Installation Manual
Fish Finder Power Amplifier
Model DI-FFAMP
A Word to the Owner of the DI-FFAMP
Congraturations on your choice of the FURUNO DI-FFAMP Fish Finder Power Amplifier. The DI-
FFAMP is a power amplifier designed for use with the internal fish finder of the TZtouch3 (TZT12F/
16F/19F) multi function display. Please carefully read and follow the recommended procedures
for installation and maintenance. Thank you for considering and purchasing FURUNO.
Operational cautions
• A separate power supply is required. Take the power from the ship's mains via the ship's switchboard.
• The DI-FFAMP is not turned off when the multi function display is powered off. The power amp's standby
power is 6.2 W, so turn it off when it is not in use.
• Bottom Discrimination, RezBoost and ACCU-FISH are disabled when the power amp is in use.
• The amp can be used with two in-hull transducers, R599LM/LH and R111LH. Do not transmit with the
transducer out of water, to prevent damage to the transducer.
• Use the multi function display to change the program version of the power amp. Contact FURUNO for
information on how to upgrade program version.
Safety Instructions
The installer must read the safety instructions before attempting to install the equipment.
CAUTION
Observe the following compass safe
distance to prevent interference to a
magnetic compass:
Standard compass Steering compass
0.3 m 0.3 m
Do not disassemble or modify the
equipment.
Fire, electrical shock or serious injury
can result.
Use the proper fuse.
Use of a wrong fuse can damage the
equipment and may cause fire.
WARNING
WARNING
Warning, Caution
Indicates a potentially hazardous situation which, if not avoided,
could result in death or serious injury.
Indicates a potentially hazardous situation which, if not avoided,
could result in minor or moderate injury.
CAUTION
Prohibitive Action Mandatory Action
12VDC 24VDC
15 A 10 A
Pub. No. IMC-45121-A
(2002, TAYA) DI-FFAMP 00019714810
Equipment list
Option
Installation
Select the mounting location considering the following points.
• Locate the unit away from areas subject to water splash.
• Select a location that is well ventilated.
• Observe the compass safe distances shown on page 1.
•Laeve the sufficient service clearance around the unit.
Procedure
1. Drill four pilot holes in the bulkhead (or tabletop) for the self-tapping screws.
2. Screw four self-tapping screws (5x20) into the pilot holes, leave 5 mm protruding.
3. Set unit onto the screws, then tightly fasten the screws to fix the unit in place.
NOTE: For mounting on a bulkhead, the connectors must face downword.
Name Type Code No. Qty Remark
Fish Finder Power Amplifier DI-FFAMP - 1
Installation Materials CP02-09600 000-037-176 1 Cable assy. (3 pcs), EMI
core, Fuses (10A/15A),
Self-tapping screws
Name Type Code No. Qty Remark
Booster Box BT-5-1 000-012-520 1 For 5 kW(10 kW) trans-
ducer (single/dual)
BT-5-2 000-012-521
Transducer cable
(For BT-5)
NCS-2RNCTSB 001-247-169 3m
001-247-170 20m
001-247-171 50m
001-247-172 100m
Tabletop mount
Bulkhead mount
OK NO
2
Wiring
Wiring Outline
The figure below shows general connection for the DI-FFAMP. Refer to the interconnection dia-
gram for details.
Procedure
1. Unfasten six screws to remove the cover.
2. Fabricate the transducer cable(s) as shown below.
Fabricate the cables for both the high and low frequencies. For a CHIRP transducer, fabricate the ID
signal cores for both the high and low frequencies.
3. Unfasten the seal nut on the cable entry for transducer cable.
4. Pass the seal nut, claw and seal onto the transducer cable, in that order.
5. Push the seal assembly into the seal nut, then tighten the super gland.
㻲㼕㼞㼟㼠㻌㼒㼞㼑㼝㼡㼑㼚㼏㼥㻌
㼛㼞㻌㻯㻴㻵㻾㻼㻌
㼠㼞㼍㼚㼟㼐㼡㼏㼑㼞
㻹㼡㼘㼠㼕㻌㻲㼡㼚㼏㼠㼕㼛㼚㻌
㻰㼕㼟㼜㼘㼍㼥㻌㻔㼄㻰㻾㻕
Multi Function
Display (COM)
㻿㼑㼏㼛㼚㼐㻌
㼒㼞㼑㼝㼡㼑㼚㼏㼥㻌
㼠㼞㼍㼚㼟㼐㼡㼏㼑㼞
Ext. KP
Ground wire
Source
6
6
150150
150150
3030 3030
Braided shield Braided shield
Drain wire
CHIRP transducer cableSingle frequency transducer cable
Core
Sheath
Wrap the shield onto the sheath.
Vinyl tape
Clamp here.
Clamp here.
Seal assembly
Seal assembly
Seal
Seal
Claw
Claw
Seal nut
Seal nut
3
6. Remove the WAGO connectors from PCB, then attach the transducer cable to the connector.
7. Clamp the braided shield with a cable clamp.
8. Attach the WAGO connector to the PCB.
9. Fasten the seal nut to fix the transducer cable.
The torque shall be 2.0 Nm and the gap between the seal nut and the super gland shall be approx. 3
mm.
