Crane EE-5621 User manual

If you have any questions about the operation of your fan,
please contact Crane Customer Care.
2 –in –1
Air Purifier
Bladeless fan
Instruction Manual
FOR MODEL:
EE-5621
PLEASE READ AND SAVE ALL INSTRUCTIONS TO ENSURE
THE SAFE AND EFFECTIVE USE OF THIS FAN.

staple
tape
or paperclip
your
receipt
HERE
SAVE YOUR DATED PROOF OF PURCHASE!
[ You will need this in case of warranty]

1
TABLE OF CONTENTS
Table of Contents, Technical Specifications &
Sustainability
P. 1
Safety Instructions
P. 2-3
List of Main Parts
P. 4
Operation & Use
P. 5
Maintenance & Customer Care
P. 6
Warranty Information
P. 7
TECHNICAL SPECIFICATIONS
Rating Voltage
220-240V
Wattage
30 W
Model Number
EE-5621
CRANE & SUSTAINABILITY
Crane USA is dedicated to your environment both
inside and outside your home. We know if
cleaned and maintained properly, our products
last for years helping to reduce unnecessary use of
resources and emissions making new products.
The Crane manual you are holding is from
recycled materials with no added finishes or harmful dyes. If the
fan should no longer operate, please be sure to dispose of the
unit in an environmentally friendly way by taking it to a public
collection point.
PLEASE DO NOT PLACE BROKEN FAN WITH
YOUR REGULAR HOUSEHOLD WASTE.

2
IMPORTANT SAFETY INSTRUCTIONS
WARNING! READ AND SAVE THESE INSTRUCTIONS. Failure to follow all of the instructions
listed below may result in electric shock, fire and/or serious personal injury.
1. Always turn the air purifier and bladeless fan off before removing the plug from the outlet.
NEVER PLUG IN OR UNPLUG WITH WET HANDS.
2. Always turn the air purifier and bladeless fan off and unplug it immediately after using and
before cleaning.
3. To protect against electrical hazards, do not place the air purifier and bladeless fan in water
or other liquids. Do not allow the fan to become wet or damp. Do not store the fan where
it can fall into water or other liquids.
4. Do not attempt to repair or replace any part of your air purifier and bladeless fan unless it
is specified in this manual. All other services should be referred to a qualified technician.
5. Use only a 220V AC outlet. ALWAYS plug and unplug unit with dry hands to avoid electric
shock.
6. Do not remove the round grounding prong from the plug.
7. Do not plug other appliances into the same outlet; it can overload the circuit and cause a
fire or electric shock.
8. Be sure to remove all packing materials from the air purifier and bladeless fan before use.
9. Do not store the air purifier and bladeless fan unattended when it is plugged in. Turn the
fan off when leaving it for an extended period of time.
10. Use the air purifier and bladeless fan only for its intended use as described in these operating
instructions.
11. Do not operate any appliance if its cord or plug is damaged, after the appliance has
malfunctioned, or after it has been dropped or damaged in any way. Always follow the
warranty instructions.
12. Ensure the power cord is plugged firmly and completely into the outlet.
13. Do not start or stop operation by plugging in or unplugging the power cord, ALWAYS use
the device controls.
14. Place air purifier and bladeless fan on a flat, level surface to avoid it overturning.
15. Never drop or insert any object into any opening. Do not insert any objects into the fan as
it may cause electric shock or damage.
16. Close supervision is necessary when any appliance is operated near children. DO NOT let
your child play with this appliance. Serious injury and electrocution may be possible. This
appliance must be operated by an adult. Children should be supervised to ensure that
they do not play with this fan or the packaging.
17. Do not use this or any appliance near flammable gasoline, benzene, thinner, etc.
SAVE THESE INSTRUCTIONS!

3
GENERAL SAFETY INSTRUCTIONS
WARNING! Read and understand all instructions. Failure to follow all instructions listed
below may result in electric shock, fire or serious personal injury. The warnings, cautions, and
instructions discussed in this instruction manual cannot cover all possible conditions and
situations that may occur. It must be understood by the user that common sense and caution
are a factor which cannot be built into this product, but must be supplied by the user.
SPECIAL INSTRUCTIONS
• To avoid a circuit overload when using this product, do not operate another high-wattage
product on the same electrical circuit.
• Avoid the use of extension cords because the extension cord may overheat and cause a
risk of fire.
SAVE ALL INSTRUCTIONS!
CAUTION: A short Power Supply Cord is provided to reduce the risk of personal injury
resulting from becoming entangled in or tripping over a longer cord. Extension cords are
available from local hardware stores and may be used if care is exercised in their use. Avoid
using an extension cord as it may overheat and cause fire.
ELECTRIC POWER
If the electric circuit is overloaded by other appliances, your fan and/or appliances may not
operate properly. The fan should be operated on a separate electrical circuit from other
operating appliances.
SAFETY WARNING
Although your air purifier and bladeless fan is easy to operate, for your safety, the below
warnings must be followed:
1. Do not place the air purifier and bladeless fan near a heat source.
2. Never leave the air purifier and bladeless fan unattended while connected to the
electrical outlet.
3. To avoid any accidents, never place hands on vents or sides when the appliance is in
operation.
4. Use the air purifier and bladeless fan on a stable surface away from water.
5. Do not unplug from the socket by pulling on the power cord.
6. The air purifier and bladeless fan must be unplugged:
A. Before any cleaning
B. After each use
C. If it appears to be faulty
D. Do not clean the unit with water
7. Do NOT use gasoline, benzene, thinner, harsh cleaners, etc., as they will damage the fan.
THIS PRODUCT IS INTENDED FOR HOUSEHOLD USE ONLY.

