Fujitsu Lifebook A6120 User manual

Copyright
i
Other product names are trademarks or
registered trademarks of their respective
companies.
© Copyright 2008 Fujitsu Limited. All rights
reserved. No part of this publication may be
copied, reproduced or translated, without the
prior written consent of Fujitsu Limited. No part
of this publication may be stored or transmitted
inanyelectronicform without the writtenconsent
of Fujitsu Limited.
This device complies with Part 15 of the FCC
rules.Operationsaresubjecttothefollowingtwo
conditions:
(1) This device may not be allowed to cause
harmful interference.
(2) This device must accept any interference
received, including interference that may
cause undesired operation.
Website: www.pc-ap.fujitsu.com
DECLARATION OF CONFORMITY
according to FCC Part 15
Copyright
Fujitsu Limited has made every effort to ensure
theaccuracyandcompleteness ofthis document.
However, as ongoing development efforts are
continually improving the capabilities of our
products, we cannot guarantee the accuracy of
the contents of this document. We disclaim
liability for errors, omissions or future changes.
LifeBook is a trademark of Fujitsu Limited.
Microsoft,Windows,MS,MS-DOS,Windows NT,
Windows XP and Windows Vista are registered
trademarks of the Microsoft Corporation of the
United States in the United States and other
countries.
Phoenix is a registered trademark of Phoenix
Technologies Corporation of the United States.
ExpressCard™ module technology is a
registered trademark of Personal Computer
Memory Card International Association.
ExpressCard ID: EC100139 (A6120).
Copyright©1981-1999MicrosoftCorporation,All
rights reserved.
Copyright© 1999 PhoenixTechnologies,Ltd., All
rights reserved.

ii
9. Ifan extensioncord is used with this product,
make sure that the total ampere rating of the
equipment plugged into the extension cord
does not exceed the extension cord ampere
rating. Also, make sure that the total rating
of all products plugged into the wall outlet
does not exceed 15 amperes.
10. Never push objects of any kind into this
product through cabinet slots as they may
touch dangerous voltage points that could
result in a fire or electric shock. Never spill
liquid of any kind on the product.
11. Do not attempt to service this product
yourself, as opening or removingcoversmay
expose you to dangerous voltage points or
other risks. Refer all servicing to qualified
service personnel.
12. Unplug this product from the wall outlet and
referservicingtoqualified service personnel
under the following conditions:
a. When the power cord or plug is damaged
or frayed.
b. If liquid has been spilled into the product.
c. If the product has been exposed to rain or
water.
d. If the product does not operate normally
whentheoperatinginstructionsarefollowed.
Adjust only those controls that are covered
bytheoperatinginstructionssinceimproper
adjustment of other controls may result in
damage and will often require extensive
work by a qualified technician to restore the
product to normal condition.
e. If the product has been dropped or the
cabinet has been damaged.
f. If the product exhibits a distinct change in
performance, indicating a need for service.
IMPORTANT SAFETY
INSTRUCTIONS
1. Readthese instructionscarefully.Savethese
instructions for future reference.
2. Follow all warnings and instructions marked
on the product.
3. Unplug this product from the wall outlet
before cleaning Do not use liquid cleaners
or aerosol cleaners. Use a damp cloth for
cleaning.
4. Do not use this product near water.
5. Donotplace this productonanunstablecart,
standor table.Theproduct maydrop, causing
serious damage to the product.
6. Slots and openings in the cabinet and the
back or bottom are provided for ventilation;
to ensure reliable operation of the product
and to protect it from overheating, these
openings must not be blocked or covered.
The openings should never be blocked by
placing the product on a bed, sofa, rug or
other similar surface. This product should
never be placed near or over a radiator or
heatregister or in a built-ininstallation unless
proper ventilation is provided.
7. This product should be operated from the
typeof powerindicatedonthemarking label.
If you are not sure of the type of power
available, consult your dealer or local power
company.
8. Do not allow anything to rest on the power
cord. Do not locate this product where
persons will walk on the cord.