10.Fabricate the external KP signal cable as shown below. (core size 0.75 sq, outer dia 7.6 approx)
11.Pass the cable through the seal nut and seal assembly, like you did with the transducer cable.
12.Push the seal assembly into the seal nut, then tighten the super gland.
13. Tighten the seal nut to fasten the cable. The torque shall be 2.0 Nm and the gap between the seal nut
and the super gland shall be approx. 3 mm.
14. Attach the WAGO connctors to the PCB.
15. Reattach the cover and fasten the screws to fix the cover.
Power cable (FRU-3P-FF-A002M-050C, 2m) and signal cables from Multi Function Diaplay (FRU-
F12F12-050C, 5m and FRU-F7F7-050C, 5m) should be connected with their attached connectors.
NOTE: Attach the EMC core to the power cable near the super
gland to prevent noise.
Attach the ground wire (IV-1.25sq, local supply) to the ground ter-
minal with a crimp-on lug (M3, local supply) to prevent interfer-
ence.
Procedure
1. Twist core.
2. Insert terminal opener and push.
3. Insert a core into hole.
4. Release the terminal opener.
5. Pull the core to confirm it is
correctly inserted.
Push
Terminal
opener
WAGO
Connector
Core
Twist
KP
Transducer cable
LF HF
KP
ID
HFLF
XDR
CHIRP transducer
For CHIRP
transducer
For two sets of
single frequency
transducers
KP signal cable
KP signal cable
To Multi Function Display
ID
HFLF
XDR
Terminal opener
SourceSource
㻯㼘㼍㼙㼜㻌㼠㼔㼑㻌
㼟㼔㼕㼑㼘㼐 㻯㼘㼍㼙㼜㻌㼠㼔㼑㻌
㼟㼔㼕㼑㼘㼐
To Multi Function Display
External KP signal cable (local supply)
VCTF0.75x4C
6
150
150
Sheath
φ6.5㻌㼠㼛㻌
φ12.5
POWER cable
EMC core
4
Troubleshooting
The table below provides basic troubleshooting procedures which the user may follow to restore
normal operation. If you cannot restore normal operation, do not check inside unit. Have a FURU-
NO dealer check the equipment.
Specifications
Frequency 26.6 to 242 kHz
Number of channels 2 ch
Output power 3 kW
Power supply 12-24 VDC: 3.2-1.9 A
Environment conditions
Ambient temperature -15°C to +55
Degree of protection IP22
Vibration IEC60945 Ed.4
Problem Reason
Cannot turn on power. • The power cable is disconnected or damaged. Check the
power cable and if it damaged, replace it.
• Check the ship’s mains and check the switch board is
turned off.
• Check the fuse on the power cable. If the fuse has blown,
find the cause then replace it.
No echo appears but fixed
range scale appears.
• The sensor cable is disconnected or damaged. Check the
cable and reconnect or replace it as necessary.
Sensitivity is low. • Gain setting is too low. Raise the gain.
• Marine life is adhering to the transduser face. Clean the
transducer face.
• Vessel is in heavily sedimented water.
5
11/Nov/2019 H.MAKI
D-1
%
$
'
&
1$0(
7,7/(
NJ
0$66
':*1R
6&$/(
$33529('
&+(&.('
'5$:1
5()1R
,17(5&211(&7,21',$*5$0
7<$0$6$.,
',))$03
),6+),1'(532:(5$03/,),(5
+0$.,
;'5B&+B6+,(/'
;'5B&+B6+,(/'
7'B,'
7(03
7(039
9
63'97'B,'967B6+,(/'
7;8B7'$
7;8B7'%
7;8B5'+
7;8B5'&
*1'
),6+),1'(532:(5$03
',))$03
