Garmin G1000 NXi User manual

190-00716-N1 2017 Revision 1
System Maintenance Manual
King Air 300 Series
Includes Instructions for Continued Airworthiness
for STC SA01535WI-D

G1000 NXi System Maintenance Manual Page i
King Air 300 Series Revision 1
190-00716-N1
© Copyright 2017
Garmin Ltd. or its subsidiaries
All Rights Reserved
Except as expressly provided herein, no part of this manual may be reproduced, copied, transmitted,
disseminated, downloaded or stored in any storage medium, for any purpose without the express prior
written consent of Garmin. Garmin hereby grants permission to download a single copy of this manual
and of any revision to this manual onto a hard drive or other electronic storage medium to be viewed and
to print one copy of this manual or of any revision hereto, provided that such electronic or printed copy of
this manual or revision must contain the complete text of this copyright notice and provided further that
any unauthorized commercial distribution of this manual or any revision hereto is strictly prohibited.
Garmin International, Inc.
1200 E. 151st Street
Olathe, KS 66062 USA
Telephone: [phone]
www.garmin.com
Garmin (Europe) Ltd.
Liberty House, Bulls Copse Road
Hounsdown Business Park
Southampton, SO40 9RB, UK
Phone: [phone]
Fax: [phone]
Garmin AT, Inc.
2345 Turner Rd., SE
Salem, OR 97302 USA
Telephone: [phone]
RECORD OF REVISIONS
Revision
Revision Date
Description
ECO #
1
1/30/2017
Initial Release
---
DOCUMENT PAGINATION
Section
Pagination
Table of Contents
i – ix
Section 1
1 – 6
Section 2
7 – 44
Section 3
45 – 94
Section 4
95 – 137
Section 5
138 – 227
Section 6
228 – 257
Section 7
258 – 339
Section 8
340 – 371
Section 9
372 - 389

G1000 NXi System Maintenance Manual Page ii
King Air 300 Series Revision 1
190-00716-N1
INFORMATION SUBJECT TO EXPORT CONTROL LAWS
This document may contain information which is subject to the Export Administration
Regulations (“EAR”) issued by the United States Department of Commerce (15 CFR, Chapter
VII Subchapter C) and which may not be exported, released or disclosed to foreign nationals
inside or outside the United States without first obtaining an export license. The preceding
statement is required to be included on any and all reproductions in whole or in part of this
manual.
This product, its packaging, and its components contain chemicals known to the State of
California to cause cancer, birth defects, or reproductive harm. This Notice is being provided in
accordance with California's Proposition 65. If you have any questions or would like additional
information, please refer to our web site at www.garmin.com/prop65.
The GDU lens is coated with a special anti-reflective coating that is very sensitive to skin oils,
waxes and abrasive cleaners. CLEANERS CONTAINING AMMONIA WILL HARM THE ANTI-
REFLECTIVE COATING. It is very important to clean the lens using a clean, lint-free cloth and
an eyeglass lens cleaner that is specified as safe for anti-reflective coatings.
All G1000 screen shots used in this document are current at the time of publication. Screen
shots are intended to provide visual reference only. All information depicted in screen shots,
including software file names, versions and part numbers, is subject to change and may not be
up to date.
CAUTION
WARNING
IMPORTANT

G1000 NXi System Maintenance Manual Page iii
King Air 300 Series Revision 1
190-00716-N1
TABLE OF CONTENTS
PARAGRAPH PAGE
1. INTRODUCTION....................................................................................................................1
Content, Scope, Purpose.................................................................................................1
Organization.....................................................................................................................2
Definitions/Abbreviations .................................................................................................3
Units of Measure..............................................................................................................4
Publications......................................................................................................................4
Revision and Distribution.................................................................................................6
2. SYSTEM DESCRIPTION.......................................................................................................7
Equipment Descriptions...................................................................................................7
G1000 Optional Interfaces.............................................................................................23
Electrical Power Distribution..........................................................................................24
Electrical Load Utilization...............................................................................................27
Pitot/Static System.........................................................................................................35
Shield Block Grounds ....................................................................................................37
G1000NXi /GFC700 Block Diagrams.............................................................................37
GDU 1050A and GDU 1550 Displays............................................................................39
Softkeys.........................................................................................................................40
FMS Knob......................................................................................................................40
GCU 477 - MFD Controller ............................................................................................41
GMC 710 - AFCS Controls ............................................................................................41
GMA 1347D Audio Panel...............................................................................................42
G1000 Normal Mode......................................................................................................43
Reversionary Mode........................................................................................................44
3. SOFTWARE AND CONFIGURATION.................................................................................45
Configuration Mode Overview........................................................................................45
G1000 System Software Information.............................................................................50
Configuration Mode........................................................................................................59
G1000 Hardware/Software Compatibility Check............................................................59
Equipment Verification (Third Party/Optional Equipment Documentation)....................60
Configuration Checklist..................................................................................................65
G1000 Software/Configuration Procedure.....................................................................67
System Software and Configuration Load .....................................................................68
Feature Enablement ......................................................................................................76
Aircraft Registration Number Entry................................................................................84

