Gaggenau DF290760 User manual

1
IMPORTANT
• The dishwasher drain hose must be installed
with a portion of it at least 20” (508mm) off the
cabinet floor; otherwise the dishwasher may not
drain properly.
• This dishwasher is intended for residential use
only, and should not be used in commercial
food service establishments.
• NEW INSTALLATION - If the dishwasher is a
new installation, most of the work must be done
before the dishwasher is moved into place.
• REPLACEMENT - If the dishwasher is
replacing another dishwasher, check
the existing dishwasher connections for
compatibility with the new dishwasher, and
replace parts as necessary.
• This appliance has been found to be in
compliance with CAN/CSA-C22.2 No. 167/UL
749. It is the responsibility of the owner and the
installer to determine if additional requirements
and standards apply in specific installations.
Inspect the Dishwasher
After unpacking the dishwasher and prior to
installation, thoroughly inspect the dishwasher for
possible freight or cosmetic damage. Report any
damage immediately. Cosmetic defects must be
reported within 30 days of installation.
NOTE: Do not discard any bags or items that
come with the original package until after the entire
installation has been completed.
The dishwasher must be installed by a qualified
service technician or installer.
• In addition to these instructions, the dishwasher
shall be installed to meet all electrical and
plumbing codes and ordinances (both national
and local).
Read these installation instructions completely
and follow them carefully. They will save you time
and effort and help to ensure safety and optimum
dishwasher performance.
To avoid possible injury or property damage,
OBSERVE ALL WARNINGS AND CAUTIONS.
These instructions are intended for use by
qualified installers only.
Important Safety Instructions
If the dishwasher is installed in a location
that experiences freezing temperatures (e.g.,
in a holiday home), you must drain all the
water from the dishwasher’s interior. Water
system ruptures that occur as a result of
freezing are NOT COVERED BY WARRANTY.
WARNING
Dishwasher Installation Instructions
English/French/Spanish
IMPORTANT INSTRUCTIONS ............................... 1
Tools Needed .......................................................... 2
Materials Needed ................................................... 2
Materials Supplied .................................................. 3
Enclosure Preparation ............................................ 5
Electrical Preparation ............................................. 6
Plumbing Preparation ..........................................7-8
Dishwasher Preparation ......................................8-9
Door Panel Installation ......................................... 10
Table of Contents
Read these Installation Instructions completely and follow them carefully.
Placing the Dishwasher ...................................10-11
Securing the Dishwasher ...................................... 11
Drain Hose Connection ...................................11-12
Hot Water Connection .....................................12-13
Electrical Connection .......................................13-14
Door Tension Adjustment ...................................... 14
Base and Toe Panel .............................................. 15
Final Instructions .................................................. 15
Customer Service ................................................. 16
9000161666 REV A · 03/06

2
TOOLS NEEDED
Hammer Hole Saw Tape Measure
Slot Screwdriver Phillips Screwdriver T-15 Screwdriver
Wire Cutter Wire Stripper
Drill Level
Adjustable Wrench
Electrical Supply Cable - Minimum #14 AWG, 2 conductor, 1 ground, insulated
copper conductors rated 75°C or higher.
Hot Water Supply Line - Minimum 3/8” O.D. copper tubing or metal braided
dishwasher supply line.
Shut-off valve and fittings appropriate for hot water supply line (copper tubing/
compression fitting, or braided hose).
90° elbow with 3/8” N.P.T. male threads on one leg, and sized to fit your water supply
line (copper tubing/compression fitting, or braided hose) on the other leg.
Teflon brand tape or other pipe thread compound to seal plumbing connections.
UL listed conduit connector or strain relief.
MATERIALS NEEDED
(Additional materials may be required to comply with local codes.)
Tools and Materials Needed

3
Dishwasher Installation Kit
A Dishwasher Installation Kit is provided with each
dishwasher and includes:
H Toe Panel Screws (2 black machine screws)
Note: These screws are included, but not used on
models with the Toe Panel Installation Kit.
I Counter Top Mounting Brackets (2 “L” shaped metal
brackets)
J Mounting Bracket Screws (2 silver wood screws)
K Rubber Drain Hose Adaptor (1 black rubber tube)
L Hose Clamps (1 spring clamp to use to attach the
rubber adaptor to the Drain Hose and 1 screw
clamp to attach the rubber adaptor to the
plumbing)
M Wire Nuts (3 for electrical connection)
N Electrical Junction Box Screws (1 silver
machine screw)
O Leg Leveler Locking Screws (2 silver coarse
threaded screws)
P Toe Panel Mounting Bracket (2 metal brackets)
Q Toe Panel Mounting Bracket Screws (2 silver
machine screws)
R 5mm Allen Wrench
S T-15 Torx Tip Wrench
L
K
J
I
H
N
M
O
Q
P
MATERIALS SUPPLIED
Accessory Parts Supplied
Accessory parts for your dishwasher come in one or more plastic bags that are outlined below.
NOTE: Make sure you save all the bags until you have completed your installation.
NOTE: Always use the supplied or recommended hardware.
Materials Supplied
Use and Care Manual Set Bag
A Use and Care Manual Set Bag is provided with
each dishwasher and includes:
A Use & Care Manual
B Quick Reference Guide (select models)
C Extra Tall Item Sprinkler
D Warranty Card
AB
C
F
G
E Installation Instructions Manual
F Integrated Door Mount Template for Custom
Door Panels (select models)
G White Cotton Insulation Strip (select models)
Installation Manual Set Bag
An Installation Instructions Manual Set Bag is
provided with each dishwasher and includes:
E
D
R
S

