Invalid Object Instance.
Returned if a given instance UID has violated the UID construction rules.
0213H Failure Resource Limitation.
The requested allocation can temporarily not be provided.
♦Remarks
•The following attributes of Basic Film Session IOD are not open to an SCU. These attributes are set
up within an SCP when a Basic Film Box SOP instance is created.
Tag Name
(2000, 0500) Referenced Film Box Sequence
(0008, 1150) > Referenced SOP Class UID
(0008, 1155) > Referenced SOP Instance UID
6.2 N-SET
♦Description
•Update attributes of the Basic Film Session SOP instance. It is possible to change all attributes that
can be specified using N-CREATE.
♦Status
•For a Warning status, attributes will not be updated, remaining in previous values. Processing can be
continued.
•For a Failure status, attributes will not be updated, remaining in previous values. Processing can be
continued.
2More than one film is commonly loaded into the laser imager. Therefore, no judgments can be formulated unless the Film Size ID
(2010, 0050) is specified by Basic Film Box. Consequently, everything is handled as “Success.”
3When the Laser Imager connected to the print server is in offline status being disabled to receive image data, Failure will be
returned.

FUJI NETWORK PRINT SERVER FN-PS551
006-203-30 2001.05 8
Code Status Meaning
0000H Success Specified attributes of the SOP instance have been updated.
The actual values assigned to attributes are returned.
0107H Warning Attribute list error.
Attributes that cannot be applied to the Basic Film Session SOP Instance have
been specified.
0116H Warning Attribute Value out of Range.
0119H Failure Class-Instance Conflict.
Returned if the SOP class Instance UID is not defined for the given SOP Class.
0213H Failure Resource Limitation.
The requested allocation can temporarily not be provided.
6.3 N-DELETE
♦Description
•Deletes all information hierarchies rooted in the Basic Film Session SOP Instance. Releases assigned
resources.
♦Status
Code Status Meaning
0000H Success The specified SOP Instance hierarchy has been deleted.
0119H Failure Class-Instance Conflict.
Returned if the SOP class Instance UID is not defined for the given SOP Class.
6.4 N-ACTION
♦Description
•After copying all information hierarchies rooted in the Basic Film Session SOP Instance, prints all
relevant films. If one or more Film Boxes are included, Printing order will, for example, be as follows.
1-2-3, 1-2-3
•Film Size IDs (2010,0050) of all Basic Film Box SOP Instances related with the Basic Film Session
SOP Instance should be the same. If different IDs are included, returns "Failure:0110H" and prints no
films. In such a case, N-ACTION should be issued to each Basic Film Box SOP Instance.
•The SCU will continuously be able to update and/or operate all information hierarchies rooted in the
Basic Film Session SOP Instance, which will not affect print operation as instructed by N-ACTION.
•Creates the Print Job SOP Instance and returns its UID, if agreed according to Association setup.
♦Parameters
Action Type Name = PRINT, Action Type ID = 1
Tag Attribute Usage Comment
(2100,0500) Referenced Print Job Sequence -/MC If Print Job SOP Class or Print Queue
Management SOP Class is negotiated.
(0008,1150) >Referenced SOP Class UID -/MC If Print Job SOP Class is negotiated.
(0008,1155) >Referenced SOP Instance UID -/MC If Print Job SOP Class is negotiated.
(2100,0010) >Print Job ID -/MC If Print Queue Management SOP Class
is negotiated.

FUJI NETWORK PRINT SERVER FN-PS551
006-203-30 2001.05 9
♦Status
Code Status Meaning
0000H Success Films in the film session have been queued for printing.
0110H Failure Processing failure.
Basic Film Box SOP Instance of different film sizes are present.
0115H Failure Invalid Argument Value.
Returned if the Action Type provided by the SCU is not recognized.
0119H Failure Class-Instance Conflict.
Returned if the SOP class Instance UID is not defined for the given SOP Class.
B602H Warning Film Session SOP instance hierachy does not contain Image Box SOP Instance.
Empty page will not be printed.
C600H Failure Film Session SOP Instance hierachy does not contain Film Box SOP Instances.
C601H Failure Unable to create Print Job SOP Instance. Print queue if full.

