Furrion Access FAN17A82 User manual

Wi-Fi Router
Routeur Wi-Fi
Enrutador Wi-Fi
Instruction Manual
Manuel d’instructions
Manual de instrucciones
Model/Modèle/Modelo: FAN17A82

Thank you for purchasing the Furrion®Wi-Fi Router. Before operating your new
product, please read these instructions carefully. This will ensure safe use and
reduce the risk of injury. This instruction manual contains information for installation,
maintenance of the product and safe use.
Please keep this instruction manual in a safe place for future reference. Be sure to
pass on this manual to any new owners of this product.
The manufacturer does not accept responsibility for any damages due to not
observing these instructions.
If you have any questions regarding our products, please contact us at:
[email protected]
2
English
Welcome

Welcome..................................................................................................2
Contents..................................................................................................3
About your Product ...............................................................................4
Product Features...................................................................................................................................4
FCC Statements ....................................................................................................................................4
IC Statement............................................................................................................................................5
Product Overview ..................................................................................6
Installation ..............................................................................................7
What’s in the box....................................................................................................................................7
Slide-in the Wi-Fi Router ....................................................................................................................7
Wi-Fi Router Configuration ..................................................................8
Power on Your Wi-Fi Router............................................................................................................ 8
Connect to Your Wi-Fi Router for Wi-Fi Configuration........................................................ 8
Log in to the Configuration Interface........................................................................................... 8
Quick Setup of your Wi-Fi Router.................................................................................................. 9
Advance Setting....................................................................................................................................11
Internet Access through the Wi-Fi Router....................................... 12
Maintenance .........................................................................................13
Power off or Reboot Your Wi-Fi Router.....................................................................................13
Reset your Wi-Fi Router ...................................................................................................................13
Specifications ......................................................................................14
Troubleshooting...................................................................................14
Warranty................................................................................................15
3
English
Contents

Furrion Wi-Fi Router supports such popular operating systems as Windows, Linux and
Mac, and smart devices like iOS and Android are compatible with this product too.
Please read this manual before using Furrion Wi-Fi Router for the first time.
Product Features
●Slide-in Design - Easy Installation
●Web/APP for configuration
●Auto detect web login/security check
●WPS supported
FCC Statements
Changes or modifications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment.
This equipment has been tested and found to comply with the limits for a Class
B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency
energy and, if not installed and used in accordance with the instructions, may cause
harmful interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged
to try to correct the interference by one or more of the following measures:
−Reorient or relocate the receiving antenna.
−Increase the separation between the equipment and receiver.
−Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
−Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator and your body. This transmitter must
not be co-located or operating in conjunction with any other antenna or transmitter.
4
English
About your Product

IC Statement
This device contains licence-exempt transmitter(s)/receiver(s) that comply with
Innovation, Science and Economic Development Canada’s licence-exempt RSS(s).
Operation is subject to the following two conditions: (1) This device may not cause
interference. (2) This device must accept any interference, including interference that
may cause undesired operation of the device.
This equipment complies with FCC/IC RSS-102 radiation exposure limits set forth for
an uncontrolled environment. This equipment should be installed and operated with
minimum distance 20cm between the radiator and your body.
5
English
About your Product

POWER STAT US
RESET
Status Indicator
Reset Button
Power Button
WPS/Status
Button
Button/
Indicator Description
Power Button
●In OFF mode, press and hold the POWER button for about 4 seconds to
turn on the device. The Status Indicator LED will be illuminated and then
off.
●In ON mode, press and hold the POWER button for about 4 second to
turn off the device.
WPS/Status
Button
●Press and hold the WPS/Status button for 5 seconds to turn on the
WPS function. The default setting is 2.4G Wi-Fi.
●Briefly press the WPS/STATUS button to view the network status. The
network status LED will be illuminated for about 20 seconds.
NOTE: You can check the network status by enabling the Status LED
option on the router configuration web page. The network status LED
will be kept illuminated unless you disable the Status LED option.
Reset Button
●Press and hold the RESET button with a pointed object for 10 seconds
to reset the device to factory default settings. All the LEDs blink 3 times
indicates you have reset the device successfully.
●Briefly press the RESET button with a pointed object to reboot the
device.
Status
Indicator
Wi-Fi Network connected and
Internet ready
●Network status indicator ON.
No valid Wi-Fi connected or Internet
not ready
●Network status indicator ON and
blinking once per second.
6
English
Product Overview

