G-Sau Trident 101 User manual
Trident 101
Wireless Spy Fishing Camera
User Manual
1
Product Package Content
After the product package is opened, please check whether or
not all items in the package are intact and complete.
In case of any shortage or damage of items, please contact the
dealer immediately.
● Wireless Spy Fishing Camera---X 1
● Wireless Spy Fishing Camera (Receiver)---X 1
● 18650 Lithium Battery---X 1
2
Product Feature Introduction
Wireless Spy Fishing Camera
(Referred to as TX)
Power Key
Camera Lens
Prior to recording, please ensure that the lens surface
is clean.
Press this key to turn the device on/off.
Charger Waterproof Protective Cap (USB Type C)
Charging socket is inside the device and provides a charging
function when the 18650 battery is installed.
During use, please do not damage the protective cap
to ensure that the device waterproof function.
Power Indicator
Constant Green Light:
Device is turned on and is under the standby state.
3
Antenna Float Unit
During video recording, please prevent this part from being
shielded by foreign objects that may affect the antenna
performance.
RF Connection State Indicator
Constant Green Light : connection is proper.
(Automatic Connection)
Flickering Green Light : connection is poor.
Battery Charging Indicator
Rotate to open the rear cover for replacement of the 18650
lithium battery.
Constant Red Light : charging is in process.
Constant Green Light : charging is complete.
Rear Cover
4
Battery Installation
Rotate to open rear cover and push antenna float unit
rearward. Confirm the battery positive and negative electrode
directions and place the battery into the device.
Align with the positioning structure and fasten back to the ❽ ❼
device. Please be sure to fasten the device firmly to ensure the
waterproof function.
* Attention:
this is the waterproof silicone ring
Please do not damage or remove
the waterproof silicon seal ring to
prevent any impact on the device
waterproof function.
18650 Lithium Battery
* Attention: please do not damage or remove the waterproof silicon seal ring
to prevent any impact on the device waterproof function*
5
Product Feature Introduction
Wireless Spy Fishing Camera (Receiver)
(Referred to as RX)
RF Connection State Indicator
Power Indicator
Constant Blue Light : Device is turned on and is under the
standby state.
Constant Blue Light : Connection is proper.
(Automatic Connection).
Flickering Blue Light : Connection is poor.
USB Type C Port
Connect to transmission cable for power supply and video
transmission.
Power Key
Toggle this key to turn the device on/off.
6
Memory Card Slot
Please insert users own Micro SD memory card.
(Maximum of 128GB Supported)
HDMI Port
Connect to transmission cable . (video transmission).
Touch Pad
For monitor viewing and operation of various functions.
Antenna Device
The antenna device is professional assembly, users can
not change antenna by yourself.
External Antenna
Receive image signals transmitted from TX end
Touch Indicator
Flashing Red Light : Single click for more than 0.5 second
and then release to feed back the
operating action.
*NOTE:
7
Insert Memory Card
Wireless Spy Fishing Camera (Receiver) - RX
Prior to the use of the device,
it is required to insert a memory card
in order to use the video
recording and photo
shooting function.
Please hold the edge of Micro SD card and please be aware of the
label direction. Insert the card with the connector end toward
the slot until the memory card is secured inside the slot.
To remove the card, grab the edge of the card, and pull the card
out.
HDMI
Micro SD
Type C ON OFF
HDMI
Micro SD
Type C ON OFF
Note:
․ Prior to the use of the device, please format the memory card rst in order to prevent any
system instability due to le not recorded by the present device.
․ When the device is under the turn-on state, please do not remove the memory card directly.
To remove the memory card, it is suggested that you turn off the device rst, in order to
prevent damage of the le recorded in the memory card.
․ Our company's product does not guarantee the compatibility with all types of Micro SD
memory cards.
․In case of any failure of memory card, please contact the memory card manufacturer.
․Please do not place the memory card at humid or moist area, such as contact with high
moisture object or corrosive object.
Please prevent placement at high temperature area, such as area with direct sunlight
exposure or area adjacent to device with heating function.
․Please check the memory card periodically to determine if there is a need to perform
formatting or replacement with a new card.
Attention: Before inserting a new memory card into the device
for the first time, it is necessary to complete the formatting first,
in order to ensure the normal function use.
8
Hardware Connection
Wireless Spy Fishing Camera (Receiver) - RX
Display Monitor
Method 1:
Connect to TV Monitor
Conrm that all connection cables are
connected completely.
Turn on device power and RX unit and TX unit
are able to per form pairing and
connection automatically.
Power Bank
(Purchase by yourself )
Device-RX
HDMI
Cable
Device-TX
Turn on the power of
Device-RX ,and wait for
the indicator to light up.
Turn on the power of Device-TX
and wait.
Turn on the monitor and the screen display
the shooting range of the camera.
9
Hardware Connection
Smart Phone
Method 2: Connect to Mobile Phone or Tablet
(Presently, only Android system is supported.)
Conrm that all connection cables
are connected completely.
Turn on device power and RX unit and TX unit
are able to per form pairing and
connection automatically.
Tablet
OGT
Adapter
Power
Transmission
Cable
OR
OR
Open the device APP and the monitor
screen displays the shooting range
of the camera.
Turn on the power of
Device-RX ,and wait
for the indicator to light up.
Device-TX
Turn on the power of Device-TX
and wait.
Device-RX
Power
Transmission
Cable
OGT Adapter
(Purchase by yourself )
10
Hardware Connection
Method 3: Connect to Mobile Phone or Tablet
(Type-Y Male/Female Connection Cable)
Conrm that all connection cables
are connected completely.
Turn on device power and RX unit and TX unit
are able to per form pairing and
connection automatically.
Power Transmission
Cable
Open the device APP and the monitor screen
displays the shooting range of the camera.
Micro USB
Connector
Adapter
(Purchase by
yourself )
USB A
Connector
Type-Y Male/Female
Connection Cable
When the device is for long-term outdoor use, to prevent insufficient power
of the mobile phone or tablet,
it is suggested to use a Type-Y Male/Female Connection Cable (optional) for
connection to a mobile power source (optional).
Tablet or
Smart Phone OGT Adapter
(Purchase by yourself )
Power Bank
(Purchase by yourself )
Device-RX
Turn on the power of
Device-RX ,and wait for
the indicator to light up.
Device-TX
Turn on the power of Device-TX
and wait.
11
Hardware Operations
Wireless Spy Fishing Camera - TX
Power Off
Long press the power key for 3~5 seconds, the indicator goes off
and the device is turned off.
Charging
The device uses 18650 lithium battery for the supply of power.
Prior to the use under standby state, please charge the battery
completely.
When a transformer is used for charging, please ensure that
there is no water on the device surface and it is under a dry
environment.
1. Open the waterproof cap on the device.
Please use a power transformer (5V DC/2.0A, not provided as
an accessory).
2. Use a conventional USB Type-C
transmission cable.
Connect one end to the device
Type-C port and the other end
to the power transformer in
order to perform charging.
Touch the power key gently, the indicator is lit up and the device
is ready for operations.
Power On
12
Hardware Interface Operations
Wireless Spy Fishing Camera (Receiver) - RX
Zoom-in Key-TX unit camera lens zoom-in adjustment
Fill Light Key-TX unit fill light brightness adjustment
Press this single key for more than 0.5 second and then
release the key, and the red light is lit up.
Standby State, Light OFF>25%>50%>75%>100%>OFF
Press this single key for more than 0.5 second and then
release the key, and the red light is lit up.
Standby state, Camera Lens 1x > 1.5x > 2x > 1x
Photo Key
Fill Light Key
Zoom-in Key
Photo Key
Video Rec Key
Press this single key for more than 0.5 second and then
release the key, and the red light is lit up.
Photos are saved in the SD card.
(MicroSD must be inserted into the RX unit to take photos.)
(Note: During operations, only one single key can be clicked on.
When multiple keys are pressed at the same time, device error may occur*)
13
Screen Interface Introduction
User can use the TV Monitor to view the camera screen
directly and the status bar on the top to determine the
TX unit status.
Capture on top right corner ：
indicates the device is now in Photo Shooting Mode.
：indicates the power level of the TX unit.
：indicates the connection quality of the RX unit.
User can also use the Smart phone or Tablet to view
the camera screen directly and to determine the
TX unit status.
Prior to use a smart phone or tablet computer to view the
camera screen, please go to Google Play store
to download the USB Camera App (this App is a freeware)
Video Rec Key
Press this single key for more than 0.5 second and then
release the key, and the red light is lit up.
Videos are saved in the SD card.
