FUN-TEK DPF-702Y User Manual
7inch Digital Photo Frame

WARNING
The power cable/disconnect device shall remain easy to operate/disconnect.
Introduction
Congratulation on your purchase of Digital Multimedia Digital Photo Frame.
Before operating the unit, please read this manual thoroughly and keep it for future reference. This
manual will help you use many of the exciting features to make your Multimedia Digital Photo Frame
view more enjoyable.
The Multimedia Digital Photo Frame enables you to view digital pictures directly from your camera’s
memory card .You can also create a slide show with multiple transition effects. No computer , digital
camera ,or internet connection is required.
The Multimedia Digital Photo Frame is compatible with the following memory card formats: SD, MMC
card and USB Host (Optional).
Precautions and Maintenance
●For indoor use only
●To avoid risks of file or electric shock ,do not expose this appliance to moisture.
●To avoid overheating, do not block the ventilation holes on the back of the DPF at any time.
●Keep your Multimedia Digital Photo Frame out of sunlight .Direct sunlight may cause damage.
●Always use the eject buttons on the memory storage card slots to remove the memory storage cards.

●Do not dismantle the Multimedia DPF. There is a risk of electric shock, and there are no user
serviceable parts inside .Dismantling your Multimedia Digital Photo Frame will void your warranty.
●Do not use the Multimedia Digital Photo Frame if conditions could allow condensation to occur, or
damage may result.
Resource
Inserting Memory Cards
Your multimedia DPF is compatible with the following memory cards:
Secure Digital Card (SD)
Multimedia Card (MMC)
USB Host (Optional)
Insert the memory card with the screen and slots all facing yourself .Do not force the memory card in the
slot.
If you are not able to easily insert the memory card completely, you may have inserted it in a wrong way.
Note : DPF = Digital Photo Frame.
DPF Side view
●DC (+12V): Input the DC power adapter to the DPF player.

●SD/MMC card: The socket for DPF player to connect the
SD/MMC memory card.
●USB Host: The socket for DPF player to the USB memory.
Player Overview
Key control and Key function:
1. ENTER BUTTON: Confirm that what you choose. And pause or play.
2. LEFT SHIFT BUTTON(◢): Left cursor selecting function and next photo.

3. RIGHT SHIFT BUTTON (◣): Right cursor selecting function and previous photo.
4. MENU BUTTON: Show the menu for selecting.
5. UP BUTTON(▲): Functional selecting button and Rotate from the button to the top cursor.
6. DOWN BUTTON(▼):Functional selecting button and Time /date from the top to the button cursor.
7. STANDBY BUTTON: Turn ON/OFF the player.
8. Bracket jack.
Getting started
Getting started
Assemble the Multimedia Digital Photo Frame bracket to prop the unit up insert adapter DC plug into the
DPF player first, then plug the power cord to a standard wall outlet.
Then the screen will display as below: (Will play the pictures automatically stored) If insert the SD/MMC
card or USB Host (Optional), then will play the pictures in the card .
DPF

Functions
The DPF setup menus allow you to configure the Video and General settings of the DPF Player.
1. Power on the DPF, will show the initial picture(Picture 1).
2. Insert the SD/MMC card or USB Host, then the DPF will play the pictures in the card automatically.
3. Press the MENU BUTTON to enter the MENU(Picture 2).
●Photo: Press ENTER key, will show all the photos when open the menu, and show 6 pictures once.
●Calendar and Clock: Press LEFT/RIGHT key select, will show the Calendar or Clock menu.
●Files: Press LEFT/RIGHT key to select, can see the contents of file.
●Favorite: Press LEFT/RIGHT key to select, then press UP/DOWN key to select the memory format or
see the content of memory.
●Setting: Press LEFT/RIGHT key to enter, will show Picture mode, Play speed, Brightness, Language and
Date Time menu.
a) Picture mode: Press ENTER to select, press LEFT/RIGHT to select the picture playing mode. Press enter
to confirm your choice.
b) Pictures Speed: Press ENTER to select, press LEFT/RIGHT to select the picture playing speed. Press
enter to confirm your choice.
c) Brightness: press ENTER to select, press LEFT/RIGHT to setting the brightness. Press enter to confirm
your choice.
d) Language: press ENTER to enter the language selection, default language is English. Press enter to
confirm your choice.
e) Date Time: Press ENTER to select and setting the Year, Month, Day, Hour, Minute and Second. Press
enter to confirm your choice.
Remarks

1) Download the photos from SD/MMC to Norflash :
- Press the MENU BUTTON to enter the MENU
- Photo : press LEFT/RIGHT key to select, will show all the photos when open the menu and show 6
pictures once.
- Press LEFT/RIGHT key to select the photo that want to download.
- Press ENTER, will show the photo with whole screen.
- Press ENTER, will show the wording on the top ”Press OK to save picture, press MENU to cancel”
- Press ENTER will show the wording on the top ”Copying……Please wait.”
- To wait the wording on the top ”Copy is successful”, then the download procedure had been
completed.
2) Delete the photos from Norflash :
- Press the MENU BUTTON to enter the MENU.
- Favorite : press LEFT/RIGHT key to select, will show ITEM “Format” and “Photo”.
- Press UP/DOWN key to select ITEM “Format”.
- Press ENTER, will show the wording ”Press OK to Format, Press Menu to Cancel”
- Press ENTER, will show the wording ”Formating local Driver………”
- To wait the wording ”Format success”. Then all the photos in the Norflash had
been deleted.(It can’t be deleted only by one).
Specification
Display: 7” TFT LCD 480*3(RGB)*234
Power: AC Adapter, Input 100-240V AC, Output 12V 500mA

Environmental operating ranges
Operation: 32-95 F, Humidity 0 - 85
Storage: -4 -140 F, Humidity 10 - 90
Powered by www.fun-tek.com
Do not dispose of this product in the usual
household garbage at the end of its lifecycle; hand
it over at a collection point for the recycling of
electrical and electronic appliances. The symbol
on the product, the instructions for use or the
packing will inform about the methods for disposal.
The materials are recyclable as mentioned in this
marking. By recycling, material recycling or other
forms of re-utilization of old appliances ,you are
making an important contribution to protect our
environment.
Please inquire at the community administration for
the authorized disposal location.