iii
13. CAUTION:When replacing the battery,be
sure to install it with the polarities in the
correct position. There is a danger of
explosion if the battery is replaced with
an incorrect type or is mistreated. Do not
recharge, disassemble or dispose of in
fire. Replace only with the same or
equivalent type recommended by the
manufacturer.Disposeof the usedbattery
according to the manufacturer’s
instructions.
14. Use only the proper type of power supply
cord set (provided in your accessories box)
for this unit. It should be a detachable type:
UL listed/CSA certified, BS1363, ASTA,
SS145 certified, rated 10A 250V minimum,
VDE approved or its equivalent. Maximum
length is 15 feet (4.6 meters).

iv
Changesormodifications not expressly
approved by Fujitsu could void this
user’s authority to operate the
equipment.
FCC NOTICES
Notice to Users of Radios andTelevision
These limits are designed to provide reasonable
protection against harmful interference in a
residentialinstallation.Thisequipment generates,
uses, and can radiate radio frequency energy
and, if not installed and used in accordance with
theinstructions, maycause harmful interference
to radio communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning
theequipment off and on, the user is encouraged
to try to correct the interference by one or more
of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the
equipment and receiver.
•Connect the equipment into an outlet that is
on a different circuit than the receiver.
•Consult the dealer or an experienced radio/
TV technician for help.
Shielded interconnect cables must be employed
with this equipment to ensure compliance with
the pertinent RF emission limits governing this
device.
Notice to Users of the USTelephone Network
Your LifeBook notebook may be supplied with
an internal modem which complies with Part 68
of the FCC rules.On this notebook is a label that
contains the FCC Registration Number and the
Ringer Equivalence Number (REN) for this
equipmentamongotherinformation. Ifrequested,
the user must provide their telephone company
with the following information:
1. The telephone number to which the
notebook is connected.
2. TheRinger EquivalenceNumber (REN) for
this equipment.
3. That the equipment requires a standard
modular jack type USOC RJ-11C which is
FCC Part 68 compliant.
4. The FCC Registration Number.
This equipment is designed to be connected to
the telephone network or premises wiring using
a standard modular jack type USOC RJ-11C
which is FCC Part 68 compliant and a line cord
between the modem and the telephone network
with a minimum of 26AWG.
The REN is used to determine the number of
devices that you may connect to your telephone
line and still have all of those devices ring when
your number is called.Too many devices on one
line may result in failure to ring in response to an
incoming call.In most, but not all, areas the sum
of the RENs of all of the devices should not
exceed five (5). To be certain of the number of
devices you may connect to your line, as
determined by the RENs, contact your local
telephone company.
If this equipment causes harm to the telephone
network, your telephone company may
discontinue your service temporarily.If possible,
they will notify you in advance.If advance notice
is not practical they will notify you as soon as
possible.You will also be advised of your right to
file a complaint with the FCC.
This fax modem also complies with fax branding
requirements per FCC Part 68.
Your telephone company will probably ask you
to disconnect this equipment from the telephone
network until the problem is corrected and you
aresure that theequipmentis not malfunctioning.

v
This equipment may not be used on coin-
operatedtelephones provided byyourtelephone
company.Connection to party lines is subject to
state tariffs. Contact your state’s public utility
commission, public service commission or
corporation commission for more information.
This equipment includes automatic dialing
capability.Whenprogrammingand/ormaking test
calls to emergency numbers:
•Remain on the line and briefly explain to the
dispatcher the reason for the call.
•Performsuchactivitiesin off-peak hours,such
as early morning or late evening.
FCC rules prohibit the use of non-hearing aid
compatible telephones in the following locations
or applications:
•Allpublicor semipubliccoin-operated or credit
card telephones.
•Elevators, highways, tunnels (automobile,
subway,railroadorpedestrian) whereaperson
with impaired hearing might be isolated in an
emergency.
•Places where telephones are specifically
installed to alert emergency authorities such
asfire,policeor medical assistancepersonnel.
•Hospital rooms, residential health care
facilities, convalescent homes and prisons.
•Workstations for the hearing impaired.
•Hotel, motel or apartment lobbies.
•Stores where telephones are used by patrons
to order merchandise.
•Public transportation terminals where
telephones are used to call taxis or to reserve
lodging or rental cars.
•Inhotelandmotel roomsasat leasttenpercent
of the rooms must contain hearing aid
compatible telephones or jacks for plug-in
hearing aid compatible telephones which will
beprovidedtohearing impaired customers on
request.