G1000 NXi System Maintenance Manual Page iv
King Air 300 Series Revision 1
190-00716-N1
Configuration Manager ..................................................................................................86
Splash Screen Loading..................................................................................................86
Clearing Default User Settings.......................................................................................87
Database Loading..........................................................................................................87
Configuration of Navigation Map for Traffic System ......................................................89
Enter Flight ID for GTX 3000 Installations .....................................................................89
GRA 5500 Legacy Software and Configuration (Non Integrated)..................................90
Interface Confirmation....................................................................................................93
MD 302 Configuration and Sensor Calibration ..............................................................94
4. INSTRUCTIONS FOR CONTINUED AIRWORTHINESS....................................................99
Airworthiness Limitations...............................................................................................99
Servicing Information...................................................................................................100
Maintenance Intervals..................................................................................................103
Visual Inspection..........................................................................................................109
Electrical Bonding Test................................................................................................114
GSU 75B, GRS 77, or GRS 7800 Earth Magnetic Field Updates................................117
GSA 80 Greasing Procedure.......................................................................................117
Flaps-in-motion Discrete Input Check..........................................................................118
GSM 86 Slip Clutch Torque Check Procedure ............................................................119
G1000 Redundant Connection Check.........................................................................122
Engine Data Check......................................................................................................126
Trim Annunciator Check ..............................................................................................128
G1000 Miscompare Checks.........................................................................................130
Nose Avionics Compartment Fans Operational Check................................................131
Instrument Panel Fans Operational Check..................................................................132
Standby Battery Periodic Checks ................................................................................132
Rudder Boost Operational Check................................................................................136
Exterior Skin Inspection Around Antennas ..................................................................137
5. TROUBLESHOOTING.......................................................................................................138
System Annunciations .................................................................................................139
G1000 Alerting System................................................................................................163
Aural & Audio Alerts.....................................................................................................164
King Air 300 Series Specific Alerts ..............................................................................166
TAWS Troubleshooting................................................................................................167
Synthetic Vision and Pathways Troubleshooting.........................................................168
GFC 700 AFCS Troubleshooting.................................................................................169

G1000 NXi System Maintenance Manual Page v
King Air 300 Series Revision 1
190-00716-N1
General Troubleshooting .............................................................................................170
Backup Communications Path Checks........................................................................182
GDU 105X Troubleshooting.........................................................................................182
GDU 105X Alerts .........................................................................................................184
GIA 63 Troubleshooting...............................................................................................192
GIA Alert Messages.....................................................................................................193
GEA Troubleshooting...................................................................................................199
GTX Troubleshooting...................................................................................................200
GDL 69A or GDL69A SXM Troubleshooting................................................................201
GSU 75B, GRS 77, or GRS 7800 and GMU 44 Troubleshooting................................203
GSU 75B/GDC 7400 Troubleshooting.........................................................................208
GWX 68 or GWX 70 Troubleshooting..........................................................................209
GMC 710 Troubleshooting...........................................................................................210
GCU 477 Troubleshooting...........................................................................................211
Software/Configuration Troubleshooting......................................................................212
Backshell/Backplate Connectors .................................................................................214
Mechanical Standby Attitude Indicator Troubleshooting..............................................222
Mechanical Standby Airspeed Indicator Troubleshooting............................................222
Mechanical Standby Altimeter Troubleshooting...........................................................223
MD 302 Standby Indicator Troubleshooting.................................................................223
GDL 59 Troubleshooting..............................................................................................224
GSR 56 Troubleshooting .............................................................................................224
GTS 820/850 Troubleshooting.....................................................................................224
GTS Traffic Processor Troubleshooting.......................................................................226
6. EQUIPMENT REMOVAL & INSTALLATION....................................................................228
GDU 1050A/1550.........................................................................................................229
GMA 1347D Audio Panel.............................................................................................229
GIA 63W Integrated Avionics Units..............................................................................230
GEA 71 Engine/Airframe Unit......................................................................................230
GTX 33( ) or GTX 3000 Transponder..........................................................................231
GTX 335R/GTRX 345R Transponder..........................................................................232
GDC 7400 Air Data Computer.....................................................................................232
GTP 59 OAT Probe......................................................................................................233
GRS 77 or GRS 7800 AHRS or GSU 75B ADAHRS...................................................233
GMU 44 Magnetometer ...............................................................................................234
GDL 69A or GDL 69A SXM .........................................................................................236