What’s in the box
Make sure you have the following items
included in the packaging. If any item
is damaged or missing, contact your
dealer.
●Wi-Fi Router x 1
●Device Identity Sticker x 1
●Warranty Card x 1
●Instruction Manual x 1
Slide-in the Wi-Fi Router
This Wi-Fi Router is designed for using
with Furrion rooftop antenna only. Refer
to the separate Furrion outdoor antenna
instruction manual about how to install it
onto the RV rooftop.
NOTE: A Furrion Rooftop Antenna with
mounting bracket (sold separately,
part#FAN73B7C) should already have
been installed on your RV rooftop. If not,
contact your RV dealer or visit
www.furrion.com to purchase it.
2” (50mm) Min.
2” (50mm) Min.
2” (50mm) Min.
7” (178mm) Min.
1. Pull to remove the cover attached
over the existing Ceiling Mount
Bracket. (Fig. 1)
RV Ceiling
Fig. 1
2. Slide the Wi-Fi Router into the
existing Ceiling Mount Bracket.
(Fig. 2)
RV Ceiling
Fig. 2
3. Your Wi-Fi Router is now fully
installed onto the RV ceiling.
7
English
Installation

Power on Your Wi-Fi Router
Turn on the power connected to the
Ceiling Mount Bracket.
The Wi-Fi Router will be turned on
automatically upon receiving power.
NOTE: You may log in to the Wi-Fi
Router and disable the auto power-on
feature through the configuration
interface. The default setting is Enabled.
If the Wi-Fi Router is turned off, press
and hold the POWER button on the top
for about 4 seconds to turn it on.
Connect to Your Wi-Fi Router
for Wi-Fi Configuration
1. Scan for wireless networks on your
mobile device or laptop. It may take
a few minutes for the network to
appear.
2. Select Local Wi-Fi network with
SSID: FURRIONAP_xxxxxx
Password: FAxxxxxx
The “xxxxxx” in the example above
corresponds to the last 6 characters
of the unique network ID address. The
default password can be found on the
SSID/WPA sticker.
3. Confirm and join the network.
Log in to the Configuration
Interface
The default IP of this Wi-Fi Router is
192.168.0.1 with subnet 255.255.255.0.
Make sure the smart device or PC
attached to this router is in the
same subnet and has an IP address
in the range between 192.168.0.2~
192.168.0.254.
1. Launch a web browser and enter
192.168.0.1 in the address bar, then
the login window will pop up.
2. Enter the default user name: admin
and password: admin.
Username:
Password:
Login Cancel
3. Click Login.
System Icon Definition
Reboot the system.
Click to logout of the system.
Click for quick setup of your
system.
8
English
Wi-Fi Router Configuration

Quick Setup of your Wi-Fi
Router
Change Administration Password
After successful login, the following
screen will appear and you will be required
to setup a new password for the “admin”
account for device management.
Username: Show the current user name.
New Password: You can enter

Confirm Password: Enter the new
password again.
Click Next to go on to the next step.
Connect to an External Wi-Fi
Network
The following window will appear,
allowing you to select an available AP
(Access Point) for Internet access.
SCAN AP: Click SCAN to scan available
APs and the following window will appear:
Choose the AP you want to connect from
the pop-up window and click Apply to
apply the network settings.
9
English
Wi-Fi Router Configuration

AP SSID: The SSID of the scanned and
applied AP will appear here. You can also
enter an available network SSID here
directly.
Password: Enter the password of the
selected AP.
Click Next to go on to the next step.
Change Wireless Settings
A new window will pop up, where you can
change wireless settings.
Network Name (SSID): Rename the
SSID of the Wi-Fi Router. For example,
rename it to My Furrion Router.
NOTE: Make sure that your SSID
is unique if there are other wireless
networks operating in your area.
Security Mode: Select a security mode:
No Encryption, WPA-PSK, WPA2-PSK,
or WPA-PSK/WPA2-PSK.
WPA Algorithms: TKIP or AES.
Password: Set the password for Internet
access through the Wi-Fi Router.
Click Next to go on to the next step.
Confirm Your Settings
In the pop-up window, click “Finish” to
save and finish the quick setup.
You should now be able to access
the Internet after the Wi-Fi Router
configuration is finished.
10
English
Wi-Fi Router Configuration