FUJI NETWORK PRINT SERVER FN-PS551
006-203-30 2001.05 10
7 Basic Film Box (1.2.840.10008.5.1.1.2)
The following DIMSE services are supported.
•N-CREATE
•N-SET
•N-DELETE
•N-ACTION
7.1 N-CREATE
♦Description
•Creates a Basic Film Box SOP instance and initializes it using the value sent from the SCU (default if
no value is sent from the SCU).
•Initialization is effected so as to link “2000, 0500” (Referenced Film Box Sequence) of Basic Film
Session SOP instance to the created Basic Film Box SOP instance.
•Creates Basic Grayscale Image Box SOP Instances as many as necessary in accordance with
(2010,0010) (Image Display Format), and specifies them to (2010, 0510) (Referenced Image Box
Sequence) of the Basic Film Box SOP Instance. Returns these values to the SCU as a Response.
•Creates Basic Annotation Box SOP Instances as many as necessary in accordance with (2010,0030)
(Annotation Display Format ID), and specifies (2010, 0520) (Referenced Basic Annotation Box
Sequence). Returns these values to the SCU as a Response. If the use of a Basic Annotation Box SOP
Class in not agreed upon, no Basic Annotation Box SOP instance is created.4
♦Attribute Information
(Basic Film Box Presentation Module)
Tag Name Usage Supported Default
(2010,0010) Image Display Format M/M See Appendix A.
(2010,0030) Annotation Display Format
ID
U/U FORMAT1 FORMAT1
(2010,0040) Film Orientation U/M PORTRAIT
LANDSCAPE
Config
(2010,0050) Film Size ID U/M 14INX17IN
14INX14IN
11INX14IN
8INX10IN
Config
(2010,0060) Magnification Type U/M CUBIC
NONE
(No magnification/reduction)
CUBIC
(2010,0080) Smoothing type U/U SHARP
SMOOTH
MEDIUM
Config
4No matter whether this situation arises, annotation Text for which Configuration setup is completed will be recorded onto film.

FUJI NETWORK PRINT SERVER FN-PS551
006-203-30 2001.05 11
(2010,0100) Border Density U/U BLACK Config
(2010,0110) Empty Image Density U/U (Not supported)
(2010,0120) Min Density U/U 0-300 Config
(2010,0130) Max Density U/M 0-300 Config
(2010,0140) Trim U/U YES
NO
Config
(2010,0150) Configuration Information U/M See Appendix B. Config
(2010,015E) Illumination U/MC 2000 cd/m2
(2010,0160) Reflective Ambient Light U/MC 10 cd/m2
(Basic Film Box Relationship Module)
(2010,0500) Referenced Film Session
Sequence
M/M
(0008,1150) >Referenced SOP Class UID M/M
(0008,1155) >Referenced SOP instance
UID
M/M
(2010,0510) Referenced Image Box
Sequence
-/M
(0008,1150) >Referenced SOP Class UID -/M
(0008,1155) >Referenced SOP instance
UID
-/M
(2010,0520) Referenced Basic Annotation
Box Sequence
-/MC
(0008,1150) >Referenced SOP Class UID -/MC
(0008,1155) >Referenced SOP instance
UID
-/MC
(2050,0500) Referenced Presentation
LUT Sequence
U/MC Basic Film
Session
Value
(0008,1150) >SOP Class UID U/MC Basic Film
Session
Value
(0008,1155) >SOP Instance UID U/MC Basic Film
Session
Value
* Specifying low densities in (2010,0100), (2010,0120) or (2010,0130) will affect film base densities.
♦Status
•If an attribute specified for the Basic Film Box SOP, but not supported by the FN-PS551, returns
"Warning:0107H."
•Returns "Success:0000H" with the UID generated using the SCP, if no Affected SOP Instance UID
(0000,1000) is available or it has been sent in length 0.
•Returns "Success:0000H" using the defaults, if values of "Usage SCU=U" elements have not been
specified.
•Returns "Warning:0116H" using the defaults, if values of "Usage SCU=U" elements exceed the range.

FUJI NETWORK PRINT SERVER FN-PS551
006-203-30 2001.05 12
•Warning or Failure will not be indicated even if a size that is not available on the Laser Imager has
been specified for image output using the Film Size ID (2010, 0050). Perform necessary procedures
up to image processing to spool onto the output queue. Image output will be enabled if, for example,
the printer is reconnected.
•Returns "Failure:0102H" if values of "Usage SCU=M" elements have not been specified. This also
applies for when no values have been sent as the DataSet.
•Returns "Failure:0106H" if values of "Usage SCU=M" elements exceed the range.
•Even for the Warning status, a Basic Film Box SOP instance will be created, enabling to continue with
processing.
•For the Failure status, no Basic Film Box SOP instance will be created. At this time, the Affected SOP
Instance UID (0000,1000) will not be returned.
Code Status Meaning
0000H Success Film Box is successfully created.
The actual values assigned to attributes are returned.
0106H Failure Invalid Attribute Value.
Mandatory attribute had illegal value.
0107H Waring Attribute list error.
An attribute not supported by the FN-PS551 has been specified.
An attribute not applicable to the Basic Film Box SOP instance has been specified.
0110H Failure Processing failure.
Returned if the number of film boxes exceeds 32.
0111H Failure Duplicate SOP instance.
Instance UID given is already in use.
0116H Warning Attribute Value Out of Range.
0117H Failure Invalid Object Instance.
Returned if a given instance UID has violated the UID construction rules.
0120H Failure Missing attribute.
Returned if a mandatory attribute is missing.
B605H Warning Requested Min Density or Max Density outside of printer’s operating range.
The printer will use its respective minimum or maximum density value instead.
7.2 N-SET
♦Description
•Updates Basic Film Box SOP Instance attributes created the last.
♦Attributes that can be updated
Tag Name Usage Supported
(2010,0060) Magnification Type U/M CUBIC
NONE
(No magnification /reduction)
(2010,0080) Smootihg type U/U SHARP
SMOOTH
MEDIUM