G1000 NXi System Maintenance Manual Page vi
King Air 300 Series Revision 1
190-00716-N1
GSA 80 and GSA 9000 Servo Motors .........................................................................236
GSM 86 and GSM 9100 Servo Gearbox .....................................................................238
GCU 477......................................................................................................................238
GMC 710......................................................................................................................238
GWX 68 or GWX 70.....................................................................................................239
Configuration Modules.................................................................................................239
GEA 71 Backshell Thermocouple Removal & Replacement.......................................244
GPS/WAAS Antennas..................................................................................................245
Diversity Transponder Antenna ...................................................................................245
Iridium Antenna............................................................................................................246
Wi-Fi Antenna..............................................................................................................246
Signal Conditioners......................................................................................................247
Instrument Panel Annunciators (Prop Synch and Standby Battery)............................247
Emergency Frequency Switch/Annunciator.................................................................248
L-3 Avionics (BF Goodrich) PS-835(C or D Model) Emergency Battery......................248
MD 302 Standby Attitude Module (SAM).....................................................................248
Mechanical Standby Indicators....................................................................................251
GIA Cooling Fans.........................................................................................................253
GDU Cooling Fans.......................................................................................................253
GTS 820/850 and GTS Processor Traffic Units...........................................................254
GPA 65 PA/LNA Unit...................................................................................................254
GA 58 Traffic Antennas................................................................................................255
GDL 59 Wi-Fi Datalink.................................................................................................255
GSR 56 Satellite Receiver...........................................................................................256
GRA 5500 Radar Altimeter..........................................................................................256
GSD 41 Data Concentrator..........................................................................................257
7. GARMIN G1000 LRU REPLACEMENT/CONFIGURATION & TESTING.........................258
GDU 1050A/1550 PFD & MFD....................................................................................258
GMA 1347D Audio Panel.............................................................................................262
GIA 63W Integrated Avionics Unit ...............................................................................269
GEA 71 Engine/Airframe Unit......................................................................................280
GTX 335R, GTX 345R, GTX 33( ), or GTX 3000 Transponder...................................294
GSU 75B ADAHRS......................................................................................................297
GDC 7400 Air Data......................................................................................................299
GRS 77 or 7800 AHRS and GMU 44 Magnetometer ..................................................305
GMU 44 Magnetometer ...............................................................................................307

G1000 NXi System Maintenance Manual Page vii
King Air 300 Series Revision 1
190-00716-N1
GSU/GRS/GMU Calibration Procedures .....................................................................308
GDL 69A or GDL 69A SXM Data Link.........................................................................317
GSA 80 Servos............................................................................................................319
GCU 477 FMS Controller.............................................................................................321
GMC 710 AFCS Controller ..........................................................................................324
GWX 68 or GWX 70 Weather Radar...........................................................................326
GRA 5500 Radar Altimeter..........................................................................................328
Garmin Traffic Systems (GTS 8XX/GTS 8XXX)..........................................................330
GDL 59.........................................................................................................................334
GSR 56........................................................................................................................337
GSD 41........................................................................................................................339
8. SUBSYSTEM FUNCTIONAL CHECKS.............................................................................341
Non-Garmin Traffic System Functional Check.............................................................341
Stormscope Functional Check.....................................................................................342
TAWS Functional Check..............................................................................................344
FliteCharts Functional Check.......................................................................................347
ChartView Functional Check........................................................................................348
SafeTaxi Functional Check..........................................................................................349
DME Functional Check................................................................................................350
ADF Functional Check.................................................................................................351
GRA 5500 Radar Altimeter Functional Check .............................................................351
Non-Garmin Radar Altimeter Check (Optional) ...........................................................351
Weight on Wheels and Low Speed Awareness Band Check ......................................352
RVSM Checks..............................................................................................................353
ESP Functional Check.................................................................................................361
GTS Traffic System Functional Check.........................................................................364
Activation of Garmin Connext......................................................................................367
GDL 59 Wi-Fi Data Link Functional Check..................................................................369
GSR 56 Satellite Receiver Functional Check ..............................................................369
Search and Rescue Functional Check.........................................................................371
9. G1000 SYSTEM RETURN TO SERVICE PROCEDURE..................................................372
Display Test.................................................................................................................372
Display Failure Test.....................................................................................................375
Reversion Mode Check................................................................................................376
Cooling Fan Fail Annunciation Check..........................................................................377
GPS Signal Acquisition................................................................................................377

G1000 NXi System Maintenance Manual Page viii
King Air 300 Series Revision 1
190-00716-N1
GPS Failure Test .........................................................................................................378
GIA Failure Test...........................................................................................................380
GEA Functional Check.................................................................................................381
Standby Instrument Electrical Power Checks..............................................................382
G1000 Backup Path Test.............................................................................................384
GFC 700 Ground Checkout.........................................................................................384
Maintenance Records..................................................................................................389