Advance Setting
Click Advance Setting to activate the advance setting page, where you can
configure advanced settings of WAN, LAN, Wi-Fi, Firewall etc.
11
English
Wi-Fi Router Configuration

12
English
Internet Access through the Wi-Fi Router
Wireless Connection
1. Scan for wireless networks on your
mobile device or laptop. It may take
a few minutes for the network to
appear.
2. Find the SSID you set for the Wi-

Router.
3. Confirm for connection to the Wi-Fi
Router.
−Now you can access to the
Internet through the Wi-Fi Router.
LAN Connection
For Internet access, you can also connect
your device (such as a laptop or smart
TV) to the LAN socket available on the
Ceiling Mount Bracket.

Power off or Reboot Your
Wi-Fi Router
Note: Be careful the Wi-Fi Router might
be hot after operating for a long time.
You can power off or reboot it when
necessary.
To power off:
●Press and hold the POWER button
on top of the Wi-Fi Router for about

The Network Status LED will flash
and then turn off.
POWER STAT US
RESET
NOTE: It is recommended to wait


To reboot:
●Log in to the configuration interface
(see “Login” section about how to log
in), then click the button.
●Or briefly press the RESET button
with a pointed object.
Reset your Wi-Fi Router
To restore the Wi-Fi Router to factory
default settings, press and hold the
RESET button using a pointed object for
about 10 seconds then release.
The LED will flash 3 times then disappear.
POWER STAT US
RESET
13
English
Maintenance

Technical Specifications
OPERATING CONDITIONS
 2412MHz to 2462MHz (802.11b/g/n (HT20))
2422MHz to 2452MHz (802.11n (HT40)
SUPPORTED SYSTEMS Wi-Fi (LAN): 802.11b/g/n
ANTENNA GAIN
 2dBi
INTERNAL GPS/GLONASS 2dBi
 2.4G Wi-Fi: 17.78dBm (max.)
 >400ft with >10Mbps throughput
POWER RATING Typical: 12Vdc @ 500mA, Peak 1A
OPERATION TEMPERATURE -20°C to 55°C / -4°F to 131°F
1. None of the LEDs are on when you turn on the router
Make sure you have power to the Ceiling Mount Bracket.
Check the connection between the Ceiling Mount Bracket and the Wi-Fi Router.
If the error persists, you may have a hardware problem. In this case you should
contact technical support.
2. You have forgotten your router login and/or password
Try the default login and password, found in the “Login” section. If this fails, you
can restore your router to its factory settings by pressing and holding the Reset
button on top of your router with a pointed object for 10 seconds or more. You will
be able to use the default login and password after the factory reset.
3. No access to the Internet
Check the external network access status and Wi-Fi connection.
14
English
Specifications
Troubleshooting



WHEN DELIVERED TO YOU IN NEW CONDITION, IN ORIGINAL PACKAGING,
FROM A FURRION AUTHORIZED RESELLER AND USED IN NORMAL
CONDITIONS, IS FREE FROM ANY DEFECTS IN MANUFACTURING, MATERIALS,
AND WORKMANSHIP. IN CASE OF SUCH DEFECT, FURRION SHALL REPLACE
OR REPAIR THE PRODUCT AT NO CHARGE TO YOU. THIS WARRANTY DOES
NOT COVER: PRODUCTS WHERE THE ORIGINAL SERIAL NUMBERS HAVE
BEEN REMOVED, ALTERED OR CANNOT READILY BE DETERMINED; DAMAGE
OR LOSS CAUSED BY ACCIDENT, MISUSE, ABUSE, NEGLECT, PRODUCT
MODIFICATION, FAILURE TO FOLLOW INSTRUCTIONS IN INSTRUCTION
MANUAL, COMMERCIAL OR INDUSTRIAL USE; DAMAGE OR LOSS CAUSED
TO THE DECORATIVE SURFACE OF PRODUCT; TO ANY DATA, SOFTWARE
OR INFORMATION; AND NORMAL WEAR AND TEAR. THIS WARRANTY ONLY

