Garmin 295W Instruction manual

L
See the Important Safety and Producllnfomwlion guide in the product box for product warnings and other
Imponant information.
Your nuvi Unit
Power and USB
connector
--Speaker
RESET button
<.9 Power key:
Slide to the left to turn the nOvi on/off;
slide to the right to lock the screen
Check your state and local traffic laws before mounting. Currently. some state la"s prohibit drivers from using
suction mounts or other devices on their windshIelds that could obstruct the driver"s vision while operating
motor 'ehicles. Other Garmin dashboard or friction mounting options should be used. See the Important SOre"·
and PrOdllCllnrormalion guide.
<1V 205vV Sef/eS q lick ~fdrt rr r,UBI

Step 1: Mount Your nuvi
Select a suitable location to mount your
nlivi on your windshield. Clean and dry
the suction cup and the selected area of
your windshield.
1. Plug the power cable into the back of
your nuvl.
2. Fit the ball on the end of the mount
into the round socket on the cradle and
press firmly until they snap together.
3. Place the suction cup on the
windshield, and flip the lever back
toward the windshield.
4. Press the bottom of your nOvi into the
cradle, and snap the top of the nOvi
into place.
5. Plug the power cable into a power
outlet in your vehicle. Your nOvi should
turn on automatically if it is getting
power.
You can also mount your nlivi to your
dashboard. See pages 13-14 for more
information.
!lilVl 2
fJ
5N Senes qUick "tart fTIan lal
Suction-cup mount
.-..-- Vehicle power
cable
Step 2: Configure Your nuvi
To tum your nlivi on, slide the
6 Power key to the left. Follow the
on-screen instructions. To tum your nlivi
off, slide the 6 Power key to the left.
Step 3: Acquire Satellites
Before the nlivi can find your current
location and navigate a route, you must
do the following:
3

Help When You Need It
To get more information when and where
you need it, use the built-in Help system
in your niivi. Touch Tools> Help. Touch
a topic to view infonnation about it.
o Touch to adjust the volume.
o Touch to open the Tools menu.
\\AR'II:"IG: ThIS product conlains a non-user-
replaceable lithium-ion battery. See the Imporllll1/
Salim' £Il1d ProdllcT IlI/il/'II/lllioll guide in the product
box for important battery safety information.
How to Charge Your nuvi
• Connect the vehicle power cable to
your niivi and to a power outlet in your
vehicle. The vehicle key may need to
be turned to ONI ACC for the nuvi to
charge.
• Connect an AC adapter (optional
accessory) to the niivi and a wall outlet.
• Connect your nOvi to a computer using
a USB cable (optional accessory). The
computer must be on for the nOvi to
charge.
_ r.,.
View map
o 0.
Where to?
:lJ1] ,_~ 4:07:
1. Go outdoors to an open area, away
from tall buildings and trees.
2. Turn the nuvi on. Acquiring satellite
signals can take a few minutes.
The.. I bars indicate satellite strength.
When at least one of the bars is green,
your nuvi has acquired atellite signals.
Now you can select a destination and
navigate to it.
Step 4: Use Your nuvi
o f}
@) O-
N
Menu Page
o GPS satellite strength
f} Battery status
@) Touch to find a destination.
o Touch to view the map.

Finding a Destination
Finding a Restaurant
1. On the Menu page, touch Where to? >
Points of Interest> Food.
2. Select a category. Touch II and II
to see more choices.
3. Select a destination. The Go! page
displays.
4. Touch Go!.
7. Select the address if necessary. The
Go! page displays.
8. Touch Go!.
Using the Go! Page
After you have found a location, your
nUvi displays the Go' page.
Garmln International
o Touch Route Info to view a
tum-by-turn map to this location.
8 Touch Go! to create a hlrn-by-turn
route to this location.
@) Touch Map to view this location and
sun·ounding areas on the map.
o Touch Save to save this location to
your Favorites.
Finding an Address
1. On the Menu page, touch Where to? >
Address.
2. Select a country, state, or province if
necessary.
3. Touch Spell City, and then enter
the name of a city until a list of cities
appears. If you are not sure of the city,
touch Search All.
4. Enter the address number, and then
touch Done.
5. Enter the street name, and then touch
Done.
6. Select the street.
1200 E151st St
OI.tl"o. KS 66062
913·397·8200
oRout.lnlg
[)istal'lCf!. 19 otni
TIme: 23 fTlIllS
Go!

Changing the Search Area
Your nuvi automatically searches for
places near your current location. To
search in adifferent area:
1. Touch Where to? > Near.
2. Select an option, and touch OK.
Setting Your Home
Location
Set your home location for the place you
return to most often.
1. To set your home location, touch
Where to? > Go Home.
2. Select an option:
• Enter your address.
• Use your current location.
• Choose from a list of recently found
locations.
Going Home
To na\ igate home after you have et your
home location, touch Where to? > Go
Home.
Changing Your Home
Location
To set adifferent home location:
1. Touch Tools> My Data> Set Home
Location.
2. Select an option:
• Enter your address.
• Use your current location.
• Choose from a list of recently found
locations.
To edit information about your home
location:
1. Touch Where to? >Favorites> All
Favorites>
Home.
2. Touch Edit, enter your changes, and
then touch Done.
Adding a Stop to Your
Route
You can add an additional stop (called a
via point) to your route. The nuvi gives
you directions to the via point, and then
to your final destination.