G1000 NXi System Maintenance Manual Page ix
King Air 300 Series Revision 1
190-00716-N1
LIST OF ILLUSTRATIONS
FIGURE PAGE
Figure 2-1, Display Units...............................................................................................................8
Figure 2-2, Flight Stream 510 .......................................................................................................9
Figure 2-3, Audio Panel................................................................................................................9
Figure 2-4, AFCS Controller .......................................................................................................10
Figure 2-5, FMS Controller .........................................................................................................10
Figure 2-6, Transponders ...........................................................................................................11
Figure 2-7, GIA unit.....................................................................................................................13
Figure 2-8, GEA unit...................................................................................................................13
Figure 2-9, GSU-75B ADAHRS with Connector and Mounting Tray ..........................................14
Figure 2-10, GDC 7400 Air Data Computer................................................................................15
Figure 2-11, OAT probe..............................................................................................................15
Figure 2-12, AHRS......................................................................................................................16
Figure 2-13, Magnetometer ........................................................................................................17
Figure 2-14, GDL 69A/69A SXM Datalink...................................................................................17
Figure 2-15, GDL 59 Wi-Fi Datalink............................................................................................18
Figure 2-16, GSR 56 Satellite Receiver......................................................................................18
Figure 2-17, GSD 41 Data Concentrator ....................................................................................19
Figure 2-18, GTS 820/850 Traffic System ..................................................................................19
Figure 2-19, GTS Traffic Processor............................................................................................20
Figure 2-20, Weather Radar.......................................................................................................20
Figure 2-21, Servo......................................................................................................................21
Figure 2-22, GSA 9000 / GSM 9100...........................................................................................21
Figure 2-23, GRA 5500 Radar Altimeter.....................................................................................21
Figure 2-24, MD 302 Standby Attitude Module...........................................................................22
Figure 2-25, 300 Series Electrical Distribution (Post G1000 STC).............................................25
Figure 2-26, G1000 Component Power Sources........................................................................26
Figure 2-27, Pitot/Static System with ADC(s) and AHRS(s) Installed.........................................35
Figure 2-28, Pitot/Static System with GDU 75B ADAHRS(s) Installed.......................................36
Figure 2-29, G1000NXi/GFC 700 Block Diagram with GSU 75B ADAHRS................................37
Figure 2-30, G1000NXi/GFC 700 Block Diagram with Separate ADC and AHRS......................38
Figure 2-31, GDU 1050A Control Interface.................................................................................39
Figure 2-32, GDU 1550 Control Interface...................................................................................39
Figure 2-33, G1000 Softkeys......................................................................................................40
Figure 2-34, MFD Controls (GCU 477 shown)............................................................................41
Figure 2-35, AFCS Controls (GMC 710 shown) .........................................................................41
Figure 2-36, GMA 1347D Controls .............................................................................................42
Figure 2-37, Normal Mode..........................................................................................................44
Figure 2-38, Automatic Reversion with MFD failure ...................................................................44
Figure 2-39, Manual Reversion with pilot PFD failure
.................................................................44
Figure 3-1, SET>ACTV Diagram ................................................................................................46
Figure 3-2, Loss of Communication............................................................................................47
Figure 3-3, Configuration Status.................................................................................................47
Figure 3-4, Data Transmission Indicators...................................................................................47
Figure 3-5, G1000 LRU Configuration File Storage....................................................................57
Figure 3-6, GSU/GRS/GDC Configuration Settings Storage......................................................58
Figure 3-7, Garmin Unit S/N Location.........................................................................................61
Figure 3-8, Garmin Unit Listed if Installed...................................................................................62
Figure 3-9, Ethernet Connections Page......................................................................................63
Figure 3-10, ESP Status Field ....................................................................................................64
Figure 3-11, Software/Configuration Overview...........................................................................67