vi
+
UL Notice
This unit requires an AC adapter to operate.Use
only UL Listed Class 2 adapter, output rating
19VDC, 4.22A.Refer to the illustration below for
the correct AC Adapter output polarity:
For Authorized RepairTechnicians Only
To reduce the risk of fire, use only #26
AWG or larger telecommunications line
cord.
For continued protection against risk of
fire,replace only with the same type and
rating fuse.
Danger of explosion if Lithium (CMOS)
battery is incorrectly replaced. Replace
only with the same or equivalent type
recommended by the manufacturer.
Dispose of used batteries according to
the manufacturer’s instruction.
Proper Disposal of Battery
Under federal, state or local law, it may be illegal
to dispose of batteries by putting them in the
rubbish bins or trash cans. Please take care of
our environment and dispose of batteries
properly. Check with your local government
authority for details regarding recycling or
disposing of unwanted batteries.
For safety, users should ensure that the
electrical ground of the power utility, the
telephone lines and the metallic water
pipes are connected together. Users
should NOT attempt to make such
connections themselves but should
contact the appropriate electric
inspection authority or electrician. This
may be particularly important in rural
areas.

Copyright
vii
NOTE ON BACKUP DATA
Pleasemakea backup of the Operating System,
any software programs, and created files (and
update regularly).
If you send this product to Fujitsu, or any of its
affiliates,suppliers,service providersorresellers
for repair, Fujitsu does not guarantee the data
integrity. It is your responsibility to back data up
beforehand.
Fujitsu does not assume any obligation for
compensation for damages, data integrity, or
restoration,etc., ifyourdata is lostforany reason,
except as written in the warranty.
NOTE ON USE REQUIRED HIGH
SAFETY
This product is designed and manufactured for
general use, including general office use,
personal use, household use and ordinary
industrial use.
This product is not designed for or intended for
use under dangerous (fatal) conditions, unless
extreme safety precautions are implemented.
Do not use this product without implementing
high-level safety precautions.
Failuretofollowthiswarningmay result in death,
personalinjury, severe physicaldamage or other
loss, if used in or near any or more of the
following:
•nuclear reaction control system in a nuclear
facility
•automatic flight control system in an airplane
or other flight control system
•mass transport control system
•medical instruments for life support system
•missile launching control for weapon system

viii
AUSTRALIAN WARNINGS
WARNING
FOR SAFETY REASONS, ONLY CONNECT
EQUIPMENT WITH A TELECOMMUNICA-
TIONSCOMPLIANCE LABEL.THIS INCLUDES
CUSTOMER EQUIPMENT PREVIOUSLY LA-
BELLED PERMITTED OR CERTIFIED.
Connection of Non Certified/Approved
peripherals may result in the equipment
operating outside the Australian EMI
Standards.
Modems connected to the Australian
telecommunications network must be operated
in accordance with the Labelling Notice. This
modem has been specifically configured to
ensure compliance with the ACA Standards. Do
not adjust your modem or software outside the
values indicated below.To do so would result in
your modem being operated in a non-compliant
manner.
Call Attempts/Retries:
Applicationssoftwareshall be configured so that
no more than 3 attempts are made to establish a
connectionto agivennumber(Note:ifthemodem
can detect service tones, up to 10 attempts can
be made). If the call sequence is unsuccessful,
there shall be a delay of at least 30 minutes
before attempting to call the number again.
Failure to set the modem and any application
software used with the modem, to the values
shown above will result in the modem being
operated in a non-compliant manner.
Consequently, this would be in violation of the
Labelling Notice for this equipment and the
Telecommunications Act 1997 prescribes
penalties for the connection of non-compliant
equipment.