4
Toe Panel Installation Kit
A Toe Panel Installation Kit is provided on select
models. These models have a special noise reducing
Toe Panel with the following mounting hardware:
Y Toe Panel Screws (2 black screws used to attach
the metal Toe Panel)
Z Plastic Base Access Panel Screws (2 long
screws used to attach the Black plastic Base
Access Panel to the dishwasher.
Note: Screw is not used on units that have
this kit.
Y
Z
Materials Supplied
H
U
T
V
W
Integrated Door Panel Installation Kit
A Door Panel Installation Kit is provided with select
dishwashers that use a custom wood door panel and
includes:
T Spring Tension Screws (2 larger silver machine
screws used to adjust the door springs to
accommodate doors of different weights)
U Door Mounting Brackets (2 metal brackets used
to mount the custom door)
V Door Mounting Bracket Screws (6 silver wood
screws)
W Door Mounting Screws (4 long silver screws
used to attach the door)
X Hook and Loop Fastening Strips (2 adhesive-
backed strips)
X

5
ENCLOSURE PREPARATION
NOTE: This dishwasher is designed to be enclosed on
the top and both sides by standard residential kitchen
cabinetry.
Select a location as close to the sink as possible for
easy access to water supply and drain lines.
For proper dishwasher operation and appearance,
ensure that the enclosure is square and has the
dimensions shown in Figure 1.
If the dishwasher is to be installed in a corner, make
sure that there is adequate clearance to open the door.
See Figure 2.
Figure 1
23-5/8" – 24-1/4" (600–616 mm)
34"
(864mm)
minimum
23-9/16"
(598mm)
90 90
Figure 2
Countertop
Figure 3
3-1/2"
(89mm)
1-5/16"
(33mm)
Enclosure Preparation
Avoid Scalding or Electrical Shock Hazard
Make sure the water supply and electrical supply
are shut off before installation or service.
Avoid Electrical Shock/Fire Hazard
Do not allow the electrical and water supply lines
to touch. Separate channels are provided under
the dishwasher (see page 10).
If the enclosure requires openings for the electrical
supply cable, hot water supply line, and dishwasher
drain hose, place them within the dimensions shown by
the shaded area of Figure 3 to avoid interference with
the dishwasher frame or other components. Make the
openings for the electrical supply cable and hot water
supply line 1” (25.4mm) diameter. Make the opening
for the dishwasher drain hose 1-1/4” (32mm) diameter.
If the openings are made through wood, sand them
smooth. If the openings are made through metal, make
them large enough to accommodate grommets or other
protective sheaths with inside diameters of 1” (25.4mm)
for the electrical supply cable and the hot water supply
line, and 1-1/4” (32mm) for the dishwasher drain hose.
Check clear-
ance between
dishwasher
door and wall
WARNING
WARNING

6
ELECTRICAL PREPARATION
Dishwasher Electrical Rating
stloV ztreH serepmA sttaW
021 06 21 054,1
)xam(
Figure 4
21"
(533mm)
30"
(762mm)
3/8" - 1/2"
(10mm - 13mm)
3" - 4"
(76mm - 102mm)
Figure 5
Electrical Preparation
Avoid Electrical Shock Hazard
Do not work on an energized circuit. Doing
so could result in serious injury or death.
Only qualified electricians should perform
electrical work. Do not attempt any work on the
dishwasher electric supply circuit until you are
certain the circuit is de-energized.
Electrical Supply
The customer has the responsibility of ensuring that the
dishwasher electrical installation is in compliance with
all national and local electrical codes and ordinances.
The dishwasher is designed for an electrical supply of
120V, 60 Hz, AC, connected to a dishwasher-dedicated,
properly grounded electrical circuit with a fuse or breaker
rated for 15 amps. Electrical supply conductors shall be
a minimum #14 AWG copper wire rated at 75°C (167°F)
or higher.
Regardless of where the electrical supply cable enters
the enclosure, position the cable 21” (533mm) from the
enclosure’s left side, as shown in Figure 4. Extend the
cable 30” (762mm) from the enclosure’s back, as shown
in Figure 4.
Remove 3” - 4” (76mm - 102mm) of the cable’s outer
casing, as shown in Figure 5, then remove 3/8” - 1/2”
(10 - 13mm) of insulation from each wire, as shown in
Figure 5.
Avoid Fire Hazard
Make sure electrical work is properly installed.
Only qualified electricians should perform
electrical work.
WARNING
WARNING