FUJI NETWORK PRINT SERVER FN-PS551
006-203-30 2001.05 13
(2010,0100) Border Density U/U BLACK
(2010,0110) Empty Image Density U/U (Not supported)
(2010,0120) Min Density U/U 0-300
(2010,0130) Max Density U/M 0-300
(2010,0140) Trim U/U YES
NO
(2010,0150) Configuration Information U/M See Appendix B.
(2010,015E) Illumination U/MC
(2010,0160) Reflective Ambient Light) U/MC
(2050,0500) Referenced Presentation
LUT Sequence
U/MC
(0008,1150) >SOP Class UID U/MC
(0008,1155) >SOP Instance UID U/MC
♦Status
•Returns "Failure:0120H" if no values have been sent as a DataSet.
•For the Warning status, attributes will not be updated, with values remaining unchanged. Processing
can be continued.
•For the Failure status, attributes will not be updated, with values remaining unchanged. Processing can
be continued.
Code Status Meaning
0000H Success Specified attributes of the SOP instance have been updated.
The actual values assigned to attributes are returned.
0107H Waring Attribute list error.
An attribute not supported by the FN-PS551 has been specified.
An attribute not applicable to the Basic Film Box SOP instance has been specified.
0110H Failure Processing failure.
The instance created the last was not specified.
0116H Warning Attribute Value Out of Range.
0119H Failure Class-Instance Conflict.
Returned if the SOP class Instance UID is not defined for the given SOP Class.
0120H Failure Missing attribute.
Returend if no DataSet is provided by the SCU.
B605H Warning Requested Min Density or Max Density outside of printer’s operating range. The
printer will use its respective minimum or maximum density value instead.
7.3 N-DELETE
♦Description
•Deletes the Basic Film Box SOP instance hierarchy created the last.
•Deletes the relevant part of (2000,0500) (Referenced Film Box Sequence) of the Basic Film Session
SOP Instance.

FUJI NETWORK PRINT SERVER FN-PS551
006-203-30 2001.05 14
♦Status
Code Status Meaning
0000H Success The specified SOP Instance hierarchy has been deleted.
0110H Failure Processing failure.
The instance created the last was not specified.
0119H Failure Class-Instance Conflict.
Returned if the SOP class Instance UID is not defined for the given SOP Class.
7.4 N-ACTION
♦Description
•After copying all information hierarchies rooted in the specified Basic Film Box SOP Instance, prints
all relevant films.
•The SCU will continuously be able to update and/or operate all information hierarchies rooted in the
Basic Film Box SOP Instance, which will not affect print operation as instructed by N-ACTION.
•Creates the Print Job SOP Instance and returns its UID, if agreed according to Association setup.
♦Parameters
Action Type Name = PRINT, Action Type ID = 1
Tag Attribute Usage Comment
(2100,0500) Referenced Print Job Sequence -/MC If Print Job SOP Class or Print
Queue Management SOP Class is
negotiated.
(0008,1150) >Referenced SOP Class UID -/MC If Print Job SOP Class is
negotiated.
(0008,1155) >Referenced SOP Instance UID -/MC If Print Job SOP Class is
negotiated.
(2100,0010) >Print Job ID -/MC If Print Queue Management SOP
Class is negotiated.
♦Status
Code Status Meaning
0000H Success Success is normally returned.
0115H Failure Invalid Argument Value.
Returned if the Action Type provided by the SCU is not recognized.
0119H Failure Class-Instance Conflict.
Returned if the SOP class Instance UID is not defined for the given SOP Class.
B603H Warning Film Box SOP Instance hierarchy does not contain Image Box SOP Instances
(empty page).
Empty page will not be printed.
C602H Failure Unable to create Print Job SOP Instance. Print queue if full.