32:(5
'&
5('࢝
$9
$9
58%
5(&7,),(5
ᩚὶჾ
9$&
ȭ+]
'3<&
127(
6+,3<$5'6833/<
237,21
9'&
)583))$0P
9&7)9LQ\O&DEW\UHFRUG
)58))&P
)58))&P
;'5B&+B6+,(/'
;'5B&+B6+,(/'
7'B,'
63'
7(03
7(039
;'5B&+B3
;'5B&+B0
9
63'97'B,'967B6+,(/'
;'5B&+B3
;'5B&+B0
7;8B7'$
7;8B7'%
7;8B5'+
7;8B5'&
.3,+
.3,&
*1'
08/7,)81&7,21',63/$<
࣐ࣝࢳࣇࣥࢡࢩࣙࣥ
ࢹࢫࣉࣞ
7=7)))
',))$03
;'5
P
P
'&
࢜ %/8
6+,(/'
1&
1&
,9VT
㺏㺓㺃㺚㺹
㺖㺹㺃㺚㺹
%/8:+7
%/.:+7
ࢲ
ࢳࣕ
ࢩࣟ
25*
%51
:+7
࢟<(/
P
7% ;'5B/)
7% ;'5B+)
;'5B/)
;'5B/)
;'B/)B6+,(/'
1&
1&
7% 7'B,'
1&
6+,(/'
;,'
*1'
7(03
%/.ࢡࣟ
࢜ %/8
7% ;'5B+)
1&
1&
7% 7'B,'
1&
6+,(/'
;,'
*1'
7(03
1&
1&
7% ;'5B/)
;'5B/)
;'5B/)
;'B/)B6+,(/'
;'5B+)
;'B+)B6+,(/'
;'5B+)
%/+5+50
%/+5+5
%/+5+5
)
;'5B+)
;'B+)B6+,(/'
;'5B+)
㏦ཷἼჾ
75$16'8&(5
75,*B,1B3
75,*B,1B1
75,*B287B3
75,*B287B1
6+,(/'
1&
1&
7%
0)'B&20
0)'B;'5
(;7B.3
,9VT
&&%
እ㒊.3
(;7(51$/.3
9&7)[&P0$;
&25(VT287(5',$ȭ
63'1&
;'5B&+B3+)
;'5B&+B0+)
;'5B&+B3/)
;'5B&+B0/)
.32+
.32&
30/+/+*
&0/0/+/+*
㏦ཷἼჾ
75$16'8&(5
%5
%)+
%5%+
%%%+
)+
1&
1&
7%
7%
*1'
1&
1&
*1'
7;B1
7;B3
7;B1
7;B3
1&
1&
*1'
1&
1&
*1'
7%
7%
;'5B3
;'5B1
;'5B3
;'5B1
%7%2267(5%2;
ࣈ࣮ࢫࢱ࣮࣎ࢵࢡࢫ
.,9VTP
%/.
5('
%/.
5('
ࢡࣟ
࢝
ࢡࣟ
࢝
㏦ཷἼჾ
75$16'8&(5
P
P
//
N+]
++
N+]
))0
1&651&76%PP
1&651&76%PP
9
9
-DQ
-DQ
29/Jan/2020 H.MAKI
牧宏昌
電子署名者:牧宏昌
DN:cn=牧宏昌, o=古野電気㈱, ou=情技課,
[email protected],c=JP
日付:2020.01.29 10:19:34 +09'00'
S-1
Transducer list
(W)
Output
（kHz）
Frequency
Transducer Hull Material Thru-hull pipe Tank
2k/2k 28/200 28BL-6HR,
200B-8/8B
Steel TFB-7000(2),
TWB-6000(2)
T-693
FRP TWB-1100(2) T-693-F
38/200 38BL-9HR,
200B-8/8B
Steel TFB-7000(2),
TWB-6000(2)
T-693
FRP TWB-1100(2) T-693-F
82/200 82B-35R,
200B-8/8B
Steel TFB-7000(2),
TWB-6000(2)
T-649
FRP TRB-1100(2) T-649-F
88/200 88B-10,
200B-8/8B
Steel TFB-7000(2),
TWB-6000(2)
T-649
FRP TRB-1100(2) T-649-F
3k/2k 107/200 100B-10R,
200B-8/8B
Steel TFB-7000(2),
TWB-6000(2)
T-649
FRP TRB-1100(2) T-694-F
3k/3k 28/38 28BL-12HR,
38BL-15HR
Steel TFB-7000(2),
TWB-6000(2)
T-681
FRP TRB-1100(2) T-681-F
28/50 28BL-12HR,
50BL-12HR
Steel TFB-7000(2),
TWB-6000(2)
T-681
FRP TRB-1100(2) T-681-F
28/88 28BL-12HR,
88F-126H
Steel TFB-7000(2),
TWB-6000(2)
T-682
FRP TRB-1100(2) T-682-F
28/150 28BL-12HR,
150B-12H
Steel TFB-7000(2),
TWB-6000(2)
T-683
FRP TRB-1100(2) T-683-F
38/50 38BL-15HR,
50BL-24HR
Steel TFB-7000(2),
TWB-6000(2)
T-681
FRP TRB-1100(2) T-681-F
2k/2k 38-75/
130-210
PM111LH Steel TFB-7000(1) T-712
FRP TRB-1100(1) T-712-F
3k/2k 28-60/
130-210
CM599LH Steel TFB-7000(1) T-712
FRP TRB-1100(1) T-712-F
28-60/80-130 CM599LM Steel TFB-7001(1) T-712
FRP TRB-1100(1) T-712-F
A-1
*1 Not only 5 kW, but also 10 kW transducers. However 10 kW transducer's output is 3 kW or less
(W)
Output
(kHz）
Frequency
Transducer Hull Material Thru-hull pipe Tank
5k/5k*1
w/BT-5
28/50 28F-38M,
50F-38M
Steel TFB-7000(2),
TWB-6000(2)
T-653
FRP TRB-1100(1) T-653-F
28/50 28F-38M,
50F-38
Steel TFB-7000(2),
TWB-6000(2)
T-653
FRP TRB-1100(1) T-653-F
28F-72,
50F-70
Steel TFB-7000(2),
TWB-6000(2)
T-673
FRP TRB-1100(1) T-673-F
A-2