7
PLUMBING PREPARATION
14"
(356mm)
Shut off
Valve
Hot Water
Supply
Line
Figure 6
Plumbing Preparation
Avoid Scald Hazard
Do not perform any work on a charged hot water
line. Serious injury could result. Only qualified
plumbers should perform plumbing work. Do not
attempt any work on the dishwasher hot water
supply plumbing until you are certain the hot
water supply is shut off.
Hot Water Supply
The hot water heater should be set to deliver
approximately 120° F (49° C) water to the dishwasher.
Water that is too hot can cause some detergents to lose
effectiveness. Lower water temperatures will increase
run times. The hot water supply pressure must be
between 15 - 145 psi (1 - 10 bar).
Hot Water Supply Plumbing
Install an easily accessible shut-off valve (not supplied)
in the hot water supply line, as shown in Figure 6. All
solder connections must be made before the water
line is connected to the dishwasher’s water inlet valve.
Water may also be supplied to the dishwasher by using
a stainless steel braided hose approved for dishwasher
use. Check with your local plumbing supply sources for
the proper hose and 90° elbow fitting.
NOTE: Regardless of where the hot water supply line
enters the enclosure, position the line 14” (356mm) from
the enclosure’s left side, as shown in Figure 6.
NOTE: Decide whether stainless steel braided hose
approved for dishwasher use or copper tubing will be
used for the hot water supply plumbing, and purchase
the correct type of hot water supply shut-off valve, 90°
elbow, and necessary fittings for the hot water supply
plumbing.
Temperatures required for soldering and
sweating will damage the dishwasher’s base
and water inlet valve. If plumbing lines are to
be soldered or sweated, keep the heat source
at least 6 inches (152.4 mm) away from the
dishwasher’s base and water inlet valve.
WARNING

8
PLUMBING PREPARATION (continued)
Drain Plumbing
Under Sink Drain Connection
If the dishwasher is to drain either directly into the
household drain plumbing or through an air gap, install a
y-branch tailpiece under the sink as shown in Figure 7.
Installing an Air Gap
If local ordinances require an air gap, as shown in
Figure 8, install it according to the manufacturer’s
instructions.
Disposer
Make sure to remove the disposer’s dishwasher drain
connection plug before connecting the dishwasher drain
hose. See Figure 9.
DISHWASHER PREPARATION
Dishwasher preparation involves four tasks:
• Installing the Mounting Brackets
• Removing the Toe Panel
• Installing the 90° elbow fitting
• Junction Box Preparation
Installing the Countertop Mounting Brackets
Figure 7 Figure 8
Figure 9
Plumbing Preparation/ Dishwasher Preparation
Y-branch
Tailpiece
Air Gap
Remove
plug
The dishwasher can be secured into its enclosure in two
ways:
1 Top Mount is used for countertops made of wood
or other materials that can easily drilled. Orient the
mounting brackets as shown in Figure 10, and
position the two small tabs on the mounting brackets
over the two slots on the dishwasher’s front corners.
Push the mounting brackets down firmly to insert the
tabs into the slots.
2 Side Mount is used for countertops made of marble,
granite, or other very hard materials that cannot be
easily drilled. Bend the mounting brackets along
the small holes and in the same direction as the
two small tabs. Orient the mounting brackets as
shown in Figure 11, and position the two small
tabs on the mounting brackets over the two slots on
the dishwasher’s front corners. Push the mounting
brackets down firmly to insert the tabs into the slots.
Before installing the supplied countertop
mounting brackets, decide which method of
securing the dishwasher into its enclosure will be
used. Once the mounting brackets are installed
on the dishwasher, removing them is difficult
and will damage the mounting brackets and the
dishwasher.
Avoid Tip Over Hazard
Do not use the dishwasher until it is completely
installed. When opening the door on an
uninstalled dishwasher, carefully open the door
while supporting the rear of the unit. Failure to
follow this warning can result in serious injury.
WARNING
Figure 10
Figure 11

9
DISHWASHER PREPARATION (continued)
Figure 12
Metal
Toe
Panel
Plastic Base
Access Panel
Dishwasher Preparation
Figure 14 Figure 15

