Fujitsu LIFEBOOK P3110 User manual

LIFEBOOK P3110
Operating Manual Notebook

Are there ...
... any technical questions or problems?
Please contact:
• our Hotline/Help Desk (see Help Desk list or visit: "http://ts.fujitsu.com/support/servicedesk.html")
• your sales partner
• your sales office
Latest information about our products, useful tips, updates etc. is available
on our website: "http://ts.fujitsu.com"

Copyright
© Fujitsu Technology Solutions 2009
2009/09
Published by
Fujitsu Technology Solutions GmbH
Mies-van-der-Rohe-Straße 8
80807 München, Germany
Contact
http://ts.fujitsu.com/support
All rights reserved, including intellectual property rights. Technical data subject to modi cations and delivery subject to availability. Any
liability that the data and illustrations are complete, actual or correct is excluded. Designations may be trademarks and/or copyrights of
the respective manufacturer, the use of which by third parties for their own purposes may infringe the rights of such owner. For further
information see http://ts.fujitsu.com/terms_of_use.html
Order-No. Fujitsu Technology Solutions: A26391-K305-Z200-1-7619

LIFEBOOK P3110
Innovative technology 1
Ports and controls 3
Important notes 5
First-time setup of your device 8
Working with the notebook 11
Security functions 31
Connecting external devices 35
Removing and installing components
during servicing 39
Settings in BIOS Setup Utility 44
Troubleshooting and tips 46
Technical data 54
Manufacturer’s notes 55
Index 62
Operating Manual

Microsoft, MS, Windows XP, Windows Vista and Windows 7 are registered
trademarks of the Microsoft Corporation.
Adobe Reader is a trademark of Adobe Systems Incorporated.
MultiMediaCard is a registered trademark of Infineon Technologies AG
Sony and Memory Stick are registered trademarks of Sony Electronics, Inc.
All other trademarks referenced are trademarks or registered trademarks of their
respective owners, whose protected rights are acknowledged.
Copyright © Fujitsu Technology Solutions GmbH2009
All rights reserved, including rights of translation, reproduction by printing, copying
or similar methods, in part or in whole.
In the event of violations, perpetrators will be liable to prosecution for damages.
All rights reserved, including rights created by patent grant or registration of a utility model or design.
Subject to availability and technical modifications.

Contents
Contents
Innovativetechnology ................................................................. 1
Furtherinformation ...................................................................... 1
Notational conventions .................................................................. 2
Ports andcontrols ..................................................................... 3
Importantnotes ........................................................................ 5
Safetynotes ............................................................................ 5
Additional safety notes for devices with radio components . . . . . ............................. 5
Energy saving .......................................................................... 6
Energy saving under Windows ....................................................... 6
Travelling with yournotebook ............................................................ 6
Beforeyoutravel ................................................................... 6
Notebook:transporting ............................................................... 7
Cleaning thenotebook .................................................................. 7
First-time setup ofyourdevice ......................................................... 8
Unpacking and checkingthedevice ...................................................... 8
Selectingalocat
ion ..................................................................... 9
Mains adapter connecting ............................................................... 9
Switchingonthedevice for the first time .................................................. 10
Working with thenotebook ............................................................ 11
Statusindicators ........................................................................ 11
Switching on the notebook . . . . ........................................................... 13
Notebook: switching off .................................................................. 14
Keyboard ............................................................................... 14
Virtualnumerickeypad .............................................................. 16
Keycombinations ................................................................... 17
Country and keyboard settings ....................................................... 18
Touchpadandtouchpad buttons .......................................................... 19
Movingthe pointer .................................................................. 19
Selectingan item .................................................................... 19
Executing commands . . . . . ........................................................... 19
Dragging items ...................................................................... 20
LCD screen ............................................................................ 20
Webcam ............................................................................... 21
Rechargeablebattery ................................................................... 22
Charging,caringforandmaintainingthe battery ....................................... 22
Removing andinstalling the battery ................................................... 22
Using thepower-managementfeatures ................................................... 25
Memory cards .......................................................................... 26
Supported formats .................................................................. 26
Insertingthememory card ........................................................... 26
Removing thememorycard .......................................................... 27
Loudspeakers and microphones . . . ....................................................... 27
SIM card ............................................................................... 28
InsertingtheSIM card ............................................................... 28
Removing a SIMcard ............................................................... 28
Wireless LAN/Bluetooth/UMTS ........................................................ 29
Switching the wireless components on and off . ........................................ 29
Accessvia UMTS ................................................................... 30
A26391-K305-Z200-1-7619, edition 1