Copyright
ix
NEW ZEALANDWARNINGS
The grant of aTelepermit for any item of terminal
equipment indicates only that Telecom has
accepted that the item complies with minimum
conditions for connection to its network. It
indicates no endorsement of the product by
Telecom, nor does it provideanysort of warranty.
Above all, it provides no assurance that any item
will work correctly in all respects with another
item of Telepermitted equipment of a different
makeormodel,nordoesit imply that anyproduct
is compatible with all of Telecom’s network
services.
Thisequipment is not capableunder alloperating
conditions of correct operation at the higher
speeds for which it is designed. 56 KBPS
connections are likely to be restricted to lower
bit rates when connected to some PSTN
implementations. Telecom will accept no
responsibility should difficulties arise in such
circumstances.
Immediately disconnect this equipment should it
become physically damaged, and arrange for its
disposal or repair.
Thisequipmentshall not be used in any manner,
which could constitute a nuisance to other
Telecom customers.
This equipment shall not be set to make
automatic calls to theTelecom “111”Emergency
Service.
This device is equipped with pulse dialing while
theNewZealand standard is DTMF tonedialing.
There is no guarantee that Telecom lines will
always continue to support pulse dialing. It is
strongly recommended that pulse dialing is not
used.
Some parameters required for compliance with
Telecom’s Telepermit requirements are
dependent on the equipment (PC) associated
withthisdevice. The associated equipment shall
be set to operate within the following limits for
compliance with Telecom’s Specifications:
For repeat calls to the same number.
There shall be no more than 10 call attempts
to the same number within any 30 minute
period for any single manual call initiation and
theequipment shall go on-hook for a periodof
not less than 30 seconds between the end of
one attempt and the beginning of the next
attempt.
For Automatic calls to different numbers.
The equipment shall go on-hook for a period
of not less than 5 seconds between the end of
one attempt and the beginning of the next
attempt.
For Automatically answered Incoming
Calls.
Incoming calls shall be answered between 3
and 30 seconds from the start of the ringing.
For correct operation, the total of the RNs of all
devices connected to a single line at anytime
should not exceed 5.The RN of this Equipment
is 0.5.
WARNING:
CONNECTION OF NON CERTIFIED/
APPROVED PERIPHERALS MAY RESULT IN
THEEQUIPMENTOPERATING OUTSIDETHE
NEW ZEALAND EMI STANDARDS.

x
NOTE:
The screens and illustrations shown in this
examples may slightly vary depending on the
operating environment that you have installed.
B. If you are located in New Zealand
1. Click start select Control panel select
"Phone and Modem Options".
2. Double click New Location.
3. Choose "New Zealand" in Country/region
pull down menu bar.
4. Select Phone system as "Tone Dialing".
5. Click OK and Apply.
NOTE: Modem setting in Windows
XP
A. If you are located in Australia
1. Click Start select Control panel select
"Phone and Modem Options".
2. Double click New Location.
3. Choose "Australia" in Country/region pull
down menu bar.
4. Select Phone system as "Tone Dialing".
5. Click OK and Apply.