FUJI NETWORK PRINT SERVER FN-PS551
006-203-30 2001.05 15
8 Basic Grayscale Image Box (1.2.840.10008.5.1.1.4)
The following DIMSE service is supported.
•N-SET
8.1 N-SET
♦Description
•Updates attribute information of the Basic Grayscale Image Box SOP instance belonging to the Film
Box SOP instance created the last.
•(2010,0060) (Magnification Type), (2010,0080) (Smoothing Type) and (2010,0150) (Configuration
Information) will prevail over values specified for the Film Box SOP instance.
•It is possible to erase image by sending (2020,0110) (Preformatted Grayscale Sequence) in length 0.
•When “2020, 0030” (requested image size) is specified, “2010, 0060” (magnification type) is
unconditionally processed as CUBIC.
•When two or more images are set in the same Image position (2020, 0010), the last one takes effect.
♦Attributes that can be Specified
(Basic Image Box Presentation Module)
Tag Name Usage Supported Default
(2020,0010) Image position M/M 1-x (See Appendix A.) Non
(2020,0020) polarity U/M NORMAL
REVERSE
Config
(2010,0060) magnification type U/U CUBIC
NONE
(No magnification/reduction)
Basic Film box
Value
(2010,0080) smoothing type U/U SHARP
SMOOTH
MEDIUM
Basic Film box
Value
(2010,0120) Min Density U/U 0-300 Basic Film box
Value
(2010,0130) Max Density U/U 0-300 Basic Film box
Value
(2010,0150) Configuration Information U/U See Appendix B. Basic Film box
Value
(2020,0030) requested image size U/U See Appendix A. None
(2020,0110) preformatted grayscale
image sequence
M/M
(0028,0002) >samples per pixel M/M 1 None
(0028,0004) >photometric interpretation M/M MONOCHROME1
MONOCHROME2
None
(0028,0010) >rows M/M 1-5792 None
(0028,0011) >columns M/M 1-5792 None
(0028,0034) >pixel aspect ratio MC/M R C (Vertical Horizontal)
R,C=1-9999
1 1
(0028,0100) >bits allocated M/M 8, 16 None
(0028,0101) >bits stored M/M 8, 10, 12 None

FUJI NETWORK PRINT SERVER FN-PS551
006-203-30 2001.05 16
(0028,0102) >high bit M/M 7, 9, 11 None
(0028,0103) >pixel representation M/M 0 None
(7fe0,0010) >pixel data M/M (any) None
(Basic Image Box Relationship Module)
(2020,0130) referenced image overlay
box sequence (note)
U/MC (Not supported)
(0008,1150) >referenced sop class uid MC/M (Not supported)
(0008,1155) >referenced sop instance uid MC/M (Not supported)
(2050,0500) Referenced Presentation
LUT Sequence
U/U
(0008,1150) >SOP Class UID U/U
(0008,1155) >SOP Instance UID U/U
♦Status
•Returns "Success:0000H" using the defaults, if values of "Usage SCU=U" elements have not been
Specified.
•Returns "Warning:0116H" using the defaults, if values of "Usage SCU=U" elements exceed the range.
•Returns "Failure:0102H" if values of "Usage SCU=M" elements have not been specified. This also
applies for when no values have been sent as the DataSet.
•Returns "Failure:0106H" if values of "Usage SCU=M" elements exceed the range.
•Returns "Failure:0106H" with regard to (7fe0,0010) (pixel data), if the data length calculated from
(0028,0010) (rows), (0028,0011) (columns) and (0028,0100) (bits allocated) does not agree with that
of (7fe0,0010) (pixel data).
•For the Warning status, updates attributes. Processing can be continued.
•For the Failure status, does not update attributes, remaining the same. Processing can be continued.
•Returns "Warning:0116H" using the maximum size, if (2020,0030) (Requested Image Size) exceeds
the maximum size determined by (2010,0010) (Image Display Format), (2010,0050) (Film Size ID)
and (2020,0010) (Image Position).
•When “NONE” has been specified for (2010, 0060) (Magnification Type), changes (2010, 0060)
(Magnification Type) from “NONE” to “CUBIC” and returns “Warning:B604H” if (0028, 0010)
(Rows) and (0028, 0011) (Columns) exceed the maximum size determined by (2010, 0010) (Image
Display Format), (2010, 0050) (Film Size ID), (2020, 0010) (Image Position) and (2010, 0040) (Film
Orientation).
Code Status Meaning
0000H Success Image instance has been updated successfully.
0106H Failure Invalid attribute value.
Mandatory attribute has illegal value.
0107H Waring Attribute list error.
0110H Failure Processing failure.
The Basic Grayscale Image Box SOP instance not belonging to the Film Box
SOP instance created the last has been specified.
0116H Warning Attribute Value Out of Range.

FUJI NETWORK PRINT SERVER FN-PS551
006-203-30 2001.05 17
0119H Failure Class-Instance Conflict.
Returned if the SOP class Instance UID is not defined for the given SOP
Class.
0120H Failure Missing attribute
Returned if a mandatory attribute of the Data Set, provided by the SCU AE, is
missing.
B604H Waring Image size is larger than image box size, the image has been demagnified.
B605H Warning Requested Min Density or Max Density outside of printer’s operating range.
The printer will use its respective minimum or maximum density value instead.
C605H Failure Insufficient memory in printer to store images.