G1000 NXi System Maintenance Manual Page x
King Air 300 Series Revision 1
190-00716-N1
Figure 3-12, MFD Aux - Database Page DB Transfer ................................................................88
Figure 3-13, Stormscope Configuration Page.............................................................................93
Figure 3-14, Stormscope Configuration......................................................................................93
Figure 4-1, GIA I/O Page ..........................................................................................................118
Figure 4-2, Discrete Indications................................................................................................118
Figure 4-3, GFC Status Page ...................................................................................................119
Figure 4-4, Ambient Temperature Conversion Chart................................................................127
Figure 4-5, Standby Battery......................................................................................................133
Figure 4-6, Power Supply Connection ......................................................................................136
Figure 4-7, Exterior Skin Inspection Around Antennas.............................................................137
Figure 5-1, Aux – System Status Page.....................................................................................138
Figure 5-2, System Annunciations............................................................................................139
Figure 5-3, Alerts & Annunciations ...........................................................................................163
Figure 5-4, Alerts Softkey Annunciation....................................................................................163
Figure 5-5, AFCS Annunciation Field .......................................................................................169
Figure 5-6, GFC Status Page ...................................................................................................172
Figure 5-7, Magnetometer Interference Test ............................................................................206
Figure 5-8, GIA 63W Backplate Connectors.............................................................................214
Figure 5-9, GEA 71 Backplate Connectors...............................................................................215
Figure 5-10, GMA 1347D Backplate Connectors......................................................................215
Figure 5-11, GTX 33/33D Backplate Connectors .....................................................................215
Figure 5-12, GTX 3000 Connectors (P3301 and P3302)..........................................................216
Figure 5-13, GTX 335R/345R Looking at Front of Connector (P3251).....................................216
Figure 5-14, GTX 345R (Only) Looking at Front of Connector (P3252)....................................217
Figure 5-15, GDU 1050A/1550 Backshell Connector (P10401 or P15001)..............................217
Figure 5-16, GRS 77 Backshell Connector (P771)...................................................................217
Figure 5-17, GRS 7800 Backshell Connector (P78001)...........................................................218
Figure 5-18, GSU 75B Connector View from Front (P751).......................................................218
Figure 5-19, GDC 7400 Mating Connector (P74001) ...............................................................218
Figure 5-20, GDL 69A/GDL 69A SXM Backplate Connector (P69A1)......................................218
Figure 5-21, GCU 477 Backshell Connector (P4751)...............................................................219
Figure 5-22, GMC 710 Backshell Connector (P7101) ..............................................................219
Figure 5-23, GWX 68 Backshell Connector (P681) ..................................................................219
Figure 5-24, GWX 70 Backshell Connector (P751) ..................................................................219
Figure 5-25, GTS 820/850 Mating Connectors (P8001 and P8002).........................................219
Figure 5-26, GTS 820/850 Mating Connector (P8003) (Rear View).........................................220
Figure 5-27, GTS Processor Connector (P8001)......................................................................220
Figure 5-28, GPA 65 Mating Connector (P651) (Rear View)....................................................220
Figure 5-29, Signal Conditioner (1PVIB1 and 2PVIB1) ............................................................220
Figure 5-30, GDL 59 Mating Connector (1P591)......................................................................221
Figure 5-31, GSR 56 Mating Connector (1P561)......................................................................221
Figure 5-32, GRA 5500 Connector (P55001) ...........................................................................221
Figure 5-33, GSD 41 Backplate Connector (P411)...................................................................221
Figure 5-34, GSA 9000 Mating Connector (P90001)................................................................221
Figure 6-1, GSA 80 Servo Gear................................................................................................237
Figure 6-2, GSM 9100 O-ring ...................................................................................................237
Figure 6-3, Configuration Module Installation...........................................................................240
Figure 6-4, GRS 7800 Configuration Module Installation .........................................................241
Figure 6-5, GSU 75B Configuration Module Installation...........................................................242
Figure 6-6, GEA Backshell Thermocouple................................................................................244
Figure 6-7, MD 302 Backshell and Config Module ...................................................................250
Figure 7-1, G1000 Normal Mode Check...................................................................................261
Figure 7-2, Aux – GPS Status Page (MFD)..............................................................................276

G1000 NXi System Maintenance Manual Page xi
King Air 300 Series Revision 1
190-00716-N1
Figure 7-3, Normal Engine Instrument Markings (MFD)...........................................................283
Figure 7-4, Ambient Temperature Conversion Chart................................................................286
Figure 7-5, Aircraft Registration................................................................................................296
Figure 7-6, GRS/GMU Calibration, Pitch/Roll Offset ................................................................310
Figure 7-7, GRS/GMU Calibration, Engine Run-Up..................................................................314
Figure 7-8, Normal Mode AHRS Check....................................................................................316
Figure 8-1, Low Speed Awareness Band Symbolization..........................................................353
Figure 8-2, RVSM Critical Region.............................................................................................355
Figure 8-3, RVSM Critical Region (modified)............................................................................357
Figure 8-4, Dial Indicator...........................................................................................................358
Figure 8-5, Static Port Measurement........................................................................................358
Figure 8-6, Static Port Measurement locations.........................................................................359
Figure 8-7, Static Port Measurement Log.................................................................................359
Figure 8-8, Traffic Map..............................................................................................................364
Figure 8-9, GSR56 Configuration Page....................................................................................370
Figure 8-10, Aux-Telephone page............................................................................................370
Figure 9-1, MFD Power Up Page..............................................................................................372
Figure 9-2, PFD Power-up System Annunciations ...................................................................373
Figure 9-3, PFD Normal Operation...........................................................................................374
Figure 9-4, GDU Reversionary Mode .......................................................................................376
Figure 9-5, AUX-GPS Status Page...........................................................................................378

G1000 NXi System Maintenance Manual Page xii
King Air 300 Series Revision 1
190-00716-N1
LIST OF TABLES
TABLE..................................................................................................................................PAGE
Table 1-1, Required Documents...................................................................................................4
Table 1-2, Reference Publications................................................................................................5
Table 2-1, Electrical Loads .........................................................................................................27
Table 4-1, Maintenance Intervals..............................................................................................103
Table 4-2, Discontinued Maintenance Intervals........................................................................108
Table 4-3, Nose Section Visual Inspection Procedure..............................................................109
Table 4-4, Nose Avionics Compartment Visual Inspection Procedure .....................................109
Table 4-5, Pilot’s Compartment Visual Inspection Procedure...................................................110
Table 4-6, Instrument Panel G1000 Equipment Visual Inspection Procedure..........................111
Table 4-7, Cabin Area Visual Inspection Procedure.................................................................112
Table 4-8, Rear Fuselage and Empennage Visual Inspection Procedure................................113
Table 4-9, Lightning Strike Inspection Procedure.....................................................................114
Table 4-10, GSM 86 Slip Clutch Torque Settings.....................................................................121
Table 4-11, Engine Data Check Test Equipment......................................................................126
Table 4-12, ITT Indication Test Points......................................................................................126
Table 4-13, Torque Indication Test Points................................................................................128
Table 4-14, Standby Battery Required Equipment ...................................................................132
Table 5-1, SVS Troubleshooting...............................................................................................168
Table 5-2, SVS-Related Alert Messages..................................................................................168
Table 5-3, AFCS Annunciation Troubleshooting.......................................................................170
Table 5-4, AFCS General Troubleshooting...............................................................................171
Table 5-5, Magnetometer Interference Test Sequence............................................................207
Table 6-1, Configuration Module Kit – 011-00979-00...............................................................240
Table 6-2, GRS 7800 Configuration Module Parts ...................................................................241
Table 6-3, GSU 75B Configuration Module Kit – 011-00979-20...............................................242
Table 6-4, Thermocouple Kit (011-00981-00)...........................................................................244
Table 7-1, ITT Indication Test Points........................................................................................285
Table 7-2, Torque Indication Test Points..................................................................................287
Table 7-3, N1 Indication Test Points.........................................................................................288
Table 7-4, N2 Indication Test Points.........................................................................................290
Table 7-5, Fuel Flow Indication Test Points..............................................................................291
Table 7-6, Oil Pressure Test Points..........................................................................................292
Table 7-7, Oil Temperature Test Points....................................................................................293
Table 7-8, Air Data System Test...............................................................................................302
Table 7-9, Vertical Speed Table ...............................................................................................304
Table 7-10, Required GRS/GMU Calibrations..........................................................................309
Table 8-1, RVSM Required Avionics ........................................................................................354
Table 8-2, In-Flight Altitude Hold Performance Test.................................................................360

G1000 NXi System Maintenance Manual Page 1
King Air 300 Series Revision 1
190-00716-N1
1. INTRODUCTION
Content, Scope, Purpose
This document provides Instructions for Continued Airworthiness (ICA) for the NXi configuration
of the Garmin G1000 Integrated Flight Deck including the GFC700 Automatic Flight Control
System (AFCS) as installed in the Beechcraft King Air 300 Series, under STC SA01535WI-D.
This document satisfies the requirements for continued airworthiness as defined by 14 CFR
Part 23.1529 and Appendix G. Information in this document is required to maintain the
continued airworthiness of the G1000 and GFC700.
Throughout this document, the GFC 700 autopilot system is included in the G1000NXi system
description and is identified separately only when needed.
References to “300 Series” throughout this document include 300, 300C, B300, B300C,
B300GT, and B300CGT models. Items in this document that are aircraft model(s) specific will
identify the model(s) instead of “300 Series”.
References to “Beechcraft” throughout this document include other Manufacturer names
including Textron Aviation, Hawker Beechcraft, and Raytheon.
Applicability
This document applies to all King Air Model 300 Series aircraft equipped with the G1000NXi
system. All G1000NXi King Air 300 Series airplanes are configured per General Arrangement
drawing 005-00629-N2 Rev 1 or subsequent.
Modification of an aircraft by this Supplemental Type Certificate (STC) obligates the aircraft
operator to include the maintenance information provided by this document in the operator’s
Aircraft Maintenance Manual and the operator’s Aircraft Scheduled Maintenance Program.
Aircraft modified by this STC have been shown to qualify for operation in Reduced Vertical
Separation Minimum (RVSM) airspace as a group aircraft in accordance with Title 14 of the
Code of Federal Regulations (14 CFR) Part 91, Appendix G, “Operations in Reduced Vertical
Separation Minimum (RVSM) Airspace”, and Federal Aviation Administration (FAA) Document
No. 91-RVSM, Change 2 dated 2/10/2004, “Guidance Material On the Approval Of
Operators/Aircraft For RVSM Operations”. This qualification is based on analysis of the
configuration and performance of the air data, automatic altitude control, altitude alerting, and
altitude reporting systems. These systems must be maintained in accordance with the
inspections and tests specified in this document and other current maintenance practices to
guarantee continued compliance to RVSM specifications.
Identifying an STC Configuration
The General Arrangement drawing lists the G1000 System Software Version numbers approved
for this STC. This section shows where to find the installed software version and airframe type
in the G1000 system for service if the technician is unsure of what G1000 software and
configuration is installed.
1. Place the G1000 system in configuration mode (reference Section 3.1 for instructions).
2. On PFD1, go to the MANIFEST CONFIGURATION page in the SYSTEM page group.
In the SYSTEM field the G1000 system software part number and version number that
is installed is shown.
3. Next go to the GDU page group and turn to the AIRFRAME CONFIGURATION page.
The airframe series, engine, and prop types are listed in the AIRFRAME box.