1. While navigating a route, touch
Menu> Where to?
2. Search for and select another location
to add to the route. Touch Go!.
3. Touch Add as Via Point to stop at this
location before your final destination.
Touch Set as new destination
to make the location your final
desti nation.
Taking a Detour
If you need to take a detour when you are
navigating a route, return to the Menu
page and touch Detour. The niivi creates
a new route if possible. If the route you
are currently taking is the only reasonable
option, the niivi might not calculate a
detour.
Stopping the Route
To top navigating a route, touch
Menu> Stop.
Using Photo Navigation
Panoramio'" provides photos that include
location infonnation called geotags. You
can load these photos onto your niivi or
SD card, and then create routes to them.
Visit http://connect.garmin.comlphotos
for more information.
To load geotagged photos to your
nuvi:
1. Connect your niivi to your computer.
2. Go to http://connect.garmin.com
Iphotos, and select a photo.
3. Select Send to Garmin Device to
save the photo to your niivi.
To navigate to aphoto:
1. Touch Where to? >Favorites>
Panoramio Photos. Photos you have
saved on the niivi drive or memory
card are listed.
2. Select a Panoramio photo.
3. Touch Go! to navigate to the location.
Touch Map to view the location on the
map.

Using the Map Page
Map Page
-.:·02fJ
Touch View map to open the Map page. Touch the map and drag to view different
parts of the map. The vehicle icon shows your current location. Touch to
view the Where Am I'l page, which provides infonnation about your current location,
including nearby hospitals, police stations, and fuel. You can also save your current
location as a Favorite.
After you touch Go!. the Map page opens with your route marked with a magenta
line. As you travel, your nUvi guides you to your destination with arrows on the map
and directions at the top of the Map page. A checkered flag marks your destination. If
you depart from the original route. your nUvi recalculates the route.
o Touch the tum indicator to view
infonnation about the next tum in your
route and to repeat the in tructions for
your next tum.
@ Touch the text bar to preview the
upcoming nlll1S in your route.
@) Touch the traffic icon to open the Traffic
menu. See page 9.
o Touch ~ to zoom in. Touch a to zoom out.
o Touch Speed to \ie\\ infoll11ation about your trip. such a the odometer.
o Touch Menu to return to the Menu page.
fI Touch Arrival to di playa map of your route.

Using FM Traffic
Use an FM TMC (Traffic Message
Channel) traffic receiver to receive traffic
information broadcast over the FM Radio
Data System. The traffic receiver is
included in some nlivi packages.
The traffic receiver is integrated in the
vehicle power cable.
To power outlet
in vehicle
To power
connector on
niivi
FM TMC Traffic Receiver
If the nlivi is connected to the traffic
receiver, connected to vehicle power,
and you are in a coverage area. the nlivi
can receive traffic delay infollnation. For
more infollnation. go to \vww.garmin
.com traffic.
e NOTE: Garmin is not responsible for
• the accuracy of the traffic infon11ation.
The FM traffic receiver receives signals
from the traffic service provider and
shows that information on your nuvi.
Traffic in Your Area
When you are receiving traffic
information, a Traffic icon appears in the
upper-left comer of the Map page. The
Traffic icon changes color to indicate
the severity of traffic conditions on
your route or the road you are currently
driving on.
Traffic icon

Severity Color Code
The color of the Traffic icon indicates the
severity of the traffic delay.
Color Description
Meaning
=
-'
Traffic is flowing
Low severity
normally.
Green
-
Medium
Traffic is slightly
,
severity
congested.
Yellow
S
High
Traffic is heavily
congested or
Red
severity
stopped.
10
Traffic on Your Route
When calculating your route, the
niivi examines the current traffic and
automatically optimizes the route for
the shortest time. If a severe traffic
delay occurs on your route while you
are navigating, the niivi automatically
recalculates the route. You might still
be routed through traffic if no better
alternative routes exist.
Ifa non-severe traffic delay occurs on
your route, the Traffic icon displays a tab
that shows how much time the delay has
added to your route. This time is already
included in your estimated arrival time.
To manually avoid traffic on your
route:
1. On the Map page, touch the Traffic
Icon.
2. Touch Traffic On Route.
3. Touch the arrows to view other traffic
delays on your route, if necessary.
4. Touch Avoid to avoid the traffic delay.
nu~ 2f)'jN Ser e qUIck ,,'art 'T'anual