Contents
Ethernet and LAN ....................................................................... 30
Security functions ..................................................................... 31
Using a Kensington Lock ................................................................ 31
Configuring passwordprotectionin BIOSSetupUtility ...................................... 31
Protecting BIOS Setup Utility (supervisor and user password) . .......................... 32
Password protection for booting of the operating system . .............................. 33
Password protection for theharddisk ..................................................... 33
Activating hard disk protection ........................................................ 34
Deactivatingharddiskprotection ..................................................... 34
Connectingexternal devices ........................................................... 35
Connecting an external monitor . . ........................................................ 36
Connecting USB devices ................................................................ 37
How toremove USB devices correctly ................................................ 37
Connecting external audio devices . . . . . . ................................................. 38
Microphone port / Line In ............................................................ 38
Headphone port . . . . . ................................................................ 38
Removing and installing components during servicing . . . .............................. 39
Notes on installing and removing boards and components .................................. 39
Harddisk ............................................................................... 39
Preparing to remove components ........................................................ 40
Installing andremoving memoryexpansion ................................................ 40
Removing a cover ................................................................... 41
Removing memory modules . . ........................................................ 41
Installing a memorymodule .......................................................... 42
Attachingthe cover .................................................................. 42
Finishing component removal ............................................................ 43
Settings in BIOS Setup Utility . . ........................................................ 44
Starting the BIOS SetupUtility ........................................................... 44
OperatingBIOSSetupUtility ............................................................. 44
Exiting BIOS SetupUtility ................................................................ 45
Exit Saving Changes - save changes and exit BIOS Setup Utility . . . . ................... 45
Exit Discarding Changes – Discard changes and exit BIOS Setup Utility . . ............... 45
Load Setup Defaults – Copy Standard Entries ......................................... 45
Discard Changes – Discard changes without exiting the BIOS Setup Utility ............... 45
Save Changes - save changes without exiting the BIOS Setup Utility . ................... 45
Save Changes and Power Off . . . . . . ................................................. 45
Troubleshootingandtips .............................................................. 46
Helpif problemsoccur ................................................................... 47
Restoring the hard disk contents under Windows . ......................................... 47
The notebook’s date ortimeis incorrect ................................................... 48
When certain characters are entered on the keyboard, only numerals are written . . ........... 48
The notebook’s LCDscreenremainsblank ................................................ 48
The LCD screen is difficultto read ........................................................ 48
The externalmonitor remains blank ...................................................... 49
The externalmonitor isblank orthe imageis unstable ..................................... 49
The notebook cannot be started . . ........................................................ 50
The notebookstops working ............................................................. 50
The printer does not print ................................................................ 51
The radio connection to a network does not work . ......................................... 51
A26391-K305-Z200-1-7619, edition 1

Contents
Acoustic warnings ....................................................................... 51
Error messagesonthescreen ........................................................... 52
Technical data ......................................................................... 54
Notebook . . ............................................................................. 54
Rechargeablebattery ................................................................... 54
Mains adapter .......................................................................... 54
Manufacturer’snotes .................................................................. 55
Energy Star ............................................................................ 55
Disposal andrecycling .................................................................. 55
DeclarationsofConformity ............................................................... 55
CEmarking ............................................................................ 56
Regulatory notices ...................................................................... 56
Regulatory information for notebooks without radio device . ............................. 57
DOC (Industry CANADA) notices ..................................................... 58
FCC Regulatory information for notebooks with radio device . . . ......................... 60
Index .................................................................................. 62
A26391-K305-Z200-1-7619, edition 1