Remove Screw
Figure 13
Junc-
tion
Box
Removing the Toe Panel
Your dishwasher will include either a Metal Toe Panel
or a Plastic Base Access Panel with a Metal Toe Panel
(model dependent).
Method A - Metal Toe Panel
The toe panel is loosely attached with tape. Remove the
tape and pull the toe panel away from the dishwasher.
Set the toe panel aside. It will be reinstalled later.
Method B - Plastic Base Access Panel with Metal Toe
Panel
The plastic base access panel and toe panel are in place
on the dishwasher, but are not attached. Remove the
toe panel first, as shown in Figure 12, then remove the
plastic base access panel, as shown in Figure 12.
When any covers are removed or the dishwasher
is out of the cabinet, electrical power and sharp
edges or points may be exposed.
Installing the 90° Elbow Fitting
NOTE: The 90° elbow fitting is not supplied with the
dishwasher, and must be purchased separately. If the
dishwasher’s hot water supply line is to be copper tubing,
make certain the elbow has a compression fitting.
Apply Teflon tape or other pipe sealant when required.
Orient the hot water supply connection leg of the elbow
toward the channel opening in the dishwasher base. See
Figure 13.
Junction Box Preparation
1 Remove junction box cover (see Figure 14) by
lifting the junction box cover up and off.
2 Remove the strain relief plate by removing the
screw at the back of the junction box, as shown in
Figure 15 and sliding the strain relief plate out.
3 Set the junction box cover, strain relief plate, and
screw aside. They will be re-installed later.
Do not overtighten the 90° elbow. Doing so may
damage the water inlet valve and cause a water
leak.
CAUTION

10
21"
(533mm)
14"
(355mm)
Figure 18
Hot Water Supply Line
and Electrical Supply
Cable Position in
Channels
Door Panel Installation
PLACING THE DISHWASHER
1 Straighten and position the hot water supply line and
the electrical supply cable as shown in Figure 18
so that they will align with their channels under the
dishwasher base.
2 Position the dishwasher close enough to the
enclosure so that you can run the dishwasher drain
hose to the under sink drain connection. Make certain
that the hot water supply line and the electrical supply
cable are in their channels under the dishwasher
base, as shown in Figure 17.
3 Slide the dishwasher into the opening making sure
that the hot water supply line and the electrical supply
cable stay in their proper channels.
4 Make sure the dishwasher is level. Adjust the rear
leveler by turning the center screw at the front of the
dishwasher, as shown in Figure 19a. Turning the
screw clockwise raises the rear of the dishwasher.
Adjust the front levelers by turning them with a
screwdriver, as shown in Figure 19b. Turning the
levelers to the right raises the dishwasher. If additional
height is needed, shims may be added under the
leveler feet.
Figure 17
GLASS DOOR HEIGHT ADJUSTMENT
(model DI291730 only)
The door height on the Gaggenau model DI291730 can
be reduced by approximately 1/2“ in order to have the
dishwasher door bottom align with the cabinetry.
1 Remove the T15 screws on each side of the lower
door as shown in Figure 16 step 1.
2 Reduce the door height by turning the 5mm Allen
head screw at the door bottom as shown in Figure 16
step 2.
3 Secure the lower door with the T15 screws as shown
in Figure 16 step 3.
2
1
3
Figure 16
5 mm
Allen
Torx 15
max. 15

11
SECURING THE DISHWASHER
1 Drive the mounting screws through the holes in the
mounting brackets as shown in Figure 20 for Top or
Side Mount.
2 After the unit is installed in the enclosure, leveled and
secured, lock the two front leg levelers in place by
driving the enclosed leg leveler locking screws into
each screw boss located in front of the levelers. See
Figure 21.
3 Tighten screws until they are flush with the surface of
the bosses.
a
b
Placing the Dishwasher/ Securing the Dishwasher
Figure 20
Top Mount
Side Mount
Figure 19
Leg
Leveler
Locking
Screw
Screw
Boss
Figure 21
Installation of the Rubber Drain Hose
Adaptor
1 Obtain the Rubber Drain Hose Adaptor and the two
hose clamps from the Dishwasher Installation Kit (do
not substitute).
2 On one outside end of the Rubber Drain Hose
Adapter is a raised rib. Insert the dishwasher drain
hose into the end without the raised rib (see Figure
22). Be sure to fully insert the drain hose.
3 Secure the connection with the Spring Clamp (see
Figure 23).
4 Use the Screw Clamp to attach the Rubber Drain
Hose Adaptor to the house plumbing (see Figure 23).
Spring
Clamp
Screw
Clamp
Figure 23
Figure 22
Raised Rib
Rubber Drain Hose Adaptor
(cross section) Dishwasher
Drain Hose
Connects to house-
hold plumbing Insert until drain
hose locks in place
Raised
Rib on
Outside
of Drain
Hose
Adaptor