Viewing the Traffic Map
The Traffic map shows color-coded
traffic flow and delays on nearby roads.
1. On the Map page, touch the Traffic
icon.
2. Touch Show Traffic Map to view the
traffic incidents on a map.
To return to the nonnal map from the
Traffic map, touch the Traffic icon, and
then touch Show Normal Map.
Viewing Traffic Delays
1. On the Map page, touch the Traffic
Icon.
2. Touch Traffic Search to view a list of
traffic delays.
3. To view details, touch an item in the
list. If there is more than one delay,
touch the arrows to view additional
delays.
Traffic Subscriptions
To add or renew atraffic subscription,
touch Tools> Settings> Traffic. For
more infonnation, go to www.gannin
.com/fmtraffic.
@ NOTE: You do not need to activate
the subscription included with your
FM traffic receiver (if it came with
one). The subscription activates
automatically after your niivi acquires
satellite signals while receiving traffic
signals from the pay service provider.

Customizing Your nuvi
Securing Your nuvi
Garrnin Lock'" is a security feature that
locks your niivi. When you hIm your
nlivi on, you can unlock it by entering a
PIN or by going to the place you have set
as your security location. Your security
location is a location that you return to
often, such as your office. Your nlivi
automatically unlocks when you are at
your security location.
@ NOTE: Ifyoll forget your PIN and
your security location, you l11ust
send your nOvi with a valid product
registration or proof of purchase to
Gannin to be unlocked.
To secure your ni.ivi:
1. Make sure that you are at your security
location and that your nuvi is receiving
satellite signals.
2. Touch Tools> Settings> Security.
3. Touch the button below Garmin Lock.
'2
4. Enter a four-digit PIN.
5. Touch Set.
Adjusting the Volume
Touch Volume. Touch (2) to lower the
volume or 0 to raise the volume.
Adjusting the Screen
Brightness
Touch Tools> Settings> Display>
Brightness. Touch [] to lower the
brightness or + to raise it.
Locking the Screen
To prevent accidental screen taps, slide
the 6 Power key to the right (611). To
unlock the screen, slide the 6 Power
key to the center position.
myGarmin™
Go to http://l1ly.garl1lin.col1l to access the
latest services for your Garmin products
and to register your niivi.
N ~ e~ q I< tar' rrar

Appendix
Resetting Your nuvi
If your nilvi stops responding, tum the
nilvi off, and then tum it back on. If this
does not help, reset your nilvi. Press and
hold the RESET button on tbe bottom of
the nilvi for several seconds.
Clearing User Data
CAUTION: This deletes all user-
entered infonnation.
1. Hold your finger on the lower-right
corner of the nOvi screen while turning
on the nOvi.
2. Keep your finger pressed until the
pop-up window appears.
3. Touch Yes to clear all user data.
All original settings are restored. Any
items that you have saved are erased.
Extras and Optional
Accessories
F or more infomlation about optional
accessories, go to https://buy.garmin
.com/shop or www.gamlin.com/extras. or
contact your Garmin dealer.
Mounting on Your
Dashboard
Use the enclosed mounting disk to
mount your nil vi on the dashboard and to
comply with certain state regulations.
It IMPORTANT: The permanent
mounting adhesive is extremely
difficult to remove after it is installed.
1. Clean and dry the dashboard where
you are placing the disk.
2. Remove the backing from the
permanent mounting adhesive on the
bottom of the disk.
3. Place the disk on the dashboard.
w1<

14
Caring for Your nuvi
Your niivi contains sensitive electronic
components that can be permanently
damaged if exposed to excessive shock
or vibration. To minimize the risk of
damage to your niivi, avoid dropping
your niivi and operating it in high-shock
and high-vibration environments.
• Do not store the niivi where prolonged
exposure to extreme temperatures can
occur, because it can cause permanent
damage.
• Do not expose the niivi to water.
Contact with water can cause the niivi
to malfunction.
• Never use a hard object or a sharp
object to operate the touch screen or
damage may result.
Cleaning Your nuvi
Your niivi is constructed of high-quality
materials and does not require user
maintenance other than cleaning. Clean
the outer casing of the niivi (not the
touch screen) using a cloth dampened
uv 205W e Ie qUi rt 'Jar al
End
~Piece
l..-- Silver
II- tip
..-
Fuse
4. Place the suction cup mount on top of
the disk. Flip the lever down (toward
the disk).
Changing the Fuse
CAUTION: When replacing the fuse,
do not lose any of the small pieces
and make sure they are put back in the
proper place.
If your ntivi will not charge in your
vehicle, you may need to replace the fuse
located at the tip of the vehicle adapter.
1. Unscrew and remove the silver or
black round end piece.
2. Remove the fuse
(glass and silver
cylinder) and replace
with a 1 A-fast blow
fuse.
3. Ensure that the silver
tip is placed in the end
piece. Screw on the
end piece.