Contents
A26391-K305-Z200-1-7619, edition 1

Innovative technology
Innovative technology
... and ergonomic design make your device a reliable and convenient companion.
The device boots very quickly, is ready for immediate use and offers a particularly
long operating time because of its high capacity battery.
With the user-friendly "BIOS Setup Utility" you can control your notebook’s hardware and better
protect your system against unauthorised access by using the powerful password properties.
Information on the connections and user components of your notebook
canbefoundin"Ports and controls", Page 3.
Further information
The Windows drivers for your device can be found on our Internet
website. The factory installation of your device does not support any
other operating system. Fujitsu Technology Solutions accepts no liability
whatsoever if any other operating system is used.
Software oriented components of these instructions refer to Microsoft products,
if they come within the scope of the delivery.
If you install other software products, pay attention to the operating
instructions of the manufacturer.
A26391-K305-Z200-1-7619, edition 1 1

Innovative technology
Notational conventions
Pay particular attention to text marked with this symbol. Failure to observe
these warnings could pose a risk to health, damage the device or lead
to loss of data. The warranty will be invalidated if the device becomes
defective through failure to observe these warnings.
Indicates important information for the proper use of the device.
►Indicates an activity that must be performed
Indicates a result
This font indicates data entered using the keyboard in a program dialogue or at
the command line, e.g. your password (Name123) or a command used to
start a program (start.exe)
This font indicates information that is displayed on the screen by a program, e.g.:
Installation is complete.
This font indicates
• terms and texts used in a software interface, e.g.: Click on Save
• names of programs or files, e.g. Windows or setup.exe.
"This font" indicates
• cross-references to another section, e.g. "Safety information"
• cross-references to an external source, e.g. a web address: For more
information, go to "http://ts.fujitsu.com"
• Names of CDs, DVDs and titles or designations of other materials, e.g.:
"CD/DVD Drivers & Utilities" or "Safety" Manual
Key indicates a key on the keyboard, e.g: F10
This font indicates terms and texts that are emphasised or highlighted, e.g.: Do
not switch off the device
2 A26391-K305-Z200-1-7619, edition 1

Ports and controls
Ports and controls
This chapter presents the individual hardware components of your device. It gives an
overview of the displays and connections of the device. Please familiarise yourself with
these components before you start to work with the device.
3
2
4
5
1
7
8
9
10
11
12
13
6
1 = Microphone
2 = Webcam
3 = ON/OFF switch
4 = LAN port
5 = Kensington Lock
6=USBpor
ts
7 = Microphone port/Line In
8 = Headphone port
9 = Memory card slot
10 = Touchpad
11 = Touchpad buttons
12 = ON/OFF switch for wireless components
13 = Status indicators
A26391-K305-Z200-1-7619, edition 1 3

Ports and controls
3
4
5
6
2
6
1
1 = Battery compartment with SIM card
slot beneath the battery
2 = Memory service compartment
3 = DC input connector (DC IN)
4 = VGA monitor port
5 = USB port
6 = Loudspeakers
4 A26391-K305-Z200-1-7619, edition 1