12
HOT WATER CONNECTION
Avoid Scald Hazard
WARNING
Do not perform any work on a charged hot water
line. Serious injury could result. Only qualified
plumbers should perform plumbing work. Do not
attempt any work on the dishwasher hot water
supply plumbing until you are certain the hot
water supply is shut off.
NOTE: Make certain that the correct 90° elbow fitting
(not supplied) for the hot water supply line has been
purchased and installed on the dishwasher as described
in the Dishwasher Preparation section of this manual.
The hot water supply line may be connected to the
dishwasher in one of two ways:
1 With braided hose.
2 With copper tubing.
Stainless Steel Braided Hose Approved for
Dishwasher Use.
After connections are made turn on the hot water supply
to check for leaks.
NOTE: Braided dishwasher supply hoses can also be
used to extend pre-existing dishwasher water supply
lines.
Figure 26 Figure 27
Figure 24
Drain Hose Connection/Hot Water Connection
Non-Metallic Tie
MIN.
20"
MIN.
20"
Non-Metallic Tie
Connecting the Drain Hose to the
Household Plumbing
The dishwasher drain hose may be connected to the
drain plumbing in one of four ways:
1 Directly to the undersink dishwasher drain connec-
tion, as shown in Figure 24.
2 Directly to a disposer dishwasher drain connection,
as shown in Figure 25.
3 To the undersink dishwasher drain connection
through an air gap, as shown in Figure 26.
4 To a disposer dishwasher drain connection through
an air gap, as shown on Figure 27.
Information on installing air gaps and disposers can
be found in the Plumbing Preparation section of this
manual.
IMPORTANT NOTES:
· If the dishwasher drain hose is to be connected to a
disposer dishwasher drain connection, remove the
plug from the disposer’s dishwasher drain connec-
tion.
· The dishwasher drain hose must have one place
along its length that is securely attached 20 inches
above the cabinet floor.
· The drain hose length can be extended if necessary.
The maximum length of the drain hose, including the
hose leading to the air gap, is 150 inches.
· The hose shown in Figure 28 is an air vent. The end
of this hose should be left in the dishwasher base.
Figure 25
Figure 28
Air Vent Hose
Do not make any
connections to this hose

13
ELECTRICAL CONNECTION
Figure 30
Strain Relief Plate
Figure 29
Strain
Relief
Plate
Hot Water Connection/Electrical Connection
Avoid Electrical Shock Hazard
WARNING
Do not work on an energized circuit. Doing so
could result in serious injury or death. Only
qualified electricians should perform electrical
work. Do not attempt any work on the dishwasher
electric supply circuit until you are certain the
circuit is de-energized.
Avoid Fire Hazard
WARNING
Make sure electrical work is properly installed.
Only qualified electricians should perform
electrical work.
Grounding Instructions
The dishwasher must be properly grounded before
operating. This appliance must be connected to a
grounded metal permanent wiring system, or an
equipment grounding conductor must be run with the
circuit conductors and connected to the equipment
grounding terminal or lead on the dishwasher. Make sure
that the dishwasher is connected to a suitable ground in
compliance with all local codes or, in the absence of a
local code, with the NATIONAL ELECTRICAL CODE in
the United States or the CANADIAN ELECTRIC CODE
C22.1-latest edition in Canada as well as any provincial/
state or municipal or local codes that apply.
1 Retrieve the strain relief plate, and install a strain
relief (not supplied) into the opening on the strain
relief plate. NOTE: Orient the strain relief as shown in
Figure 29.
2 Pass the electrical supply cable through the strain
relief, as shown in Figure 30. Make sure the outer
wire casing extends about 1/2” (13mm) through the
strain relief.
3 Tighten the strain relief screws.
4 Slide the strain relief plate into the junction box, and
secure it to the junction box with the supplied screw.
Outer Wire
Casing
Temperatures required for soldering and sweating
will damage the dishwasher’s water inlet valve.
If plumbing lines are to be soldered or sweated,
keep the heat source at least 6 inches (152.4 mm)
away from the dishwasher’s water inlet valve.
• If using a solder joint instead of a compression fitting,
be sure to make all solder connections before
connecting the water line to the dishwasher.
• Make certain there are no sharp bends or kinks in the
water line that might restrict water flow.
• Be sure to use pipe thread compound or Teflon brand
tape to seal the connection when required.
• Before connecting the copper hot water supply line
to the dishwasher, flush it with hot water to clear any
foreign material.
• Turn on the water supply to check for leaks after
making connections.
NOTE: Do not use pipe sealant on compression fittings.
Copper Tubing
Strain Relief
(not supplied)