Table of Contents
xi
Table of Contents
SHOCK SENSOR UTILITY ............... 29
POWER SOURCES ........................... 31
Connecting the Power Adapter ....................31
Power On .....................................................32
Power Off .....................................................32
CHANGINGTHE INTERNAL
BATTERY PACK ........................... 33
ADDING MEMORY MODULE ........... 34
Where to install memory module .................34
Preparing necessary items ..........................34
Installing memory module ............................34
Checking the memory capacity ....................36
Changing memory module...........................36
TROUBLESHOOTING....................... 38
Identifying the Problem ................................38
Specific Problems ........................................38
Troubleshooting Table ..................................39
NOTE:
A copy of LifeBook User's Manual is located in
your Microsoft Windows OS or you can find it in
Fujitsu’s website at http://www.pc-ap.fujitsu.com/.
You can use this LifeBook User’s Manual to find
out more information about the functions and
features of your notebook.
NAMES OFTHE PARTS
ANDTHEIR FUNCTIONS ............. 1
Exterior features: Front features
of the notebook .......................................1
Exterior features: Front view
of the notebook .......................................3
Exterior features: Side view..........................4
Exterior features: Bottom view
of the notebook .......................................6
Exterior features: Rear view of notebook .....7
STATUS INDICATOR LED................. 8
Num Lock Indicator ......................................8
Caps Lock Key .............................................8
Scroll Lock Indicator.....................................8
Power Indicator ............................................8
Battery Charging Indicator ...........................8
Battery Level Indicators................................8
Disk Drive Access Indicator .........................8
RUNNINGTHE NOTEBOOK
ON ITS BATTERY ......................... 9
Recharging the battery.................................9
Running the notebook on its battery ............10
Checking the power level of the battery .......10
Low battery condition ...................................11
POWER MANAGEMENT................... 12
USING FINGERPRINT
AUTHENTICATION............................ 15
Characteristics of fingerprint
authentication .........................................15
Configuration of registration information ......16
Register log-in information
on homepages ........................................16
Log into homepages using fingerprint
authentication .........................................19
Change registration information ...................20
Save/Read registration information ..............23
Setup window...............................................26

Getting to Know Your LifeBook
1
NAMES OFTHE PARTS
ANDTHEIR FUNCTIONS
Front features of the notebook
1. 1.3 Mega Pixels Camera
The location of the built-in camera.
2. LCD Panel Latch
The LCD panel latch locks and releases
the LCD panel.
3. Internal Digital Microphone
It allows you to record the sounds and
voice in monaural manner.
4. LCD Panel
The display screen of the notebook.
(This picture is for illustration purpose only and may look different from the actual unit)
1
2
3
4
5
6
7
8
91069
11
The phenomena described below are
characteristicsof LCDpanelsand do not
indicate that LCD panels are defective.
•The TFT color LCD screen of your
notebook, composes of more than
2,350,000pictureelements(number
of dots when the screen resolution
is set at 1024 by 768 pixels). It was
manufactured using advanced
technologies.For technical reasons,
LCD screen may have pixels that do
not light and pixels that are always
lit.
•LCD panels may display slight
varying colors and uneven density.

2
5. LifeBook Application Panel
TheLifeBookapplicationpanelprovidesone-
touch application launch capability.
6. Status Indicator LED
This indicator displays operating status
symbols that correspond to specific
components of your notebook.
7. Power and Suspend/Resume Button
This button allows you to power on or off the
notebook. You can use also this button to
suspendnotebook activity without turning off
the power to it and to resume the notebook
from suspend mode.
8. Spill Resistant Keyboard
A full-function keyboard with dedicated
Windows keys.
Spill resistant keyboard does not imply the
keyboard is water-proof. If liquid is spilled
onto the keyboard, power off your notebook
immediately and turn the notebook upside
down to drain off the liquid.
9. Speakers
The built-in dual speakers provide stereo
sound.
10. Touch Pad
It allows you to control the display cursor
(mouse pointer).
11. Fingerprint Sensor or Scroll Button
Your notebook may be equipped with either
Fingerprint Sensor or Scroll Button.
The Fingerprint Sensor provides an
alternative way for Windows logon
authenticationas wellas softwareapplication
and web sites logon authentications.Please
refer to the section on “Using Fingerprint
Authentication” for more details. The
Fingerprint Sensor also allows you to scroll
up and down a document by sweeping your
finger up or down the sensor.
The Scroll Button allow you to scroll up and
down a document.
Some applications may not allow you to
scroll up and down a document.