with a mild detergent solution, and
then wipe dry. Avoid chemical cleaners
and solvents that can damage plastic
components.
Avoiding Theft
• To avoid theft, remove the niivi and
mount from sight when it is not in use.
Remove the residue on the windshield
left by the suction cup.
• Do not keep your niivi in the glove
compartment.
• Use the Garmin Lock feature. See page
12 for more information.
Declaration of Conformity
(DoC)
Hereby, Garmin declares that this
niivi product is in compliance with the
essential requirements and other relevant
provisions of Directive 1999/SfEC.
To view the full Declaration of
Conformity, see the Garmin Web site for
your Garmin product: www.garmin.com.
,UVI 295W SerieS qt"C/\ start mclfwal
Specifications
Size: 4.76 in. Wx 2.9 in. Hx 0.76 in. 0
(12.1 x 7.4 x 1.95 em)
Weight: OJ 7 pounds (172.5 g)
Display: 4J in. diagonal (10.9 em);
480 x 272 pixels; bright, J 6-bit LCD, white
backlight, touch screen
Temperature: See the Important Safety and
Product Information guide.
Data storage: Internal memory and optional
removable SO card.
Computer interface: USB mass storage
Power input: DC vehicle power using
included vehicle power cable
Usage: 5 W max.
Charge time: Approximately 4 hours (E
Battery life: up to 4 hours
CAUTION: The niivi is not
waterproof.
For a complete list of specifications, see
the Web page for your product on the
Garmin Web site: www.garmin.com.
15

Software License Agreement
BY USING THE PRODUCT. YOU AGREE TO BE BOU D BY THE TERMS A D CO DITlONS OF THE
FOLLOWING SOFTWARE LICENSE AGREEMENT. PLEASE READ THIS AGREEME T CAREFULLY.
Gannin grants you a limited license to use the software embedded in this device (the "Software") in binary
executable fonn in the nonnal operation of the product. Title. ownership rights. and intellectual property rights in
and to the Software remain in Gamlin.
You acknowledge that the Software is the property ofGannin and is protected under the United States of America
copyright laws and international copyright treaties. You further acknowledge that the structure, organization. and
code of the Software are valuable trade secrets of Gannin and that the Software in source code fonn remains
a valuable trade secret ofGannin. You agree not to decompile, disassemble, modify, reverse assemble. reverse
engineer, or reduce to human readable fonn the Software or any part thereof or reate any derivative works based
on the Software. You agree not to export or re-export the Software to any country in violation of the export control
laws of the United States of America.
•
GARMINr.
In the USA, contact Garmin Product Support by phone: [phone] or
[phone]; or go to www.garmin.com/support. In Europe, contact Garmin
(Europe) Ltd. at +44 (0) 870.8501241 (outside the UK) or 0808 2380000 (in the UK).
Garmin® and nuvi® are trademarks of Garmin Ltd. or its subsidiaries, registered in the
USA and other countries. Garmin Lock
N
and myGarmin N are trademarks of Garmin
Ltd. or its subsidiaries and may not be used without the express permission of Garmin.
RDS- TMC Traffic Information Services France © ViaMichelin 2006.
© 2008 Garmin Ltd. or its subsidiaries
www.garmin.com
March 2008 Part Number 190-00909-00 Rev. B Printed in Taiwan