(MicroSD must be inserted into the RX unit to record videos.)
REC on top right corner ：
indicates the device is now in Video Recording Mode.
To connect the device for the first time, please simply follow
the App instructions to complete initial setting.
Once connection is made, for subsequent connections in the
future, the device will be connected automatically.
14
Fill Light Key
Zoom-in Key
After connecting the RX unit to a monitor equipment, power on
and connecting the screen to the monitor, user can use two
fingers to press the two keys of Fill Light Key and Zoom-in ❶ ❷
Key simultaneously for approximately 5 seconds.
The monitor screen then displays SD Card Format and the
format is complete.
Memory Card Formatting
Wireless Spy Fishing Camera (Receiver) - RX
Attention: Before inserting a new memory card into the device
for the first time, it is necessary to complete the formatting
first, in order to ensure the normal function use.
15
FCC Statement:
Federal Communication Commission Interference Statement
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a particular installation.
If this equipment does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to correct the interference
by one of the following measures:
● Reorient or relocate the receiving antenna.
● Increase the separation between the equipment and receiver.
● Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
● Consult the dealer or an experienced radio/TV technician for help.
FCC Caution: Any changes or modifications not expressly approved by the party responsible for
compliance could void the users authority to operate this equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) This device may not cause harmful interference, and (2) this device must
accept any interference received, including interference that may cause undesired operation.
For product available in the USA/Canada market, only channel 1~11 can be operated.
Selection of other channels is not possible.
This device and its antennas(s) must not be co-located or operating in conjunction with any
other antenna or transmitter except in accordance with FCC multi-transmitter product
procedures.
IMPORTANT NOTE:
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum distance 20cm
between the radiator & your body.
Product Info.
Wireless Spy Fishing Camera
Product Name : Wireless Spy Fishing Camera
Model No. : Trident 101
FCC ID: 2A2CB-0000011000101
Wireless Spy Fishing camera (Receiver)
Product Name :Wireless Spy Fishing Camera (Receiver)
Model No. : Trident 101
FCC ID : 2A2CB-0000011000102
Safety Regulations
16
We thank you for choosing Trident 101 product.
From the date of your purchase, you are entitled to warranty services
satisfying the following conditions:
Within seven days after the purchase of the device, in case you discover any
defect or failure, you may choose to return or exchange the device.
After seven days of your purchase, you are entitled to a warranty period of
twelve months starting from the date of purchase indicated on the invoice or
warranty sticker.
Warranty card number is indicated on the product label sticker attached to
the top of the box.
Consumer is required to preserve the purchase certificate or invoice properly
to protect personal rights and interests.
In case where no relevant certificate can be provided, the consumer may not
be entitled to enjoy the warranty benefit.
Non-warranty Scope
● Damage due to natural disaster (earthquake or lightning strike, etc.),
improper storage, collision or compression under heavy load, etc.
● Counterfeit of order number, warranty card number, invoice or damaged
warranty card.
● Repair or modification not made by the Company or cooperating dealer
stores.
● Product damage due to improper use of water immersion,
lost or compression.
● Product not sold by the Company or cooperating dealer.
Technical Support
If you have any questions on the use of the product, please contact our
telephone service direct line, or please go to the FAQ / Online Solution of the
G-Sau website.
Service Direct Line: +886-2-8771-0006
Online Solution: www.g-sau.com
Product Warranty
17
Product Warranty
Repair Service and Warranty Clause
G-sau guarantees that all products have been tested completely
in order to prevent defects of raw material and manufacturing
process. In addition, all products comply with the specification
announced.
For the product purchased by you is within the warranty period,
in case of any defect or damage under the condition or normal
use, you may contact the G-Sau dealer of your original purchase
in order to request the dealer of your original purchase to send
your product back to GSau for repair.
CCXXxxLPyyyZzW
Dealer Seal
吉邵股份有限公司 G-Sau Co., Ltd.
台灣總公司
Headquarter
1 0 5 4 0 台 北 市 松 山 區 南 京 東 路 三 段 3 4 6 - 4 號6樓6 0 2 - 2
Rm. 602-2, 6F., No. 346-4, Sec. 3, Nanjing E. Rd., Songshan Dist., Taipei City , Taiwan (R.O.C.)
TEL：886-2-87710006：
FAX：：
WEB：www.g-sau.com：
E-mal：：
Table of contents