Important notes
Important notes
ImportantnotesNotes
This chapter contains essential safety information which must be followed
when working with your notebook. Other notes also provide useful information
which will help you with your notebook.
Safety notes
SafetynotesNotes
Please note the information provided in the "Safety" manual and
in the following safety notes.
Please pay special attention to the sections in the manual marked
with the symbol on the left.
When connecting and disconnecting cables, observe the relevant
notes in this operating manual.
Read the information on the ambient conditions in the "Technical data",
Page 54 and "First-time setup of your device", Page 8 before preparing your
notebook for use and switching it on for the first time.
When cleaning the device, please observe the relevant notes in the
section "Cleaning the notebook", Page 7.
Pay attention to the additional safety notes for devices with wireless
components provided in the "Safety" manual.
Please refer to the notes in the chapter "Removing and installing
components during servicing", Page 39.
This notebook complies with the relevant safety regulations for data processing
equipment. If you have questions about using your notebook in a particular area,
please contact your sales outlet or our Hotline/Service Desk.
Additional safety notes for devices with
radio components
Radiocomponent :WirelessLAN:Bluetooth,safetynotes
If a radio component (Wireless LAN, Bluetooth or UMTS) is integrated in your notebook, you
must be sure to observe the following safety notes when using your notebook:
• Switch off the radio components (the ON/OFF switch must be in the "OFF "position),
when you are at an airport or driving in a car.
• Switch off the radio components (the ON/OFF switch must be in the "OFF" position),
when you are in a hospital, an operating theatre or near electronic medical equipment.
The transmitted radio waves can impair the operation of medical devices.
• Switch off the radio components (the ON/OFF switch must be in the "OFF" position), when
you take the device close to flammable gases or into hazardous environments (e.g. petrol
station, paintshops), as the transmitted radio waves can cause an explosion or a fire.
A26391-K305-Z200-1-7619, edition 1 5

Important notes
Energy saving
NotesEnergyEnergysaving
Switch the notebook off when it is not in use. Switch off external, connected devices if you
are not using them. If you use the energy saving functions, the notebook uses less energy.
You will then be able to work for longer before having to recharge the battery.
Energy efficiency is increased and the environmental impact is reduced.
You save money while protecting the environment.
Energy saving under Windows
►Make use of the power management features (see ""Using the power-management features",
Page 25").
Travelling with your notebook
MobileoperationNotesTransp ortatio nNotebook
Please observe the points listed below when travelling with your notebook.
Before you travel
►Back up important data stored on your hard disk.
NotebookTravel,notebook
►Switch off the radio component for data security reasons. With data traffic via a wireless
connection, it is also possible for unauthorised third parties to receive data.
Information on activating data encryption is provided in the documentation
for your radio component.
►If you wish to use your notebook during a flight, first check with the flight
attendants if it is OK to do so.
When travelling in other countries
►If you are travelling abroad, check that the mains adapter can be operated with the
local mains voltage. If this is not the case, obtain the appropriate mains adapter for
your notebook. Do not use any other voltage converter!
►Check whether the local mains voltage and the power cable are compatible. If this is
not the case, buy a power cable that matches the local conditions.
►Enquire with the corresponding government office of the country you will be
travelling in as to whether you may operate the radio component integrated in
your notebook there (see also "CE marking", Page 56).
►If you use a modem, incompatibilities with the local telephone system may result. This
may result in poor performance, or the modem may not work at all.
Check whether you need a country-specific telephone adapter (available as an optional
accessory).
6 A26391-K305-Z200-1-7619, edition 1

Important notes
Notebook: transporting
Protect the notebook from severe shocks and extreme temperatures
(e.g. direct sunlight in a car).
►If your device has an optical drive, remove all data media (e.g. CD, DVD) from the drives.
TransportationNotebook
►Switch the notebook off.
►Unplug the mains adapter and all external devices from the power socket.
►Disconnect the mains adapter cable and the data cables for all external devices.
►Close the LCD screen.
►To protect against damaging jolts and bumps, use a notebook carrying
case to transport your notebook.
Cleaning the notebook
Do not clean any interior parts yourself; leave this job to a service technician.
Only use cleaning products designed for computers. Normal household
cleaners and polishes can damage the markings on the keyboard and the
device, the paintwork or the notebook itself.
Ensure that no liquid enters the notebook.
The LCD screen very sensitive to scratches. Only clean the display
surface with a very soft, slightly damp cloth.
►Switch the notebook off.
CleaningNotesNotebo okKeyboardTouchpadLCDscreenCrystalView display
►In order to prevent accidentially switching the device on, remove the power cable from the mains
adaptor and remove the battery (see "Removing and installing the battery", Page 22).
The surface can be cleaned with a dry cloth. If particularly dirty, use a cloth which has
been moistened in mild domestic detergent and then carefully wrung out.
To clean the keyboard and the touchpad, you can use disinfectant wipes.
Ensure that no liquid enters the device.
A26391-K305-Z200-1-7619, edition 1 7

