Full Boar FBDCD-22150 User manual

KNOW YOUR PRODUCT
WARNING: Read all safety warnings and all instructions. Failure to follow the
warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
1019
2000W
CORE DRILL
• Ø150MM MAX. CAPACITY
• VARIABLE SPEED
• INTEGRATED
COOLANT FEED
INSTRUCTION MANUAL

2
Power input: 2000W
Voltage: 220-240V ~ 50Hz
No-load speed: 0-1900/min
Hand-held drilling: Ø80 mm max.
Stand mounted drilling: Ø150 mm max.
Drilling depth: 700 mm max.
Spindle thread: Ø1¼ UNC Male
Sound power level: 102.2 dB(A)
Weight (tool only): 6.5 kg
SPECIFICATIONS - MODEL NO. FBDCD-22150
KNOW YOUR PRODUCT
1. Water outlet
2. Spindle
3. Gear housing
4. Top side handle mount
5. Shoulder support
6. Shoulder support pad
7. Carbon brush cover
8. Reset button
9. Lock-on button
10. Pistol grip
11. Variable speed trigger
12. Side handle
13. Water inlet hose
14. Water supply on/off tap
15. Snap-on hose coupler
16. RCD Reset
17. LED
18. RCD Test
19. RCD (Residual-Current Device)
20. Shoulder support screws x 4
21. Screwdriver
1
2
3
4
11
5
6
9
10
7
8
12
1314
15
16
17
18
19
20
21

3
SPECIFICATIONS...................................................... Page 02
KNOW YOUR PRODUCT........................................... Page 02
INTRODUCTION....................................................... Page 04
SAFETY INSTRUCTIONS........................................... Page 04
ASSEMBLY................................................................. Page 09
SET-UP & PREPARATION........................................... Page 10
OPERATION.............................................................. Page 12
MAINTENANCE........................................................ Page 16
TROUBLE SHOOTING.............................................. Page 17
DESCRIPTION OF SYMBOLS................................... Page 18
CONTENTS............................................................... Page 19
WARRANTY............................................................... Page 20
TABLE OF CONTENTS

4
Congratulations on purchasing a Full Boar Core Drill.
Your Full Boar Core Drill FBDCD-22150 is ideal for wet or
dry core drilling downwards or horizontally in concrete,
masonry and similar materials for pipe installations and
anchoring or rails, fencing, etc. A safety friction clutch and
integral RCD device ensure easy, safe and reliable use.
The core drill may be hand-held for drilling up to 80mm.
For sizes above 80mm, it must be mounted on a drilling
stand. The drill stand is available from Bunnings subject to
availability.
INTRODUCTION
ELECTRICAL SAFETY
SAFETY INSTRUCTIONS
Read and understand the manual prior to operating this tool.
Save these instructions and other documents supplied with this tool for future reference.
The manufacturer cannot accept any liability for damage or accidents which arise due to a failure to
follow these instructions and the safety information.
WARNING! When using mains-powered equipment, basic safety precautions,
including the following, should always be followed to reduce risk of fire, electric
shock, personal injury and material damage.
This product has been designed for 220V and 240V only. Always check that the power supply
corresponds to the voltage on the rating plate.
Note: The supply of 220V and 240V is interchangeable for Australia and New Zealand.
This tool is double insulated, therefore no earth wire is required.
If the supply cord of this power tool is damaged, it must be replaced by a specially prepared cord
available through the service organization.
Note: Double insulation does not take the place of normal safety precautions when operating this
tool. The insulation system is for added protection against injury resulting from a possible electrical
insulation failure within the tool.
Using an Extension Lead
Always use an approved extension lead suitable for the power input of this tool. Before use, inspect
the extension lead for signs of damage, wear and ageing. Replace the extension lead if damaged
or defective. When using an extension lead on a reel, always unwind the lead completely. Use of an
extension lead not suitable for the power input of the tool or which is damaged or defective may
result in a risk of fire and electric shock.