4
LIST OF MAIN PARTS
FIGURE 1:
1
2
1. Air Outlet
2. Remote Control
3. Upper Base
4. Control panel
5. Filter Cover
6. Filter
7. Rotator
8. Base
3
7
4
5
8
6
FIGURE 2: Control Panel
9
9. LED Display
10. Power
11. Fan Speed
10
12. Timer
13. Oscillation
11
12
13
FIGURE 3: Remote Control
14
14. Power
15. Timer + (add time)
17
15
16. Timer –(decrease time)
17. Raise Fan Speed
18. Decrease Fan Speed
18
16

5
OPERATION & USE
REMOVE plastic covering from the filter before the first use.
The air purifier and bladeless fan may be operated by the control panel (as shown in figure 2)
or by your remote control.
Place the fan in the desired location on a flat and stable surface. Plug in the Air Purifier and
Bladeless fan.
Note: The air purifier and bladeless fan is now in standby mode.
Power (ON/OFF)
To turn the unit power on, press the key to turn on the power. The fan starts at the F5
speed level. Touching the key again will stop the unit.
Fan Speed
While the unit is on, press the key to adjust the fan speed to desired level (F1 to F9 level).
The speed setting is displayed on the LED display.
Press the or on the remote control to raise and lower the fan speed.
Oscillation (LEFT/RIGHT)
While the unit is on, press the key to allow the fan to oscillate left and right. To stop the
oscillation, press the key again.
Press the on the remote to turn the oscillation on and off.
Timer
While the unit is on, press the key to set the timer. You can set the time between 15 minutes
and 12 hours. Each touch of the key will increase the timer.
Note: the first press of the will start the timer at 15 minutes. Each press of the (timer icon) will raise
the time: 15 minutes, 30 minutes, 45 minutes, 1 hour-12 hours.
Press the button on the remote control and the LED display will show 6h and the air purifier
and bladeless fan will shut off after 6 hours. Press the again to increase the time by 1 hour
up to 12 hours. Press the after 12 hours and the timer function is cancelled.
Press the (icon) button on the remote control and the LED display will show 5h and the air
purifier and bladeless fan will shut off after 5 hours. Each press of the again to decrease
the time down to 15 minutes. Press the again after 15 and the timer function is cancelled.
Press the key on the control panel or the / button on the remote control to cancel the set
timer function.

6
REPLACING THE HEPA FILTER
The life of the filter will vary depending n the air quality and usage.
1. Gently pull the tab on the filter door to access the HEPA filter
2. Remove the filter by pulling the filter towards you.
3. Discard the old HEPA filter.
4. Insert the new HEPA filter into the unit by sliding it into place.
5. Replace the filter door and gently push until fully closed.
DO NOT ATTEMPT to clean the HEPA filter.
MAINTENANCE
CAUTION:
Always be sure that the air purifier and bladeless fan is switched OFF and unplugged. Do not
immerse air purifier and bladeless fan in water or allow water to drip into the interior of the air
purifier and bladeless fan, as this could create an electric shock hazard.
CARE AND CLEANING
1. Always turn off the air purifier and bladeless fan and disconnect the cord from the
electrical outlet before cleaning your fan.
2. Light accumulated dust may be removed from the air purifier and bladeless fan with
a soft cloth.
3. Clean the outside of the air purifier and bladeless fan by wiping with a damp cloth and
buff with a dry cloth.
DO NOT use any detergents or abrasives and do not allow any water to enter the air
purifier and bladeless fan.
DO NOT allow water to run into the interior of the air purifier and bladeless fan as this
could create a fire or electric shock hazard.
4. NEVER use ALCOHOL or any other solvents to clean the air purifier and bladeless fan.
Storing
1. Store the air purifier and bladeless fan in a dry location.
2. Do not place any heavy items on top of the air purifier and bladeless fan during storage
as this may result in possible damage of appliance.
3. Remove the battery form the remote when storing the air purifier and bladeless fan.
BATTERY REPLACEMENT
1. Keep batteries out of reach of children. Should a child swallow a battery, consult a
doctor immediately
2. Do not recharge or dispose in fire.
3. Keep in a dry and cool place.
4. Insert battery in right direction
CRANE CUSTOMER CARE
If you have any questions with regard to the operation of this air purifier and bladeless
fan, or are in need of a spare part, please contact your regional Crane Distributor

7
CRANE WARRANTY
For more information regarding the warranty policy,
please contact us.
L I M I T E D W A R R A N T Y
Thank you for purchasing a Crane product which has been tested to meet our stringent quality
standards. This product is warrantied to be free from manufacturing defects under normal use and
conditions for 6 months.
PLEASE CONTACT US BEFORE RETURNING THIS PRODUCT TO THE STORE.
CALL CRANE CUSTOMER CARE FOR PROBLEMS AND QUESTIONS. WE CAN HELP.
WARRANTY REQUIRES A DATED PROOF OF PURCHASE.
This warranty is void if the defect is due to accidental damage, misuse, abuse, neglect, improper repair or
alteration by unauthorized persons, or a failure to follow operating instructions provided with the product.
This warranty does not apply to normal wear and tear or commercial use.
In no event shall liability exceed the purchase price paid by the purchaser of the product. Under no
circumstances shall there be liability for any loss –direct, indirect or incidental –or consequential damage
arising out of, or in connection with the use of this product.
Any instructions or warranty included in this manual may be subject to change without notice. For the
most up-to-date instructions and warranty information, please contact us by phone or email.
TO RECEIVE WARRANTY INSTRUCTIONS AND RETURN AUTHORIZATION,
PLEASE CALL OR EMAIL CRANE CUSTOMER CARE.
CRANE PHILIPPINES
37-E1 Baler Street S.F.D.M. Quezon City
Telephone no: 8376-6466
Email: [e-mail]
Website: crane-philippines.com
