Gasmate AVENIR GM178-101 User manual

1
Create the ultimate outdoor kitchen by adding a
Gasmate Avenir Sink Module to your Avenir BBQ (sold
separately)
304 grade stainless steel top, fascia and cabinet doors
with powder coated cabinet trolley and shelves
Hot and cold tap mixer
Assembled dimensions (mm): 655W x 910/1068H x 575D
Important: Retain these instructions for future use.
5201-07/20
Gasmate® is a registered trademark of: Sitro Group Australia Pty Ltd www.gasmate.com.au
Aber Living - Hamilton, N.Z. www.gasmate.co.nz
AVENIR
SINK MODULE
Model No. GM178-101

32
EXPLODED DIAGRAM
No. Description QTY
1 Sink module top 1
2 Bottom shelf 1
3 Castor without brake 2
4 Castor with brake 2
5 Left side panel 1
6 Right side panel 1
7 Back panel 1
8 Top panel 1
No. Description QTY
9 Left door assembly 1
10 Right door assembly 1
11 Door handle 2
12 Top panel front fascia 1
13 Sink faucet 1
14 Sink 1
15 Drain assembly 1
No. Description QTY
A Screw M6x15 20
B Screw M6x12 21
C Screw M5x12 4
E Spring washer Ø6 16
F Wingnut M6 4

32
STEP 1
Using 16x M6x15mm screws (A) and 16x 6mm spring washers (D) attach 2x castors without brakes (3) and 2x castors
with brakes to the bottom shelf (2).
ASSEMBLY INSTRUCTIONS
GENERAL INFORMATION
General Assembly
Remove the module from the packing carton. Check
against parts list and lay components out within easy
reach. Do not throw the carton away, unfold flat and use
as a protective work surface. Contact your supplier for
replacement parts if necessary.
Tools You Will Need
Standard Phillips-head screwdriver (or cordless drill and
bits) and Adjustable spanner (open ended shifter) or
spanners.
Check Module for any Damage
Inspect Module parts as you proceed. Contact your
supplier for assistance regarding replacement of any
damaged or missing parts. Do not assemble or operate a
module that appears damage.
Kitchen/Module Installation
Modules can only be installed to the right hand side of
the BBQ. The side burner MUST NOT be removed.
Leave at least 200mm of distance between the back
of the unit and the wall for ventilation. All units must be
undercover.

544
ASSEMBLY INSTRUCTIONS
STEP 2
Using 4x M6x12mm screws (B) attach the left side panel (5) and the right side panel (6) to the bottom shelf (2).
STEP 3
Using 5x M6x12mm screws (B) attach the back panel (7) to the bottom shelf (2) and the left and right panels (5,6).
5

544 5
ASSEMBLY INSTRUCTIONS
STEP 4
Using 4x M6x12mm screws (B) attach the top panel (8) to the left and right panels (5,6).
STEP 5
Using 4x M6x12mm screws (B) attach the door handles (11) to the left door (9) and to the right door (10).

766
ASSEMBLY INSTRUCTIONS
STEP 6
Attach doors (9,10) to assembled sink module cabinet.
STEP 7
Using 4x M5x12mm screws (C) attach the top panel front fascia (12) to the left and right panels (5,6).
7

766 7
ASSEMBLY INSTRUCTIONS
STEP 8
Attach the sink faucet (13) to the sink top module (1) using the fastening pack provided. Attach sink (14) to the sink top
assembly (1). Attach the drain assembly (15) to the sink (14).
STEP 9
Using 4x M6x12mm screws (B) attach assembled sink module top (1) to assembled sink module cabinet.

988
KITCHEN/MODULE INSTALLATION
Modules can only be installed to the right hand side of the BBQ. The side burner MUST NOT be removed.
Modules must be a minimum of 200mm away from walls for ventilation. All units must be undercover.
STEP 1
Unscrew the BBQ side shelf from the BBQ (if attached).
Using 4x M6x15 screws (A) and 4 x wingnuts attach the BBQ to the module. Repeat this step on the other side of the
module if attaching more modules.
STEP 2
Reattach the side shelf to the last module in your kitchen using 4x M6x15mm screws (A) leaving a 5mm gap and
1x M5x12mm screw (C).

988
This page has been left intentionaly blank

1110
This page has been left intentionaly blank

1110
This page has been left intentionaly blank

Aber Living warrants the purchaser of this product against defects in workmanship and material, for a period of up to 24
months from the date of purchase. The warranty is non-transferable and becomes void if used for commercial or rental
purposes.
Warranty and purchase receipt of this product are to be retained as proof of purchase and must be presented if making
a claim under the terms of the Aber Living Warranty. Repairs under warranty are free of charge, provided the product is
delivered to our Service Department or Authorised Service Agent and freight charges both ways are paid by the owner.
No liability will be accepted for any loss of damage in transit.
Note: In most cases the Barbecue Body only will need to be returned.
Aber Living reserves the rights to replace or repair the product within the warranty period. Warranty does not apply to
any defect, deterioration (including corrosion if located within 1km of the sea), loss, injury or damage occasioned by or
as a result of the misuse or abuse, negligent handling or if the product has not been installed and used in accordance
with the instructions. The warranty is void if there is evidence of the product being tampered with by unauthorised
persons.
If the product includes one or a number of accessories, only the defective accessory or part will be replaced, eg. hose,
regulator, rotisserie, piezo igniter, roast hood, side burner and rail burners.
In the event of Aber Living choosing to replace the product, the warranty will expire at the original date, i.e. 24 months
from the original purchase date.
Where this product contains information from an overseas country, nothing in that information is intended to limit any
condition, guarantee, right or remedy which may be available under the Consumer Guarantees Act 1993, except to the
extent permitted by that Act.
Approved for Outdoor Use Only
Fat fires are not covered under warranty
For service, spare parts or product information in New Zealand, please call Aber Living on the Customer Service Line -
0800 161 161. www.aberliving.co.nz
YOUR PURCHASE RECORD (please complete)
Date of Purchase________________________________________________________________________
Model Number__________________________________________________________________________
Serial Number (if applicable)_______________________________________________________________
Purchased from_________________________________________________________________________
2 YEAR
LIMITED WARRANTY