5
SAVE THESE INSTRUCTIONS
1. Work area safety
a. Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b. Do not operate power tools in explosive atmospheres, such as in the presence of
flammable liquids, gases or dust. Power tools create sparks which may ignite the dust or
fumes.
c. Keep children and bystanders away while operating a power tool. Distractions can
cause you to lose control.
2. Electrical safety
a. Power tool plugs must match the outlet. Never modify the plug in any way. Do not
use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and
matching outlets will reduce risk of electric shock.
b. Avoid body contact with earthed or grounded surfaces, such as pipes, radiators,
ranges and refrigerators. There is an increased risk of electric shock if your body is
earthed or grounded.
c. Do not expose power tools to rain or wet conditions. Water entering a power tool will
increase the risk of electric shock.
d. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the
power tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged
or entangled cords increase the risk of electric shock.
e. When operating a power tool outdoors, use an extension cord suitable for outdoor
use. Use of a cord suitable for outdoor use reduces the risk of electric shock.
3. Personal safety
a. Stay alert, watch what you are doing and use common sense when operating a
power tool. Do not use a power tool while you are tired or under the influence of
drugs, alcohol or medication. A moment of inattention while operating power tools may
result in serious personal injury.
b.Use personal protective equipment. Always wear eye protection. Protective
equipment such as dust mask, non-skid safety shoes, hard hat, or hearing protection used
for appropriate conditions will reduce personal injuries.
c. Prevent unintentional starting. Ensure the switch is in the off-position before
connecting to power source and/or battery pack, picking up or carrying the tool.
Carrying power tools with your finger on the switch or energising power tools that have
the switch on invites accidents.
d. Remove any adjusting key or wrench before turning the power tool on. A wrench or a
key left attached to a rotating part of the power tool may result in personal injury.
e. Do not overreach. Keep proper footing and balance at all times. This enables better
control of the power tool in unexpected situations.
GENERAL POWER TOOL SAFETY WARNINGS
WARNING! Read all safety warnings and all instructions. Failure to follow the
warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference. The term “power tool”
in the warnings refers to your mains-operated (corded) power tool or battery
operated (cordless) power tool.

6
GENERAL POWER TOOL SAFETY WARNINGS (cont.)
f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and
gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in
moving parts.
g. If devices are provided for the connection of dust extraction and collection facilities,
ensure these are connected and properly used. Use of dust collection can reduce dust-
related hazards.
h. Do not let familiarity gained from frequent use of tools allow you to become
complacent and ignore tool safety principles. A careless action can cause severe injury
within a fraction of a second.
4. Power tool use and care
a. Do not force the power tool. Use the correct power tool for your application. The correct
power tool will do the job better and safer at the rate for which it was designed.
b. Do not use the power tool if the switch does not turn it on and off. Any power tool
that cannot be controlled with the switch is dangerous and must be repaired.
c. Disconnect the plug from the power source and/or the battery pack from the power
tool before making any adjustments, changing accessories, or storing power tools.
Such preventive safety measures reduce the risk of starting the power tool accidentally.
d. Store idle power tools out of the reach of children and do not allow persons
unfamiliar with the power tool or these instructions to operate the power tool.
Power tools are dangerous in the hands of untrained users.
e. Maintain power tools. Check for misalignment or binding of moving parts, breakage
of parts and any other condition that may affect the power tool’s operation. If
damaged, have the power tool repaired before use. Many accidents are caused by
poorly maintained power tools.
f. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to control.
g. Use the power tool, accessories and tool bits etc. in accordance with these
instructions, taking into account the working conditions and the work to be
performed. Use of the power tool for operations different from those intended could
result in a hazardous situation.
h. Keep handles and grasping surfaces dry, clean and free from oil and grease. Slippery
handles and grasping surfaces do not allow for safe handling and control of the tool in
unexpected situations.
5. Service
a. Have your power tool serviced by a qualified repair person using only identical
replacement parts. This will ensure that the safety of the power tool is maintained.
b. If the supply cord of this power tool is damaged, it must be replaced by a specially
prepared cord available through the service organization.