First-time setup of your device
First-time setup of your device
First- timese tupGettingstarted
Please read the chapter "Important notes", Page 5.
If your device is equipped with a Windows operating system, the necessary
hardware drivers and supplied software are already pre-installed.
A system test is performed when your device is first switched on. Various messages
can appear. The display may remain dark for a short time or may flicker.
Please follow the instructions on the screen.
NEVER switch off your device during the first-time setup process.
On delivery, the battery can be found in the battery compartment or in the accessories kit.
The battery must be charged if you want to operate your device using the battery.
When used on the move, the built-in battery provides the device with the necessary power. You
can increase the operating time by using the available energy-saving functions.
For instructions on how to connect external devices (e.g. mouse, printer) to your
device, please refer to the operating manual for your device.
Unpacking and checking the device
Should you discover any damage that occurred during transportation,
notify your local sales outlet immediately!
►Unpack all the individual parts.
PackagingTran sport
►Check your device for any visible damage which may have occurred during transportation.
You may need the packaging in the future, if you need to transport your device.
8 A26391-K305-Z200-1-7619, edition 1

First-time setup of your device
Selecting a location
SelectingalocationDeviceMainsadapter
Select a suitable location for the device before setting it up. Follow
the instructions below when doing so:
• Never place the device or the mains adapter on a heat-sensitive surface.
The surface could be damaged as a result.
• Never place the device on a soft surface (e.g. carpeting, upholstered furniture,
bed). This can block the air vents and cause overheating and damage.
• The underside of the device heats up during normal operation. Prolonged contact
with the skin may become unpleasant or even result in burns.
• Place the device on a stable, flat, non-slippery surface. Please note that the
rubber feet of the device may mark certain types of delicate surfaces.
• Keep other objects at least 100 mm away from the device and its
mains adapter to ensure adequate ventilation.
• Never cover the ventilation slots of the device.
• Do not expose the device to extreme environmental conditions. Protect
the device from dust, humidity, and heat.
Mains adapter connecting
Preparingforo perationMainsadapter
Observe the safety precautions in the enclosed "Safety" manual.
The supplied power cable conforms to the requirements of the country in
which you purchased your device. Make sure that the power cable is approved
for use in the country in which you intend to use it.
The mains adapter’s power cable should only be connected to a mains socket
if the device is connected to the mains adapter.
1
2
3
►Connect the mains adapter cable (1) to
the DC jack (DC IN) of the device.
►Connect the power cable (2) to the
mains adapter.
►Plug the power cable (3) into a mains outlet.
A26391-K305-Z200-1-7619, edition 1 9

First-time setup of your device
Switching on the device for the first time
Switchingonforthefirstt ime
The device must be supplied with power through the mains adapter during this process.
When you switch on the device for the first time, the supplied software is
installed and configured. Because this procedure must not be interrupted,
you should set aside enough time for it to be fully completed and connect
the device to the mains using the mains adapter.
During the installation process, DO NOT restart the device unless
you are requested to do so!
To make it easier to use your device for the first time, the operating system
is pre-installed on the hard disk.
►Switch on your device.
►During installation, follow the instructions on screen.
Consult the operating system manual if anything is unclear about the requested input data.
If a Windows operating system is installed on your device, you will find more
information on the system and drivers, help programmes, updates, manuals etc.
on the device or on the Internet under "http://ts.fujitsu.com/support".
10 A26391-K305-Z200-1-7619, edition 1