ANY ATTEMPT TO TRANSFER THIS WARRANTY SHALL MAKE IT IMMEDIATELY
VOID. THIS WARRANTY IS ONLY VALID IN THE COUNTRY OF PURCHASE.
THIS WARRANTY AND REMEDIES SET FORTH ABOVE ARE EXCLUSIVE AND IN
LIEU OF ALL OTHER WARRANTIES, REMEDIES AND CONDITIONS, WHETHER
ORAL OR WRITTEN, EXPRESS OR IMPLIED. FURRION SPECIFICALLY DISCLAIMS
ANY AND ALL IMPLIED WARRANTIES, INCLUDING, WITHOUT LIMITATION,
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE. IF FURRION CANNOT LAWFULLY DISCLAIM IMPLIED WARRANTIES
UNDER THIS LIMITED WARRANTY, ALL SUCH WARRANTIES, INCLUDING
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR
PURPOSE ARE LIMITED IN DURATION TO THE DURATION OF THIS WARRANTY.
No Furrion reseller, agent, or employee is authorized to make any modification,
extension, or addition to this warranty.
15
English
Warranty

FURRION IS NOT RESPONSIBLE FOR DIRECT, INDIRECT, SPECIAL, INCIDENTAL
OR CONSEQUENTIAL DAMAGES RESULTING FROM ANY BREACH OF
WARRANTY OR CONDITION, OR UNDER ANY OTHER LEGAL THEORY,
INCLUDING BUT NOT LIMITED TO LOST PROFITS, DOWNTIME, GOODWILL,
DAMAGE TO OR REPLACEMENT OF ANY EQUIPMENT OR PROPERTY, ANY
COSTS OF RECOVERING, REPROGRAMMING, OR REPRODUCING ANY
PROGRAM OR DATA STORED IN OR USED WITH FURRION PRODUCTS.
FURRION’S TOTAL LIABILITY IS LIMITED TO THE REPAIR OR REPLACEMENT OF
THIS PRODUCT PURSUANT TO THE TERMS OF THIS WARRANTY.
SOME STATES DO NOT ALLOW THE EXCLUSION OR LIMITATION OF
INCIDENTAL OR CONSEQUENTIAL DAMAGES OR EXCLUSIONS OR LIMITATIONS
ON THE DURATION OF IMPLIED WARRANTIES OR CONDITIONS, SO THE ABOVE
LIMITATIONS OR EXCLUSIONS MAY NOT APPLY TO YOU. THIS WARRANTY
GIVES YOU SPECIFIC LEGAL RIGHTS, AND YOU MAY ALSO HAVE OTHER RIGHTS
THAT VARY BY STATE OR (WHERE APPLICABLE IN THE COUNTRIES WHERE
FURRION HAS NON-US/CANADIAN AUTHORIZED DEALERS) COUNTRY. NO
ACTION OR CLAIM TO ENFORCE THIS WARRANTY SHALL BE COMMENCED
AFTER THE EXPIRATION OF THE WARRANTY PERIOD.
Keep your receipt, delivery slip, or other appropriate payment record to establish the
warranty period. Service under this warranty must be obtained by contacting Furrion
at [email protected]
Product features or specifications as described or illustrated are subject to change
without notice.
16
English
Warranty

Nous vous remercions pour l'achat de ce routeur Wi-Fi Furrion®Avant d’utiliser votre
nouveau produit, veuillez lire attentivement les présentes consignes. Cela garantit
une utilisation en toute sécurité et réduit tout risque de blessures. Le présent manuel
d'instructions contient des informations sur l'installation, l'entretien et l'utilisation
sécurisée du produit.
Veuillez conserver le présent manuel d’instructions en lieu sûr afin de pouvoir vous
y référer ultérieurement. Veillez à transmettre ce manuel à d'éventuels nouveaux
propriétaires de ce produit.
Le fabricant décline toute responsabilité pour tous dommages résultant du non-
respect des présentes consignes.
Si vous avez des questions concernant nos produits, veuillez nous contacter à
l'adresse suivante: [email protected]
17
Français
Bienvenue