7
DRILL SAFETY WARNINGS
1) Safety instruction for all operations
a. Use the auxiliary handle. Loss of control can cause personal injury.
b. Brace the tool properly before use. This tool produces a high output torque and
without properly bracing the tool during operation, loss of control may occur resulting in
personal injury.
c. Hold the power tool by insulated gripping surfaces, when performing an operation
where the cutting accessory may contact hidden wiring or its own cord. Cutting
accessory contacting a “live” wire may make exposed metal parts of the power tool “live”
and could give the operator an electric shock.
2) Safety instructions when using long drill bits
a. Never operate at higher speed than the maximum speed rating of the drill bit. At
higher speeds, the bit is likely to bend if allowed to rotate freely without contacting the
workpiece, resulting in personal injury.
b. Always start drilling at low speed and with the bit tip in contact with the workpiece.
At higher speeds, the bit is likely to bend if allowed to rotate freely without contacting the
workpiece, resulting in personal injury.
c. Apply pressure only in direct line with the bit and do not apply excessive pressure.
Bits can bend causing breakage or loss of control, resulting in personal injury.
d. Keep the cord clear of the accessory being used. Do not wrap the cord around your
arm or wrist.
WARNING! Some dust created by power sanding, sawing, grinding, drilling and
other construction activities contain chemicals known to cause cancer, birth defects
or other reproductive harm.
Some examples of these chemicals are:
• Lead from lead-based paints;
• Crystalline silica from bricks, cement and other masonry products, and;
• Arsenic and chromium from chemically-treated timber.
Your risk from exposure to these chemicals varies, depending on how often you
do this type of work. To reduce your exposure to these chemicals; work in a well
ventilated area, and work with approved safety equipment, such as those dust masks
that are specifically designed to filter out microscopic particles.
e. Always wear eye protection and a dust mask for dusty applications and when
drilling/chiselling overhead. Particles can be absorbed by your eyes and inhaled easily
and may cause health complications.

8
CORE DRILL SAFETY WARNINGS
a. Wear ear protectors. Exposure to noise can cause hearing loss.
b. Wear safety goggles or other eye protection. Drilling operations cause chips to fly.
Flying particles can cause permanent eye damage.
c. Bits, tools and drilling area get hot during operation. Wear gloves when touching
them.
d. Make sure not to cut through electric mains, gas or water pipes. Use detection
devices prior to drilling.
e. Make sure the cutting accessory is fitted properly.
f. Check all screws and tighten securely before you use the machine.
g. When drilling downward, make sure the core can drop safely without injuring
someone standing beneath.
h. Drilling is only allowed downward or horizontally. Overhead (upward) drilling with
water cooling is NOT PERMITTED.
i. When drilling, always use the side handle and hold the machine firmly with both
hands.
j. Inspect the machine before every use. Do not use the machine if there are any defectives
on the mains plug, power cord, trigger switch or any part of the housing. Have the machine
repaired by an authorized repair agent.
k. Switch off the machine immediately if there is any leak of water.
l. After interrupting the cut, do not switch on until the core bit can rotate freely.
m. Always trigger off the switch to prevent the machine from accidentally self starting.
Note this procedure especially after the power supply is interrupted or the plug is
disconnected from the power outlet.
n. In case of jammed core bit disconnect the machine from the power supply, remove
the reason for the jam before turning on the machine again.
o. Block off the working area and place warning signs on both sides of the wall when
drilling through from one side to the other.
p. Always use core drill bits that fit the mounting thread. Do not use any aftermarket
adaptors to use other accessories.
q. When dry drilling, only use core drill bits designed for dry drilling. Make sure
adequate ventilation and extraction is available when dry drilling.
Wet drilling
a. Wet drilling is suitable for stone and concrete.
b. Always use core bits designed for wet drilling.
c. Prevent water from entering the motor or other electrical components. Make sure the RCD
is not in contact with water.
d. Use only pure tap water for cooling purposes.

9
Shoulder support (5)
Use the shoulder support when you wish to apply extra pressure to the drilling
operation.
1. To fit the shoulder support, first remove the shoulder support pad (6) on the
rear of the shoulder support (5).
2. Using the four shoulder support screws (20)
fit shoulder support in the rear of the core
drill with supplied screwdriver (21) (fig. 2).
3. Re-attached the shoulder support pad (6)
after securely tighten the four screws.
WARNING! Ensure the tool has been switched off and disconnected from
the power supply and completely stopped before performing any of the
following operations.
Fitting the side handle (12)
The side handle should be assembled to the
diamond core drill prior to use. This is done
by screwing the threaded end of the handle
firmly (fig. 1) in to either side of the gear
housing (3), or alternatively top side handle
mount (4). Choose the most appropriate
position considering user comfort (preferred
hand) and the task at hand.
Fig. 1
WARNING! Always use the core drill with the side handle (12) properly
assembled.
ASSEMBLY
Fig. 2
WARNING! Always use the core drill with the shoulder support (5) fully
assembled and securely fitted.

