FUTURE FIRES PanoramicFX1 User manual

FUTURE FIRES
OPERATING INSTRUCTIONS
PanoramicFX1

CONTENTS
INSTALLATION INSTRUCTIONS
Air Access
Hearth
Gaps bet een the PANORAMICFX1 and flammable materials
Flooring Load-Bearing
Flue Pipe Damper
Connection to the Flue
MODEL PANORAMICFX1
WEIGHT 70 KG
OUTPUT MAX. 8 KWs mean
SPACE HEATING OUTPUT 8 KWs mean
FLUE MASS GAS FLOW 7.6 MEAN
Tests carried out at 12 Pa flue draught (0.048 inches WG) with doors closed
Tests carried out with primar air slider full open and with restriction on secondar air suppl (6mm diameter hole left
open)
OPERATIONAL INSTRUCTIONS
Lighting Preparation
Temperature Control
Fuel to use
Cleaning the glass
Smoke
Maintenance of the PANORAMICFX1
Trouble shooting

INSTALLATION OF YOUR PANORAMICFX1
Before installing your stove, you should check ith a Chimney S eep to ensure that there
is proper ventilation and to identify any possible damage to the chimney that might need
repairing prior to installation. The chimney needs to be free of any obstructions and is
appropriate for the oodburning stove. S eep the chimney. Do a smoke test to check for
draft and gas tightness.
All installations of the PANORAMICFX1 must comply ith relevant Building Regulations
(eg Document J). These are available for do nload at
http:// .planningportal.gov.uk/uploads/br/BR_PDF_ADJ_2002.pdf
All local regulations, including those referring to national and European standards need to be complied with
when installing the appliance.
Air Access
A minimum requirement is that there should be a steady supply of air to the room containing the
stove.
Any air inlet grilles need to be so positioned that they are not liable to blockage
There must be fixed ventilation available.
Refer to the building regs ADJ) which give the requirements for roomheaters of differing outputs.

Hearth
The stove should be installed on a non-combustible hearth. The hearths themselves should be
constructed of suitably robust materials and to appropriate dimensions that in normal use it
prevents fabrics catching fire and people getting burnt.
In the case of the PANORAMICFX1, the hearth should be of 225mm in front of the stove and 150
mm to each side measured from the door of the combustion chamber.
Hearth Installation
Gaps bet een the PANORAMICFX1 and flammable materials
When installing your PANORAMICFX1 woodburning stove, a minimum space of 250mm at the
side and a minimum of 400mm at the rear needs to be allowed between the stove and any
inflammable materials.
Any walls close to the stove should naturally not be flammable.
There should be a gap between a flue pipe that is not insulated and anything flammable. This
gap should be a minimum of 3 x the outside diameter of the flue pipe 375mm for 5” single wall
flue pipe), or 1.5 x the flue diameter 375mm for 5” single wall flue pipe) to non combustible
surface.
Flooring Load-Bearing
Prior to the installation of the PANORAMICFX1, investigation must be made to make sure that
the floor can stand the weight of the stove and ancilliaries. The weight of the stove is xxxxxxxx
Flue Pipe Damper
If the chimney has a strong updraft, then it should be fitted with a flue pipe damper or draft
stabilizers, to regulate draft.
This must always allow for a 20% opening.
Connection to the Flue
The PANORAMICFX1 has a connection at the rear and top.
The flue connections need to be sealed with fire cement or equivalent. The flue blanking plug
should be positioned over the unused outlet.
The PANORAMICFX1 is not suitable for a shared flue

The flue gas temperature directly downstream of the flue spigot/socket in °C, with closed
firedoors), under nominal heat output conditions is 261Degrees Centigrade
There is a need to provide access for cleaning the appliance, the flue gas connector and the
chimney flue.
A register plate
This is the plate used to seal off the throat of the fireplace and has a
hole for the flue pipe, access for sweeping and, if required, a bracket to support the flue
pipe.
The 5” flue pipe needed to go from the stove to the register plate.
Prior to using the product the installation must be approved by a qualified person.
Instructions for mounting, installation and use are enclosed with the product. The
installation may only be used once it has been inspected and approved.

OPERATING INSTRUCTIONS
All local regulations, including those referring to national and European standards need
to be complied with when installing the appliance
Lighting Preparation
It is recommended that windows and doors are opened when lighting the stove for the first time.
Ensure that firebricks and other internal components are in position and that all packaging has
been removed.
The process for lighting the stove is as follows:
a) Ensure that the bottom air control is open fully-
b) Put some paper/ne spaper at the back/bottom of the stove. Place some small pieces of
ood on top of the paper and larger pieces on top of this. When ready, light the paper and
ensure that the door is fully closed and locked. Do not try to run the PANORAMICFX1 ith
the door ajar.
c) Once the ood is fully lit, then bigger pieces of ood can be added, as required.
d) When the fire is burning ell, then regulate the fire ith the bottom air control. Do not
try to put in too much ood at the start. Aim for a small hot fire. If a large piece is added,
increase the top vent to compensate.
Warnings
Keep the door closed except during ignition, refuelling and removal of residue material.
All parts of the appliance, especially the external surfaces, will be hot to touch when in operation and due
care will need to be taken
Do not make any unauthorised modification of the appliance
The use of only replacement parts recommended by the manufacturer
In case of a chimney fire take appropriate action, including:
In the event of a chimney fire occurring:
• Dial 999 and ask for the Fire Service there is no charge)
• Close down the ventilation as much as possible.
• Move furniture & rugs away from the fireplace and remove any nearby ornaments.
• Feel the chimney breast in other rooms for signs of heat.
• If a wall is becoming hot, move furniture away.
• Ensure that access to your attic or roof space is available for the Fire Service as they will
want to thoroughly check this area for signs of possible fire spread.
The PANORAMICFX1 appliance is not suitable for installation in a shared flue system
The appliance is capable of intermittent operation only .

Temperature Control
The temperature that your PANORAMICFX1 burns at can significantly impact on it’s
performance.
For example, the most efficient temperature for your stove to burn at is 115 °C - 245°C. Below
this level, may result in the inefficient burning of the fuel and could start to build up residue in the
chimney and on the glass door at the front. Above this temperature and the heat may cause
damage to the PANORAMICFX1 and potentially cause a fire hazard with residue in the chimney.
We would recommend the purchase of a wood stove thermometer to ensure that these issues are
monitored and addressed.
8kW output is achieved with the primary air fully open and secondary air at ~ 20% open
assuming that you fit a control to the secondary air)
Fuel to use
As with other wood burning stoves, seasoned wood needs to be used in the PANORAMICFX1.
This is wood that has been dried for at least 6-12 months. It should be cut to size and stacked
ideally under cover with gaps at the side to allow for wind/drying air.
Cleaning the glass
The glass should be cleaned/wiped with a paper towel ideally after each fire, to avoid residue
building up.
Smoke
Wood can release pollutants into the atmosphere when poor burning techniques are used. The
hazards include smoke and carbon monoxide.
Ventilation
A minimum requirement is that there should be a steady supply of air to the room containing the
stove.
Any air inlet grilles need to be so positioned that they are not liable to blockage
There must be fixed ventilation available.
Refer to the building regs ADJ) which give the requirements for roomheaters of differing outputs.
There should be adequate provision of combustion and ventilation air and air intake grilles supplying
combustion air, should be kept free from blockage;
Smoke consists of particles of unburned wood which form as a result of incomplete combustion. It
contains harmful pollutants that can trigger coughs, runny noses, headaches and eye and throat
irritation. Unburned fuel can also be deposited as creosote in the chimney, providing the potential
for a chimney fire. Smoke can also contribute to smog which is carcinogenic.
Carbon monoxide CO) is generated wherever combustion of a carbon based fuel occurs so that
all gas, oil, coal and wood boilers as well as wood burning stoves have the potential to produce
dangerous levels of CO gas if installed or operated incorrectly.
The following good practice is suggested:
• Burn small, hot fires - they produce much less smoke than ones that are left to smoulder.

• Burn seasoned wood. This is wood which has been allowed to try over at least one summer
season. Green wood is a major culprit in the creation of creosote.
• Burn logs that are 10 -15 cm 4-6 inches) in diameter. Fires burn better with more surface
area exposed to the flame.
• Never burn rubbish, plastics, cardboard, glossy paper or polystyrene.
• Never burn wood that has been taken from salt water. Chlorine combines with the smoke to
produce dioxins and furans, which are dangerous carcinogens.
• Never burn treated or painted wood, particulate-board or plywood.
• Store wood outside, off the ground and covered. Bringing green wood indoors to dry can
promote the growth of allergy-causing mould spores circulating indoors.
• Have the PANORAMICFX1 installed by a professional and have it inspected and cleaned
every year.
• Make sure the fire is getting enough air - check that the air inlet is open wide enough to keep
the fire burning briskly, resulting in complete combustion and less smoke.
• never use liquid fuels
• Occasional adverse weather conditions may cause a down draught during which it would be best not to
use the appliance
Malfunction
In case of malfunction eg overheating, reduce air supply if practical, do not open the door, and keep a safe
distance.
Nb
Running the stove with only the bottom air control open will provide oxygen for the wood to
burn on the fire base but will not provide air for the volatile gases above the fire bed to
combust, resulting in a smoky inefficient fire.
The stove is not suitable for burning solid fuel ie. briquettes\ coal\coke\smokeless fuel.
Note: The above notes on operating your stove should be taken as guidelines only. Each
stove installation is unique and the operation of each stove is subject to many variables
including; the fuel used, the size of the room, chimney performance, ventilation. As
such, the best operation of your stove ill be learned through experience only.
Maintenance of the PANORAMICFX1
Maintenance of the PANORAMICFX1 should only be undertaken when the stove is completely
cold.
Regular Maintenance Requirements
• External vacuuming of the stove/Clean with a soft brush should be undertaken every day if
the stove is in regular use Do not use any forms of chemical cleaning as this will damage the
PANORAMICFX1).
• The chimney should be swept at least once a year-this should include an inspection of the
firebricks, handles, seals. There is also a need for regular cleaning of the appliance, of the flue gas
connector and highlighting the need to check for blockage prior to re-lighting after a prolonged shut
down period
• Ashes should only be removed when the fire is out and has been left to cool completely. A
thin layer of ash can be left in the bottom of the stove, as this can help to protect the firebrick
underneath and help in the combustion process.

• The internal firebricks may need replacing overtime, but only when they have deteriorated to
the point of failing to insulate properly.
• If the glass is blackened with soot, it can easily be cleaned using one of the many specialist
stove glass cleaning products available from stove shops.
Trouble shooting
Symp
tom
Action
Residue on the Glass resulting in Darkening
• Only use seasoned dry wood
• Ensure that the top air vent is being used
once the fire is operating
Run the stove at a higher temperature-bearing
in mind suggested operating conditions
Smoke in the room
hen opening door
•
Only open the door when there are low
flames
• Check chimney
• Make sure that flue gases exit at the rear of
the stove
High
combustion
levels
• Check and replace seals inc door) if
required
•
Consult chimney sweep
Warranty
This stove has a two year guarantee covering any defects arising from faulty
workmanship during normal use of the stove.
The guarantee does not cover parts deemed to be replaceable in the normal usage of the
stove. These include: Glass & Door rope seal & Fire Brick linings