G1000 NXi System Maintenance Manual Page 2
King Air 300 Series Revision 1
190-00716-N1
EXAMPLE:
For a configuration that loaded “King Air B300 PT6A-60A”, the AIRFRAME section will display:
SERIES: B300
ENGINE: PT6A-60A
PROP: HARTZELL 4
Organization
The following outline briefly describes the organization of this manual:
Section 2: System Description
Provides a complete description of the type design change associated with installing the G1000
integrated cockpit system in the King Air 300 Series. An overview of the G1000 system
interface is also provided.
Section 3: Software and Configuration
Provides software and configuration loading instructions for a complete system software load.
Section 4: Instructions for Continued Airworthiness
Provides maintenance instructions for continued airworthiness of the G1000 system.
Section 5: Troubleshooting
Provides troubleshooting information to aid in diagnosing and resolving potential problems with
the G1000 system.
Section 6: Equipment Removal & Replacement
Gives instructions for the removal and replacement of G1000 equipment.
Section 7: Garmin G1000 LRU Replacement/Configuration & Testing
Gives instructions for loading software, configuring, and testing of G1000 equipment.
Section 8: Subsystem Functional Checks
Gives instructions for testing G1000 subsystems.
Section 9: G1000 System Return to Service Procedure
Specifies return-to-service procedures to be performed upon completion of maintenance of the
G1000 system.

G1000 NXi System Maintenance Manual Page 3
King Air 300 Series Revision 1
190-00716-N1
Definitions/Abbreviations
ADAHRS: Air Data and Attitude Heading Reference System
ADF: Automatic Direction Finder
ADS-B: Automatic Dependent Surveillance – Broadcast
ADTS: Air Data Test Set
AFCS: Automatic Flight Control System
AFM: Airplane Flight Manual
AFMS: Airplane Flight Manual Supplement
AHRS: Attitude Heading Reference System
CDU: Control Display Unit
CFR: Code of Federal Regulations
DME: Distance Measuring Equipment
EAU: Engine/Airframe Unit
ESP: Electronic Stability and Protection
FIS-B: Flight Information Services – Broadcast
FS: Flight StreamTM
GPS: Global Positioning System
GPWS: Ground Proximity Warning System
HSDB: High-Speed Data Bus (Ethernet)
IAU: Integrated Avionics Unit
ICS: Inter-Com System
ITT: Interstage Turbine Temperature
LRU: Line Replaceable Unit
MFD: Multi-Function Display
MMC: Multi-Media Card
OAT: Outside Air Temperature
PED: Personal Electronic Device
PFD: Primary Flight Display
PVT: Position Velocity Time
RVSM: Reduced Vertical Separation Minimum
STBY: Standby
STBY ATT: Standby Attitude Indicator
STBY ALT: Standby Altimeter
STBY A/S: Standby Airspeed Indicator
STC: Supplemental Type Certificate
TAWS: Terrain Awareness & Warning System
TIS: Traffic Information Services
TIS-A: Traffic Information Services – A
TIS-B: Traffic Information Services – Broadcast
WAAS: Wide Area Augmentation System
VHF: Very High Frequency

G1000 NXi System Maintenance Manual Page 4
King Air 300 Series Revision 1
190-00716-N1
Units of Measure
Unless otherwise stated, all units of measure are English units.
Publications
The following documents are required by this maintenance manual to perform maintenance. It
is the responsibility of the owner / operator to ensure latest versions of these documents are
used during operation, servicing or maintenance of the airplane.
Table 1-1, Required Documents
Part Number
Garmin Document
005-00629-00 Master Drawing List, Garmin G1000/GFC 700 in Beechcraft Model 300/B300 Series King
Air
005-00629-N2
General Arrangement, G1000/GFC 700, King Air 300/B300 Series
005-00629-40
Main Instrument Panel Installation, King Air 300/B300
005-00629-41
Pedestal Re-Configuration, King Air 300/B300
005-00629-42
GWX Radar Install, King Air 300/B300
005-00629-43
Antenna Install, King Air 300/B300
005-00629-44
Electrical Equipment Install, Nose Bay, King Air 300/B300
005-00629-45
Roll Servo Install, King Air 300/B300
005-00629-46
Yaw & Pitch Servo Install, King Air 300/B300
005-00629-48
Pitch Trim Servo Install, King Air 300/B300
005-00629-49
Magnetometer Install, King Air 300/B300
005-00629-50
OAT Sensor Install, King Air 300/B300
005-00629-52
Optional Equipment Install, Tail Shelf, King Air 300/B300
005-00629-54
Wire Harness Installation, Nose, King Air 300/B300
005-00629-55
Wire Harness Installation, Cabin, King Air 300/B300
005-00629-56
Wire Harness Installation, Tail, King Air 300/B300
005-00629-57
Control Wheel Modification, King Air 300/B300
005-00629-59
Circuit Breaker Panel Modification, King Air 300/B300
005-00629-61
Lighting Modification, King Air 300/B300
005-W0226-00
Wiring Diagram, G1000/GFC 700, King Air 300/B300
Beechcraft Documents
101-590097-9
Super King Air 300 and 300LW Maintenance Manual
101-590097-15
Super King Air 300 and 300LW Wiring Diagram Manual
101-590097-161
Super King Air 300 Airworthiness Limitations Manual
130-590031-7
Super King Air B300 and B300C Electrical Wiring Diagram Manual
130-590031-11
Super King Air B300 and B300C Maintenance Manual
130-590031-197
Super King Air B300 and B300C Avionics Wiring Diagram Manual (Proline 21)
130-590031-211
Super King Air B300 and B300C Airworthiness Limitations Manual
101-590097-13
King Air Series Component Maintenance Manual
98-39006
King Air Structural Inspection and Repair Manual
Other Documents
85-292-1-1033
Signal Conditioner Installation Manual (Meggitt Sensing Systems)
9016182 Mid-Continent Instruments - Installation Manual and Operating Instructions,
4200 Series Attitude Indicator
TP-336
L-3 Avionics Systems – Emergency Power Supply Installation Manual, PS-835