10
SET-UP & PREPARATION
Mounting and removing a diamond core drill bit
WARNING! To reduce the risk of injury, turn power off and disconnect
the drill from the power source before installing and removing accessories,
before adjusting or changing set- ups or when making repairs. Be sure the
variable speed trigger (11) is in the off position. An accidental start-up can
cause injury.
This tool uses threaded core bits and adaptors which thread directly onto the
spindle (2).
1. Choose the appropriate core bit for the size of the hole.
2. Follow the core bit or manufacturer’s recommendations for mounting the bit. You
may require an adaptor to fit the bit onto the spindle. The thread of the bit or
adaptor must match the thread of the spindle (2).
3. Smear the end thread with grease (not
included) (fig. 3).
4. Hold the spindle (2) using a wrench (not
included) over the spindle flats and tighten
the core bit with a second wrench (fig. 4).
Fig. 3
Fig. 4

11
SET-UP & PREPARATION (cont.)
Attaching water supply
1. Run water through garden hose to remove
any foreign matter before attaching to the
diamond core drill (fig. 5).
2. Set the water supply on/off tap (14) to the
off position (fig. 6).
3. Connect garden hose (min. I/D ؽ”) to the
snap-on hose coupler (15) (fig. 7).
Note: The maximum permitted pressure of the
water supply is 17 psi.
4. The water tap and/or the water supply on/
off tap (14) is used to regulate the flow of
water. The flow of water should be regulated
to a steady stream.
ON
ON
Fig. 5
ON
ON
Fig. 6
ON
ON
Fig. 7
WARNING! Use core drill only horizontally or vertically downwards. Do not
drill vertically upwards.
WARNING! Keep water away from the motor to prevent an electrical short
circuit.
WARNING! Use core bits designed
for wet use only.

12
OPERATION
Variable speed trigger (11)
1. To start operation, squeeze the variable
speed trigger (fig. 8).
Note: The more the variable speed trigger is
depressed, the faster the diamond core bit will
rotate.
Note: If the variable speed trigger (11) does
not switch on the core drill, refer “Electric
shock protection” on page 13.
2. To stop operation, fully release the variable speed trigger.
Lock-on button (9)
The lock-on button allows the tool to continue operating without holding the
variable speed trigger (11).
1. For continuous operation, fully press and
hold in the variable speed
trigger (11).(fig. 9).
2. Press the lock-on button and then the
variable speed trigger (11) can be released
while the tool continues to operate (fig. 10).
3. To stop the operation, squeeze and release
the variable speed trigger (11)
Fig. 8
Fig. 9
Fig. 10

13
OPERATION (cont.)
Electric shock protection
The power cord of the core drill includes a Residual Current Device (RCD) (19),
which protects the user against electric shock by interrupting the circuit when a
leakage current of 10 mA or greater is detected.
1. If the variable speed trigger (11) does not
switch on the core drill, press the RESET (16)
on the RCD (19).
2.The LED (17) on the RCD (19) should light up
confirming power is connected to the core
drill (fig. 11).
3. You can test the RCD (19) by pressing the
TEST (18) whilst the core drill is running. The
power circuit should be broken and the core
drill will stop operation.
WARNING! Do not use the machine if the RCD (19) does not function
properly. For the RCD to work, the machine must be connected to an
earthed power supply. Always test the RCD before every operation.
Fig. 11
WARNING! If in the test mode the switch does not break the circuit, DO
NOT USE THE CORE DRILL. Never use the RCD (19) as a mains switch.
Thermal protection
After the machine has worked in overload for a period of time, a thermal protection
circuit shuts off the machine to protect the motor. If this occurs, always remove from
the workpiece. The machine will again be operational after the thermal protection
has cooled down. The time of cooling down depends on the heat of the motor and
the ambient temperature.
1. Press the reset button (8) to reset the
thermal protection circuit once the core drill
has cooled down sufficiently (fig. 12).
Fig. 12

14
OPERATION (cont.)
Safety clutch
The core drill is fitted with a mechanical friction clutch (safety clutch) to reduce
kickback. If the diamond core bit touches the reinforcing steel bar when drilling in
reinforced concrete, or the motor is otherwise suddenly overloaded, the core drill
may start to vibrate. REDUCE THE PRESSURE OF DRILLING IMMEDIATELY.
If the diamond core bit catches and
jams, the safety clutch will slip to
protect the operator. If this happens,
switch off the drill and remove it from
the power supply.
The mechanical clutch reduces
kickback therefore following
pro-longed and continuous jamming
of the bit during use it will become
worn and slip at lower torque levels.
When this happens the clutch may
need servicing.
WARNING! Be aware of the location of pipe work and wiring.
WARNING! When the bit grabs, the machine will always twist in the
counterclockwise direction. If you are drilling into the floor, make sure that
the side handle is in front of your left leg, never between your legs.
WARNING! Hold the core drill tightly with both hands to counteract the
torque reaction force when the bit begins to turn.
CORRECT INCORRECT