14
Figure 33
Figure 34
1/8”
3mm
Figure 32
Figure 35
Figure 31 • Do not pre-twist the wires before connecting them
with wire nuts.
• Extend the dishwasher’s stranded wires 1/8”
(3mm) beyond the power supply cable’s solid
wires, as shown in Figure 31.
5 Using the supplied wire nuts, connect the electrical
supply wires to the dishwasher’s wires, black to
black, white to white, and green or bare. Make certain
that the insulated wires show no bare wire from the
bottoms of the wire nuts. Gently tug the wires to make
certain they are securely connected.
6 Press the wires into the junction box as shown in
Figure 32. Make certain that the wire nuts do not
loosen.
7 Place the cover on the junction box and secure it to
the junction box with the supplied screw.
DOOR TENSION ADJUSTMENT (only on
fully integrated models with custom
door panels)
After the dishwasher and custom door panel are
installed, open and close the door several times to make
sure that it does so with ease. If the door falls open too
quickly, the spring tension needs to be adjusted.
To Adjust the Spring Tension:
1 Obtain the provided Spring Tension Screws from the
Integrated Door Panel Installation Kit.
2 Insert the screws as shown in Figure 33. Turning the
screw clockwise increases the spring tension.
TOE PANEL INSTALLATION
Method A - Regular Toe Panel Installation
Install the Toe Panel Mounting Brackets
Step 1 - Insert the short leg of the Toe Panel Mounting
Bracket into the recess of the dishwasher base as shown
in Figure 34.
Step 2 - Use the toe panel screws from the Dishwasher
Installation Kit and a T-15 screwdriver to install the toe
panel as shown in Figure 35.
BASE AND TOE PANEL (Continued)
Method B - Plastic Base Access Panel and Toe Panel
Installation (select models)
1 Place the Plastic Base Access Panel under and up
the front bottom panel of the dishwasher, as shown in
Figure 36a.
2 Insert the Plastic Base Access Panel screws into the
Plastic Base Access Panel, as shown in Figure 36b.
ELECTRICAL CONNECTION (continued)
Electrical Connection/ Door Tension Adjustment/ Base and Toe Panel
Avoid Fire Hazard
Make sure there are no loose electrical
connections. Make sure all electrical
connections are properly made.
WARNING

15
3 Place the Cotton Insulation Strip under the unit,
between the bottom of the Plastic Base Access Panel
and the floor, as shown in Figure 36c.
4 Attach the Metal Toe Panel to the Plastic Base
Access Panel using the Toe Panel Screws included in
the Toe Panel Installation Kit. See Figure 36d.
NOTE: You will not use the normal Toe Panel Screws
included in the Dishwasher Installation Kit on these
models.
Figure 36
a
b
d
c
Base and Toe Panel/ Final Instructions
In some conditions, Hydrogen gas can form in
a hot water system that has not been used for
weeks. Hydrogen gas is explosive. Before filling
a dishwasher from a system that has been off for
weeks, run the water from a nearby faucet in a well
ventilated area until there is no sound or evidence
of gas.
FINAL INSTRUCTIONS
1 Energize the dishwasher power supply circuit.
2 Consult the Dishwasher Use and Care Manual, and
run the dishwasher through one complete cycle. If
the dishwasher does not operate properly, refer to
the Self-Help section of the Use and Care Manual. If
the dishwasher still does not operate properly, refer
to the Customer Service Section of the Use and Care
Manual.
WARNING
A
B
Figure 37
Figure 38
Dimension
A
B
27 3/16” - 30 7/16”
(690mm - 774mm)
23 3/16” - 23 3/8”
(589mm - 594mm)
Integrated Panel Dimensions for
Custom Door Panels
25”
(636 mm)
23-1/16”
(586 mm)
1/4” max.
(6 mm)
Figure 38
DOOR PANEL INSTALLATION
Accessory Panel Installation Kits (select models)
This kit allows you to install a custom panel (up to 1/4”
thick) on your dishwasher. The panel dimensions are
shown in Figure 37. Install the panel before sliding the
dishwasher into place. Contact Customer Service to see
if a kit is available for your model and to obtain ordering
instructions.
Fully Integrated Models
Fully integrated models allow you to have a custom door
panel made to match your cabinetry. The custom door
can be a two-piece configuration to look like a drawer at
the top and a cabinet door at the bottom or like a single
full-length door. A template is included with the fully
integrated models to explain the mounting procedure.
NOTE: The door springs that are included with the Fully
Integrated units will provide proper function for custom
door panels weighing between 9 and 15 pounds. Custom
Door panels weighing up to 18 pounds require the use of
the Tension Adjustment Screws (See page 14 for details
on the proper use of the Tension Adjustment Screws).

