GBlife PM1232 User manual
Instruction Manual
Please keep it well for future reference.
Please read the instruction carefully before using.
Please refer to the actual product for the appearance.
The company reserves the right of final interpretation.
Official Web: http://www.gblife.tech/
Company: ShenZhen Yisilang E-commerce Co.,Ltd.
Contents
Cautious
Components
Features
Operations
Buttons
Specifications
Filters
01
02
03
04
05
06
07
Prohibition Mark
Do not touch the plug with wet hands.
Do not obstruct the air outlet/inlet.
The unit is for DC 12V voltage only,
please use the original adpater.
Clean the unit and remove the dust on
the plug regularly.
Please do not use strong corrosive
detergent to damage the surface and
clean the unit carefully.
Please unplug the unit when cleaning
or not in use, otherwise, a fire disaster
may occur due to short circuit.
Please keep the unit away
from places with flammable gas like
heater or fireplace.
This unit is not suitable for the disabled,
the mentally handicapped or the child.
The exception is if the person responsible
for safety is present and assists in the
operation of the unit.
Do not wash or reuse the HEPA filter.
Do not place the unit in a place with
heavy moisture or smoke.
Behaviors with this mark must be prohibited, otherwise,
product damage or safety accident may occur.
Behaviors with this mark should follow the instruction strictly,
otherwise, product damage or safety accident may occur.
Behaviors with this mark need to pay more attention,
otherwise, product damage or other losses may occur.
Warning Mark
Attention Mark
01
Safety Precautions
02 03
Please read the manual carefully before using and keep it well.
Body
Composite
filter
Composite
filter
DC 12V AC Adapter
②
Product Components Product Features
Product Features
①
Compact Design
One-button Start, Easy Operation
LED Indicator, Differ From Others
Purification
Functions
3 in 1 Multifunctional
Smoke
Dust,Mites,Pollen
Animal dander, Fibers
Effectively filters and eliminates indoor PM2.5, smoke, dust and pollen;
removes formaldehyde, VOC and creates a fresh environment.
Primary filter:
HEPA filter :
Carbon
sponge filter:
Primary
filter
HEPA
filter
Carbon
sponge
filter
Intercept hair, fiber velvet, large particles, dander, etc.
Effectively purify harmful gaseous pollutants
such as formaldehyde and VOC in the air.
Remove particulate pollutants such as PM2.5, fumes,
catkins, dander, and pollen from the air. Filter bacteria
such as Staphylococcus aureus.
04
05
【
POWER BUTTON
】
【
FILTERS LIFESPAN
】
Fan Speed Filter Life Rate Additions
Operation Tips Buttons Instruction
Applications
Sleep Speed
Medium Speed
High Speed
Please make sure the adapter(DC 12V)of air purifier is compatible
with the socket.
Please make sure the plug is plugged in and tightly connected to
the power outlet.
Do not use if the power, plug or unit is damaged, or the product is
not working properly.
Do not touch the power cord with wet hands.
Warnings
1.Firstly plug the output
of the power adapter
into the connector on
the back of the
purifier.
2.Plug the other end of
the adapter into a
suitable power outlet
and the purifier goes
into standby.
3.Tap the power
button to turn on
the purifier.
4.Purifier works
normally.
Office Table Reading Room Hotel Room Baby Room
On/Off
a.When the power supply DC 12V is connected, the On/Off indicator lights red and the purifier
enters the standby state.
b.In the standby state, touch the On/Off indicator lights white, the product enters the working
state, and the fan runs at the default intermediate speed.
c.In the working state, touch the On/Off, the fan will cycle between medium speed, high speed,
shutdown (shutdown can be delayed for 100ms), and low speed. The speed level indicator light
is displayed accordingly.
d.When it is adjusted to the sleep level(low speed), the light is turned off after 5 seconds, and the
key light is turned off to enter sleep mode. The fan runs at a low speed. After entering the sleep
mode, touch the key to wake up the sleep mode, and continue to enter the sleep mode when
there is no shift position within 5 seconds.
a.High-speed 1 hour for 0.5 hour calculation, mid-speed 1 hour for 1 hour calculation, low-speed
2 hours for 1 hour calculation, when the filter life time limit is ≥95% hour, the power button lights
in red and flash twice per second, until the lifespan reset. If not reset after the lifespan used up,
the power button lights in blue and flash flash twice per second, until the lifespan reset.
-0.50
-1.00
-1.50
Reduce 1 hour per 2 hours running
Reduce 1 hour per 1 hour running
Reduce 1 hour per 0.75 hours running
c.If reset is required, press On/Off for more than 5 seconds in the first 5 seconds after power-on
of standby state. The On/Off LED flashes for six times(Twice one second), it is resettled.
b.Filter life reset: When the filter life reaches the limit of 95%, On/Off button flash in red after
power on for 1 min(regardless of the speed). When reaches 100%, the red and white lights will
be on for a long time 1 min after press the On/Off. Long press On/Off for more than 5 seconds
in the power on state, red light flashes 6 times (twice per second) to complete reset.
06 07
1.Tap the On/Off button until the indicator
light is off, turn off and unplug the
purifier, rotate the base cover to open
and take out 2 old filters.
2.Take off all of packing films on filters.
3.Place 2 new filters and cover the
base cover well.
Product Model
Packing position Packing of main engine Remarks
Shape
Quantity 1 1 1
Rated Voltage
Rated Power
Area
Dust Cleaning Air Demand
Sound Level
Net Weight
Gram Weight
Product Size
Package Size
52dB(A)
1.6kg
2.3kg
170*170*264mm
202*202*350mm
inward
outward
inward
outward outward
inward
Filter Replacement
Packing List
Specifications Parameters
PM1232
10W
110-240V~
70m³/h
5-8m2
Main unit Manual AC adapter
inward
outward outward
inward
Filters cannot be washed in water.
Suggest replacing the filters when it reaches the lifespan limit.
Suggest cleaning the unit with softly wet cloth.
Please do not use water or corrosive detergent to clean the unit.
Suggest using a soft brush to clean the upper air outlet.
Please place the components to the original places after cleaning.
Cleanings
Notes