Getting to Know Your LifeBook
3
2. HDA-Out
It allows jack sensing of the following audio
output devices.
• Headphone
It allows you to connect a Ø3.5mm
headphone to it. There are commercially
available headphones with different types
ofconnector.Pleasecheckthe compatibility
of these headphones before purchase.
3. HDA-In
It allows jack sensing of the following audio
input devices.
• Microphone
It allows you to connect a Ø3.5mm mono
or stereo microphone to it.
Exterior features:Front view
of the notebook
1. Wireless LAN/ Bluetooth* ON/OFF Switch
The switch allows you to turn on and off the
Wireless LAN/ Bluetooth communications.
Slide the switch to the right to turn it on, or
slide the switch to the left to turn it off.
Remember to off this switch where the use
of electronic devices is restricted, for
example, in hospitals and on airplanes.
Turn off this switch if you intend to carry your
notebook around. If you set your notebook
in standby mode with this switch on, the
notebook may resume operation
unexpectedly when it is carried around.This
may damage the hard disk.
* For model with Bluetooth.
(This picture is for illustration purpose only and may look different from the actual unit)

4
(This picture is for illustration purpose only and may look different from the actual unit)
4. SD/MS/xD Card Slot
The Memory Stick/SD card slot allows you
to install a flash memory card for data
storage.This architecture allows you to
transfer data from a variety of different
digital devices, such as SD card, xD card
and Memory Stick.
5. USB 2.0 Port
The USB 2.0 port allows you to connect
Universal Serial Bus devices. USB 2.0
devices transfer data at up to 480Mbps and
is backward compatible with USB 1.1
devices,whichtransfer data at upto12Mbps.
6. IEEE 1394 Port
You can use this port to connect to a
multimedia device with an IEEE 1394 port
such as a digital video camera.
7. DC-IN Jack
You plug in the supplied AC adapter into this
port to power your notebook and charge the
battery.
Exterior features: Side view
Right view of the notebook
1. ExpressCard™ and PC Card Eject
Buttons
You press these buttons to eject the
ExpressCard™ module and PC card
installed in the card slots.
2. PC Card
It allows you to install an optional PC Card.
3. ExpressCard™ Slot
It allows you to connect ExpressCard™
module.
There are two sizes of ExpressCard™
module.Oneis 34mm wide (ExpressCard™/
34) and the other is 54mm wide
(ExpressCard™/54).
This LifeBook can support both sizes of
ExpressCard™ accessory.
NOTE:
ExpressCard™ Compliance ID: EC100139
(A6120).

Getting to Know Your LifeBook
5
(This picture is for illustration purpose only and may look different from the actual unit)
Left view of the notebook
1. Built-in Optical Disk Drive
Yournotebookcomes with an internal optical
disk drive, which may vary between
countries. Please check with your local
distributor for actual configuration.
If this LifeBook come with an optical
drive that can read DVD titles, then this
drive is pre-set at factory to read DVD
titles with region codes for specific Asia
Pacific markets (e.g. code 3 for Asian,
code 4 for Australia, code 6 for China).
The first time you play a DVD title with a
regioncode differentfrom that of the DVD
optical drive - the region code set at
factory, you will be prompted to change
the region code of the DVD optical drive.
The region code of a DVD optical drive
canbe changed up to 4 times,afterwhich
it will be locked so that the DVD optical
drive can only play DVD titles of the final
region code set.

6
Exterior features: Bottom
view of the notebook
1. Expansion RAM Module Slot
The location of the expansion memory slot.
2. Internal Hard Disk Drive
The location of the internal hard disk drive.
(This picture is for illustration purpose only and may look different from the actual unit)
3. Internal Battery Pack Bay
The location of the internal battery pack.