Garmin
e
is a trademark of Garmin ltd. or its subsidiaries, registered in the USA and other countries. These trade-
marks may not be used without the express permission of Garmin.
NAVTEQ is a trademark in the U.S. and other countries. All other company names and trademarks mentioned or
referenced in this documentation are the properties of their respective owners. All rights reserved.
•
GARMIN,.
software), FAR 52.227-19 (JUN 1987) (commercial
computer software clause for civilian agencies),
DFARS 252.227-7015 (NOV 1995) (DOD technical
data - commercial items clause); FAR 52.227-
14 Alternates I, II, and III (JUN 1987) (civilian
agency technical data and noncommercial computer
software clause); and/or FAR 12.21 I and FAR
12.212 (commercial item acquisitions), as applicable.
In case of conflict between any of the FAR and
DFARS provisions listed herein and this License, the
construction that provides greater limitations on the
Government's rights shall control. The contractor/
manufacturer is Garmin International, Inc., 1200 East
151st Street, Olathe, KS 66062, USA and NAVTEQ
North America LLC, 222 Merchandise Mart Plaza,
Suite 900, Chicago, Illinois 60654.
conflict of laws provisions, or (ii) the United Nations
Convention for Contracts for the International Sale
of Goods, which is explicitly excluded. You agree
to submit to the jurisdiction of Illinois for any and
all disputes, claims and actions arising from or in
connection with the Data provided to you hereunder.
Government End Users. If End User is an agency,
department, or other entity of the United States
Government, or funded in whole or in part by
the U.S. Government, then use, duplication,
reproduction, release, modification, disclosure
or transfer of the Product and accompanying
documentation is subject to restrictions as set forth
in DFARS 252.227-70I4(a)(I) (JUN 1995) (DOD
commercial computer software definition), DFARS
27.7202-1 (DOD policy on commercial computer
KS 66062, USA; (3) Garmin (EUROPE) LTD.,
LIBERTY HOUSE, HOUNSDOWN BUSINESS
PARK, SOUTHAMPTON, S040 9RB, UNITED
KINGDOM; OR (4) Garmin CORPORATION
CUSTOMER SERVICE, No. 68, JANGSHU 2nd
ROAD, SHIJR, TAIPEI COUNTY, TAIWAN.
License Terms And Conditions
Garmin (''we'' or "us") provides you with storage
media containing the computer Software (the
"Software") and the embedded or accompanying
digital map Data, including any "online" or
electronic documentation and printed materials
(together called the "Product" for purposes of this
License Agreement), and grants you a limited, non-
exclusive license to use the Product in accordance
with the terms of this Agreement. You agree to use
this Data together with the Garmin product for solely
personal, or if applicable, for use in your business'
internal operations, and not for service bureau,
time-sharing, resale or other similar purposes.
Accordingly, but subject to the restrictions set forth
in the following paragraphs, you may copy this
Data only as necessary for your use to (i) view it,
and (ii) save it, provided that you do not remove
any copyright notices that appear and do not modify
the Software or Data in any way. You agree not
to otherwise reproduce, copy, modify, decompile,
disassemble, reverse engineer or create derivative
works of any portion of the Product, and may not
•
GARMIN,.
NAVTEQ END-USER LICENSE AGREEMENT
The software embedded in your Garmin product
(the "Software") is owned by Garmin Ltd. or its
subsidiaries ("Garmin"). The third-party map data
embedded in or accompanying your Garmin product
(the "Data") is owned by NAVTEQ North America
LLC and is licensed to Garmin. Both the Software
and Data are protected under copyright laws and
international copyright treaties. The Software and
Data are licensed, not sold. The Software and
Data are provided under the following license and
are subject to the following terms and conditions
which are agreed to by End User ("you" or "your"),
on the one hand, and Garmin and its licensors
(including their licensors and suppliers) and affiliated
companies on the other hand.
IMPORTANT: CAREFULLY READ THIS
LICENSE BEFORE USING THIS PRODUCT.
INSTALLING, COPYING, OR OTHERWISE
USING THIS PRODUCT INDICATES YOUR
ACKNOWLEDGMENT THAT YOU HAVE
READ THIS LICENSE AND AGREE TO ITS
TERMS. IF YOU DO NOT AGREE, RETURN THE
COMPLETE PRODUCT WITHIN 10 DAYS OF
. THE DATE YOU ACQUIRED IT (IF PURCHASED
NEW) FORA FULL REFUND TO ONE OF
THE FOLLOWING: (1) THE DEALER FROM
WHICH YOU PURCHASED THIS PRODUCT
(2) Garmin INTERNATIONAL, INC. CUSTOMER
SERVICE, 1200 EAST 151st STREET, OLATHE,
Printed in Taiwan
Garmin Corporation
No. 68, Jangshu 2
nd
Road, Shijr.
Taipei County, Taiwan
Garmin (Europe) ltd.
Liberty House, Hounsdown
Business Park, Southampton,
Hampshire, S040 9RB UK
www.garmin.com
Part Number 190-00883-00 Rev. A
© 2007 Garmin ltd. or its subsidiaries
Garmin International, Inc.
1200 East 151$1 Street, Olathe,
Kansas 66062, USA
November 2007

