Garmin GpsMap 12” User instructions

3-1-21
1 of 2
GARMIN GPSMAP 12”–COMMON SETTINGS
(FINSEEKER ONLY)
If equipped with a Garmin GpsMap 12” in a single or twin MFD (multi-function display) arrangement
and separate round gauges, the fuel level will be analog driven and displayed on the separate speed/fuel
gauge. The MFD will not give digital fuel level although fuel consumption can be monitored on the MFD if
the fuel amount is entered correctly before boating (instructions are below).
If equipped with two Garmin GpsMap 12” MFDs (multi-function displays) and no separate round
gauges, fuel level can be displayed on the MFD. All data capabilities such as maps, sonar, and vessel data
can be displayed on either screen. The screens do not have to display the same information. You can have
maps on one display and vessel information on the other.
To turn on commonly used displays:
➢Home
➢Press ‘A/V-Gauges-Controls’
➢Press ‘vessel’
➢Press and hold any unwanted box on the screen
➢Press ‘replace data’
oTo read fuel level and vessel info on MFD(s) with no separate round gauges on
instrument panel:
▪Press ‘engine’
oAny of the data in the rectangular, digital displays can be changed by:
▪Touch and hold the unwanted info box
▪Press ‘replace data’
▪Select desired data
▪‘Back’ saves the selection
oTo display fuel used during trip:
▪Touch and hold any of the rectangular digital displays
▪Press ‘replace data’
▪Press ‘trip’
▪Press ‘trip fuel used’ (to reset see below)
▪‘Back saves the selection
oFor GPS information:
▪Press ‘GPS’
▪Select ‘GPS heading’, ‘GPS position’, or ‘GPS speed’
▪‘Back’ saves the selection
oFor water depth:
▪Press ‘water’
▪Press ‘depth’
▪‘Back’ saves the selection

3-1-21
2 of 2
To enter fuel filling:
➢Home
➢Press ‘A/V-Gauges-Controls’
➢Press ‘engine’
➢Press ‘menu’
oSelect fill up tanks or add fuel or set total fuel on board or reset trip
To view charts:
➢Home
➢Charts
➢Select desired type
To view sonar:
➢Home
➢Sonar
➢Select desired type
For Garmin MFD owner’s manual:
➢Home
➢Info
➢(swipe up)
➢Owner’s manual
➢Open
Home screen –touch A/V-Gauges-Controls and then
Engine or Charts Engine screen

3-1-21
3 of 2
Replace data screen after touching and holding
unwanted data in rectangular information box Select entry screen
For Charts screen –Home/Charts/then select chart For Sonar screen –Home/Sonar/then select chart