Getting to Know Your LifeBook
7
(This picture is for illustration purpose only and may look different from the actual unit)
4. Video Output (S-Video)Terminal
You can use this port to connect to a TV
with S-video port for high quality video
output using an optional S-video cable.
5. External VGA Port
TheexternalVGA portallowsyouto connect
an external display or CRT monitor.
6. Modem (RJ-11) Port
It allows you to connect your notebook
internal modem to a phone line socket using
a supplied RJ-11 cable.
Exterior features:Rear view of
the notebook
1. Anti-theft Lock Slot
It allows you to attach an optional physical
lock down device.
2. USB 2.0 Ports
The USB 2.0 ports allow you to connect
Universal Serial Bus devices. USB 2.0
devices transfer data at up to 480Mbps and
is backward compatible with USB 1.1
devices,whichtransfer data at upto12Mbps.
3. LAN (RJ-45) Port
This port allows you to connect to a LAN
(local area network) using an optional LAN
cable.The port is compatible with 1000/100/
10 Base-T networks.

8
12 3
456
(This picture is for illustration purpose only and may look different from the actual unit)
STATUS INDICATOR LED
1. Num Lock Indicator ( 1)
This indicator lights up when the keyboard
is locked in Num Lock mode.(You can use
the keyboard as a ten-digit keyboard when
the Num Lock mode is turned on).
Youcan toggletheNumLockmodebyusing
the [ ] key.
2. Caps Lock Key (
A
)
You can toggle the Caps Lock mode by
using the [ ] key.
3. Scroll Lock Indicator ( )
This indicator turns on when the lock mode
is turned on.
You can toggle the Scroll Lock button by
usingthe [ ] keywhile holding down
the [ ] key.
4. Power Indicator ( )
Thisindicator turns on when there ispower
to the notebook.
It turns off when the notebook is powered
off.This indicator will blink if the notebook
is put in suspend mode.
5. Battery Charging
Indicator ( )
Thisindicator turnson when internalbattery
is being charged.
6. Battery Level Indicator
()
The standard Battery Level Indicator state
thepresence of stardard Li-ionbattery.The
indicator show the remaining power of the
battery.
7. Disk Drive Access
Indicator ( )
This indicator turns on when an internal
hard disk drive or built-in optical disk drive
is being accessed.
Do not power off the notebook when the
disk drive access indicator is shown.
Failure to do so corrupt data on the disk
aswellastheinstalled operatingsystem.

Getting to Know Your LifeBook
9
RUNNINGTHE NOTEBOOK
ON ITS BATTERY
Recharging the battery
1. Connect theACadapterto yournotebook.
The moment you connect an AC adapter to
your notebook, the notebook begins to
charge the internal standard battery pack.
2. When the battery level indicator turns off
after the battery is completely charged,
(while the notebook is in off mode)
disconnect the AC adapter from the
notebook.
Before using the supplied battery pack
for the very first time after purchase,
remember to charge it fully.If a charged
batteryhas notbeenrechargedformore
thana month, chargeitfully beforeusing
it.
When the battery is fully charged while
the notebook is in power off mode, the
Battery Level LED indicator turns off.
When the battery is 90% or more
charged, it cannot be recharged even if
the AC adapter is connected. The
batterycanberecharged whenitspower
level (i.e. remaining battery life) is 89%
or less.
When a notebook is turned off, the
Battery Level LED indicator goes off
immediately if the battery is completely
charged.
The chargeability of the battery
degradeswhenit isusedin anextremely
hot or cold place.
When the battery is very hot, for
example, immediately after long usage
of the notebook, the battery protection
feature may be activated to prevent the
batteryfrom being recharged.When the
temperature decreases, the notebook
automatically begins to charge the
battery.
When an optional modular bay battery
is installed, it is charged along with the
internal standard battery. (Optional
modular bay battery is applicable to
selected models only.)