transfer or distribute it in any fonn, for any purpose,
except to the extent pennitted by mandatory laws.
Restrictions. Except where you have been
specifically licensed to do so by Garmin, and
without limiting the preceding paragraph, you may
not use this Data with any products, systems, or
applications installed or otherWise connected to or in
communication with vehicles, and which are capable
of dispatch, fleet management or similar applications
where the Data is used by a central control center
in dispatching a fleet of vehicles. In addition, you
are prohibited from renting or leasing the Data or
the Gannin products containing the Data to any
other person or .third party. Only those rental car
companies that are specifically authorized by Gannin
in writing to rent Garmin products containing the
Data to their rental customers are pennitted to rent
out such products.
No Warranty. This Product (including the Data)
is provided to you "as is," and you agree to use
it at your own risk. Garmin and its licensors
(and their licensors and suppliers) make no
guarantees, representations or warranties of
any kind, express or implied, arising by law or
otherwise, including but not limited to, content,
quality, accuracy, completeness, effectiveness,
reliability, merchantability, fitness for a particular
purpose, usefulness, use or results to be obtained
from the Product, or that the Data or server will be
uninterrupted or error- free.
Disclaimer of Warranty. GarminAND
ITS LICENSORS (INCLUDING THEIR
LICENSORS AND SUPPLIERS) DISCLAIM
ANY WARRANTIES, EXPRESS OR
IMPLIED, OF QUALITY, PERFORMANCE,
MERCHANTABILITY, FITNESS
FOR A PARTICULAR PURPOSE OR
NONINFRINGEMENT. NO ORAL OR WRITTEN
ADVICE OR INFORMATION PROVIDED BY
Garmin OR ITS SUPPLIERS AND LICENSORS
SHALL CREATE A WARRANTY, AND
YOU ARE NOT ENTITLED TO RELY ON
ANY SUCH ADVICE OR INFORMATION.
THIS DISCLAIMER OF WARRANTIES IS
AN ESSENTIAL CONDITION OF THIS
AGREEMENT. Some States, Territories and
Countries do not allow certain warranty exclusions,
so to that extent the above exclusion may not apply
to you.
Disclaimer of Liability. Garmin AND ITS
LICENSORS (INCLUDING THEIR LICENSORS
AND SUPPLIERS) SHALL NOT BE LIABLE
TO YOU: IN RESPECT OF ANY CLAIM,
DEMAND OR ACTION, IRRESPECTIVE OF
THE NATURE OF THE CAUSE OF THE CLAIM,
DEMAND OR ACTION ALLEGING ANY
LOSS, INJURY OR DAMAGES, DIRECT OR
INDIRECT, WHICH MAY RESULT FROM THE
USE OR POSSESSION OF THE INFORMATION;
OR FOR ANY LOSS OF PROFIT, REVENUE,
CONTRACTS OR SAVINGS, OR ANY OTHER
DIRECT, INDIRECT, INCIDENTAL, SPECIAL
OR CONSEQUENTIAL DAMAGES ARISING
OUT OF YOUR USE OF OR INABILITY TO USE
THIS INFORMATION, ANY DEFECT IN THE
DATA OR INFORMATION, OR THE BREACH OF
THESE TERMS OR CONDJTIONS, WHETHER
IN AN ACTION IN CONTRACT OR TORT OR
BASED ON A WARRANTY, EVEN IF Garmin
OR ITS LICENSORS HAVE BEEN ADVISED
OF THE POSSIBILITY OF SUCH DAMAGES.
Garmin'S AND ITS LICENSORS' TOTAL
AGGREGATE LIABILITY WITH RESPECT TO
ITS OBLIGATIONS UNDER THIS AGREEMENT
OR OTHERWISE WITH RESPECT TO THE
Garmin PRODUCT OR THE DATA SHALL NOT
EXCEED $1.00. Some States, Territories and
Countries do not allow certain liability exclusions or
damages limitations, so to that extent the above may
not apply to you.
Disclaimer of Endorsement. Reference to any
products, services, processes, hypertext links to
third parties or other Data by trade name, trademark,
manufacturer, supplier or otherwise does not
necessarily constitute or imply its endorsement,
sponsorship or recommendation by Garmin or
its licensors. Product and service information are
the sole responsibility of each individual vendor.
The NAVTEQ name and logo, the NAVTEQ and
NAVTEQ ON BOARD trademarks and logos,
and other trademarks and trade names owned by
NAVTEQ North America LLC may not be used in
any commercial manner without the prior written
consent ofNAVTEQ.
Export Control. You agree not to export from
anywhere any part of the Data provided to you or
any direct product thereof except in compliance with,
and with all licenses and approvals required under,
applicable export laws, rules and regulations.
Indemnity. You agree to indemnify, defend and hold
Garmin and its licensors (including their respective
licensors, suppliers, assignees, subsidiaries, affiliated
companies, and the respective officers, directors,
employees, shareholders, agents and representatives
of each of them) free and harmless from and against
any liability, loss, injury (including injuries resulting
in death), demand, action, cost, expense, or claim
of any kind or character, including but not limited
to attorney's fees, arising out of or in connection
with any use or possession by you of the Product
(including the Data).
Entire Agreement. These terms and conditions
constitute the entire agreement between Garmin (and
its licensors, including their licensors and suppliers)
and you pertaining to the subject matter hereof, and
supersedes in their entirety any and all written or
oral agreements previously existing between us with
respect to such subject matter.
Governing Law.
(a) For European Union NAVTEQ Data
The above terms and conditions shall be governed
by the laws of the Netherlands, without giving
effect to (i) its conflict of laws provisions, or (ii)
the United Nations Convention for Contracts for
the International Sale of Goods, which is explicitly
excluded. You agree to submit to the jurisdiction of
the Netherlands for any and all disputes, claims and
actions arising from or in connection with the Data
provided to you hereunder.
(b) For North American NAVTEQ Data and other
non-European Union NAVTEQ Data
The above tenns and conditions shall be governed
by the laws of Illinois, without giving effect to (i) its