G1000 NXi System Maintenance Manual Page 5
King Air 300 Series Revision 1
190-00716-N1
The following publications are recommended to be on hand during the performance of
maintenance activities.
Table 1-2, Reference Publications
Part Number Garmin Document
190-00716-N2 Airplane Flight Manual Supplement, G1000/GFC 700, Textron Aviation King Air
300/300LW King Air
190-00716-N3 Airplane Flight Manual Supplement, G1000/GFC 700, Textron Aviation King Air
B300/B300C King Air
190-02042-00 G1000 Cockpit Reference Guide for the King Air 300 Series
190-00355-04 GDL 69 Series SiriusXM Satellite Radio Activation Instructions
190-00303-10 GRS77/GMU44 Installation Manual
190-00303-72 GSA8X/GSM85(A) Installation Manual
190-00303-83 GSM 86 Servo Gear Box Installation Manual
190-00313-63 GMU 44 Installation Location Magnetic Interference Survey Procedure
190-00313-12 Circular Connector (and Configuration Module) Installation Instructions
190-01091-00 GRS 7800 Installation Manual
190-01277-00 GRA 5500 Installation Manual
190-01639-00 GSU 75 Installation Manual
Generic installation manuals for individual Garmin LRUs are also available through the ‘Dealer
Resource Center’ section of the Garmin web site; refer to Section 1.6 for details.

G1000 NXi System Maintenance Manual Page 6
King Air 300 Series Revision 1
190-00716-N1
Revision and Distribution
This document is required for maintaining the continued airworthiness of the aircraft. When this
document is revised, every page will be revised to indicate current revision level.
Garmin Dealers may obtain the latest revision of this document on the Garmin Dealer Resource
Center website.
Owner/operators may obtain the latest revision of this document from the https://fly.garmin.com/
Support page, or by contacting a Garmin dealer, contacting Garmin Product Support at 913-
397-8200, toll free 866-739-5687, or using around the world contact information on
https://fly.garmin.com/.
A Garmin Service Bulletin describing the revision to this document will be sent to Garmin
dealers if the revision is determined to be significant.

G1000 NXi System Maintenance Manual Page 7
King Air 300 Series Revision 1
190-00716-N1
2. SYSTEM DESCRIPTION
Equipment Descriptions
GFC 700 Operation
The GFC 700 is a fail-passive digital flight control system composed of multiple G1000 LRUs
and servos. The following functions are provided by the GFC 700 in this installation:
•Flight Director
•Autopilot
•Pitch Trim
•Yaw Damper
•Electronic Stability and Protection (optional)
Flight Director:
The Flight Directors operate within the GIA 63Ws and use data from the G1000 system,
including air, attitude and flight data, to calculate commands for display to the pilot and for the
Autopilot. Flight director command bars and mode annunciations are sent to the PFDs through
a high-speed Ethernet connection for display to the pilot and copilot. The flight directors
operate independently of the autopilot and allow the pilot to hand-fly the command bars, if
desired. The GMC 710 allows the pilot to switch the active director between flight director #1
(GIA1) and flight director #2 (GIA2).
Autopilot:
The autopilot operates within one high-speed GSA 80 servo (pitch trim), two GSA 80 servos
(pitch and roll), and one GSA9000 servo (yaw). Flight director data is processed within the
servos and turned into aircraft flight control surface commands. The autopilot cannot operate
unless the flight director is engaged.
Manual Electric Trim:
When the autopilot is not engaged, the pitch trim servo may be used to provide a Manual
Electric Pitch Trim (MEPT) function. This allows the pilot or co-pilot to adjust pitch trim from the
PITCH TRIM switch on the control wheel in lieu of using the elevator trim wheel. Trim speeds
are scheduled to provide easier control over a wide speed or configuration range. The PITCH
TRIM switch is split into two halves. The left half arms MEPT. The right half controls direction.
Both halves must be actuated at the same time to command the pitch trim servo to operate. If
only one half of the PITCH TRIM switch is actuated for more than 3 seconds, a red PTRM
message will appear on the PFDs.
Yaw Damper:
The yaw damper reduces Dutch roll tendencies and coordinates turns. It can operate
independently of the autopilot and may be used during normal hand-flight maneuvers.
Electronic Stability and Protection:
Electronic Stability and Protection (ESP) is an optional function that is intended to assist the
pilot in maintaining the airplane in a safe flight condition within the aircraft flight envelope. This
envelope is defined by pitch, roll, and airspeed. This feature is only active when in flight and the
autopilot is off.