Bienvenue.............................................................................................. 17
À propos de votre produit...................................................................19
Caractéristiques du produit............................................................................................................19
Déclarations FCC ................................................................................................................................19
Déclaration d’Industrie Canada (IC)...........................................................................................20
Présentation du produit...................................................................... 21
Installation ........................................................................................... 22
Contenu de l’emballage...................................................................................................................22
Encastrer le routeur Wi-Fi...............................................................................................................22
Configuration du routeur Wi-Fi......................................................... 23
Mettre votre routeur Wi-Fi en marche.......................................................................................23
Vous connecter à votre routeur Wi-Fi pour la configuration Wi-Fi ..............................23
Vous connecter à l’interface de configuration ......................................................................23
Configuration rapide de votre routeur Wi-Fi ..........................................................................24
Paramètres avancés .........................................................................................................................26
Accès Internet via le routeur Wi-Fi....................................................27
Entretien............................................................................................... 28
Redémarrer votre routeur Wi-Fi ou le mettre hors tension .............................................28
Réinitialiser votre routeur Wi-Fi....................................................................................................28
Caractéristiques.................................................................................. 29
Dépannage ........................................................................................... 29
Garantie................................................................................................ 30
Contenu
18
Français

Le routeur Wi-Fi Furrion prend en charge les principaux systèmes d'exploitation tels
que Windows, Linux et Mac. Les appareils intelligents comme iOS et Android sont
également compatibles avec ce produit.
Veuillez lire le présent manuel avant votre première utilisation du routeur Wi-Fi Furrion.
Caractéristiques du produit
●Conception encastrable pour une installation facile
●Configuration Web/APP
●Détection automatique de la connexion Web/vérification de sécurité automatique
●Prise en charge WPS
Déclarations FCC
Toute modification ou tout changement non expressément approuvé(e) par la partie
responsable de la conformité est susceptible d'engendrer une annulation du droit
d'utilisation de l'équipement par l'utilisateur.
Le présent équipement a été testé et déclaré conforme aux limitations pour appareils
numériques de classe B, aux termes de la Section 15 des règlements de la FCC.
Ces limitations sont conçues pour fournir une protection raisonnable contre les
interférences nocives dans un environnement domestique. Cet appareil génère, utilise
et peut émettre de l'énergie RF (radiofréquence) et peut, en cas d'installation ou
d'utilisation non conforme aux instructions, engendrer des interférences nuisibles au
niveau des communications radio. Rien ne garantit toutefois l'absence d'interférences
dans le cadre d'une installation particulière.
Si cet équipement produit des interférences perturbant la réception de la radio
ou de la télévision (ce que vous pouvez déterminer en éteignant et en allumant
l'équipement), nous vous recommandons d'essayer d'éliminer les interférences d'une
des façons suivantes:
−Réorientez ou déplacez l'antenne de réception.
−Augmentez l'espacement entre l'équipement et le récepteur.
−Branchez l'appareil sur une prise de courant située sur un circuit différent de celui
sur lequel le récepteur est branché.
−Consultez votre fournisseur ou un technicien radio/TV expérimenté.
19
Français
À propos de votre produit

Cet équipement est conforme aux limitations prévues par la FCC concernant
l'exposition aux radiations dans le cadre d'un environnement d'accès libre. Le
présent équipement doit être installé et utilisé en ménageant une distance d'au

installé au même endroit qu'une autre antenne ou qu’un autre émetteur, ou être utilisé
conjointement à une autre antenne ou à un autre émetteur.
Déclaration d'Industrie Canada (IC)
Le présent appareil contient des émetteurs/récepteurs exempts de licence conformes au
Cahier des charges sur les normes radioélectriques (Radio Standard Specifications,
RSS) relatives aux appareils avec exemption de licence d'ISED Canada. La
fonctionnement est assujetti aux deux conditions suivantes: (1) Le présent appareil
ne doit pas causer d'interférences. (2) Le présent appareil doit accepter toutes les
interférences, y compris celles susceptibles de provoquer un fonctionnement non
souhaité de l'appareil.
Cet équipement est conforme aux limitations prévues par la Section 102 des

d'accès libre. Le présent équipement doit être installé et utilisé en ménageant une

20
Français
À propos de votre produit