© 2006-2008 Garmin Ltd. or its subsidiaries
Part Number 190-00720-0 I Rev. D
A
GARMIN,.
Important Safety and Product Information
• Warnings
no charge to the customer for parts or labor, provided that
the customer shall be responsible for any transportation
cost. This warranty does not cover failures due to abuse,
misuse, accident, or unauthorized alteration or repairs.
This product is intended to be used only as a travel
aid and must not be used for any purpose requiring
precise measurement of direction, distance, location
or topography. Garrnin makes no warranty as to the
accuracy or completeness of map data in this product.
THE WARRANTIES AND REMEDIES CONTAINED
HEREIN ARE EXCLUSIVE AND IN LIEU
OF ALL OTHER WARRANTIES EXPRESS,
IMPLIED, OR STATUTORY, INCLUDING ANY
LIABILITY ARlSING UNDER ANY WARRANTY
OF MERCHANTABILITY OR FITNESS FOR
A PARTICULAR PURPOSE, STATUTORY OR
OTHERWISE. THIS WARRANTY GIVES YOU
SPECIFIC LEGAL RlGHTS, WHICH MAY VARY
FROM STATE TO STATE.
IN NO EVENT SHALL GARMIN BE LIABLE
FOR ANY INCIDENTAL, SPECIAL, INDIRECT,
OR CONSEQUENTIAL DAMAGES, WHETHER
RESULTING FROM THE USE, MISUSE, OR
INABILITY TO USE THIS PRODUCT OR FROM
DEFECTS IN THE PRODUCT. SOME STATES DO
NOT ALLOW THE EXCLUSION OF INCIDENTAL
OR CONSEQUENTIAL DAMAGES, SO THE ABOVE
LIMITATIONS MAY NOT APPLY TO YOU.
Garrnin retains the exclusive right to repair or replace
the unit or software or offer a full refund of the purchase
price at its sole discretion. SUCH REMEDY SHALL BE
YOUR SOLE AND EXCLUSIVE REMEDY FOR ANY
April 2008
BREACH OF WARRANTY.
To obtain warranty service, contact your local Garmin
authorized dealer or call Garmin Product Support for
shipping instructions and an RMA tracking number.
Securely pack the unit and a copy of the original sales
receipt, which is required as the proof of purchase for
warranty repairs. Write the tracking number clearly on
the outside of the package. Send the unit, freight charges
prepaid, to any Garmin warranty service station.
Online Auction Purchases: Products sold through
online auctions are not eligible for rebates or other
special offers from Garmin. Online auction confirmations
are not accepted for warranty verification. To obtain
warranty service, an original or copy of the sales receipt
from the original retailer is required. Garrnin will not
replace missing components from any package purchased
through an online auction.
International Purchases: A separate warranty is
provided by international distributors for units purchased
outside the United States. This warranty is provided
by the local in-country distributor and this distributor
provides local service for your unit. Distributor
warranties are only valid in the area of intended
distribution. Units purchased in the United States or
Canada must be returned to the Garmin service center
in the United Kingdom, the United States, Canada, or
Taiwan for service.
Printed in Taiwan
Failure to avoid the foUowing potentiaUy hazardous
situations could result in an accident or collision
resulting in death or serious injury.
• When installing the unit in a vehicle, place the
unit securely so it does not obstruct the driver's
view of the road or interfere with vehicle operating
controls, such as the steering wheel, foot pedals,
or transmission levers. Do not place in front of or
above any airbag. (See diagram.)
Do 001"",001 • Do 00'.1".
where driver's ",. - . ""'" unsecured on
field of vision the vehicle
is blocked. dashboard.
Do not mount in front of an
airbag field of deployment.
• When navigating, carefully compare information
displayed on the unit to all available navigation
sources, including information from street signs,
Battery Warnings
If these guidelines are not followed, the internal lithium-
ion battery may experience a shortened life span or may
present a risk of damage to the GPS unit, fire, chemical
burn, electrolyte leak, and/or injury.
• Contact your local waste disposal department to
properly dispose of the unit/battery.
• Do not leave the unit exposed to a heat source or in
a high temperature location, such as in the sun in an
visual sightings, and maps. For safety, always
resolve any discrepancies or questions before
continuing navigation and defer to posted road signs.
• Always operate the vehicle in a safe manner. Do not
become distracted by the unit while driving, and
always be fuUy aware of aU driving conditions.
Minimize the amount of time spent viewing the
unit's screen while driving and use voice prompts
when possible. Do not input destinations, change
settings, or access any functions requiring prolonged
use of the unit's controls while driving. Pull over
in a safe and legal manner before attempting such
operations.
• The unit is designed to provide route suggestions.
It is not designed to replace the need for driver
attentiveness regarding road closures or road
conditions, traffic congestion, weather conditions, or
other factors that may affect safety while driving.
unattended vehicle on a hot day. To prevent damage,
remove the unit from the vehicle or store it out of
direct sunlight, such as in the glove box.
• Do not puncture or incinerate.
• When storing the unit for a limited length of time,
store within the following temperature range:
_4° to 140°F (-20° to 60°C). When storing the unit
for an extended time, store within the following
temperature range: 32° to 77°F W to 25°C).