15
KNOW YOUR PRODUCT
Core drilling tips
• After tightening the diamond core bit connect the core drill to the power supply
and lightly press the variable speed trigger (11) to check that the diamond core
bit is rotating evenly.
•Gently drill at a low speed until the core penetrates the surface approx.. 5-10mm
deep. If holding by hand, start the cut by approaching at an angle of about 30
degrees to the cutting surface. (A large piece of wood with a large V notch cut
in it will help prevent the bit from wandering at the beginning). Once about a
third of the arc is cut, straighten the bit to the correct perpendicular angle while
keeping enough feed pressure on the bit to prevent it from wandering. If using a
rig, use a very light feed pressure to prevent the bit from wandering until the bit
is fully penetrated into the cut.
• Reduce the drill speed just prior to the core bit breaks through the workpiece,
the bit will be very liable to get stuck. When breaking through, hold the machine
tightly and reduce feed pressure.
•It is recommended that a lower speed should be used when drilling with larger
core bits.
• After shutting down and switching off the power supply, remove the core bit.
• Clean core bit with clean with water after use.
WARNING! Keep the motor air vents free of dust to maintain ventilation
and proper cooling of the motor.
WARNING! If the bit gets stuck, do not try to rock it loose by turning
the variable speed trigger (11) on and off. That is hazardous and could
damage the motor. Rather, unplug the machine and use a wrench on the bit
mounting to work it loose.
OPERATION (cont.)

16
MAINTENANCE
WARNING! To reduce the risk of injury, turn unit off and disconnect
machine from power source before installing and removing accessories,
before adjusting or changing set-ups or when making repairs. Be sure the
trigger switch is in the OFF position. An accidental start-up can cause injury.
• Regularly take the tool to an authorized repair agent for inspection. This includes
checking the carbon brushes.
• This unit is fitted with a mechanical clutch to reduce kickback therefore following
pro-longed and continuous jamming of the bit during use the clutch may need
servicing.
• Keep the ventilation vents of the diamond core drill clean at all times.
• After each use, blow air through the diamond core drill housing to ensure it is
free from all dust particles which may build up. Build up of dust particles may
cause the diamond core drill to overheat and fail. Wear approved eye protection
and approved dust mask when performing this procedure.
• If the enclosure of the diamond core drill requires
cleaning, do not use solvents but a moist soft cloth
only. Never let any liquid get inside the diamond
core drill; never immerse any part of the diamond
core drill into a liquid.
• Ensure the shoulder support (5) with shoulder
support pad (6) are fitted securely onto the
diamond core drill. Regularly check and tighten the
four screws if necessary (fig. 13).
• Your power tool requires no additional lubrication.
Carbon brushes
When the carbon brushes wear out, the core drill will spark
and/or stop. Discontinue use as soon as this happens. They
should be replaced prior to recommencing use of the core
drill. Carbon brushes are a wearing component of the core
drill, therefore not covered under warranty. Continuing to use
the core drill when the carbon brushes need to be replaced
may cause permanent damage to the tool. Carbon brushes
will wear out after many uses but when the carbon brushes need to be replaced,
take the core drill to an electrician or a qualified power tool repairer for a quick
and low cost replacement. Always replace both carbon brushes at the same time.
Note: Ozito Industries will not be responsible for any damage or injuries caused
by the repair of the core drill by an unauthorised person or by mishandling of the
core drill.
Fig. 13

17
If your tool seems not to operate properly, follow the instructions below. If this does
not solve the problem, please contact your repair agent.
• Core bit does not cut well
If the material is too hard for the core bit, select a more suitable core bit with
harder segments.
If the water flow is too high the diamond segments are not sufficiently abraded and
do not self sharpen. Decrease the water flow.
• Segments are damaged or look glazed and polished
Jerking the machine during drilling or pushing too hard will be damage the
segments. Conversely, too gentle a feed will cause the diamond segments to
become glazed. Keep the bit steadily working.
To sharpen and true up the diamond segments simply drill into an appropriate
dressing stone as many times as necessary to restore cutting performance.
• Motor does not run
1. Check that the RCD (19) has been reset.
2. Check that the carbon brushes are making proper contact and are not over worn.
Refer Carbon Brushes in the maintenance section on page 15.
• Core cutters does not drill through the concrete
1. Safety clutch may need to be serviced. The unit needs to be serviced by a
Qualified Power Tool Repairer.
• Core drill vibrates
1. Core bit is worn or damaged. Replace core bit.
2. Core bit has touched reinforcing bar in concrete. Reduce drilling speed.
• Drill progress is slow
1. Core bit is worn or damaged. Replace core bit.
• Water flow is intermittent
1. Grit or chips partially blocking the water flow. Stop the drill, remove from power
supply and clear the blockage.
• Expelled water flow is very clear
1. The water flow is too fast which can prevent the segments from re-sharpening.
Reduce the water flow.
• Segments and core are burnt
1. Increase the water flow.
• Segments wear too fast
1. Choose a more appropriate core bit (with harder segments).
TROUBLESHOOTING