16
Customer Service
© BSH Home Appliances Corporation 2005 • Litho U.S.A. 07/04
Customer Service
Also, if you are writing, please include a daytime
phone number where you can be reached. You
will find the model and serial number information
on the label located on the top edge of the inner
door of your dishwasher. It will look similiar to this:
Your Gaggenau dishwasher requires no special
care other than that described in the Care and
Maintenance section of the Use and Care
Manual. If you are having a problem with your
dishwasher, before calling for service please
refer to the Self Help section in the Use and
Care Manual. If service is necessary, contact
your dealer or installer or an authorized service
center. Do not attempt to repair the appliance
yourself. Any work performed by unauthorized
personnel may void the warranty.
Please be sure to include (if you are writing), or
have available (if you are calling), the following
information:
• Model number
• Serial number
• Date of original purchase
• Date the problem originated
• Explanation of the problem
CAUTION
Removing any cover or pulling the
dishwasher from the cabinet can expose
hot water connections, electrical power and
sharp edges or points.
If you are having a problem with your Gaggenau
dishwasher and are not pleased with the service
you have received, please take the following
steps (in the order listed below) until the problem
is corrected to your satisfaction:
1. Contact your installer or the Gaggenau
Authorized Service Contractor in your area.
2. E-mail us from the customer service section
of our website, www.gaggenau-usa.com.
3. Write us at:
Gaggenau
5551 McFadden Avenue
Huntington Beach, CA 92649
4. Call us at 1-800-828-9165.
Please make a copy of your invoice and keep it
with this manual. The customer must show proof
of purchase to obtain warranty service.

1
Instructions de sécurité importantes
IMPORTANT
• Le tuyau de drainage du lave-vaisselle doit
être installé avec une portion à au moins 20 po
(508 mm) au-dessus du plancher de l’armoire,
autrement l’appareil peut ne pas se drainer
adéquatement.
• Le lave-vaisselle est destiné à un usage
résidentiel seulement, et ne doit pas être utilisé
de façon commerciale.
• NOUVELLE INSTALLATION - Si le lave-vaisselle
est une nouvelle installation, la plupart du travail
doit être effectué avant l’installation de l’appareil.
• REMPLACEMENT - Si le lave-vaisselle en
remplace un autre, vérifier les connexions
existantes relativement à la compatibilité et
remplacer toutes pièces nécessaires.
• Cet appareil est conforme avec CAN/CSA-C22.2
No. 167/UL 749. Il incombe au propriétaire et
à l’installateur de déterminer si des exigences
et normes additionnelles s’appliquent pour une
installation spécifique.
Vérification du lave-vaisselle
Après avoir déballé le lave-vaisselle et avant
l’installation, vérifier entièrement l’appareil afin de
voir s’il présente des dommages esthétiques ou
autres. Rapporter tout dommage immédiatement.
Les défauts esthétiques doivent être rapportés dans
un délai de 30 jours suivant l’installation.
REMARQUE : ne pas jeter les sacs ou les
pièces fournis avec l’emballage d’origine tant que
l’installation n’est pas complétée.
Le lave-vaisselle doit être installé par un technicien
ou installateur qualifié seulement.
• En plus de ces instructions, l’appareil doit être
installé conformément aux codes et règlements
électriques et de plomberie (nationaux et locaux).
Lire entièrement ces instructions d’installation et
les observer. Elles permettront d’économiser temps
et argent et assureront un rendement sécuritaire et
optimal du lave-vaisselle.
INSTRUCTIONS IMPORTANTES ..............................1
Outils nécessaires .....................................................2
Matériaux nécessaires ..............................................2
Matériaux fournis .......................................................3
Préparation de l’espace .............................................4
Préparation électrique ...............................................5
Préparation de la plomberie ...................................6-7
Préparation du lave-vaisselle ..................................7-8
Installation du panneau de porte ...............................9
Mise en place .......................................................... 10
Fixation du lave-vaisselle ......................................... 10
Connexion du tuyau de drainage ............................. 11
Connexion eau chaude ............................................12
Connexion électrique ..........................................13-14
Réglage tension de la porte .................................... 14
Base et panneau inférieur ..................................14-15
Instructions finales ................................................... 15
Service à la clientèle ............................................... 16
Table des matières
Lire entièrement les instructions d’installation et les observer.
Pour éviter tout dommage à la propriété
et blessures, OBSERVER TOUS LES
AVERTISSEMENTS. Ces instructions sont
destinées à un installateur qualifié seulement.
Si le lave-vaisselle est installé dans un endroit
où il y a du gel (ex. : comme dans un chalet),
il faut drainer l’eau de l’intérieur de l’appareil.
Des ruptures du système d’eau survenants
à cause du gel ne sont pas couverts par la
garantie.
AVERTISSEMENT
Instructions d’installation du lave-vaisselle
Anglais/Français/Espagnol
9000161666 RÉV A · 03/06