• Do not operate the unit outside of the following
temperature r\ll1ge: -40 to BloF (_20° to 55°C).
NOTE: Refer to the Specifications section in your
product's owner's manual to determine if the lithium-ion
battery in your specific Garmin product is replaceable.
If this unit contains a non-user-replaceable, rechargeable
lithium-ion battery, do not remove or attempt to
remove the battery.
If
this unit contains a replaceable, rechargeable lithium-
ion battery, the following warnings also apply:
• Do not recharge the battery out of the unit or
disassemble the battery.
• Keep the used battery away from children. Do not
disassemble, puncture, or damage the battery.
• Only replace with a Garmin lithium-ion battery
pack. Using another battery presents a risk of fire or
explosion. To purchase a replacement battery, see
your Garmin dealer or the Garmin Web site.
WARNING: This product, its packaging, and its
components contain chemicals known to the State of
California to cause cancer, birth defects, or reproductive
harm. This notice is provided in accordance with
California's Proposition 65. See www.garmin.com
Iprop65 for more information.
Important Information
MAP DATA INFORMATION: One of the goals of
Garmin is to provide customers with the most complete
and accurate cartography that is available to us at a
reasonable cost. We use a combination of govemmental
and private data sources, which we identify in product
literature and copyright messages displayed to the
consumer. Virtually all data sources contain some
inaccurate or incomplete data. In some countries,
complete and accurate map information is either not
available or is prohibitively expensive.
NOTICE REGARDING WINDSffiELD
MOUNTING LEGAL RESTRICTIONS: State law in
Minnesota and Califomia prohibits or restricts drivers
from using suction mounts on their windshields while
operating motor vehicles. (See California Vehicle Code
26708(a); Minnesota Statutes Section 169.71) Other
Garmin dashboard or friction mount options should be
used when driving in those states. Many other states have
enacted restrictions against placing "non-transparent
material" upon the windshield or placing objects upon
the windshield that obstruct the driver's vision (for
example, New Jersey law currently prohibits windshield
objects that "unduly interfere" with the driver's vision
to the front or sides). Check your state and local laws
and ordinances where you drive before using the suction
cup mount on your windshield. IT IS THE USER'S
RESPONSmILITY TO USE THE GARMIN UNIT
AND MOUNTING OPTIONS IN SUCH A MANNER
THAT THE USER IS IN COMPLIANCE WITH
ALL APPLICABLE LAWS AND ORDINANCES.
Remember to always mount your Garmin unit in a
location that does not obstruct the driver's view of the
road. Garmin does not assume any responsibility for
any fines, penalties, or damages that may be incurred as
a result of disregarding this notice or as a result of any
state or local law or ordinance relating to the use of your
Garmin unit.
The California Electronic Waste Recycling Act of
2003 requires the recycling of certain electronics. For
more information on the applicability to this product, see
www.erecycle.org.
Caring for the Screen
Clean the screen with water, isopropyl alcohol, or
eyeglass cleaner: do not use cleaners containing
ammonia, which can harm the coating on the screen.
If the unit has a touch screen, follow these guidelines
as well:
• The touch screen is intended for finger operation.
• Although a PDA stylus may also be used to operate
the touch screen, never attempt this while operating
a vehicle.
• Never use a hard or sharp object to operate the touch
screen or damage may result.
European FM Transmitter Notice
Use ofFM transmitters is currently illegal in certain
European countries due to specific radio frequency
restrictions. You must check the local regulations in
all European countries in which you intend to use the
FM transmitter to ensure its legality. You accept full
responsibility for complying with all such laws and
regulations applicable in your particular country of
operation.
For a list of countries that currently prohibit the use of
FM transmitters and countries that currently require you
to obtain a license prior to using the FM transmitter, see
www.garmin.comlfm-notice.
FCC Compliance
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(I) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant
to part 15 of the FCC rules. These limits are designed
to provide reasonable protection against harmful
interference in a residential installation. This equipment
generates, uses, and can radiate radio frequency
energy and may cause harmful interference to radio
communications if not installed and used in accordance
with the instructions. However, there is no guarantee that
interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio
or television reception, which can be determined by
turning the equipment off and on, the user is encouraged
to try to correct the interference by one of the following
measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and
the receiver.
• Connect the equipment into an outlet that is on a
different circuit from the GPS unit.
• Consult the dealer or an experienced radiolTV
technician for help.
This product does not contain any user-serviceable parts.
Repairs should only be made by an authorized Garmin
service center. Unauthorized repairs or modifications
could result in permanent damage to the equipment, and
void your warranty and your authority to operate this
device under Part 15 regulations.
Industry Canada Compliance
Category I radiocommunication devices comply with
Industry Canada Standard RSS-21O. Category II
radiocommunication devices comply with Industry
Canada Standard RSS- 310.
Limited Warranty
This Garmin product is warranted to be free from defects
in materials or workmanship for one year from the date
of purchase. Within this period, Garmin will, at its sole
option, repair or replace any components that fail in
normal use. Such repairs or replacement will be made at
