GPSMAP® 2106/2110
quick reference guide
Finding an Item
To find an item from your current location:
1. From any page, press FIND to open the Find From Current Position Page.
2. Highlight a category, and press ENTER. For some categories, you might need to select
multiple subcategories.
3. Highlight an item in the search results list, and press ENTER. The Review Page
appears showing item information, map location, chart name, distance and bearing,
and options for creating a waypoint or viewing the next item in the search results list.
Marking a Waypoint
To mark your current location:
1. Press and hold ENTER/MARK until the Review
Waypoint Page appears. The GPSMAP 2106/2110
captures your current location, and then creates a
default name and symbol for the new waypoint.
2. To accept the waypoint with the default
information, press ENTER. To change any
waypoint information, highlight the appropriate field,
and press ENTER.
To create a new waypoint from a map feature:
1. Use the map pointer to highlight a map feature.
2. Press and release ENTER/MARK to capture the
pointer location and open the Review Page.
3. Press the Create Wpt soft key to open the Review
Waypoint Page.
4. To accept the waypoint with the default information,
press ENTER, or to change any waypoint information,
highlight the appropriate field and press ENTER.
Navigating to a Destination
To navigate to a destination
1. Press NAV to access the Navigation menu.
2. Highlight Go To Point, Follow Route, Follow Track, or TracBack, and press ENTER.
3. Use the ROCKER to highlight a point, track, or route from the list, and press ENTER.
4. If you selected a point, press the Go To soft key. If you selected a route or saved track,
choose from the selections, and press ENTER.
5. Follow the magenta route created on the Map Page. You can also use the Compass
Page to help you navigate.
Using the MOB (Man OverBoard) Feature
The Man OverBoard (MOB) function simultaneously marks and sets a course back to the
marked location for quick response to emergency situations.
To start the MOB function:
1. Press and hold NAV/MOB. A message appears
asking you if you want to begin navigation to the
MOB waypoint.
2. Press ENTER to begin navigating to the MOB
location.
3. To stop navigation to the MOB location, press
NAV, highlight Stop Navigation, and press
ENTER.
To stop navigation to the MOB location:
1. Press NAV/MOB.
2. Highlight Stop Navigation, and press ENTER.
Review Waypoint Page
Review Map Point Page
Review Waypoint PageFind From Current Position Page
Man OverBoard
Navigation Menu Navigation on the Map Page

To turn on the GPSMAP 2106/2110:
1. Press and hold the POWER key.
2. When the I Agree on-screen button is highlighted, press ENTER to acknowledge the
warning and open the Map Page.
Startup/Shutdown Sequence
To change a setting using the Main Menu:
1. From any page, press and hold ADJ/MENU
to open the Main Menu.
2. Use the ROCKER to select a tab, and then
press right or left on the ROCKER to select a
sub tab.
3. Highlight the field you want to change, and
press ENTER.
4. Make any changes, and press ENTER.
5. Press QUIT to return to the main page.
Using the Main Menu
ADJ—press to show available options and features for the current
function.
MENU—press and hold to open the Main Menu.
POWER/BACKLIGHT—press and hold to turn the unit on or off. Press
and release to adjust the screen backlighting.
PAGE—press to cycle through the main pages in sequence or return
from a sub page to a main page.
QUIT—press to return to a previous page, restore a data field’s
previous value, or exit out of menus.
ENTER—press to select highlighted fields, confirm menu options, or
enter data.
MARK—press and hold for two seconds to capture your current location
and open the Review Waypoint Page.
NAV—press and release to access navigation options.
MOB (Man OverBoard)—press and hold to mark your current location
and instantly set a return course.
ZOOM—press up to increase, or press down to decrease the range of
the Map Page, Highway Page, and other range-related functions.
ROCKER—press up, down, right, or left to move through lists,
highlight fields, select options and locations, enter data, or move
the map pointer.
FIND—press to initiate the Find option, so you can search for user
points, map items, and any optional data card information.
DATA—press to toggle the display of a main page with or without
function windows and data fields.
CNFG—press and hold to open the Configuration window to customize
a main page.
Using the GPSMAP 2106/2110 Keypad
190-00677-01 Rev. A © Copyright 2006 Garmin Ltd. or its subsidiaries Printed in Taiwan
The GPSMAP 2106/2110 contains four main pages. Additional main pages appear as you add
optional hardware. Press PAGE to view each page.
Viewing Main Pages
Adjusting the Backlight
To adjust the backlight level:
1. Press and release the POWER key.
2. Press up or down on the ROCKER to
adjust the backlight level.
3. Press ENTER to quit.
To turn off the GPSMAP 2106/2110:
Press and hold the POWER key.
Map Page Map Split Page
Highway PageCompass Page
Highest Selectable Lowest
Warning Page Map Page