2
Outils et matériaux nécessaires
Marteau Scie-cloche Ruban à
mesurer
Tournevis à
fente Tournevis Phillips Tournevis T-15
Coupe-fil Dégaine-fil Niveau
Clé réglable
OUTILS NÉCESSAIRES
Perceuse
Câble d’alimentation électrique - Minimum n° 14 AWG, 2 conducteurs, 1 mise à la terre, con-
ducteur en cuivre isolé coté 75 °C ou plus.
Tuyau de canalisation en eau chaude - Tuyau en cuivre, minimum 3/8 po D.E. ou canalisation
en métal bridé.
Soupape d’arrêt et raccords appropriés pour canalisation en eau chaude (tuyau en cuivre/rac-
cord à compression ou tuyau bridé).
Coude 90° avec filets mâles 3/8 po N.P.T. sur un pied, dont la dimension s’ajuste à la canalisa-
tion en eau (tuyau en cuivre/raccord à compression ou tuyau bridé) sur l’autre pied.
Ruban Teflon ou produit pour filets de tuyau afin de sceller les connexions de plomberie.
Connecteur de conduit listé UL ou réducteur de tension.
MATÉRIAUX NÉCESSAIRES
(D’autres matériaux peuvent être requis pour être conformes aux codes locaux.)

3
Nécessaire d’installation du lave-vaisselle
Ce nécessaire comprend ce qui suit :
H TVis pour panneu du bas (2 vis usinées noires)
Remarque : ces vis sont comprises, mais
non utilisées pour les modèles à nécessaires
d’installation de panneau de base.
I Fixations de plan de travail (2 «L» en métal)
J Vis de fixation (2 vis à bois argentées)
K Adaptateur de tuyau de drain en caoutchouc (1
tuyau en caoutchouc noir)
L Pinces à tuyau (1 pince à ressort argenté à
utiliser avec adaptateur en caoutchouc vers tuyau
de drain et 1 pince à vis pour fixer l’adaptateur en
caout-chouc à la plomberie)
M Serre-fils (3 connexions électriques)
N Vis de boîte de jonction (1 vis usinée argentée)
O Vis de verrouillage de pied niveleur (2 vis à gros
filets argentées)
P Fixation de panneau supérieur (2 fixations en
métal)
Q Vis de fixation de panneau supérieur (2 vis
usinées argentées)
R Clé Allen 5 mm
S Tournevis T-15
L
K
MATÉRIAUX FOURNIS
Pièces accessoires fournies
Les pièces pour le lave-vaisselle sontdans un ou plusieurs sacs, comme décrit ci-dessous.
REMARQUE : s’assurer d’avoir tous les sacs afin de compléter l’installation.
REMARQUE : toujours utiliser la quincaillerie fournie ou recommandée.
Sac avec guided’utilisation et d’entretien
Matériaux fournis
Ce sac comprend ce qui suit :
A Instructions d’utilisation et d’entretien
B Guide de référence rapide (certains modèles)
C Gicleur pour grands articles
D Carte de garantie.
C
AB
F
G
E Guide d’instructions d’installation
F Gabarit de fixation de porte intégrée pour
panneaux de porte sur mesure (certains
modèles)
G Bande isolante en coton blanc (certains
modèles)
Sac avec guide d’installation
Ce sac est inclus avec chaque lave-vaisselle et
comprend :
E
D
R
S
J
I
H
N
M
O
Q
P

4
Nécessaire d’installation du panneau du bas
Un nécessaire d’installation de panneau inférieur est
fourni avec certains modèles. Ces modèles sont dotés
d’un panneau inférieur spécial réduisant le bruit et
ayant la quincaillerie suivante :
Y Vis de panneau du bas (2 vis noires utilisées fixer
le panneau du bas en métal)
Z Vis de panneau d’accès de base en plastique
(2 longues vis argent pour fixer panneau d’accès
de base en plastique au lave-vaisselle)
Remarque : la vis n’est pas utilisée pour les
appareils dotés de ce nécessaire.
Y
Z
Matériaux fournis
H
U
T
V
W
Nécessaire d’installation de panneau de porte
intégrée
Ce nécessaire est fourni avec certains modèles
utilisant un panneau de porte en bois sur mesure et
comprend :
T Vis de tension à ressort (2 vis usinées larges
argentées pour régler les ressorts de porte pour
accommoder les différents poids de porte)
U Fixations de porte (2 en métal utilisées pour
installer la porte sur mesure)
V Vis de fixation de porte (6 vis à bois argentées)
W Vis de fixation de porte (4 longues vis argentées
pour fixer la porte)
X Crochet et attaches en boucle (2 attaches à dos
adhésif)
X