18
Warning
Read instruction manual
min Revolutions or
reciprocation per minute n0No load speed
V Volts Hz Hertz
~ Alternating current W Watts
Diameter
Regulator compliance mark
Wear ear, eye and breathing
protection
mm Millimetres
Double Insulated
Power tools that are no longer usable should not be
disposed of with household waste but in an environmentally
friendly way. Please recycle where facilities exist. Check with
your local council authority for recycling advice.
Recycling packaging reduces the need for landfill and raw
materials. Reuse of recycled material decreases pollution in the
environment. Please recycle packaging where facilities exist.
Check with your local council authority for recycling advice.
CARING FOR THE ENVIRONMENT
DESCRIPTION OF SYMBOLS

19
CONTENTS
Distributed by:
Ozito Industries Pty Ltd
AUSTRALIA (Head Office)
1-23 Letcon Drive, Bangholme Victoria, Australia, 3175
Telephone: [phone]
1 x Diamond core drill
1 x Front handle
1 x Shoulder support
4 x Shoulder support screws
1 x RCD (fitted)
1 x Water inlet hose with on/of tap (fitted)
1 x Screwdriver
1 x Carry bag

20
WARRANTY EXCLUSIONS
The following actions will result in the warranty being void.
If the tool has been operated on a supply voltage other than that specified on the tool.•
If the tool shows signs of damage or defects caused by or resulting from abuse, accidents•
or alterations.
Failure to perform maintenance as set out within the instruction manual.•
If the tool is disassembled or tampered with in any way.
The warranty excludes damage resulting from product misuse or product neglect.
•
•
This warranty is given by Ozito Industries Pty Ltd.
ABN: 17 050 731 756
Ph.1800 069 486
Australia/New Zealand (Head Office)
1-23 Letcon Drive, Bangholme, Victoria, Australia 3175
FB1
WARRANTY
TO ENSURE A SPEEDY RESPONSE PLEASE HAVE THE MODEL NUMBER AND DATE OF
PURCHASE AVAILABLE. A CUSTOMER SERVICE REPRESENTATIVE WILL TAKE YOUR CALL
AND ANSWER ANY QUESTIONS YOU MAY HAVE RELATING TO THE WARRANTY POLICY
OR PROCEDURE.
The benefits provided under this warranty are in addition to other rights and remedies which
are available to you under law. The warranty covers manufacturer defects in materials,
workmanship and finish under normal use.
1 YEAR WARRANTY
Your product is guaranteed for a period of 12 months from the original date of purchase.
If a product is defective it will be repaired in accordance with the terms of this warranty.
Warranty excludes consumable parts, for example: wheels, bearings.
Our goods come with guarantees that cannot be excluded under Australian Consumer law &
Consumer Guarantees Act 1993 (NZ). You are entitled to a replacement or refund for a major
failure and to compensation for other reasonably foreseeable loss or damage. You are also
entitled to have the goods repaired and replaced if the goods fail to be of acceptable quality
and the failure does not amount to a major failure.
`Australia 1800 069 486
New Zealand 0508 069 486
YOUR WARRANTY FORM SHOULD BE RETAINED BY YOU AT ALL TIMES. IN ORDER TO MAKE A
CLAIM UNDER THIS WARRANTY YOU MUST RETURN THE PRODUCT TO YOUR NEAREST
BUNNINGS WAREHOUSE (see www.bunnings.com.au or www.bunnings.co.nz for store locations)
WITH YOUR BUNNINGS REGISTER RECEIPT. PRIOR TO RETURNING YOUR PRODUCT FOR
WARRANTY PLEASE TELEPHONE OUR CUSTOMER SERVICE HELPLINE:
