Full Boar FBT-0700U Installation instructions
Danger! - Read the operating instructions to re-
duce the risk of inquiry
Caution! Wear ear-mus. The impact of noise
can cause damage to hearing.
Caution! Wear a breathing mask. Dust which
is injurious to health can be generated when
working on wood and other materials. Never use
the device to work on any materials containing
asbestos!
Caution! Wear safety goggles. Sparks gene-
rated during working or splinters, chips and dust
emitted by the device can cause loss of sight.
Select between the individual functions only when
the equipment is at a standstill. If you fail to obser-
ve this point, the equipment may be damaged.
The reprinting or reproduction by any other me-
ans, in whole or in part, of documentation and
papers accompanying products is permitted only
with the express consent of the iSC GmbH.
Subject to technical changes
FBT-0700U
GB Additonal operating & safety instructions Rotary Hammer Drill Kit
Service information
Please note that the following parts of this product are subject to normal or natural wear and that the
following parts are therefore also required for use as consumables.
Category Example
Wear parts* Carbon brushes, chuck
Consumables* Drill bits, chisels
Missing parts
* Not necessarily included in the scope of delivery!
Paul Downhill
- 135 -
explains the following conformity according to EU directives and norms for
the following product
Rotary Hammer Drill FBT-0700U (Full Boar)
2014/29/EU
2005/32/EC_2009/125/EC
2014/35/EU
2006/28/EC
X2014/30/EU
2014/32/EU
2014/53/EC
2014/68/EU
90/396/EC_2009/142/EC
89/686/EC_96/58/EC
X2011/65/EU
X2006/42/EC
Annex IV
Noti ed Body:
Noti ed Body No.:
Reg. No.:
2000/14/EC_2005/88/EC
Annex V
Annex VI
Noise: measured LWA = dB (A); guaranteed LWA = dB (A)
P = KW; L/Ø = cm
Noti ed Body:
2004/26/EC
Emission No.:
Standard references: EN 60745-1; EN 60745-2-6; EN 55014-1; EN 55014-2;
EN 61000-3-2; EN 61000-3-3
Milton Keynes, 24.05.2017
First CE: 16 Archive-File/Record: NAPR016815
Art.-No.: 42.579.54 I.-No.: 11027 Documents registrar: Robert Gehard
Subject to change without notice Wiesenweg 22, D-94405 Landau/Isar
HHGL Ltd, Witan Gate House, 500 – 600 Witan Gate, Milton Keynes MK9 1BA
Declaration of conformity
Beiblatt_FBT_0700U.indd 1 19.06.2017 07:53:31
Items supplied
Please check that the article is complete as
specied in the scope of delivery. If parts are
missing, please contact our service center or the
sales outlet where you made your purchase at
the latest within 5 working days after purchasing
the product and upon presentation of a valid bill
of purchase. Also, refer to the warranty table in
the service information at the end of the operating
instructions.
• Open the packaging and take out the equip-
ment with care.
• Remove the packaging material and any
packaging and/or transportation braces (if
available).
• Check to see if all items are supplied.
• Inspect the equipment and accessories for
transport damage.
• If possible, please keep the packaging until
the end of the guarantee period.
Danger!
The equipment and packaging material are
not toys. Do not let children play with plastic
bags, foils or small parts. There is a danger of
swallowing or suocating!
Proper use
The tool is designed for drilling with hammer acti-
on in concrete, rock and brick, as well as for chi-
seling work, always using the respective correct
drill or chisel bit.
The equipment is to be used only for its prescri-
bed purpose. Any other use is deemed to be a
case of misuse. The user / operator and not the
manufacturer will be liable for any damage or inju-
ries of any kind caused as a result of this.
Technical data
Mains voltage: ........................220-240 V ~ 50 Hz
Power input: ............................................ 1050 W
Idling speed: ........................................ 0-500 rpm
Blow rate: .......................................... 0-4100 rpm
Drilling capacity in concrete/stone (max.): 38 mm
Protection class: ...........................................II / &
Weight: .......................................................6.9 kg
Danger!
Sound and vibration
Sound and vibration values were measured in
accordance with EN 60745.
LpA sound pressure level ..................... 94.2 dB(A)
KpA uncertainty ............................................. 3 dB
LWA sound power level ..................... 105.2 dB(A)
KWA uncertainty ............................................. 3 dB
The hammer drill is not designed for outdoors
use as specied I Article 3 of Directive 2000/14/
EC_2005/88/EC.
Wear ear-mus.
The impact of noise can cause damage to hea-
ring.
Total vibration values (vector sum of three direc-
tions) determined in accordance with EN 60745.
Hammer drilling in concrete (Handle)
Vibration emission value ah,HD = 13.901 m/s2
K uncertainty = 1.5 m/s2
Hammer drilling in concrete (Additional
handle)
Vibration emission value ah,HD = 9.815 m/s2
K uncertainty = 1.5 m/s2
Chiseling (Handle)
Vibration emission value ah,Cheq = 14.644 m/s2
K uncertainty = 1.5 m/s2
Chiseling (Additional handle)
Vibration emission value ah,Cheq = 9.752 m/s2
K uncertainty = 1.5 m/s2
The specied vibration value was established in
accordance with a standardized testing method. It
may change according to how the electric equip-
ment is used and may exceed the specied value
in exceptional circumstances.
The specied vibration value can be used to
compare the equipment with other electric power
tools.
The specied vibration value can be used for initi-
al assessment of a harmful eect.
Keep the noise emissions and vibrations to a
minimum.
• Only use appliances which are in perfect wor-
king order.
• Service and clean the appliance regularly.
• Adapt your working style to suit the appliance.
• Do not overload the appliance.
• Have the appliance serviced whenever
necessary.
• Switch the appliance off when it is not in use.
• Wear protective gloves.
Caution!
Residual risks
Even if you use this electric power tool in ac-
cordance with instructions, certain residual
risks cannot be rules out. The following ha-
zards may arise in connection with the equip-
ment’s construction and layout:
1. Lung damage if no suitable protective dust
mask is used.
2. Damage to hearing if no suitable ear protecti-
on is used.
3. Health damage caused by hand-arm vibra-
tions if the equipment is used over a pro-
longed period or is not properly guided and
maintained.
For EU countries only
Never place any electric power tools in your
household refuse.
To comply with European Directive 2012/19/EC
concerning old electric and electronic equipment
and its implementation in national laws, old elec-
tric power tools have to be separated from other
waste and disposed of in an environment-friendly
fashion, e.g. by taking to a recycling depot.
Recycling alternative to the return request:
As an alternative to returning the equipment to
the manufacturer, the owner of the electrical
equipment must make sure that the equipment
is properly disposed of if he no longer wants to
keep the equipment.The old equipment can be
returned to a suitable collection point that will
dispose of the equipment in accordance with the
national recycling and waste disposal regulations.
This does not apply to any accessories or aids
without electrical components supplied with the
old equipment.
Beiblatt_FBT_0700U.indd 2 19.06.2017 07:53:31
